Flock Audio Patch XT Manuel utilisateur
USER MANUAL
V.1.0.0
2
TABLE OF CONTENTS
TABLE OF CONTENTSPATCHXT MANUAL
Cover...........................................................................................................................1
Table Of Contents.......................................................................................................2
Thank you from Flock Audio………………………………………………..……………..3
Introduction to the PATCH XT System..……………………..………………..………….4
Important Safety Notices…………….………………………..………………..………….5
What's in the Box...…….………………………..……………..………………..………….6
Front Panel Identifications……..……………..……………………..……………….…….7
Rear Panel Identifications……….……………..…………..………..……………….…….8
Rear Panel Cable Connections………………………………..………………..………….9
Hardware Chassis Measurements……………………………..………………..………..10
Toggle & Control Center............................................................................................11
Routing Examples (Pt.1)……………………………….…………………………………..12
Routing Examples (Pt.2)……………………………….…………………………………..13
Routing Examples (Pt.3)……….…………………………………………………………..14
Front Panel LED Indicator..………………………………………………………………..15
Install New Firmware …………………………………………………………..………….16
Introducing the XTH Cable Hanger...........................................................................17
Assembling the XTH Cable Hanger...........................................................................18
Troubleshooting………………………………………………………..…………………..19
Software & System Requirements………………………………………………………..20
User Notices & Warranty………………………….…………………..…………………..21
End………………………………………………………..………………………..………..22
Certifications:
3THANK YOU FROM FLOCK AUDIO
THANK YOU
Where do I begin to start by saying Thank you for your support…
I started working on a conceptual design known as “PATCH” in early 2016 when I decided to
leave my stable career and chose to pursue the path less travelled of designing and developing a
better & more efficient process for professional audio recording engineers in the depths of my
basement home recording studio.
In need of a better solution other than the available 1870’s technology known as a traditional
patch bay, the concept was born to create a fully digitally controlled but 100% analog circuit
routing system that wouldn’t color or alter the audio signals passing through it.
After 2 years of strenuous work and constant focus, Flock Audio the company I started, created
the worlds first and most advanced digitally controlled analog audio routing system with features
never before possible in conventional analog audio routing.
I’m honoured to have so many customers believe in what Flock Audio stands for…Innovations
above Expectations. We have an incredible team of professionals from engineers, software
developers & everyone in-house who helped create this one of kind piece of professional audio
history.
We look forward to providing the pro audio world with more innovations and excellent service to
help assist aspiring and seasoned professionals to create masterpieces for years to come.
Thank you again for choosing to make Flock Audio a part of your professional audio identity.
Darren Nakonechny
(CEO/Director/Founder)
Sincerely,
Thank you…
PATCHXT MANUAL
4INTRODUCTION TO THE PATCH SYSTEM
INTRODUCTION
The Flock Audio PATCH XT System is a digitally controlled, 100%
analog audio patchbay routing system. A combination of Software
known as the PATCH APP and a 192 Point Connection (96 Inputs
& 96 Outputs) PATCH XT Hardware component allows users to
easily route and control analog audio routings without having to
resort to the use of manual patch cables.
The PATCH APP software application (OSX & Windows
compatible) is designed with familiarity in mind. PATH’s in the
application represent audio signal flows from top to bottom.
Signal flows are divided up into single vertical columns allowing
users to drag + drop available analog audio equipment connected
to the PATCH XT’s Hardware component. This analog audio
equipment is cataloged in the Hardware Index located to the left
side of the PATCH APP.
The PATCH XT Hardware component is a 3U rack mountable unit
that acts as the centrepiece hub of an audio equipment
processing setup. Utilizing digital control over analog audio
signals is what makes the PATCH XT System unique and unlike
anything else in the audio industry.
This manual with go more in-depth into the functions, features
and recommended usage of the Flock Audio PATCH XT System.
INTRODUCTION TO THE PATCHXT SYSTEM…
PATCHXT MANUAL
5IMPORTANT SAFETY NOTICES
IMPORTANT SAFETY NOTICES
IMPORTANT SAFETY NOTICES
To avoid risk of electric shock, injury or death, it is recommended to never
attempt to self-service a Flock Audio PATCH XT System. There are no self
repairable or removable parts in the system. If your Flock Audio PATCH XT
System requires repairs, please contact our support centre to arrange for a
Flock Audio Certified Repair Technician. (www.flockaudio.com/support)
#1. Do Not Self-Service
To avoid risk of damage to your PATCH XT System, avoid having liquids &/
or spills near your PATCH XT System. If accidental spill occurs, safely shut
off your PATCH XT System using the front power button, unplug the wall
outlet and disconnect IEC power cable from the system. Once completed
please contact Flock Audio Support to arrange for a Certified Repair
Technician to remove and repair if required.
#2. Avoid Liquid &/or Spills
Proper mount spacing and rack mount ventilation is required to ensure your
Flock Audio PATCH XT System does not overheat. It is recommended that
the rear of the rack is open for proper ventilation and that the user DOES
NOT mount the PATCH XT System above any tube related audio
equipment. If necessary, there should be a 1/2 - 1U Rack Space between
the PATCH System and any warm or tube related audio equipment to avoid
unexpected shutdowns or internal damage.
#4. Proper Rack mount Ventilation Requirements
It is recommended that you always use a properly shielded and grounded
IEC Power Cable (110V/220V) with your PATCH XT System. The Chassis is
designed to work with the earth ground inside the box for both a safe &
quiet audio operation. Never remove or use a IEC cable accessory without
the grounding pin.
#5. Use Properly Grounded IEC Power Cables
Although no damage or immediate danger will occur if 48V Phantom Power
is engaged on a Preamp connected to the Input of the PATCH XT System, it
is not recommended to leave that 48V source active for a lengthly period of
time.
#6. External 48V Phantom Power (I.E. Connected Preamp)
Never use your Flock Audio PATCH XT System during any electrical or
dangerous lightning storms. Calmly shutdown your System, Unplug the IEC
power cable from the wall outlet or power conditioner until it is safe to
continue use. It’s also recommended to keep the system unplugged if not in
use for long extended periods of time.
#7. Discontinue Use During Electrical Storms
Flock Audio Inc. reserves the right to revise or change the information
contained within this manual without notice. All revisions or changes will be
noted by the Version Number located on the front title page of this manual
and the latest digital manual will be provided via web link in the PATCH APP
Software Application.
#8. Disclaimer Notice
#9.Certifications
PATCHXT MANUAL
#3. Shutting Down Your PATCH XT
To properly shut down your PATCH XT Hardware, it is always recommended
that you first put your PATCH XT to sleep by pressing the Sleep/Wake
button on the front panel, and then toggle the white large switch on the
rear panel to "O". The lifespan of your PATCH XT will not be affected if you
choose to sleep the unit instead of shutting it down during regular studio
usage.
6WHATS IN THE BOX
WHAT'S IN THE BOX
WHAT'S INCLUDED IN THE BOX
USB-A TO USB-B (6FT LOCKING) 6 STEP QUICKSTART GUIDE
IEC POWER CABLE
(110V or 220V)
PATCHXT 3U HARDWARE
HARDWARE INDEX
SETUP QR CODE
PATCHXT MANUAL
7FRONT PANEL INDENTIFICATIONS
Front Inputs 1-2!
Neutrik XLR/TRS Combo Jacks
(Activated using Software)
Front Outputs 1-2!
Neutrik XLR Male Jacks
(Activated using Software)
Multi-Purpose LED Indicator!
Blue LED Indicator
(Learn more on Page 33)
Sleep/Wake Button!
Toggle On/Off Sleep/Wake Mode
FRONT PANEL
FRONT INDENTIFICATIONS
PATCHXT MANUAL
8REAR PANEL INDENTIFICATIONS
REAR PANEL
IEC Power Connection!
Master Power Switch
Rear Inputs 1-96!
DB-25/D-SUB Connectors
Inputs: 1-8, 9-16, 17-24, 25-32, 33-40, 41-48,
49-56, 57-64, 65-72, 73-80, 81-88, 89-96
(8 Balanced Audio Channels per Connector)
Tascam 25 Pinout Wiring Standard
USB-B Host Connector!
USB-B to USB-A Cable
(Threaded locking USB 2.0 Connector)
Rear Outputs 1-96!
DB-25/D-SUB Connectors
Outputs: 1-8, 9-16, 17-24, 25-32, 33-40, 41-48,
49-56, 57-64, 65-72, 73-80, 81-88, 89-96
(8 Balanced Audio Channels per Connector)
Tascam 25 Pinout Wiring Standard
Inputs & Outputs (1-2)!
Channels 1-2 can be routed to the
Front Panel Inputs & Outputs using
the PATCH APP Software.
REAR PANEL INDENTIFICATIONS
IMPORTANT: Always ensure that the Power
Connector is inserted securely into the Power Input
of the PATCH XT System Hardware.
NOTE PATCH XT IS DESIGNED WITH A FIXED PROFESSIONAL LINE
LEVEL OF +4 TO WORK IN ACCORDANCE WITH OTHER INDUSTRY
STANDARD OUTBOARD PROCESSING HARDWARE. WHEN USING
OTHER TYPES OF LEVELS FOR SIGNAL ROUTING, YOU MAY NEED
TO HAVE ADDITIONAL ACCESSORIES CONNECTED INLINE.
PROFESSIONAL +4 LINE LEVEL
Ethernet Host Connector!
Long-Distance Host Cable for Long-
Distance Computer Control
PATCHXT MANUAL
9REAR PANEL CABLE CONNECTIONS
REAR PANEL CABLE CONNECTIONS
IEC Power Cable
(Included In Box)
*Cable Type Based on your Region
(Cable examples courtesy of Pro Audio LA)
DB-25/D-SUB Cable Snakes
(Female/Male XLR & TRS Options Available)
(Cables Not Included)
REAR VIEW
REQUIRED CABLES FOR OPERATION
NOTE INPUTS & OUTPUTS ON THE REAR PANEL OF THE
PATCH XT SYSTEM ARE SEPARATELY DESIGNATED. YOU
CANNOT USE AN OUTPUT AS AN INPUT OR VICE VERSA.
PLEASE ENSURE TO AVOID RISK OR DAMAGE TO THE
PATCH SYSTEM OR OTHER EXTERNAL HARDWARE THAT IS
CONNECTED THAT YOU MAKE THE PROPER
CONNECTIONS ACCORDINGLY. TO LEARN MORE OF
ABOUT PROPERLY CONNECTING EXTERNAL HARDWARE
TO THE PATCH SYSTEM SEE THE BOTTOM OF THIS PAGE.
INPUTS & OUTPUTS NOTICE
CONNECTING
PATCH XT TO EXTERNAL
HARDWARE EXAMPLE.
NOTE ALL EXTERNAL HARDWARE MUST BE
CONNECTED IN THIS METHOD SHOWN TO THE
LEFT SIDE OF THIS DESCRIPTION.
PATCH XT (OUT) —-> EXTERNAL HARDWARE (IN)
EXTERNAL HARDWARE (OUT) —-> PATCH
OUTPUT
INPUT
(OUTPUT) FROM PATCH TO
(INPUT) OF EXTERNAL GEAR
(OUTPUT) FROM EXTERNAL GEAR
TO (INPUT) OF PATCH
PATCHXT MANUAL
USB-A To USB-B (Cable)
(6’ USB 2.0 - Cable Included In Box)
CAT5/CAT6 (Cable)
(Not Included, Purchased Separately)
10 CHASSIS DIMENSIONS
323.9 mm"
12.75 in
133.4 mm"
5.25 in
482.6 mm"
19 in
425 mm"
16.75 in
HARDWARE CHASSIS MEASUREMENTS
FRONT VIEW
REAR VIEW
CHASSIS DIMENSIONS
25 lbs / 11.3 kg
(Weight)
482.6 mm"
19 in
133.4 mm"
5.25 in
425 mm"
16.75 in
323.9 mm"
12.75 in
PATCHXT MANUAL
