Universal Tool
™
IMPACTS
General Safety Information & Replacement Parts
WARNING: Risk of injury to persons. Read and
understand operation instructions. Always become familiar
with all the instructions and warnings before operating any
pneumatic tool.
TABLE OF CONTENTS
General Safety Information ...........................2
Air Compressor and Air Tool Safety...................2-3
Tool Specifications ..................................3
Installation ........................................4
Maintenance / Lubrication ............................4
Troubleshooting ....................................5
Warranty ..........................................5
Service Parts.......................................6
UT8150P-2 (Pin Retainer)
UT8150R-2 (Ring Retainer)
1/2" Pistol Impact Wrench
WARNING:This product contains chemicals known to
the State of California to cause cancer and birth defects or
other reproductive harm. Wash hands after handling.
WARNING:This product contains lead, a chemical known to
the State of California to cause cancer and birth defects or
other reproductive harm. Wash hands after handling.
Universal Tool a Division of Florida-Pneumatic Manufacturing Corporation
851 Jupiter Park Lane, Jupiter FL 33458
7.2.2.3 GENERAL SAFETY RULES
• Multiplehazards.Readandunderstandthesafetyinstructionsbefore
installing,operating,repairing,maintaining,changingaccessorieson,
orworkingnearthepowertool.Failuretodosocanresultinserious
bodilyinjury.
• Onlyqualiedandtrainedoperatorsshouldinstall,adjustorusethe
powertool.
• Donotmodifythispowertool.Modicationsmayreducetheeffec-
tivenessofsafetymeasuresandincreasetheriskstotheoperator.
• Donotdiscardthesafetyinstructions–givethemtotheoperator.
• Donotuseatoolifthetoolhasbeendamaged.
• Warningsshallbegivenagainsttheriskofexplosionorreduetothe
materialbeingprocessed;
• Warningsshallbegivenagainsttheriskofcutting.
7.2.2.4 PROJECTILE HAZARDS
• Failureoftheworkpiece,ofaccessories,orevenofthetoolitselfmay
generatehighvelocityprojectiles.
• Alwayswearimpact-resistanteyeprotectionduringoperationofthe
tool.Thegradeofprotectionrequiredshouldbeassessedforeach
use.
7.2.2.5 ENTANGLEMENT HAZARDS
• Entanglementhazard-choking,scalpingand/orlacerationscanoccur
ifneckware,hairorglovesarenotkeptawayfromtoolandacces-
sories.
7.2.2.6 OPERATING HAZARDS
• Useofthetoolmayexposetheoperator’shandstohazardsincluding
crushing,impacts,cutsandabrasionsandheat.Wearsuitablegloves
toprotecthands.
• Operatorsandmaintenancepersonnelmustbephysicallyableto
handlethebulk,weightandpowerofthetool.
• Holdthetoolcorrectly:bereadytocounteractnormalorsudden
movements–havebothhandsavailable.
• Maintainabalancedbodypositionandsecurefooting.
• Keephandsawayfromrotatingorreciprocationaccessories,spindles
orothermovingparts.
• Releasethestartandstopdeviceinthecaseofaninterruptionofthe
energysupply
• Useonlylubricantsrecommendedbythemanufacturer.
7.2.2.7 REPETITIVE MOTIONS HAZARDS
• Whenusingapowertool,youmayexperiencediscomfortinyour
hands,arms,shoulders,neck,orotherpartsofyourbody.
• Whileusingapowertool,positionyourbodyinacomfortable
posture.Maintainsecurefootingandavoidawkwardoroff-balanced
postures.Changingyourpostureduringextendedtasksmayhelp
avoiddiscomfortandfatigue.
• Ifyouexperiencesymptomssuchaspersistentorrecurringdiscom-
fort,pain,throbbing,aching,tingling,numbness,burningsensation,
orstiffness,donotignorethesewarningsigns.Promptlytellyour
employerandconsultaqualiedhealthprofessional.
7.2.2.8 ACCESSORY HAZARDS
• Onlyusesizesandtypesofaccessoriesandconsumablesthatare
recommendedbythepowertoolmanufacturer.
7.2.2.9 WORKPLACE HAZARDS
• Slips,tripsandfallsaremajorcausesofworkplaceinjury.Beaware
ofslipperysurfacescausedbyuseofthetoolandalsooftriphazards
causedbytheairlineorhydraulichose.
