FixAir In-Duct_MU
Versión: 1.04
Page 9 of 17
Bipolar Ionization
ENGLISH
External components.
No. component.
Internal components.
Front panel.1.
Front panel screws (6 in
total)
2.
On/Off Button.0. UVC-UVA LED lights.6.
Ionizers’ pilot LED lights.7.
Quick blow fuse.8.
Side covers.3.
Back plate.4.
5. Electrical cord connector.
Carbon fiber brushes.9.
These components are high in energy and oxidize both the organic and inorganic
pollutants present in the air, pollutants that can generate unpleasant odors, with
only carbon dioxide, water and other harmless elements resulting
as byproducts.
Transport and Packaging.8.
All FixAir products undergo thorough quality control checks before
being carefuly packed, and their packaging is suitably designed and
manufactured for transport. When opening the package, with the Con-
tents List in hand do check that all contents are complete, in good
condition and that the device is opperational. Please report any
findings to your dealer inmediately, for claims made at a later date will
not be honoured.
To select the proper location for the instalation of your FixAir Room
device, the following considerations must be taken into account:
Installing.9.
Only qualified staff may work on the device!
When installed in a cold room, connect the device to a
Ground Fault Circuit Interrupter (GFCI) socket, or
directly to the evaporator unit.
Only qualified staff may mount or carry out maintance on
the device.
The device must be connected to a Ground Fault Circuit
Interrupter (GFCI) socket, or directly to the evaporrator
unit of the air conditioner when installed in a cold room.
