Fluke 106 Manuel utilisateur

PN 4343876

June 2013

All product names are trademarks of their respective companies.

106 & 107

Digital Multimeters

Users Manual

LIMITED WARRANTY AND LIMITATION OF LIABILITY

This Fluke product will be free from defects in material and workmanship for one year from the date of purchase. This war-

ranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or

abnormal conditions of operation or handling. Resellers are not authorized to extend any other warranty on Fluke’s behalf.

To obtain service during the warranty period, contact your nearest Fluke authorized service center to obtain return authoriza-

tion information, then send the product to that Service Center with a description of the problem.

THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH AS FITNESS FOR A PARTICULAR

PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE IS NOT LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR

CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY CAUSE OR THEORY. Since some states or countries

do not allow the exclusion or limitation of an implied warranty or of incidental or consequential damages, this limitation of

liability may not apply to you.

Fluke Corporation

P.O. Box 9090

Everett, WA 98206-9090

U.S.A.

Fluke Europe B.V.

P.O. Box 1186

5602 BD Eindhoven

The Netherlands

Table of Contents

Title Page

Introduction .................................................................................................................... 1

Safety Information .......................................................................................................... 1

Safe Working Practices .................................................................................................. 1

Instrument Overview ...................................................................................................... 5

Terminals................................................................................................................... 5

Display....................................................................................................................... 5

Auto Power Off............................................................................................................... 6

Auto Backlight Off........................................................................................................... 6

Measurements................................................................................................................ 6

Data Hold .................................................................................................................. 6

Measure AC and DC Voltage .................................................................................... 7

Measure AC or DC Current ....................................................................................... 8

Measure Resistance.................................................................................................. 9

Test for Continuity ..................................................................................................... 9

Test Diodes (107 Only).............................................................................................. 10

Measure Capacitance................................................................................................ 10

Measure Frequency and Duty Cycle (107 Only)........................................................ 10

Maintenance................................................................................................................... 11

106 & 107

Users Manual

General Maintenance................................................................................................ 11

Test the Fuse ............................................................................................................ 12

Replace Batteries and the Fuse................................................................................ 13

Service and Parts .......................................................................................................... 13

General Specifications................................................................................................... 14

Accuracy Specifications................................................................................................. 15

Introduction

The Fluke 106 and 107 Multimeters (the Product) are

6000 count instruments.

The Product is battery powered with a digital display.

Except where noted, the descriptions and instructions in

this Users Manual apply to both the 106 and 107.

Unless otherwise identified, all illustrations show the 107.

Safety Information

The Fluke 106 and 107 comply with IEC 61010-1 CAT III

600 V overvoltage standard. See Specifications.

A Warning identifies conditions and procedures that are

dangerous to the user. A Caution identifies conditions

and procedures that could cause damage to the Product

or the equipment under test.

International electrical symbols used on the Product and

in this manual are explained in Table 1.

Safe Working Practices

Review the safety information and comply with the safe

working practices.

106 & 107

Users Manual

Warning

To prevent possible electrical shock, fire, or

personal injury:

•Carefully read all instructions.

•Read all safety information before you

use the Product.

•Use the Product only as specified, or the

protection supplied by the Product can

be compromised.

•Do not use the Product around explosive

gas, vapor, or in damp or wet

environments.

•Do not use and disable the Product if it

is damaged.

•Do not use the Product if it operates

incorrectly.

•Examine the case before you use the

Product. Look for cracks or missing

plastic. Carefully look at the insulation

around the terminals.

•Use only correct measurement category

(CAT), voltage, and amperage rated

probes, test leads, and adapters for the

measurement.

•Measure a known voltage first to make

sure that the Product operates correctly.

•Do not use test leads if they are

damaged. Examine the test leads for

damaged insulation and measure a

known voltage.

•Limit operation to the specified

measurement category, voltage, or

amperage ratings.

•Do not apply more than the rated voltage,

between the terminals or between each

terminal and earth ground.

•Do not use the HOLD function to

measure unknown potentials. When

HOLD is turned on, the display does not

change when a different potential is

measured.

