Fisher-Price ROCKET 77807 Instructions d'installation

Model Numbers: 77806, 77807, 77808

COMMAND

MANUAL

ROCKET

™

THE WONDER DOG

COMMAND

MANUAL

Out of thisWorld

TA LE OF CONTENTS

From out of this world...and into your home. . . . . . . .2-3

Rocket™The Wonder Dog . . . . . . . . . . . . . . . . . . . .4-5

Trainer in Training (3+ Years) . . . . . . . . . . . . . . . . . .6-7

Expert Trainer (6+ Years) . . . . . . . . . . . . . . . . . . . .8-15

Just for Fun! . . . . . . . . . . . . . . . . . . . . . . . . . . . .16-17

Alkaline Batteries . . . . . . . . . . . . . . . . . . . . . . . . .18-19

Caring for Rocket™. . . . . . . . . . . . . . . . . . . . . . . . . .20

Before You Call Us . . . . . . . . . . . . . . . . . . . . . . . . . .21

Consumer Information . . . . . . . . . . . . . . . . . . . . . . . .24

FCC Note (United States Only) . . . . . . . . . . . . . . . .25

ICES Statement (Canada Only) . . . . . . . . . . . . . . . . .25

Warranties . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26-27

Certificate of Pedigree . . . . . . . . . . . . . . . . . . .29 & 31

JUST CAN’T WAIT ???

Follow these simple instructions to try out

Rocket™The Wonder Dog!

1. Install alkaline batteries in the P.P.T. and the dog.

Refer to pages 18-19.

2. Fit the remote headset on your child’s head, with the

microphone toward your child’s mouth.

3. Open the large cover on the P.P.T.

4. Slide the dog’s Power Switch (on his belly) to the

ON ●position.

5. With the glowing L.E.D. on the dog’s head lit, press a

Command Button on the P.P.T.

6. Then, have your child speak the command into the

remote headset microphone and watch Rocket™go

into action!

To learn how to properly use Rocket™The Wonder

Dog, please read through this entire manual carefully.

FROM OUT OF THIS WORLD...

Way, way out in the Milky-Bone Galaxy, beyond

the Canine Comets and the famous Dog Star and

even Pluto, there’s a world of friendly creatures

known as the Planet Rrruff. Here, everyone romps

and runs, sits up and begs, curls up

and sleeps, and of course, wags

their tails. They do a lot of licking.

But mostly they like to play. Every-

one’s favorite friend was RocketTM.

Each day, other Rrruffians would

come over and beg him to play. RocketTM would roll

his eyes patiently, scratch a little, shake and wag his

tail. Then he would trot along to join his friends in

a game of Tag or Rrred Rrrover or Who’s Got the

Biscuit? But RocketTM thought there must be more to

life. When night came, he would gaze out at the

stars and wonder.”I wonder what else is out there?”

“I wonder why stars sparkle?” “I wonder what it’s

like to have someone love you?” Then RocketTM

would walk around in a circle three times, lie down

and sleep soundly until morning.

One day, just as the sun came up, RocketTM

perked up his ears and sniffed all around. Something

was different. Strange. New and wonderful. RocketTM

followed his nose to see where it would lead. His

nose led him uphill and down, over the Slow Rrriver,

through the Rrredwood Forest and right to the edge

of the Rrred Sea. Sitting there, sparkling in the sun,

was the strangest contraption RocketTM had

ever seen!

2K9

...AND INTO YOUR HOME.

“Bow-WOW!” RocketTM barked in wonder as he

bounded through the opening of the shiny machine.

“It looks like a dog house made of silvery stars! And

look at all the neat buttons.” Being the wondering

dog he was, RocketTM started pushing those buttons

with his left paw. He was so curious about the

flashing lights and whirring sounds, he didn’t even

notice the door sliding closed behind him. But he

did notice when the contraption started to move.

Up it flew, soaring into the sky, carrying

RocketTM away from the Planet Rrruff and through

the Milky-Bone Galaxy, past the Dog Star and the

Canine Comets and even Pluto, rocketing him

toward a new world full of exciting new adventures.

“I wonder what it will be like...”

wondered RocketTM.

YOUR OWN WONDER DOG

Remote

Headset

Dog

Personal

Puppy Trainer

(P.P.T.)

Command L.E.D.

(Glows)

Large Cover

Power L.E.D.

(Glows)

Program Switch Door

Trainer 1Play ★Trainer 2

Name Button N

Erase All Hole

Command

Buttons

(See page 5)

Power

Switch

Treat

Microphone

L.E.D.