• Proceedwithcareinunfamiliarsurroundings.Hiddenhazardsmay
exist,suchaselectricityorotherutilitylines.
• Thispowertoolisnotintendedforuseinpotentiallyexplosiveatmo-
spheresandisnotinsulatedfromcomingintocontactwithelectric
power.
• Makesuretherearenoelectricalcables,gaspipesetc.thatcould
causeahazardifdamagedbyuseofthetool.
7.2.2.10 DUST AND FUME HAZARDS
• Dustfromsomeworkprocessescancausecancer,birthdefectsor
otherrespiratorydiseases.Riskassessmentofthesehazardsand
implementationofappropriatecontrolsisessential.
• Ifthepneumatictoolisusedinadustlledenvironmentexhaust
aircancauseadusthazard
• Dustsandfumesgeneratedwhenusingpowertoolscancause
illhealth(forexample:cancer,birthdefects,asthmaand/order-
matitis);riskassessmentofthesehazardsandimplementationof
appropriatecontrolsofisessential.
• Riskassessmentshouldincludedustcreatedbytheuseofthetool
andthepotentialfordisturbingexistingdust.
• Operateandmaintainthepowertoolasrecommendedinthese
instructions,tominimizedustorfumeemissions
• Directtheexhaustsoastominimizeddisturbanceofdustinadust
lledenvironment
• Wheredustsorfumesarecreated,thepriorityshallbetocontrol
thematthepointofemission.
• Allintegralfeaturesoraccessoriesforthecollection,extractionor
suppressionofairbornedustorfumesshouldbecorrectlyused
andmaintainedinaccordancewiththemanufacturer’sinstructions.
• Select,maintainandreplacetheconsumable/insertedtoolas
recommendedintheseinstructions,topreventanunnecessary
increaseindustorfumes
• Userespiratoryprotectionasinstructedbyyouremployeroras
requiredbyoccupationalhealthandsafetyregulations;
7.2.2.11 NOISE HAZARDS
• Unprotectedexposuretohighnoiselevelscancausepermanent,
disabling,hearinglossandotherproblemssuchastinnitus(ring-
ing,buzzing,whistlingorhummingintheears);
• Riskassessmentofthesehazardsandimplementationofappropri-
atecontrolsofisessential.
• Appropriatecontrolstoreducetheriskmayincludeactionssuchas
dampingmaterialstopreventworkpiecesfrom‘ringing’
• Usehearingprotectionasinstructedbyyouremployeroras
requiredbyoccupationalhealthandsafetyregulations;
• Operateandmaintainthepowertoolasrecommendedinthese
instructions,topreventanunnecessaryincreaseinnoiselevels;
• Select,maintainandreplacetheconsumable/insertedtoolas
recommendedintheseinstructions,topreventanunnecessary
increaseinnoise.
7.2.2.12 VIBRATION HAZARDS
• Exposuretovibrationcancausedisablingdamagetothenerves
andbloodsupplyofthehandsandarms;
• Wearwarmclothingwhenworkingincoldconditionsandkeep
yourhandswarmanddry;
• Ifyouexperiencenumbness,tingling,painorwhiteningoftheskin
inyourngersorhands,stopusingthepowertool,andtellyour
employer.Youshouldalsoseekmedicaladvicefromaqualied
occupationalhealthprofessional.
• Operateandmaintainthepowertoolasrecommendedinthese
instructions,topreventanunnecessaryincreaseinvibration;
• Select,maintainandreplacetheconsumable/insertedtoolas
recommendedintheseinstructions,topreventanunnecessary
increaseinvibrationlevels;
• Supporttheweightofthetoolinastand,tensionerorbalancer,
becausetheoperatorcanthenusealightergriptosupportthetool.
• Holdthetoolwithalightbutsafegriptakingaccountofthe
requiredhandreactionforces,becausetheriskfromvibrationis
generallygreaterwhenthegripforceishigher.
7.2.3ADDITIONAL SAFETY INSTRUCTIONS FOR PNEUMATIC
POWER TOOLS - AIR SUPPLY & CONNECTION HAZARDS
• Airunderpressurecancausesevereinjury.
• Alwaysshutoffairsupply,drainhoseofairpressureanddiscon-
necttoolfromairsupplywhennotinuse,beforechangingacces-
soriesorwhenmakingrepairs.
• Neverdirectairatyourselforanyoneelse.
• Whippinghosescancausesevereinjury.Alwayscheckfordam-
agedorloosehosesandttings.