•Do not touch voltages >30 V ac rms, 42 V

ac peak, or 60 V dc.

Digital Multimeters

Safe Working Practices

•Do not use test leads if they are

damaged. Examine the test leads for

damaged insulation and measure a

known voltage.

•Keep fingers behind the finger guards on

the probes.

•Remove all probes, test leads, and

accessories before the battery door is

opened.

•Do not exceed the Measurement

Category (CAT) rating of the lowest rated

individual component of a Product,

probe, or accessory.

•Remove the input signals before you

clean the Product.

•Use only specified replacement parts.

•Use only specified replacement fuses.

•Have an approved technician repair the

Product.

•Remove the batteries if the Product is

not used for an extended period of time,

or if stored in temperatures above 50 °C.

If the batteries are not removed, battery

leakage can damage the Product.

•Replace the batteries when the low

battery indicator shows to prevent

incorrect measurements.

For safe operation and maintenance of the

product, repair the Product before use if the

batteries leak.

106 & 107

Users Manual

Table 1. International Electrical Symbols

AC (Alternating Current) Earth Ground

DC (Direct Current) Fuse

AC or DC Capacitance

Risk of Danger. Important information. See Manual. Diode



Battery

CAT II

Measurement Category II is applicable to test and

measuring circuits connected directly to utilization

points (socket outlets and similar points) of the low

voltage MAINS installation.

CAT III

MEASUREMENT CATEGORY III is applicable to test and

measuring circuits connected to the distribution part of the

building’s low-voltage MAINS installation.

CAT IV

Measurement Category IV is applicable to test and

measuring circuits connected at the source of the

building’s low voltage MAINS installation.

Conforms to relevant North American Safety Standards. Conforms to European Union directives.

Conforms to relevant South Korean EMC Standards Inspected and licensed by TÜV Product Services



This product complies with the WEEE Directive (2002/96/EC) marking requirements. The affixed label indicates that you must

not discard this electrical/electronic product in domestic household waste. Product Category: With reference to the equipment

types in the WEEE Directive Annex I, this product is classed as category 9 "Monitoring and Control Instrumentation" product. Do

not dispose of this product as unsorted municipal waste. Go to Fluke’s website for recycling information.

Digital Multimeters

Instrument Overview

Terminals

1 2 3

hhc01.e

Item Description

1 Input terminal for ac and dc current

measurements to 10 A and current

frequency (107 only) measurements.

2 Common (return) terminal for all

measurements.

3 Input terminal for voltage, resistance,

continuity, diode (107 only), capacitance,

and frequency (107 only) measurements.

Display

1 2 3 4 5 6 7 8

1314

hhc02.eps

Item Description

1Hi

h volta

2Displa

Hold is enabled

3 Continuit

selected

4 Diode test is selected

5Dut

cle is selected

6M, k

–

decimal prefix

7

–

Ohms is selected

8Hz

–

Frequenc

is selected

–

Farads for capacitance

10 mV

–

millivolts

–

amps or volts

12 DC,

–

dc or ac volta

e or current

13 Auto Ran

e mode is enabled

14 Batter

is low and should be chan

106 & 107

Users Manual

Auto Power Off

The Product automatically powers off after 20 minutes’

inactivity.

To restart the Product, turn the rotary switch back to the

OFF position and then to a necessary position.

To disable the Auto Power Off function, hold down the

Shift key when turning on the Product, until PoFF shows

on the display.

Auto Backlight Off

The backlight automatically turns of after 2 minutes’

inactivity.

To disable the Auto Backlight Off function, hold down the

key when turning on the Product, until LoFF shows on

the display.

Note

To disable both the Auto Power Off function and

the Auto Backlight Off function, you can also hold

down the Shift key and the



key at the same

time, until both PoFF and LoFF show on the

display.

Measurements

Data Hold

Warning

To prevent possible electrical shock, fire or

personal injury, do not use the HOLD function

to measure unknown potentials. When HOLD

is turned on, the display does not change

when a different potential is measured.

To hold the present reading, push . Push again

to resume normal operation.
