1INTRODUCTION

Thank you for purchasing Moving Head FL-232 BEAM 7R. For safety reasons and to ensure the

trouble-free operation, carefully read the instructions.

2SAFETY INFORMATION

1. CAUTION ! Avoid looking directly into the light source (meant especially for epileptics)!

2. CAUTION ! Keep away from fire!

3. Before connecting the unit to the mains, make sure it is not damaged mechanically. If you

notice any signs of damage you should contact your dealer immediately. Do not connect the

device to the mains.

4. Do not use the device in high humidity conditions and at temperatures above 40° C

5. The device must be installed on stable structures

6. WARNNING! Minimum distance of inflammable materials from the surface: 12m.

7. To reduce the risk of electrical shock or fire, do not expose this unit to rain or moisture.

8. Do not spill water or other liquids into or on to your unit.

9. During long periods of non-use, disconnect the units main power.

10. It should be installed in a well-ventilated place, at a distance of 50cm or more with the walls.

At the same time, please check if the fan and ventilation holes are unobstructed.

11. Disconnect the power supply before installation.

The product has perfect performance and integrity packing. All users should be strictly comply with the

warning and operating instructions as stated. Or we aren't in charge of any result by misusing. Any damage

resulting by misuse is not within the company’s warranty.

WARNING! THE BULB IS HOT!

Please turn off or restart the device only after 20 minutes after turning off the lamp, once it is fully cooled

down. Frequent switching will reduce the life span of lamps and bulbs.

CAUTION! The head and yoke must be unlocked before operation! Check the pan/tilt locks!

3PRODUCT INFORMATION

3.1 Features

Lamp: equivalent discharge lamp 7R, 230W

Resetting the lamp on and off using the DMX512 signal

Extremely fast and precise movement

Electronic monitoring of the error message

Ultra compact design, light weight device (17.2 kg)

PAN / TILT speed control via DMX

3 lenses

Aluminum construction with plastic elements

Two side handles for transportation

PAN / TILT lock for safe handling

Minimum distance to illuminated surfaces: 3m

3.2 Specification

Power consumption: 330W

Power supply voltage: 100 - 240V

Moving Head FL-232 BEAM 7R F1000083

www.flash-butrym.pl

Voltage frequency: 50/60Hz

Lamp type: 7R

Display: LCD Matrix

Color: Color wheel - 14 colors + white

ZOOM: No

Beam angle (min): 1°

Beam angle (max): 1°

Dimming: Linear: 0 - 100%

Prism: 8-facet, rotating

FROST filter: Yes

FOCUS: Electronic

GOBO wheel: 7 patterns + open

PAN range: 540°

TILT range: 280°

Number of DMX channels: 16 / 17 / 20

DMX standard: DMX 512

Control interface: Wheel controller

Operating modes: Automatic, Sound, DMX-512, Master/Slave

Features: Resetting the lamp on and off using the DMX512 signal

AC IN: powerCON

AC OUT: powerCON

DMX IN: XLR - 3 pin, XLR - 5 pin

DMX OUT: XLR - 3 pin, XLR - 5 pin

IP Rating: IP20

Housing made: ABS

Cooling: Active

Height [cm]: 52

Width [cm]: 40

Depth [cm]: 32

Weight [kg]: 17,2

Weight with packaging [kg]: 19

Set includes: Power cord, Power cord (LINK), Mounting bracket (2pcs)

4INSTALLATION

After removing the packaging, check if the device was not damaged during transport. Before connecting to

the mains, make sure that the device is securely mounted. The manufacturer is not responsible for damage

caused by unstable mounting.

Ensure proper connection to the mains and proper grounding. Make sure that the electrical parameters are

consistent with device requirements. All activities, including connecting the device to the mains must be

performed by qualified personnel.

5CONNECTIONS

The device is equipped with the following interfaces:

1. DMX (in/out): XLR 5-pin, XLR 3-pin socket

www.flash-butrym.pl

2. Power (in/out): powerCON socket

5.1 Connecting DMX signal

The connection is performed using cable with XLR-female -> XLR-Male plugs.

CAUTION: At the last fixture, the DMX signal has to be terminated with a terminator. Solder a 120resistor

between signal (-) and signal (+) into a XLR plug and plug it in the DMX output of the last fixture.

5.2 Voltage specification

Input Voltage

Total Power

Frequency

100~240V

330W

50/60Hz

5.3 Connecting power supply

The connection is performed using power cable with PowerCon connector (included).

The device must be operated by qualified personnel. Make sure that the power grid supply parameters are

consistent with device parameters and limitations are not exceeded.

CAUTION! In the case of cable damage do not attempt to repair. Replacement or repair can be made only

on the manufacturer or by a person with appropriate permissions.

