Fluance Ai81 Manuel utilisateur

Ai81 - Powered Floorstanding Speakers

User Manual v1.0

Serious Performance™Fluance.com

Fluance Ai81 User Manual 2

Introduction

Thank you for your purchase of your Fluance product. We hope you enjoy your experience.

If you have any questions please visit us at: Fluance.com/support

Fluance believes everyone should experience audio in its truest form, recreating the per-

formance the way the artist intended. Utilizing only superior components and expert audio

engineering, their products are a testament to the performance that can be achieved when

a passion for music takes center stage. The perfect complement to any audiophile’s lifestyle,

you’ll be enjoying live performances in your home for years to come.

Break-in Period

Our speakers have a Butyl rubber ring surrounding the cone. The break-in period allows

the rubber to loosen and stretch, allowing the cone a larger range of movement, resulting

in better sound reproduction. We recommend 10-12 hours of play at moderate volume to

achieve this.

For additional product information, please consult the manual at: Fluance.com/resources

Need Help?

Scan this QR Code for easy

setup instructions, videos, and

frequently asked questions.

Don’t forget to register your product with us!

Fluance.com/registration

Fluance.com/videos

Fluance.com/resources Fluance.com/support Fluance.com/contact

Fluance Ai81 User Manual 4

What’s Included

LIFETIME

Customer Support

Quick Start

Guide

Speaker

Wire

Lifetime

Customer Support

2 Year

Warranty

Ai81 Passive

Speaker

(Left Channel)

Ai81 Active

Speaker

(Right Channel)

VOL +

VOL -

TREBLE BASS

Remote

Control

CR2032

Battery

Power

Cable

Fluance Ai81 User Manual 5

Front & Back Panel Layout

1. Control Knob

• Volume

• Input Selection

• Power ON/OFF

2. Source LED

• Blue (Solid) - Bluetooth®Paired

• Blue (Flashing) - Bluetooth®Pairing Mode

• Green (Solid) - RCA 1

• Purple (Solid) - RCA 2

• White (Solid) - Optical

• Red (Solid) - Standby Mode

• Red (Flashing) - Mute

3. IR Sensor

4. Speaker Input

5. Optical Input

6. RCA Input 1

7. RCA Input 2

8. Subwoofer Output

9. Bluetooth®Reset Pairing

10. Left Speaker Output

11. AC Input

12. Fuse (T3.15AL 250V)

13. Power Switch

Remote Control Layout

1. Power ON/OFF

2. Volume UP/DOWN

3. Source

4. Treble UP/DOWN

5. Mute

6. Play/Pause & Bluetooth®Pairing Reset*

*To enable Bluetooth®Pairing Reset, press + hold for 3 seconds.

7. Forward/Back

8. LED Brightness - (100% > 25% > OFF)

9. Bass UP/DOWN

Passive SpeakerActive Speaker













 

Active Speaker (Back)

VOL +

VOL -

TREBLE BASS

1 5

3 8

Fluance Ai81 User Manual 6

3. Connect the power cable to the back of the Active Speaker and set the power switch

to the ON position.

Product Setup

1. Position the speakers with the Active Speaker on the right and the Passive Speaker

on the left.

2. Connect one end of the speaker wire to the binding posts on the back of the

Active Speaker and connect the other end of speaker wire to the binding posts on the

back of the Passive Speaker.

IMPORTANT: Ensure the same color wire is connected to the same color binding posts

on each speaker.

NOTE: If placing the speakers near a wall, it is recommended to keep 6-12

inches away from the wall.

NOTE: The included speaker wire is 8ft. If placing your speakers further than 8ft

apart it is recommended to use standard 18 gauge speaker wire to connect the

speakers over the longer distance.

Loosen the

binding post

Insert speaker

wire through hole

Tighten the

binding post

Passive Speaker Active Speaker

Passive

Speaker

Active

Speaker

Fluance Ai81 User Manual 7

Press on the remote to cycle

through the audio inputs.

Press on the remote to turn the unit

on/off.

Turning On/Off Unit

Source Selection

Adjusting Source LED Brightness

Press the Control Knob to turn on the

unit. Hold to turn off the unit.

Press the Control Knob to cycle

through the audio inputs.

Use the LED Brightness button on the Remote to cycle between 100%, 25% and OFF

brightness levels.

