USER’S GUIDE
This fine instrument is equipped with a FISHMAN PREFIX™
ACOUSTIC GUITAR SYSTEM.
Please read these instructions carefully. If you have any questions or
problems, please call our CUSTOMER SERVICE LINE at (978) 988-
9665.
The PREFIX™ is an instrument-mounted pickup / preamp system that
offers total control of your amplified guitar sound.
THE PICKUP
The PREFIX™ ACOUSTIC GUITAR SYSTEM includes a FISHMAN
ACOUSTIC MATRIX pickup; made with a unique co-polymer sensing
material available exclusively from FISHMAN. This technology is not
available from any other manufacturer. The sensing material exhibits a
sensitivity and dynamic range that far surpasses all other known sens-
ing materials.
The ACOUSTIC MATRIX transducer is a fully EMI shielded, multi-layer
sandwich of co-polymer strips that run the length of the pickup. This
design allows the pickup to sense the motion of the entire saddle
length, providing superb string to string balance, as well as sensitivity
to both the strings and top of the instrument.
THE PREAMP
The PREFIX™ preamp module incorporates a unique "flip-top" battery
compartment for easy access. Level is set by the VOLUME control.
Shelving BASS & TREBLE and a semi-parametric CONTOUR control
are included for precise tone shaping. A LOW BATTERY indicator lets
you know when it’s time to change the battery.
FISHMAN PREFIX™
2
ONBOARD ACOUSTIC GUITAR SYSTEM
3
PREAMP FUNCTIONS
BATTERY COMPARTMENT
Pull the small tab at the top of the PREFIX™ preamp toward you.
The body of the preamp will swing out, revealing the BATTERY COM-
PARTMENT. Insert a fresh 9V alkaline battery.
ENDPIN JACK
The PREFIX™ has no ON/OFF switch. It is turned on only when an
instrument cable is plugged into the endpin jack. To conserve the bat-
tery, remove the instrument cable from the endpin jack when the unit
is not being used.
NOTE: Plug an instrument cable into the endpin jack before you plug
into the sound equipment. Doing so will prevent loudspeaker damage.
BATTERY LOW LED
When plugging into the endpin jack, the LOW BATTERY light will flash
momentarily, indicating that the power is on. When the LOW BATTERY
light stays on, it is time to change the battery.
FISHMAN PREFIX™
4
CONTROLS
VOLUME CONTROL
The Volume control affects both microphone and pickup. Goes from
very quiet to very loud.
BASS CONTROL
This is a boost/cut shelving tone control. The center detent yields a
flat response.
CONTOUR This is a wide-range semi-parametric filter. It may be
used to shape the instrument's tone or to control feedback (see
pages 5 and 6).
The CONTOUR Level slider controls the amount of boost or cut
applied to the selected Contour FREQUENCY. The center detent
yields a flat response.
The Contour FREQUENCY slider determines the frequency band
that is boosted or cut by the CONTOUR Level control. The fre-
quency is variable between 250 Hz and 10 kHz.
TREBLE CONTROL
This is a boost/cut shelving tone control. The center detent yields a
flat response.
ONBOARD ACOUSTIC GUITAR SYSTEM
5
SUGGESTED EQ SETTINGS
BRILLIANCE
If you are playing through a guitar amplifier
or have dead strings on the instrument,
you can brighten up your sound by setting
the Contour FREQUENCY slider to 10 kHz
and raising the CONTOUR Level to taste.
MID CUT
Boost the CONTOUR Level.
Adjust the Contour FREQUENCY slider
until you find the offensive frequency.
Cut the CONTOUR Level to suit your
taste.
You can also cut midrange by boosting
the BASS and TREBLE sliders to realize
an implied mid-cut at 800 Hz.
FISHMAN PREFIX™
6
SUGGESTED EQ SETTINGS, Continued
CUT THROUGH
For cutting through a live band mix at
high volumes.
FINGERSTYLE
This setting will add fullness to the bass
and definition to the treble.
SPECIFICATIONS
Nominal Input Level: -20 dBV
Input Overload: (20 Hz - 20 kHz)-2 dBV
Input Impedance: 20 M Ohms
Output Impedance: Less than 3.5 k Ohms
Nominal Output Level: -12 dBV
THD: Less than .04 %, -20 dBV input
Signal to Noise Ratio: 77 dB
(A weighted referred to nominal
-20 dBV input)
Current Drain: Less than 1 mA
Power Supply: 9V Alkaline battery
(estimated 550 hours continuous use with low
battery indicator at 6.5V)
Bass Control Range: ± 12 dB at 60 Hz
± 3 dB at 350 Hz
Treble Control Range: ± 12 dB at 10 kHz
± 3 dB at 2.4 kHz
Contour Control Range: ± 12dB
(adjustable from 250 Hz to 10 kHz)
Q = 0.5
All specifications subject to change without notice.
ONBOARD ACOUSTIC GUITAR SYSTEM
7
INSTALLATION BY A QUALIFIED PROFESSIONAL REPAIRMAN IS STRONGLY
RECOMMENDED. FISHMAN TRANSDUCERS WILL NOT BE RESPONSIBLE FOR ANY
DAMAGES THAT MAY RESULT FROM IMPROPER INSTALLATION.
The FISHMAN PREFIX™ ACOUSTIC GUITAR SYSTEM is warranted to function for a period
of One (1) Year from the date of purchase. If the unit fails to function properly within the
warranty period, free repair and the option of replacement or refund in the event that
FISHMAN is unable to make repair are FISHMAN’s only obligations. This warranty does not
cover any consequential damages or damage to the unit due to misuse, accident, or neglect.
FISHMAN retains the right to make such determination on the basis of factory inspection.
Products returned to FISHMAN for repair or replacement must be shipped in accordance
with the Return Policy, as follows. This warranty remains valid only if repairs are performed
by FISHMAN. This warranty gives you specific legal rights and you may also have other
rights which may vary from state to state.
RETURN POLICY
To return products to FISHMAN TRANSDUCERS, you must follow these steps...
1. Call FISHMAN TRANSDUCERS at 978-988-9199 for a Return Authorization Number
(“RAN”).
2. Enclose a copy of the original Bill of Sale as evidence of the date of purchase, with
the product in its original packaging and a protective carton or mailer.
3. FISHMAN TRANSDUCERS’ technicians will determine whether the item is covered by
warranty or if it instead has been damaged by improper customer installation or other
causes not related to defects in material or workmanship.
4. Warranty repairs or replacements will be sent automatically free of charge.
5. If FISHMAN TRANSDUCERS determines the item is not covered by warranty, we will
notify you of the repair or replacement cost and wait for your authorization to proceed.
FISHMAN TRANSDUCERS
®
340-D Fordham Road Wilmington MA 01887 USA
Phone 978-988-9199 Fax 978-988-0770 www.fishman.com
009-087-002 3-98
LIMITED WARRANTY
