FlashLogic FLRSCH7 Manuel utilisateur

REVISION DATE

20141105

DOCUMENT NUMBER

NOTICE The manufacturer will accept no responsability for any electrical

damage resulting from improper installation of this product, be that either

damage to the vehicle itself or to the installed device. This device must be in-

stalled by a certiﬁed technician. Please review the Installation Guide carefully

before beginning any work.

BEFORE INSTALLATION

1- Connect module to computer

2- Login to Weblink account

3- Flash ﬁrmware to module (module is not preloaded with ﬁrmware)

4- Use accessories accordingly (accessories are sold separately)

U.S. Patent No. 8,856,780

INSTALL GUIDE

FLCCHRSCH8FLRSCH7EN

HARDWARE

FLRSCH7

FIRMWARE

FLCCHRSCH8FLRSCH7

ACCESSORIES

FLPROG REQUIRED

FLRF1/2/4 OPTIONAL

CARLINK ASCL2 OPTIONAL

17441

U.S. Patent No. 8,856,780

VEHICLE LIST - 1 OF 1

MAKE

MODEL

YEAR

INSTALL TYPE

FEATURES

DATA IMMOBILIZER BYPASS

DOOR LOCK

DOOR UNLOCK

ARM OEM ALARM

DISARM OEM ALARM

TRUNK/HATCH RELEASE

DOOR STATUS OUTPUT

TRUNK STATUS OUTPUT

BRAKE PEDAL STATUS OUTPUT

TACHOMETER OUTPUT

SECURE TAKEOVER

GLOW PLUGS STATUS

RAP SHUTDOWN CTRL

DODGE

Dart STD key (Tip-Start) AT (without Autolight) 13 1 • • • • • • • • • • • •

Dart STD key (Tip-Start) AT (with Autolight) 13 2 • • • • • • • • • • • •

RAM

1500 STD key (Tip-Start) AT 13-14 3 • • • • • • • • • •

1500 Diesel STD key (Tip-Start) AT 14 3 • • • • • • • • • • •

2500 / 3500 STD key (Tip-Start) AT 13-14 3 • • • • • • • • • •

2500 / 3500 Diesel STD key (Tip-Start) AT 14 3 • • • • • • • • • • •

NOTE

I WARNING: All vehicle doors must be

closed and locked prior to remote start

sequence.

PAGE 2 OF 22

• 20141105

FLCCHRSCH8FLRSCH7EN

DOC.: #17441

U.S. Patent No. 8,856,780

BOX CONTENTS - 1 OF 1

VS2VS2

VS1VS1

MS1MS1

MS2MS2

BOX CONTENTS

T-HARNESS 1

AFTERMARKET HOOD SWITCH AND CABLE

WARNING STICKER

10 PIN CONNECTOR

12 PIN CONNECTOR

BLUE

PROGRAMMING

BUTTON

LED 2

LED 1

MODULE

BLACK

RF PORT/

WEBLINK PORT

BLACK

BLUE

TELEMATIC

PORT

WHITE

WEBLINK CABLE (required accessory sold separately)

WEBLINK CABLE

COMPUTER

USB PORT

4 PIN BLACK CABLE

MODULE

WEBLINK PORT

PAGE 3 OF 22

• 20141105

FLCCHRSCH8FLRSCH7EN

DOC.: #17441

U.S. Patent No. 8,856,780

PAGE 4 OF 22

• 20141105

FLCCHRSCH8FLRSCH7EN

COMPATIBLE ACCESSORIES - 1 OF 1

FLRF1/2/4 RF KIT

RF KIT (accessories sold separately)

(NC)

ANTENNA

MODULE

RF PORT

FLHRNTM

TELEMATIC KIT (accessories sold separately)

(NC)

CARLINK

MODULE

TELEMATIC PORT

10 11 12 13 14 15 16

12345678

FLHRNTM

TELEMATIC KIT (accessories sold separately)

MODULE

TELEMATIC PORT

CAR CONNECTIONPN 4120260 OBDII CONNECTOR

VEHICLE

OBDII PORT

(NC)

DOC.: #17441

U.S. Patent No. 8,856,780

TYPE 1 - WIRE CHART - 1 OF 1

MAKE

MODEL

YEAR

WIRE

DESCRIPTION

CONNECTOR

NAME

CONNECTOR

COLOR

CONNECTOR

TYPE

POSITION

WIRE

COLOR

POLARITY

MODULE

LOCATION

COMPONENT

LOCATOR

DODGE

Dart

STD key

(without

Autolight)