The Source LED will show the below color for each source:

(Blue) Bluetooth

(Green) RCA 1 (Purple) RCA 2

(White) Optical

NOTE: When set to OFF, the LED will turn on for 5 seconds when power is turned on or

new Source is selected before turning off again.

VOL +

VOL -

TREBLE BASS

VOL +

VOL -

TREBLE BASS

VOL +

VOL -

TREBLE BASS

VOL +

VOL -

TREBLE BASS

VOL +

VOL -

TREBLE BASS













 













 

Fluance Ai81 User Manual 8

EQ Adjustment

Use the Bass/Treble buttons on the Remote to adjust each from -5 to +5.

LED Behavior:

Red (Flash 2x) - Bass/Treble Set to -5 or +5

Source Color (Flash 2x) - Bass/Treble Set to 0

Note: If using a source device, with its own EQ settings, ensure it is set to at (0). Some apps also

include an EQ that should also be set to at.

EQ Reset

To reset the Bass and Treble levels to 0 put the speakers into Standby Mode and press and

hold the Bluetooth Reset button until the red LED ashes. This will reset the speaker to

default settings but will not reset Bluetooth Settings.

RCA Input

1. Connect the RCA cable to your

source device (Turntable, Smartphone,

Computer...).

2. Connect the other end of the RCA ca-

ble to back of the Active Speaker.

4. Adjust volume on Ai81 as well as

source device.

3. Press the Control Knob to select the

RCA input (RCA 1 - Green; RCA 2 -

Purple), or Press the Source button on

the remote control.

*RCA to RCA cable not included

Note: If using a turntable an internal or

external preamp is required.

VOL +

VOL -

TREBLE BASS

Fluance Ai81 User Manual 9

Optical Input

1. Connect the Optical cable to your source

device (TV, Computer, Game Console...).

Ensure protective caps are removed from

the ends of the Optical cable.

2. Connect the other end of the Optical

cable to the back of the Active Speaker.

4. Adjust the volume on Ai81 as well

as source device.

3. Press the Control Knob to select the Opti-

cal Input (White LED).

Optical Audio Signal Compatibility

The Ai81 does not support Dolby Digital Audio or DTS Audio. Locate the audio output

settings on your source device and ensure Dolby Digital is turned off. The correct audio

output setting is commonly referred to as PCM or Stereo.

Some TVs also require that audio output be enabled. This setting may be referred to as

External Speakers. Ensure this is selected as your speaker/audio output.

For instructions on a specic device, please consult the device’s user manual.

*Optical cable not included













 

Press the Source button on the remote

control.

VOL +

VOL -

TREBLE BASS

Fluance Ai81 User Manual 10

• Press and hold on the Remote

for 3 seconds to reset Bluetooth©

pairing.

• Press the Bluetooth©Pairing Reset

Button on the back of the unit.

Bluetooth®Pairing

1. Press the Control Knob to select the

Bluetooth©input (Blue LED).

3. Use the Remote to Play/Pause and go

Forward/Backward on your source

device.

2. Pair to “Fluance Ai81” on your

source device.

4. If your device cannot nd “Fluance

Ai81”, you can reset Bluetooth©pairing:

NOTE: Adjust Volume on the source

device as well as the Ai81.

Important: Ensure any apps and

devices have the EQ disabled (at)

and Volume Normalization disabled

for best performance

VOL +

VOL -

TREBLE BASS

NOTE: How you access your device’s

Bluetooth©settings may vary from one

manufacturer to another. Maximum line of

sight for Bluetooth©range is 33ft. Obstacles

may decrease transmission distance.

Note: Unit will attempt to auto-pair to

the last paired device.

Bluetooth

My Devices

Settings

Fluance Ai81













 

Press the Source button on the remote

control.

VOL +

VOL -

TREBLE BASS

Fluance Ai81 User Manual 11

Subwoofer Output

IMPORTANT: When a subwoofer cable is connected, the Ai81 will automatically cut

frequencies below 80Hz to optimize performance. The subwoofer cable must be removed

to resume full frequency playback.

1. Connect the Subwoofer cable to your powered subwoofer.

2. Connect the other end of the Subwoofer cable to the back of the Active Speaker.

3. Adjust the volume on the Subwoofer for the best listening experience.

Fluance offers matching subwoofers for the ultimate audio experience.

For more information visit: Fluance.com/subwoofer

DB10

*Subwoofer cable not included
