Fisher Engineering Minute Mount 2 Manuel utilisateur
OWNER'S MANUAL
Original Instructions
June 15, 2022
Lit. No. 41780, Rev. 03
This manual supersedes all editions with an earlier date.
CAUTION
Read this document before operating or servicing snowplow.
Lit. No. 41780, Rev. 03 3 June 15, 2022
SNOWPLOW OWNER DATA SHEET
Register your snowplow online at www.sherplows.com
Owner Name: ________________________________________________________________________
Date Purchased: ______________________________________________________________________
Dealer Name: ___________________________________________ Phone: ______________________
Dealer Address: ______________________________________________________________________
Vehicle Model/Year: ___________________________________________________________________
Snowplow Model/Year: _________________________________________________________________
Snowplow Type/Size: ___________________________________________ Weight: ___________ lb/kg
Ballast: No ___ Yes ___ Amount____________lb/kg
Insta‑Act®Hydraulic Unit Serial Number: ___________________________________________________
Blade Serial Number (located above Warning/Caution label): ___________________________________
Lit. No. 41780, Rev. 03 5 June 15, 2022
TABLE OF CONTENTS
Snowplow Owner Data Sheet ...............................3
Preface ..................................................................7
Safety ....................................................................8
Vehicle Application Information...........................15
Ballast Requirements .......................................16
Getting to Know Your Snowplow.........................17
Minute Mount®2 System..................................17
Mount Kits ........................................................18
INTENSIFIRE™ Snowplow Headlamps...........18
Cab Controls ....................................................19
Straight Blade Controls.................................20
XtremeV™/XV2™/XLS™ Controls...............21
Accessories and Options ................................... 22
Attaching Snowplow to Vehicle ...........................25
Operating Your Snowplow.................................. 29
Controls........................................................... 29
Straight Blade Hand‑Held Control ............... 29
Straight Blade Joystick Control.....................32
XtremeV/XV2/XLS Hand‑Held Control ....... 36
XtremeV/XV2/XLS Joystick Control ............ 40
FLEET FLEX Electrical System ................... 45
SECURITY GUARD™ System ................. 46
Smooth Stop/Soft Stop ............................. 50
One ‑Touch FLOAT .....................................51
XtremeV Blade Positions .................................52
XV2 Blade Positions ...............................55
XLS Blade Positions........................................ 58
Snowplow Headlamp Check ............................61
Anti‑Wear Shoe Adjustment.............................62
Hydraulic System ............................................ 64
Blade Drop Speed Adjustment........................ 65
Scrape Lock Adjustment – HT Series™.......... 66
Transporting Snowplow................................... 69
Driving and Plowing on Snow and Ice .............70
Plowing Snow...................................................71
General Instructions......................................72
Hard‑Packed Snow.......................................72
Deep Snow ...................................................72
Clearing Driveways .......................................73
Clearing Parking Lots ...................................74
Parking with Snowplow Attached.....................74
Towing Disabled or Stuck Vehicle....................74
Lit. No. 41780, Rev. 03 6 June 15, 2022
Detaching Snowplow from Vehicle
and Storage .......................................................75
Maintenance....................................................... 80
Maintenance Videos ....................................... 80
Preseason Check............................................ 80
In‑Season Maintenance...................................81
Postseason Maintenance.................................82
XtremeV™/XV2™ Cutting Edge Wear and
Leveling Adjustment Procedure..................... 83
Greasing XV2 Pivot Pin Hinge ........................ 84
Aiming Headlamp Beams................................ 85
Hydraulic System .............................................87
Fluid Level.....................................................87
Annual Fluid Change ................................... 89
Hose Routing.............................................91
Air Removal ............................................. 94
Hose or Fitting Replacement ........................97
Installing Hydraulic Fittings and Hoses........ 98
Fuse Replacement .......................................... 99
Snowplow Vehicle Battery Best Practices .....100
Vehicle............................................................101
Recycle ..........................................................101
Emergency Parts/Tools..................................102
Troubleshooting..............................................102
Harness Diagram – 3‑Port, 2‑Plug System.......103
...................................104
.......107
TABLE OF CONTENTS
Lit. No. 41780, Rev. 03 7 June 15, 2022
PREFACE
This manual has been prepared to acquaint
you with the safety information, operation, and
maintenance of your new FISHER®snowplow.
Please read this manual carefully and follow all
recommendations.
Before installing a snowplow, make sure that
your vehicle is equipped with all the vehicle
manufacturer's and our required options for
trouble‑free operation of your snowplow. Keep this
manual accessible. It is a handy reference in case
minor service is required.
Your FISHER snowplow Insta‑Act®hydraulic unit
and blade both have a serial number. Record
these serial numbers on the Snowplow Owner
Data Sheet at the front of this manual to refer to
when necessary.
When service is necessary, bring your snowplow
to your local FISHER outlet. They know your
snowplow best and are interested in your
complete satisfaction.
The illustrations found in this manual represent
typical components. They may not match your
exact installation.
Most of the information in this Owner's Manual
applies to all Minute Mount®2 applications.
XtremeV™, XV2™, and XLS™ applications are
called out in the text or under separate headings,
as applicable.
Lit. No. 41780, Rev. 03 8 June 15, 2022
WARNING/CAUTION & INSTRUCTION
LABELS
Become familiar with and inform users about the
warning/caution and serial number labels on the
back of the blade and the instruction label on the
headgear.
NOTE: If labels are missing or cannot be read,
see your sales outlet.
SAFETY
SAFETY DEFINITIONS
NOTE: Indicates a situation or action that can
lead to damage to your snowplow and vehicle
or other property. Other useful information
can also be described.
WARNING
Indicates a potentially hazardous
situation, that if not avoided, could result
in death or serious personal injury.
CAUTION
Indicates a potentially hazardous situation
that, if not avoided, may result in minor
or moderate injury. It may also be used to
alert against unsafe practices.
Lit. No. 41780, Rev. 03 9 June 15, 2022
SAFETY
Instruction Labels Warning/Caution Label
XL
S™ Blades
Only
(both sides)
Multiple Pinch
Points Label
or
Lit. No. 41780, Rev. 03 10 June 15, 2022
SAFETY
Code Denition
YY 2‑Digit Year
MM 2‑Digit Month
DD 2‑Digit Day
LL 2‑Digit Location Code
XXXX 4‑Digit Sequential Number
ZZZZZZ 5‑ or 6‑Digit Blade Assembly PN
YYMMDDLLXXXXZZZZZ
ZZZZZ
zzzzz YYMMDDLLXXXXZZZZZ
Serial Number Label
Lit. No. 41780, Rev. 03 11 June 15, 2022
SAFETY
SAFETY PRECAUTIONS
Improper installation and operation could cause
personal injury and/or equipment and property
damage. Read and understand labels and the
Owner's Manual before installing, operating, or
making adjustments.
WARNING
Lower the blade when the vehicle is
parked. Temperature changes could
change hydraulic pressure, causing the
blade to drop unexpectedly or damaging
hydraulic components. Failure to do this
could result in serious personal injury.
WARNING
Remove blade assembly before placing
vehicle on hoist.
CAUTION
Read Owner's Manual before operating or
servicing snowplow.
WARNING
Do not exceed GVWR or GAWR
including the blade and ballast.
The rating label is found on the
driver-side vehicle door
cornerpost.
CAUTION
Plowing speed should not exceed 10 mph
(16 km/h).
CAUTION
See your FISHER®outlet for application
recommendations.
CAUTION
Transport speed should not exceed
45 mph (72 km/h). Further reduce speed
under adverse travel conditions.
