Installation and operating instructions
FB222 bike tracker
Introduction
In developing the products we offer, the manufacturers have acted with the utmost care and in
accordance with international standards.
Warranty
We offer a 12-month warranty on the products, which is valid from the date of purchase. Keep the
invoice or block you received at the time of purchase and / or the warranty card of the device,
because you can only enforce your warranty claim if you have them. During the warranty period, we
will replace any defective main unit, accessory or software of the product in the event of any defect
attributable to a manufacturing, material or software defect. Subsequent repairs to the device or its
accessories are not permitted by the manufacturer due to the design of the device.
The warranty does not cover a product (or accessory) that has been damaged or rendered inoperable
due to attempts to modify or repair the software, physical impact, poor voltage, improper use.
To ensure proper, effective and safe use of the product, read the instruction manual carefully and
keep it for future reference. Flexcom Kommunikációs Kft. Shall not be liable for any damage, product
damage, short-term or long-term health damage that may occur as a result of use, repair, storage
and transport other than those described in this manual.
Rights, trademarks
© 2019, Flexcom Kommunikációs Kft.
All rights reserved. No part of our printed or online publications may be reproduced, distributed or
transmitted in any form or by any means, including photocopying, recording or other electronic and
mechanical methods, without the prior written permission of the publisher. To obtain a permit,
contact your dealer:
Contact
Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03
Flexcom Communication Ltd.
2151 Fót, Szent Imre str. 94. HUNGARY
Email: [email protected]
Website: https://nyomkovetes.net
Office
2151 Fót, Dózsa György str. 34. HUNGARY
Phone: +36 1 769 1005
Mobile 1: +36 70 3333 525
Mobile 2: +36 70 3333 527
Phone service: (Monday-Thursday) 9.00–15.00
Every effort has been made to ensure that the information in our documents is accurate. Flexcom
Kommunikációs Kft. Is not responsible for typographical errors and misspellings.
Flexcom GPS Tracking Solutions, GPS Positioning System, Nyomkovetes.net is a registered trademark
and domain name of Flexcom Kommunikációs Kft. In Hungary. Other company and product names
mentioned herein may be trademarks of their respective companies.
Protection of personal data
The product is a complete product as a combination of hardware and software components. For safe
and correct use, proceed as described in this manual during installation and use. Keep the device or
software out of the reach of unauthorized persons. Our company provides all technical and regulatory
conditions to ensure that data management complies with legal requirements and that your data does
not fall into unauthorized hands. We accept no liability for damage resulting from unauthorized use of
the product and software.
2022/09/09 09:03 3/21 Installation and operating instructions
Flexcom wiki - https://wiki.nyomkovetes.net/
Formats and notations
The following style settings are used in descriptions, guides, and other documents:
Bold text Name of product components, instructions, options, processes, services, user interface
elements.
Italic text Links to other publications, emphasis.
Courier text System messages, internet addresses, document names.
Warning and cautionary signs:
Tips, advice, ideas.
Document download option.
General attention to information about the product or its operation.
Indication of situations with a lower risk to the user or the product (minor injuries,
inconveniences).
Indication of situations which present a higher risk to the user (serious injury, possibly
death) or which may cause damage or destruction of the product.
Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03
Product description
Hogyan működik a
nyomkövetés a Flexcom-
nál?
The device combines several
functions of accurate
positioning, safety,
monitoring, emergency
alarms and full tracking. It
supports GPRS / Internet
data transfer functions and
can be widely used in many
areas of location-based
services, traffic safety and
management.
Based on its design and
mounting, the device is
primarily designed to track
bicycles - as a result, its
users are primarily vehicle
owners (adults or children).
Settings that affect the operation of the device can only be changed from another device
(smartphone, computer) with the help of our software application - so users can be sure that the
device always works according to the parameters they specify.