Sit

Lie Down

Shake Hands

Do Trick

Let’s Go

Stand Up

Beg

Speak

Bad Puppy

START

Your child or children can

interact with the dog in two

different modes, depending

on their age: Trainer in

Training (3+ years) or Expert

Trainer (6+ years). Choose

which mode you’d like to start!

Trainer in Training (3+ Years)

Open the P.P.T. Large Cover for this

mode.Your child wears the remote

headset and uses the P.P.T. with the

Large Cover open. Your child simply

presses the desired Command

Button on the P.P.T., speaks into

the headset and your dog goes

into action!

Expert Trainer (6+ Years)

Close the P.P.T. Large Cover for this

mode. Your child wears the remote

headset and programs (records) a

new name and voice commands into

the P.P.T. There’s no need to use the

Command Buttons on the P.P.T. (after

programming it) in this advanced

mode, so keep the Large Cover

closed! Your child speaks the pro-

grammed name and voice commands

into the headset. Watch your dog

perform the desired command!

The P.P.T. can recognize up

to two master’s voices – so no

one’s left out. Simply slide the

Program Switch to Trainer 1

to program one child’s voice.

Then, slide the Program

Switch to Trainer 2 to program

another child’s voice.

Power

Switch

Important!

Make sure the L.E.D. on

the microphone points

away from

your child’s

mouth and

toward the

glowing

L.E.D. on the

dog’s head.

TRAINER IN TRAINING (3+ YEARS)

• Fit the remote headset on your child’s head. Be sure

to place the microphone (on the mouthpiece) about

/2"- 2" from your child’s mouth (not too close or far

away). Make sure the L.E.D. on the mouthpiece points

toward the glowing L.E.D. on the dog’s head.

• Hook the P.P.T. to your child using the convenient

belt clip.

• Open the Program Switch Door on the P.P.T. and select

Play ★. Close the Program Switch Door. You’re in

Trainer in Training Mode.

• Slide the dog’s Power Switch

(on his belly) to the ON ●

position. The dog needs to

wake up (about 15 seconds).

Important!

To conserve battery life,

we recommend that you

slide the dog's Power

Switch to the OFF

position when your child

is not playing with the dog.

To turn off power on the

P.P.T., press and hold the

Large Cover closed for five

seconds. The power L.E.D.

will shut off.

TRAINER IN TRAINING (3+ YEARS)

• Open the Large Cover on the P.P.T.

• Make sure the glowing L.E.D. on the dog’s head is lit.

• Press a Command Button (try ) on the P.P.T.

• Your child must speak into the microphone.

Your child says: “Sit.”

• Make sure your child waits until the glowing L.E.D. on

the dog’s head is lit before pressing another Command

Button. If your child presses a Command Button on

the P.P.T. before the glowing L.E.D. lights, the dog

ignores the command and may do something different.

Hint

If the dog does not

receive another command

after approximately two

minutes, the dog will

automatically go to sleep

(shut-off). To turn back

on, simply pat the

dog’s back.

Hint

If the dog ignores

the command, he may

surprise you with his

response!

Hint

Your child must speak into

the microphone within

three seconds of pressing

a Command Button. Also,

any word will do!

Programming a New Name

• Have your child choose a new name for the dog. Practice

saying the dog’s new name–speaking clearly and in a

normal voice (not too loud or soft). When playing with the

dog, your child needs to say the dog’s new name the

same way it is programmed (recorded).

• Fit the remote headset on your child’s head. Be sure to

place the microphone (on the mouthpiece) about 11

/2"- 2"

from your child’s mouth (not too close or far away).

• Slide the dog’s Power Switch (on his belly) to the

OFF Oposition. The dog is not needed for programming.

• Open the Program Switch Door. Slide the Program

Switch to Trainer 1or Trainer 2. Make sure you take

note of which master’s voice is programmed on

Trainer 1and on Trainer 2.

• Press the Name Button .

• Listen for the voice prompt through remote headset.

“Please say your dog’s name.”

• Now, it’s your child’s turn to say the dog’s name.

Your child says: “Rocket.”

Important!

Your child must choose

a quiet room to program

(record a voice) the P.P.T.

Hint

Your child can choose a

new name...be creative!

Hint

The dog can have two

masters (and two names)

simply by sliding the Pro-

gram Switch to Trainer 1

for the first child and then

Trainer 2for a second child.

Make sure the second

child (Trainer 2) picks a

different name for the

dog than the first child,

Trainer 1.

EXPERT TRAINER (6+YEARS)