• Wheneveruniversaltwistcouplings(clawcouplings)areused,lock
pinsmustbeinstalled.
• Donotexceedthemaximumairpressurestatedonthetool.
• Usewhipchecksafetycablestosafeguardagainstpossiblehoseto
toolandhosetohoseconnectionfailure.
• Nevercarryanairtoolbythehose.
Safety Information
FLORIDA-PNEUMATIC.COM
Please contact 1-800-356-3392 for further assistance.
Safety Information (continued)
AIR COMPRESSOR AND AIR TOOL SAFETY
1. Risk of Bursting. Do not adjust the regulator to result in output
pressure greater than the marked maximum pressure of this air
tool.
2. Ensure the hose is free of obstructions or snags. Entangled or
snarled hoses can cause loss of balance or footing and may
become damaged.
3. Never leave a tool unattended with the air hose attached.
4. Do not operate this tool if it does not contain a legible warning
label.
5. Do not continue to use a tool or hose that leaks air or does not
function properly.
6. Never direct a jet of compressed air toward people or animals.
7. Protect your lungs. Wear a face or dust mask if the operation is
dusty.
WARNING: Some dust created by power sanding, sawing,
grinding, drilling and other construction activities contains
chemicals known to cause cancer, birth defects or other
reproductive harm. Some examples of these chemicals are:
Lead from lead based paint, crystalline silica from bricks
and cement and other masonry products, arsenic and
chromium from chemically-treated lumber.
Your risk from those exposures varies, depending on how
often you do this type of work. To reduce your exposure to
these chemicals: work in a well-ventilated area, and work
with approved safety equipment, such as dust masks that
are specically designed to lter out microscopic particles.
Important Warnings - Impacts
Specications
1. Eye protection and hearing protection and safety gloves must always be worn when operating an impact wrench or impact
driver.
2. When using heavy impact sockets or sockets on impact wrenches with 3/4” drive anvils or larger, a socket retaining ring
and pin should be used to prevent the socket falling off and causing injury.
3. Use only impact sockets and accessories. Only use sockets designated “FOR USE WITH IMPACT WRENCHES”, hand tool
sockets can break, creating a hazard from ying pieces. Always check sockets, retainers and drives regularly for wear or
damage and replace when necessary.
Accessory Hazards
4. Disconnect the assembly power tool for threaded fasteners from the energy supply before changing the inserted tool or
accessory.
5. Do not touch sockets or accessories during impacting as this increases the risk of cuts, burns or vibration injuries.
6. Use only sizes and types of accessories and consumables that are recommended by the assembly power tool for threaded
fasteners manufacturer; do not use other types or sizes of accessories and consumables.
Vibration Level (m/sec2): 10.7 Noise Level (dBA): 97
Model
Free
Speed Bolt Square Impacts Max, Torque Weight Length Air Cons
Number (RPM) Capacity Drive Per Min. ft/ l b s @ 90 p si (l b s) (In.) (CFM)
UT8150P-2 9500 9/16" 1/2" 1, 600 725 5.75 7-1/4 8
UT8150R-2 9500 9/16" 1/2" 1, 600 725 5.75 7-1/4 8
Universal Tool a Division of Florida-Pneumatic Manufacturing Corporation
851 Jupiter Park Lane, Jupiter FL 33458
Installation
1 Cleaning the air hose
□A 3/8" air hose is required, with a maximum length of 25 ft.
□Clean the air hose of accumulated dust and moisture
before connecting it to the air supply.
NOTE: If a longer air hose is required, connect a 1/2" air
hose to the 3/8" air hose to ensure the impact wrench has
the necessary air supply.
Recommended Air Line Set-Up
Part Description
AAir Tool
B Quick Plug
C Quick Coupler
D Air Hose
E In-line Regulator
F In-line Lubricator
G In-line Filter
H Air Compressor
Ensure the air line is shut-off and drained of air before removing this tool for service or changing sockets. This will prevent the tool from
operating if the throttle is accidentally engaged.
LUBRICATION
□An in-line lter-regulator-lubricator is recommended as it increases tool life and keeps the tool in sustained operation.
□Regularly check and ll the in-line lubricator with air tool oil. Avoid using excessive amounts of oil.
□Adjust the in-line lubricator by placing a sheet of paper next to the tool’s exhaust ports and holding the throttle open approximately 30
seconds. The lubricator is properly set when a light stain of oil collects on the paper.