12V ~ White 06 pin 06 Red (+) Ignition connector F

Ground ~ White 06 pin 03 Black (-) Ignition connector F

Ignition ~ White 06 pin 04 Purple/Brown (+) Ignition connector F

Imo Lin ~ White 06 pin 05 White/Green (DATA) Ignition connector F

CanH ~ Black 16 pin 06 Gray/White (DATA) OBDII connector ~

CanL ~ Black 16 pin 14 Yellow (DATA) OBDII connector ~

Parking Light ~ Black 06 pin 03 White/Brown (MUX) Parking light switch A

Rap Shutdown ~ ~ ~ ~ Purple (-) Driver kick panel harness B

PAGE 5 OF 22

• 20141105

FLCCHRSCH8FLRSCH7EN

DOC.: #17441

U.S. Patent No. 8,856,780

MS1MS1

MS2MS2

OBDII

10 11 12 13 14 15 16

1234567 8

VS2VS2

VS1VS1

2 K

3456

CANL - 14

PARKING LIGHT (MUX) - 03

RAP SHUTDOWN (-)

HORN (-)

CANH - 06

02 GRAY - RAP SHUTDOWN (-) OUTPUT

TYPE 1 - WIRING DIAGRAM - 1 OF 1

OBDII CONNECTOR

PARKING LIGHT SWITCHPARKING LIGHT SWITCH

MODULE

11 GRAY/GREEN - HORN (-) OUTPUT

OPTIONAL

BROWN/RED

BROWN/YELLOW

WHITE/BLACK - GROUND (-)

WHITE/BROWN (NC)

WHITE/RED (NC)

WHITE

DRIVER KICK PANEL

HARNESS

BLACK

IGNITION CONNECTOR

IGNITION HARNESS

IGNITION NODE

AFTERMARKET HOOD SWITCH (-)

04 GRAY/WHITE - HOOD STATUS (-) INPUT

WITHOUT OEM HOOD SWITCH:

INSTALL AND CONNECT TO

AFTERMARKET HOOD SWITCH

TELEMATIC PORT

RF PORT/WEBLINK PORT

PAGE 6 OF 22

• 20141105

FLCCHRSCH8FLRSCH7EN

DOC.: #17441

U.S. Patent No. 8,856,780

TYPE 2 - WIRE CHART - 1 OF 1

MAKE

MODEL

YEAR

WIRE

DESCRIPTION

CONNECTOR

NAME

CONNECTOR

COLOR

CONNECTOR

TYPE

POSITION

WIRE

COLOR

POLARITY

MODULE

LOCATION

COMPONENT

LOCATOR

DODGE

Dart

STD key

(with

Autolight)

12V ~ White 06 pin 06 Red (+) Ignition connector F

Ground ~ White 06 pin 03 Black (-) Ignition connector F

Ignition ~ White 06 pin 04 Purple/Brown (+) Ignition connector F

Imo Lin ~ White 06 pin 05 White/Green (DATA) Ignition connector F

CanH ~ Black 16 pin 06 Gray/White (DATA) OBDII connector ~

CanL ~ Black 16 pin 14 Yellow (DATA) OBDII connector ~

Parking Light ~ Black 06 pin 03 White/Brown (MUX) Parking light switch A

Rap Shutdown ~ ~ ~ ~ Purple (-) Driver kick panel harness B

Autolight Off ~ Black 06 pin 06 White/Yellow (MUX) Parking light switch A

PAGE 7 OF 22

• 20141105

FLCCHRSCH8FLRSCH7EN

DOC.: #17441

U.S. Patent No. 8,856,780

MS1MS1

MS2MS2

OBDII

10 11 12 13 14 15 16

1234567 8

VS2VS2

VS1VS1

1000 OHMS

3456

IGNITION CONNECTOR

IGNITION HARNESS

CANL - 14

PARKING LIGHT (MUX) - 03

AUTOLIGHT OFF - 06

RAP SHUTDOWN (-)

HORN (-)

CANH - 06

02 GRAY - RAP SHUTDOWN (-) OUTPUT

TYPE 2 - WIRING DIAGRAM - 1 OF 1

IGNITION NODE

OBDII CONNECTOR

PARKING LIGHT SWITCHPARKING LIGHT SWITCH

MODULE

11 GRAY/GREEN - HORN (-) OUTPUT

OPTIONAL

BROWN/RED

BROWN/YELLOW

WHITE/BLACK - VEHICLE SIDE

WHITE/BROWN (NC)

