120W FOLDABLE SOLAR PANEL
120W FOLDABLE SOLAR PANEL
INSTRUCTION MANUAL & WARRANTY
MODEL C120
PN: FLC-C4-201200-4
ACCESSORIES INCLUDED:
20A / (12V/24V)
PWM controller
Carry bag
10 in 1
interchangeable
connectors
1’ (0.3m) cable
with Anderson
to DC5521 male
connector
1’ (0.3m) cable
with Anderson
to alligator clip
cable
1’ (0.3m) cable
with bare cable
with Anderson
connector
2
Thank you for purchasing this FLEXSOLAR® product. Before operating, please read
these instructions carefully. This instruction manual contains information for safe
use and maintenance of the product.
Please keep this instruction manual in a safe place for future reference.
The manufacturer does not accept responsibility for any damages due to not
following these instructions.
TABLE OF CONTENTS
General
Safety Precautions for Using a Foldable Solar Panel
General Operation Notes
Pg. 02
Product Overview
120W Foldable Solar Panel
Cables
Solar Charger Controller (PWM)
Pg. 04
Before Using
What’s in the Box
Pg. 12
Operation
Installation
Choose the location
System Connection
Pg. 13
Maintenance Pg. 15
Warranty Statement Pg. 16
GENERAL
Please carefully read the following operation and safety instructions. Non-compliance
with these instructions may void the product warranty.
This guide contains information regarding the operation and safe handling
FLEXSOLAR® solar panels and components. All operations must be read and
understood before attempting operation. If there are any questions, please contact
your dealer or FLEXSOLAR® customer support for further information.
The user should conform to all safety precautions in the guide when using solar
panels. Before using a solar photovoltaic system (including cable, power station
3
or other electric equipment), the user should be familiar with the mechanical and
electrical requirements for photovoltaic systems. Keep this guide in a safe place for
future reference.
• All solar panels come with permanently attached output ports. Your dealer can
provide additional extension cables to simplify module wiring.
• Exercise caution when wiring or handling solar panels exposed to sunlight.
• Photovoltaic solar panels convert light energy to direct-current electrical
energy and are designed for outdoor use.
• Solar panels may be hung, placed flat, or use provided kickstand to face
towards the sun.
• Do not frequently connect or disconnect wires attached to solar panels when
they are exposed to sunlight in order to extend panel service life.
• Do not attempt to disassemble the solar panel, and do not remove any
attached nameplates or components. Doing so will void the warranty.
• Do not apply paint or adhesive to the solar panel.
• Do not use mirrors or other hardware to artificially concentrate sunlight on the
solar panel.
Safety Precautions for Using a Foldable Solar Panel
• Solar panels produce electrical energy when exposed to sunlight.
• FLEXSOLAR® solar panels can be connected in series. When connected together
(either in series or parallel), make sure that each solar panel has the same
rated voltage. Your dealer can provide additional cables to simplify panel
connections.
• Observe the instructions and safety precautions for all other components used
in the system, including wiring, cables, connectors, and etc.
• Use only equipment, connectors, wiring, and mounting hardware suitable for
use in a photovoltaic system.
• Always use the same type of solar panel in a particular photovoltaic system.
• Under normal operating conditions, solar panels will produce currents and
voltages that may vary from those listed in the data sheet. Data sheet values
are applicable at standard test conditions only.
General Operation Notes
• Do not stand or step on the solar panel.
• Do not drop the solar panel or allow objects to fall on the solar panel.
• Do not place any heavy objects on the solar panel.
4
PRODUCT OVERVIEW
120W Foldable Solar Panel (FLC-C4-201200-4)
FLEXSOLAR® solar panels are made of monocrystalline solar cells in series with high
efficiency, high transmission rate, and anti-aging EVA. They are designed for easy use,
extended longevity, and portable operation.
Unfolded View of the 120W Foldable Solar Panel:
Folded View of the 120W Foldable Solar Panel:
359mm/ 14.1inch
564mm/ 22.2inch 41mm/ 1.6inch
564mm/ 22.2inch
1653mm/ 65.1inch
5
Specifications
Maximum Power (Pmax) 120W
Max Power Voltage (Vmp) 19.8V
Max Power Current (Imp) 6.06A
Open Circuit Voltage (Voc) 23.7V
Short Circuit Current (Isc) 6.36A
Cell Efficiency 22%
Cell Type Monocrystalline
Power tolerance ± 10%
Temperature Co-efficient (Power) -0.45%/ °C
Temperature Co-efficient (Voltage) -0.32%/°C
Temperature Co-efficient (Current) +0.02%/ °C
NOCT (Air 20°C, Sun 0.8kW/m², Wind
1m/s)
45±2°C
Weight (Includes Accessory Items) 10.1 lbs/(4.6kg)
Operation Temperature
IP Rating IP65
Cables
• Passed conduction test, there was no short circuit, open circuit, dislocation, etc.
• Cables are free of dirt, scratches, damage, color difference or other defects.
• All materials meet RoHS environmental standards.