□If it is necessary to store the tool for an extended period of time (overnight, weekend, etc.), generously lubricate the tool through the air
inlet. Run the tool for approximately 30 seconds to ensure the oil is evenly distributed throughout the tool. Store the tool in a clean and
dry environment.
□Recommended lubricants: Air tool oil or any other high grade turbine oil containing moisture absorbent, rust inhibitors, metal wetting
agents, and an EP (extreme pressure) additive.
Maintenance
FLORIDA-PNEUMATIC.COM
Please contact 1-800-356-3392 for further assistance.
Warranty
Limited Warranty: Universal Tool warrants its tools to be free from defects in material and workmanship for one year from the date of
purchase. This warranty does not apply to tools which have been abused, misused, modied or repaired by someone other than Universal
Tool or its authorized service centers. If a UT tool proves defective in material or workmanship within one year after purchase, return
it to any authorized service center or Universal Tool freight prepaid. Please enclose your name, address and adequate proof of date of
purchase and a short description of the defect. Universal Tool will,at its option, repair or replace defective tools free of charge. Repairs or
replacements are warranted as described above for the remainder of the original warranty period. Universal Tool's sole liability and your
exclusive remedy under this warranty is limited to repair or replacement of the defective tool.
There are no other warranties expressed or implied and Universal Tool shall not be liable for incidental, consequential or special damages,
or any other damages,costs or expenses excepting only the cost or expense of repair or replacement as described above.
Troubleshooting
Problem Possible Cause Solution
The tool runs slowly or will not
operate.
There is grit or gum in the tool. Flush the tool with air tool oil or gum solvent.
The tool is out of oil. Lubricate the tool according to the lubrication
instructions in this manual.
The air pressure is low. □Adjust the regulator on the tool to the
maximum setting.
□Adjust the compressor regulator to the tool’s
maximum setting of 90 psi.
The air hose leaks. Tighten and seal the hose ttings with pipe thread
tape if leaks are found.
The air pressure drops. □Ensure the hose is the proper size. Long
hoses or tools using large volumes of air may
require a hose with an I.D. of ½" or larger
depending on the total length of the hose.
□Do not use a multiple number of hoses
connected together with a quick connect
tting. This causes additional pressure drops
and reduces the tool power. Directly connect
the hoses together.
There is a worn rotor blade in the motor. Replace the rotor blade.
There is a worn ball bearing in the motor. Remove and inspect the bearing for rust, dirt, and
grit. Replace or clean and grease the bearing with
bearing grease.
There is moisture blowing out
of the tool’s exhaust.
There is water in the tank. Drain the tank. (See the air compressor manual
for instructions.) Lubricate the tool and run it until
water is not evident. Lubricate the tool again and
run for 1-2 seconds.
The tool impacts slowly or not
at all.
The tool needs lubricating. Lubricate the air motor and the impact mechanism
according to the lubrication instructions in this
manual.
The tool regulator setting is in the wrong position. Adjust the regulator on the tool to the maximum
setting.
The tool impacts rapidly, but
will not remove bolts.
The tool has a worn impact mechanism. Replace the worn impact mechanism components.
The tool does not impact. The impact mechanism is broken. Replace the broken impact mechanism
components.
Universal Tool a Division of Florida-Pneumatic Manufacturing Corporation
851 Jupiter Park Lane, Jupiter FL 33458
Service Parts / Exploded View Drawing
Ref
#
Part Number Description Qty Ref
#
Part Number Description Qty.