Moving Head FL-232 BEAM 7R F1000083

www.flash-butrym.pl

6OPERATION MANUAL

6.1 DMX channel list

16CH mode (Smal)

Channel

Function

Effect

CH 1

Color wheel

0: White

5: White + red

9: Red

13: Red + orange

18: Orange

22: Orange + aquamarine

26: Aquamarine

30: Aquamarine + light orange

35: Light orange

39: Light orange + cold white

43: Cold white

47: Cold white + lavender

52: Lavender

56: Lavender + light yellow

60: Light yellow

64: Light yellow + cyan

69: Cyan

73: Cyan + violet

77: Violet

82: Violet + yellow

86: Yellow

90: Yellow + CTO260

94: CTO260

99: CTO260 + CTO190

103: CTO190

107: CTO190 + CTB8000

111: CTB8000

116: CTB8000 + pink

120: Pink

124: Pink + white

128-145: White

146-255: Pattern clockwise rotation, slow-fast

CH 2

Strobe

0-9: Close

10-240: Strobe, slow-fast

241-255: Open

CH 3

Dimmer

0-255: 0-100%

www.flash-butrym.pl

CH 4

Gobo wheel

0-4: White (open)

5: Gobo 1

10: Gobo 2

15-15: Gobo 3

20-19: Gobo 4

25: Gobo 5

30: Gobo 6

35: Gobo 7

40: Gobo 8

45: Gobo 9

50: Gobo 10

55: Gobo 11

60: Gobo 12

65: Gobo 13

70: Gobo 14

75: Gobo 15

80: Gobo 16

85: Gobo 17

90-129: Gobo clockwise rotation, fast-slow

130-134: Stop

135-170: Gobo counterclockwise rotation, slow-fast

171: Gobo 1 shake, slow-fast

176: Gobo 2 shake, slow-fast

181: Gobo 3 shake, slow-fast

186: Gobo 4 shake, slow-fast

191: Gobo 5 shake, slow-fast

196: Gobo 6 shake, slow-fast

201: Gobo 7 shake, slow-fast

206: Gobo 8 shake, slow-fast

211: Gobo 9 shake, slow-fast

216: Gobo 10 shake, slow-fast

221: Gobo 11 shake, slow-fast

226: Gobo 12 shake, slow-fast

231: Gobo 13 shake, slow-fast

236: Gobo 14 shake, slow-fast

241: Gobo 15 shake, slow-fast

246: Gobo 16 shake, slow-fast

251: Gobo 17 shake, slow-fast

CH 5

Prism

0-127: Prism Off

128-255: Prism On

CH 6

Prism rotation

0-127: 0° - 420°

128-190: Clockwise rotation, fast-slow

191-192: Stop

193-255: Counterclockwise rotation, slow-fast

CH 7

Empty

0-255: No function

CH 8

Frost

0-127: Frost Off

128-255: Frost On

CH 9

Focus

0-255: Focus, far-close

CH 10

Pan

0-255: Pan rotation 0°-540°

CH 11

Pan fine

0-255: Pan rotation fine

CH 12

Tilt

0-255: Tilt rotation 0°-280°

CH 13

Tilt fine

0-255: Tilt rotation fine

CH 14

Empty

0-255: No function

CH 15

Reset

0-127: No function

128-255: Reset

CH 16

Lamp on / off

0-25: No function

26-100: Lamp off

101-255: Lamp on

Moving Head FL-232 BEAM 7R F1000083

www.flash-butrym.pl

17CH mode (Stan)

Channel

Function

Effect

CH 1

Color wheel

0: White

5: White + red

9: Red

13: Red + orange

18: Orange

22: Orange + aquamarine

26: Aquamarine

30: Aquamarine + light orange

35: Light orange

39: Light orange + cold white

43: Cold white

47: Cold white + lavender

52: Lavender

56: Lavender + light yellow

60: Light yellow

64: Light yellow + cyan

69: Cyan

73: Cyan + violet

77: Violet

82: Violet + yellow

86: Yellow

90: Yellow + CTO260

94: CTO260

99: CTO260 + CTO190

103: CTO190

107: CTO190 + CTB8000

111: CTB8000

116: CTB8000 + pink

120: Pink

124: Pink + white

128-145: White

146-255: Pattern clockwise rotation, slow-fast

CH 2

Strobe

0-9: Close

10-240: Strobe, slow-fast

241-255: Open

CH 3

Dimmer

0-255: 0-100%

www.flash-butrym.pl

CH 4

Gobo wheel

0-4: White (open)