WHITE/RED - CONNECTOR SIDE

WHITE

DRIVER KICK PANEL

HARNESS

BLACK

AFTERMARKET HOOD SWITCH (-)

04 GRAY/WHITE - HOOD STATUS (-) INPUT

WITHOUT OEM HOOD SWITCH:

INSTALL AND CONNECT TO

AFTERMARKET HOOD SWITCH

TELEMATIC PORT

RF PORT/WEBLINK PORT

PAGE 8 OF 22

• 20141105

FLCCHRSCH8FLRSCH7EN

DOC.: #17441

U.S. Patent No. 8,856,780

TYPE 3 - WIRE CHART - 1 OF 1

MAKE

MODEL

YEAR

WIRE

DESCRIPTION

CONNECTOR

NAME

CONNECTOR

COLOR

CONNECTOR

TYPE

POSITION

WIRE

COLOR

POLARITY

MODULE

LOCATION

COMPONENT

LOCATOR

RAM

1500 /

1500 Diesel

STD key

13-14

12V D2664A Black 06 pin 06 Red (+) Ignition connector F

Ground D2664A Black 06 pin 03 Black (-) Ignition connector F

Mux D2664A Black 06 pin 04 Purple/Brown (+) Ignition connector F

Ignition ~ Gray 04 pin 02 Pink/Green (+) Trailer pack connector, right of steering ~

Imo Lin D2664A Black 06 pin 05 White/Green (DATA) Ignition connector F

CanH D7405A Black 16 pin 06 Gray/White (DATA) OBDII connector ~

CanL D7405A Black 16 pin 14 Yellow (DATA) OBDII connector ~

Parking Light D2242A Black 10 pin 01 White/Brown (MUX) Parking light switch A

Rap Shutdown ~ ~ ~ ~ Purple (-) Driver kick panel harness B

2500 /

2500 Diesel /

3500 /

3500 Diesel

STD key

13-14

12V D2664A Black 06 pin 06 Red (+) Ignition connector F

Ground D2664A Black 06 pin 03 Black (-) Ignition connector F

Mux D2664A Black 06 pin 04 Purple/Brown (+) Ignition connector F

Ignition ~ Gray 04 pin 02 Pink/Green (+) Trailer pack connector, right of steering ~

Imo Lin D2664A Black 06 pin 05 White/Green (DATA) Ignition connector F

CanH D7405A Black 16 pin 06 Gray/White (DATA) OBDII connector ~

CanL D7405A Black 16 pin 14 Yellow (DATA) OBDII connector ~

Parking Light D2242A Black 10 pin 01 White/Brown (MUX) Parking light switch A

Rap Shutdown ~ ~ ~ ~ Purple (-) Driver kick panel harness B

PAGE 9 OF 22

• 20141105

FLCCHRSCH8FLRSCH7EN

DOC.: #17441

U.S. Patent No. 8,856,780

MS1MS1

MS2MS2

OBDII

10 11 12 13 14 15 16

1234567 8

VS2VS2

VS1VS1

12345

6 7 8 9 10

CANL - 14

PARKING LIGHT (MUX) - 01

RAP SHUTDOWN (-)

HORN (-)

CANH - 06

02 GRAY - RAP SHUTDOWN (-) OUTPUT

TYPE 3 - WIRING DIAGRAM - 1 OF 1

OBDII CONNECTOR

PARKING LIGHT SWITCHPARKING LIGHT SWITCH

MODULE

11 GRAY/GREEN - HORN (-) OUTPUT

OPTIONAL

BROWN/RED

BROWN/YELLOW

WHITE/BLACK (NC)

WHITE/BROWN

WHITE/RED (NC)

WHITE (NC)

BLACK

DRIVER KICK PANEL

HARNESS

IGNITION CONNECTOR

IGNITION HARNESS

IGNITION NODE

AFTERMARKET HOOD SWITCH (-)

04 GRAY/WHITE - HOOD STATUS (-) INPUT

WITHOUT OEM HOOD SWITCH:

INSTALL AND CONNECT TO

AFTERMARKET HOOD SWITCH

TELEMATIC PORT

RF PORT/WEBLINK PORT

PAGE 10 OF 22

• 20141105

FLCCHRSCH8FLRSCH7EN

DOC.: #17441