1 900-0104 Cap Screw 4 23 9305-009B Rear End Plate 1
2 900-1806 Spring Washer 4 24 900-2305 Ball Bearing 1
3 9303R-002 Hammer Case w/Bushing 1 25 9303R-020 Rear Gasket 1
4 9303R-019B Front Gasket 1 26 900-4311 Insert Recoil 4
5 9305F-XI-010 Anvil Bushing 1 27 9303D-001 Motor Housing 1
6 9303D-P-011A4 Anvil 1 28 900-41108 O-Ring 2
9303D-P-011B4 2” Anvil 1 29 9303-022 Valve Sleeve 1
7 9303D-P-042 Lock Pin 1 30 9303-021B Regulator Knob 1
8 9303D-P-043 Spring 1 31 900-1301 Cap Screw 1
9 9303D-P-044 Plug 1 32 9303-023 Reverse Valve 1
10 9305-016 Hammer Pin 2 33 9303-032 Spring 1
11 9305V-017 Hammer 2 34 900-3805 Steel Ball 1
12 9305F-XI-012 Hammer Cage 1 35 9303D-024 Trigger 1
13 9305-020-B Rear Washer 1 36 900-3326 Spring Pin 1
14 9303D-025 Hammer Case Pilot 1 37 9306-027-B Bushing 1
15 9303-026 Motor Clamp Washer 2 38 9306-026 Valve Stem 1
16 900-2317B Ball Bearing 1 39 9306-028-B Spring 1
17 9305-005B Front End Plate 1 40 9305-021 Exhaust Deector 1
18 9303R-007-C Rotor 1 41 9306-035 Mufer 1
19 9305H-008D Rotor Blade 6 42 9242-024C Air Inlet (1/4” NPT) 1
20 900-3203 Snap Ring 1 43 9303D-022 Housing Cover(Option) 1
21 9305-006-B Cylinder 1 44 9303D-026 Handle Rubber(Option) 1
22 9305-031 Pin 1
UT8150P-2 (Pin Retainer)
FLORIDA-PNEUMATIC.COM
Please contact 1-800-356-3392 for further assistance.
Service Parts / Exploded View Drawing
Ref
#
Part Number Description Qty Ref
#
Part Number Description Qty.
1 900-0104 Cap Screw 4 23 9303R-020 Rear Gasket 1
2 900-1806 Spring Washer 4 24 900-4311 Insert Recoil 4
3 9303R-002 Hammer Case w/Bushing 1 25 9303D-001 Motor Housing 1
4 9303R-019B Front Gasket 1 26 900-41108 O-Ring 2
5B 9305F-XI-010 Anvil Bushing 1 27 9303-022 Valve Sleeve 1
6 9250-033 Anvil Collar 1 28D 9303-021B Regulator Knob 1
7 900-4103 O-Ring 1 29 900-1301 Cap Screw 1
8 9305F-XI-011NA4 Anvil 1 30 9303-023 Reverse Valve 1
9305F-XI-011NB4 2” Anvil 1 31 9303-032 Spring 1
9 9305-016 Hammer Pin 2 32 900-3805 Steel Ball 1
10D 9305V-017 Hammer 2 33 9303D-024 Trigger 1
11 9305F-XI-012 Hammer Cage 1 34 900-3326 Spring Pin 1
12 9305-020-B Rear Washer 1 35 9306-027-B Bushing 1
13 9303D-025 Hammer Case Pilot 1 36 9306-026 Valve Stem 1
14 9303-026 Motor Clamp Washer 2 37 9306-028-B Spring 1
15 900-2317B Ball Bearing 1 38 9305-021 Exhaust Deector 1
16 9305-005B Front End Plate 1 39 9306-035 Mufer 1
17B 9303R-007-C Rotor 1 40 9242-024C Air Inlet (1/4” NPT) 1
18C 9305H-008D Rotor Blade 6 41 900-3203 Snap Ring 1
19 9305-006-B Cylinder 1 42 9303D-022 Housing Cover(Option) 1
20 9305-031 Pin 1 43 9303D-026 Handle Rubber(Option) 1
21 9305-009B Rear End Plate 1
22 900-2305 Ball Bearing 1
UT8150R-2 (Ring Retainer)
Universal Tool a Division of Florida-Pneumatic Manufacturing Corporation
851 Jupiter Park Lane, Jupiter FL 33458
Universal Tool
™
Questions, problems, missing parts?
Call Customer Service
8 a.m.-5 p.m., EST, Monday-Friday
1-800-356-3392
FLORIDA-PNEUMATIC.COM
Retain this manual for future use.
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Florida Pneumatic Moteur à percussion
Florida Pneumatic
Florida Pneumatic FP-745TCI Manuel
Florida Pneumatic
Florida Pneumatic FP-720B Manuel
Florida Pneumatic
Florida Pneumatic FP-777A Manuel
Florida Pneumatic
Florida Pneumatic FP-793B Manuel
Florida Pneumatic
Florida Pneumatic Universal Tool UT8350C Manuel
Florida Pneumatic
Florida Pneumatic Universal Tool UT8080Q Manuel
Florida Pneumatic
Florida Pneumatic FP723 Instructions d'installation
Florida Pneumatic
Florida Pneumatic FP-797 Manuel
Florida Pneumatic
Florida Pneumatic Universal Tool UT8365C Manuel