5: Gobo 1

10: Gobo 2

15-15: Gobo 3

20-19: Gobo 4

25: Gobo 5

30: Gobo 6

35: Gobo 7

40: Gobo 8

45: Gobo 9

50: Gobo 10

55: Gobo 11

60: Gobo 12

65: Gobo 13

70: Gobo 14

75: Gobo 15

80: Gobo 16

85: Gobo 17

90-129: Gobo clockwise rotation, fast-slow

130-134: Stop

135-170: Gobo counterclockwise rotation, slow-fast

171: Gobo 1 shake, slow-fast

176: Gobo 2 shake, slow-fast

181: Gobo 3 shake, slow-fast

186: Gobo 4 shake, slow-fast

191: Gobo 5 shake, slow-fast

196: Gobo 6 shake, slow-fast

201: Gobo 7 shake, slow-fast

206: Gobo 8 shake, slow-fast

211: Gobo 9 shake, slow-fast

216: Gobo 10 shake, slow-fast

221: Gobo 11 shake, slow-fast

226: Gobo 12 shake, slow-fast

231: Gobo 13 shake, slow-fast

236: Gobo 14 shake, slow-fast

241: Gobo 15 shake, slow-fast

246: Gobo 16 shake, slow-fast

251: Gobo 17 shake, slow-fast

CH 5

Prism

0-127: Prism Off

128-255: Prism On

CH 6

Prism rotation

0-127: 0° - 420°

128-190: Clockwise rotation, fast-slow

191-192: Stop

193-255: Counterclockwise rotation, slow-fast

CH 7

Empty

0-255: No function

CH 8

Frost

0-127: Frost Off

128-255: Frost On

CH 9

Focus

0-255: Focus, far-close

CH 10

Pan

0-255: Pan rotation 0°-540°

CH 11

Pan fine

0-255: Pan rotation fine

CH 12

Tilt

0-255: Tilt rotation 0°-280°

CH 13

Tilt fine

0-255: Tilt rotation fine

CH 14

Empty

0-255: No function

CH 15

Reset

0-127: No function

128-255: Reset

CH 16

Lamp on / off

0-25: No function

26-100: Lamp off

101-255: Lamp on

CH 17

Pan / Tilt speed

0-5: Fastest

6-250: Fast-slow

251-255: Fastest

Moving Head FL-232 BEAM 7R F1000083

www.flash-butrym.pl

20CH mode (Defe)

Channel

Function

Effect

CH 1

Color wheel

0: White

5: White + red

9: Red

13: Red + orange

18: Orange

22: Orange + aquamarine

26: Aquamarine

30: Aquamarine + light orange

35: Light orange

39: Light orange + cold white

43: Cold white

47: Cold white + lavender

52: Lavender

56: Lavender + light yellow

60: Light yellow

64: Light yellow + cyan

69: Cyan

73: Cyan + violet

77: Violet

82: Violet + yellow

86: Yellow

90: Yellow + CTO260

94: CTO260

99: CTO260 + CTO190

103: CTO190

107: CTO190 + CTB8000

111: CTB8000

116: CTB8000 + pink

120: Pink

124: Pink + white

128-145: White

146-255: Pattern clockwise rotation, slow-fast

CH 2

Strobe

0-9: Close

10-240: Strobe, slow-fast

241-255: Open

CH 3

Dimmer

0-255: 0-100%

Table des matières

Langues :

Autres manuels Flash Équipement d'éclairage

Flash

Flash F7000563 Manuel utilisateur

Flash

Flash F7000560 Manuel utilisateur

Flash

Flash EVENT Series Manuel utilisateur

Flash

Flash F7100335 Manuel utilisateur

Flash

Flash Laser mini LED White Manuel utilisateur

Flash

Flash HAZER 900 2019 Manuel utilisateur

Flash

Flash F7100303 Manuel utilisateur

Flash

Flash Big Eye Manuel utilisateur

Flash

Flash LED NEW EFFECT LIGHT Manuel utilisateur

Flash

Flash F7000050 Manuel utilisateur

Flash

Flash F7100330 Manuel utilisateur

Flash

Flash 19x40W PRO Manuel utilisateur

Flash

Flash F7100523 Manuel utilisateur

Flash

Flash FOLLOW SPOT 350W Manuel utilisateur

Flash

Flash F7000686 Manuel utilisateur

Flash

Flash F7100327 Manuel utilisateur

Flash

Flash F7100443 Manuel utilisateur

Flash

Flash LED PAR 18x10W RGBW 4in1 IP20 Manuel utilisateur

Flash

Flash FLG-256 Manuel utilisateur

Flash

Flash LOGO Manuel utilisateur

Flash

Flash FL-233 BEAM Manuel utilisateur

Flash

Flash F7200204 Manuel utilisateur

Flash

Flash LED PAR 56 SLIM RGB Aura F7000253a Manuel utilisateur

Flash

Flash WashFX 1000 IP65 Manuel utilisateur

Manuels Équipement d'éclairage populaires d'autres marques

Brizo

Brizo 8SP-MU-4 Manuel utilisateur

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Manuel utilisateur

IKEA

IKEA BJÖRKSPIREA Manuel utilisateur

Laserworld

Laserworld Evolution Series ES-400RGB Manuel utilisateur

Alien

Alien RG STAR Manuel utilisateur

EuroLite

EuroLite LED B-40 Manuel utilisateur

Qazqa

Qazqa Suplux SL 3 Black 103062 Manuel utilisateur

Commercial Electric

Commercial Electric 54568141 Manuel utilisateur

CREE LIGHTING

CREE LIGHTING 304 Series Manuel utilisateur

Goobay

Goobay 49867 Manuel utilisateur

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Manuel utilisateur

Alkalite

Alkalite Krypton KT-81 Manuel utilisateur

Clas Ohlson

Clas Ohlson GU10 Manuel utilisateur

DTS

DTS DELTA 10 F Manuel utilisateur

ring

ring Solar Steplight Manuel utilisateur

One Stop Gardens

One Stop Gardens 57696 Instructions de montage

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Manuel utilisateur

SIREM

SIREM Swimeo A2 Manuel utilisateur