-4 F to 149 F (-20℃ to 65℃)
6
Specifications
Category Location Description Cable
Length
Wire
Specification
Remark
Output
Ports
From
junction
box
Suspension line of
USB 2.0
3 ft
(1 M)
16AWG Connected
Type C (PD 60W) / / Built In
LED Indicators
USB 3.0
Suspension line of
Anderson
Accessories /
1 ft
(0.3 M) 16AWG /
/ 16AWG
1 ft (0.3 M) 16AWG
10 ft
(3 M) 16AWG Connected
Note: the specification of 10-in-1 interchangeable connectors is below
Bare cable with
Anderson
connector
Anderson to
alligator
clip cable
10-in-1
interchangeable-
connectors
PWM Cotroller
Anderson to
DC5521
male connector
Polyester case
1 ft (0.3 M) 16AWG
/
/
20A/12V
With velcro
storage
pocket
/
/
A B CE F GH L I
13.80±0.5
12.0±0.5
12.4±0.5
11.0±0.5
10.8±0.5
10.4±0.5
11.4±0.5
K
14.0±0.5
9x26±0.5
33±0.5
11±0.5
5.5x2.1
female head
7.9x5.6x0.9mm
0.9mm
1.4mm
6.3x3.0mm 5.5x2.5mm
Φ5.6±0.1
Φ7.9±0.1
11.0±0.5
10.4±0.5
Φ4.3±0.1
Φ6.0±0.1
Φ3.0±0.1
Φ6.3±0.1
Φ5.5±0.1
Φ2.5±0.1
Φ5.5±0.1
Φ1.7±0.1
Φ1.7±0.1
Φ4.8±0.1
Φ1.7±0.1
Φ1.35±0.1
Φ4.0±0.1
Φ3.5±0.1
Φ1.1±0.1
Φ3.0±0.1
Φ0.7±0.1
Φ2.5±0.1
7
20A Pulse Width Modulation (PWM) Controller
• Built-in industrial micro controller.
• Big lcd display, all adjustable parameter
• Full 3-stage PWM charge management.
• Built-in short-circuit protection, open-circuit protection, reverse protection,
over-load protection.
• Dual MOSFET reverse current protection, low heat production.
Safety Instructions
1. Make sure your battery has enough voltage for the PWM to recognize the battery
type before first installation.
2. The battery cable should be as short as possible to minimize loss.
3. The PMW is suitable for lead acid batteries (Flood, AGM, GEL) and lithium ions,
(please make sure the PWM is set for the right type of battery before usage). It is not
suited for nickel metal hydride, or other types of batteries.
4. The PWM is only suitable for regulating solar modules. Never connect any other
charging source to the PWM.
5. It is normal for the PWM to be hot when the PWM is at work. Please install the PWM
on a flat and well-ventilated place.
SOLAR CHARGER CONTROLLER (PWM)
8
1Positive solar input terminal 5Positive load output terminal
2Negative solar input terminal 6Negative load output terminal
3Positive battery output terminal
4Negative battery output
terminal
20A Pulse Width Modulation (PWM) Controller
Cable for solar panel connection 20AWG
Cable for battery connection 20AWG
Connector N/A - customer to supply the
connection to battery based on
configuration
Dimension (W x H x D) 5.2*2.8*1.3 inch (133*70*34mm)
Net Weight 0.34lb/(154g)
Operation Temperature -31°F to 149°F (-35°C to 65°C)
Lithium
battery
Settable
voltage
Build-in
timer
MCU
control
SOLAR CHARGE CONTROLLER
USB
-
/
+
1 2 3 4 5 6
9
LCD Display/Key
Display Settings
Menu: switch between different display, or to enter/exit setting by long press.
Up: press to increase value
Down: press to decrease value
Attention:
1. Press the [down] button to on/off load manually at main display.
2. The work mode is working as below:
[24H] Load output 24 hours
[1-23H] Load on after sunset and closed after, setting hours
[0H] Dusk to dawn
+
MENU
UP
DOWN
/
ON/OFF
-/
V%
AH hour
amper
load
output
battery
solar panel
voltage
digital display
charge
on:equalation/buce
flicking:float
e
ect
V
H
V
V
V
main display
1
battery type
6
work mode
5
float or CV voltag
2
discharge reconn
3
discharge stop
4
Browsing
Interface
Press menu to
browse different
interface
Set
Parameter
In interface 2-5,
long press menu
to enter setting,
and using [up]
[down] to set the
parameter, long
p r e s s m e n u
ag a i n to e x i t .
long press
[down]
10
Charging Parameters
NOTE:
1). Charging parameters may vary based on availability of sunlight on the solar
panels.
2). Product specifications are subject to change without notice.
3). Bold italic typeface voltage *2, *4 while using 24/48 system.
MODEL 1210 1220 1230
SYSTEM VOLTAGE 12V/24V AUTO
Charge Current 10A 20A 30A
Discharge Current 10A 20A 30A
Max Solar Input <50V
Battery Type b01Sealed b02GEL b03Flood
Equalization 14.4V 14.2V 14.6V
Float Charge 13.7V (default, adjustable)
Discharge Stop 10.7V (default, adjustable)
Discharge Reconnect 12.6V (default, adjustable)
Battery Type b04 Iron
lithium 4
Strands
b05 Iron
lithium 5
Strands
b06 lithium
ion 3 Strands
b07 lithium
ion 4
Strands
Constant Charging
Voltage 3.6V*4/*5 4.2V*3/*4
Recovery Charge Voltage 3.4V*4/*5 4.0V*3/*4
Low Voltage Protection 2.6V*4/*5 3.1V*3/*4
Low Voltage Recovery 2.9V*4/*5 3.7V*3/*4
b04~b07 Parameters can’t be set
USB Output 5V/2A
Self-consume <10mA
Operating Temperature -35~+60°C
Size/Weight 133*70*34mm/154g