2022/09/09 09:03 5/21 Installation and operating instructions
Flexcom wiki - https://wiki.nyomkovetes.net/
How to use
The device has a built-in SIM card that can be used anywhere in the world, a strong battery and a
rugged, waterproof aluminum cover that is resistant to external influences. With the help of the built-
in motion sensor, you can receive an immediate alarm if the device or the bicycle is moved by
unauthorized persons. It works continuously, it cannot be switched off. When discharged, it turns on
automatically when the charger is connected.
The device can be mounted under the bottle holder of the bicycle with special custom safety screws
manufactured by us. Communication is via the SIM card built into the device and the internet
connection provided by the mobile service providers. The current position of the device, previous
route, statistics, etc. are provided by the computer or mobile phone application we have developed.
The device is already set up and handed over ready for use. After commissioning, the device
automatically connects to the GPS / BEIDOU and GSM networks (if available) using the satellite
receiver and SIM card and starts collecting position data.
When switched on
The device continuously registers position data, which can be queried with SMS commands at a
limited level.
The device sends the position data to the software service center - their processed results (eg
map route display, list of route events, real-time tracking) - can be viewed in the phone or
computer application.
You can find detailed information on the installation, use, maintenance and decommissioning of the
device in the further sections of the documentation.
The device is protected by a safety label - it must not be disassembled, as breaking the
insulation may damage the device and void the warranty. The built-in SIM card in your
device cannot be replaced at home. If you wish to transfer the device to another person,
please contact our customer service to make the necessary settings!
Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03
2022/09/09 09:03 7/21 Installation and operating instructions
Flexcom wiki - https://wiki.nyomkovetes.net/
Technical parameters
Physical characteristics
Parameter Value
DImensions (mm) W: 41, L: 85, H: 22,3
Weight (g) 130
Cover Aluminum and plastic
Humidity from 5% to 95% (non condensing)
Water resistance IP65 (protected against dust-free, low-pressure
water jets)
Operating temperature from -20C to +70C
Storage temperature from -40C to +85C
Memory
Parameter Value
Built-in No
SD card No
Energy supply
Parameter Value
Battery Li-ion polimer 3.7V 2000mAh
Charging 5V/1A
Power consumption at rest 2.5 mAh
Power consumption in active state 40 mAh
Operating time
Parameter Value
Standby time 30 days
Network
Parameter Value
GNSS GPS, BEIDOU sat system + Wifi + LBS + AGPS
Type of data traffic GSM/GPRS
SIM card Micro
GSM frekvencies 850, 900, 1800, 1900 MHz
GSM chip MT2503
GSM signal strength measurement Yes
Satellite receiver chip MT5931
Satellite receiver sensitivity -143 - -159 dbm
Signal L1,1575.42MHz C/A code
Measurement accuracy 5 m
Communication
Parameter Value
TCP Yes
Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03
Sensors
Parameter Value
Motion sensor Yes
Interface
Parameter Value
GSM antenna Internal
Satellite receiver antenna Internal
Charger connector Micro USB
Display LED
2022/09/09 09:03 9/21 Installation and operating instructions
Flexcom wiki - https://wiki.nyomkovetes.net/
Használati útmutató
Transport and storage
The packaging is designed to protect the product from the usual physical effects during transport. Be
careful to avoid effects other than these.
The packaging of the product is not water, flame and heat resistant and only moderately pressure
resistant. Therefore, do not keep the box in a humid environment, out of the reach of heat-emitting
equipment, or place heavy objects on it.
Commissioning
The package consists of a box containing the device and its accessories.
Unpacking
Open the box.1.
Remove the product.2.
Remove the retaining insert to protect the device.3.
Remove the accessories below.4.
Contents of the package
1 tracking device
1 charger
1 charging cable
Last
update:
2021/05/06
10:14
en:devices:manufacturers:flexcom:area:bike:fb222:manual:full https://wiki.nyomkovetes.net/doku.php?id=en:devices:manufacturers:flexcom:area:bike:fb222:manual:full
https://wiki.nyomkovetes.net/ Printed on 2022/09/09 09:03
2 pieces of security screws and 1 piece of wrench
1 installation instructions
Installing the device
You can attach the device to the frame of the bicycle with the safety screws included in the package,
as follows:
