Fisher & Paykel DE09 Manuel technique

500A277P046

Use and Care

With Installation Instructions

We care about our environment

RECYCLED PAPER

RECYCLABLE

Read this book carefully.

It is intended to help you operate and

maintain your new dryer properly.

Keep it handy for answers to your

questions.

If you don’t understand something or

need more help, write (include your

phone number)

Consumer Relations Manager

Camco Inc.

1 Factory Lane, Suite 310

Moncton, N.B. E1C 9M3

Save time and money.

Before you request service...

check the Problem Solver section, it

lists causes of minor operating

problems that you can correct

yourself.

If you received a

damaged dryer...

Immediately contact the dealer (or

builder) that sold you the dryer.

Write down the model

and serial numbers.

You’ll find them on a label on the

front of the dryer behind the door.

These numbers are also on the

Consumer Product Ownership

Registration Card that came with

your dryer. Before sending in this

card, please write these numbers

here:

Model Number

Serial Number

Use these numbers in any

correspondence or service calls

concerning your dryer.

WARNING: For your safety the information in this manual must be followed to minimize the

risk of fire or explosion or to prevent property damage, personal injury or death.

– Do not store or use gasoline or other

flammable vapors and liquids in the vicinity

of this or any other appliance.

– WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch;

do not use any phone in your building.

• Clear the room, building or area of all

occupants.

• Immediately call your gas supplier from a

neighbor’s phone. Follow the gas supplier’s

instructions.

• If you cannot reach your gas supplier, call

the fire department.

– Installation and service must be performed

by a qualified installer, service agency, or the

gas supplier.

Safety Instructions................... 3, 4

Installation Instructions

Exhaust.........................................................6, 7

Electric Dryer ...................................................8

Gas Dryer .....................................................8, 9

Reversible Door Instructions .......................5

Operating Instructions, Tips

utomatic Drying ........................................13

Drying Selection Guide.......................12, 13

Electronic Sensor Control..........................13

Extra Care Program..............................10, 12

Knits Drying Tips ..................................11, 12

Lint Filter ........................................................11

Loading ...................................................11, 15

Operating the Dryer..............10, 11, 12, 13

Permanent Press

Drying Tips .........................................11, 15

Sorting Clothes .....................................11, 12

Special Instructions.....................................12

Timed Drying.........................................12, 13

End Cycle Signal ..........................................10

Care and Cleaning

Dryer Exhaust ...............................................14

Exterior ...........................................................11

Light Bulb Replacement.............................13

Lint Filter ........................................................11

Problem Solver ............................. 15

Consumer Services

Model and Serial Numbers..........................2

Repair Service .................................................2

Warranty ........................................................16

Warning - It is extremely important that you read and adhere to the

following instructions. Failure to do so could cause bodily injuries

and / or property damage due to fire.

Important Safety Instructions

IMPORTANT SAFETY INSTRUCTIONS

Read all instructions before using this appliance

• Use this appliance only for its intended purpose

as described in this Use and Care Book.

This dryer must be properly installed

and located in accordance with the

Installation Instructions before it is used.

– Properly ground to conform with Local Codes.

Follow details in Installation Instructions.

– Locate where the temperature is above 50˚F.

(10˚C.) for satisfactory operation of the dryer

control system. Do not install or store the dryer

where it will be exposed to the weather.

– Connect to a properly rated, protected and sized

power supply circuit to avoid electrical overload.

– Exhausting to the outside is STRONGLY

RECOMMENDED to prevent large amounts of

moisture and lint from being blown into the room.

Carefully follow the Exhausting Details in the

Installation Instructions.

Do not repair or replace any part of the

appliance or attempt any servicing

unless specifically recommended in this

Use and Care Book or in published user-repair

instructions that you understand and have the

skills to carry out.

When disconnecting this appliance

pull by the plug rather than the cord

to avoid damage to the cord or junction

of cord and plug. Make sure that the cord

is located so that it will not be stepped on, tripped

over or otherwise subjected to damage or stress.

To Minimize the Possibility of a

Fire Hazard

• Exhaust Duct – See Installation Instructions. Use

only rigid metal or flexible metal 4” diameter

ductwork for exhausting to the outside. USE OF

PLASTIC OR OTHER COMBUSTIBLE

DUCTWORK CAN CAUSE A FIRE. FOIL OR

OTHER EASILY PUNCTURED DUCTWORK

CAN CAUSE A FIRE IF IT COLLAPSES OR

BECOMES OTHERWISE RESTRICTED IN USE

OR DURING INSTALLATION.

•Do not use heat to dry articles containing rubber,

plastic, or similar materials (such as padded bras,

tennis shoes, galoshes, bath mats, rugs, bibs, pillows,

baby pants, plastic bags, etc.) as these materials may

melt or burn. Also, some rubber materials, when

heated, can under certain circumstances produce fire

by spontaneous combustion.

• Do not store items that may burn or melt (such as

clothing, paper material, plastics or plastic

containers, etc.) on top of the dryer during the

operation.

•Garments labeled “Dry Away from Heat” (such

as life jackets containing Kapok or foam) must

not be put in your dryer.

• Do not wash or dry articles that

have been cleaned in, washed in,

soaked in, or spotted with combustible

or explosive substances (such as wax,

paint, gasoline degreasers, dry-

cleaning solvents, kerosene, etc.) which may ignite

or explode. Do not add these substances to the

wash water. Do not use these substances around

your washer and/or dryer during operation.

• Any article on which you have used a cleaning

solvent, or which contains flammable materials (such

as cleaning cloths, mops, towels used in beauty

salons, restaurants or barber shops, etc.) must not be

placed in or near the dryer until all traces of these

flammable liquids or solids and their fumes have

been removed. There are many highly flammable

items used in homes such as: acetone, denatured

alcohol, gasoline, kerosene, some household

cleaners, some spot removers, turpentines, waxes,

wax removers and products containing petroleum

distillates.

(continued on next page)

•Clean the lint filter before each load

to prevent lint accumulation inside

the dryer or in the room.

DO NOT OPERATE THE DRYER

WITHOUT THE LINT FILTER IN

PLACE.

•Keep the area around and underneath your

appliances free from the accumulation of

combustible materials, such as lint, paper, rags,

chemicals, etc.

• Regularly inspect the exhaust duct to be sure it

has not been crushed or otherwise restricted.

• The interior of the dryer cabinet and the exhaust

duct connection inside the dryer should be cleaned

every 2 to 3 years, or more often if needed, by a

qualified service person. (see Care & Cleaning

section)

To Minimize the Possibility of Injury

• Never reach into the dryer while the drum is

moving. Before loading, unloading or adding clothes,

wait until the drum has completely stopped.

•Do not dry fiberglass articles in your dryer. Skin

irritation could result from the remaining glass

particles that may be picked up by clothing during

subsequent dryer uses.

• The laundry process can reduce the

flame retardance of fabrics. To avoid

such a result, the garment manufacturer’s

care instructions should be followed very

carefully.

• Close supervision is necessary if this

appliance is used by or near children.

Do not allow children to play inside,

on, or with this appliance or any

discarded appliance. Dispose of

discarded appliances and shipping or

packing materials properly. Before discarding a

dryer, or removing from service, remove the door

of the dryer compartment.

SAVE THESE

INSTRUCTIONS

• Keep all laundry aids (such as

detergents, bleaches, fabric softeners,

etc.) out of the reach of children,

preferably in a locked cabinet. Observe

all warnings on container labels to avoid

personal injury.

•Keep the floor around your appliances clean and

dry to reduce the possibility of slipping.

•To minimize the possibility of electric shock,

unplug this appliance from the power

supply before attempting any maintenance

or cleaning (except the removal and

cleaning of the lint filter).

• NOTE: Turning the Cycle Selector

knob to an OFF position does NOT

disconnect the appliance from the power

supply.

•Do not tamper with the controls.

•Do not operate this appliance if it is damaged,

malfunctioning, partially disassembled, or has

missing or broken parts, including a damaged

cord or plug.

•Never climb on or stand on the dryer top.

•DO NOT place items exposed to cooking oils in

your dryer. Items contaminated with cooking oils

may contribute to a chemical reaction that could

cause a clothes load to catch fire.

•If yours is a gas dryer, it is equipped with an

automatic electric ignition and does not have a

pilot light. DO NOT ATTEMPT TO LIGHT WITH A

MATCH. Burns may result from having your hand in

the vicinity of the burner when the automatic ignition

may turn on.

Dryer-applied Fabric Softeners or

Anti-static Conditioners

You may wish to soften your laundered fabrics or

reduce the static electricity in them. We recommend

you use either a fabric softener in the wash cycle,

according to the manufacturer’s instructions for those

products, or try a dryer-added product for which the

manufacturer gives written assurance on the package

that their product can be safely used in your dryer.

Service or performance problems caused by the use of

these products are the responsibility of the

manufacturers of those products and are not covered

under the warranty of this appliance.

IMPORTANT SAFETY INSTRUCTIONS

REVERSIBLE DOOR INSTRUCTIONS

These instructions are for changing the hinges from the

right side to the left side. If you need to change the hinges from the left side to

the right side, follow these same instructions (merely

reverse all references to the left and right).

Tools Needed

Standard #2 Phillips screwdriver

DRYER DOOR

1. Open the door and remove the filler plugs opposite the

hinges.

(A tape-tipped putty knife

or a needle-nosed plier

will help to remove the

plugs. Be careful not to

damage the paint.)

2. With the door completely

open, remove the bottom

screw attaching each hinge

to the dryer front. (Do not

remove the screws located

on the door itself).

3. Insert these screws about half way into the top holes,

for each hinge, on the opposite side (where you

removed the filler plugs).

4. Loosen the remaining top screw

from each hinge on the dryer front,

half way.

5. With one hand holding

the top of the door, and

the other hand holding

the bottom, remove the

door from the dryer

front by lifting it UP

and OUT.

6. Rotate the door 180˚.

Insert it on the opposite

door frame by moving the

door IN and DOWN until

the top hinge and the

bottom hinge are resting on

the top screws inserted in

step 3.

7. With the other screws, secure

each hinge at the bottom.

8. Tighten the top screws of each

hinge.

9. Reinsert the plastic plugs on the side from which the

door was removed.

Reversible Door Instructions

Installation and service must be performed by a qualified installer, service agency or the gas supplier.

IMPORTANT: Have your dryer installed properly.

NOTE: The WARNING and IMPORTANT instructions appearing in this manual are not meant to cover all

possible conditions and situations that may occur. It must be understood that common sense, caution, and

carefulness are factors that CANNOT be built into the dryer. These factors MUST BE supplied by the person(s)

installing, maintaining, or operating the dryer.

Failure to install, maintain, and/or operate this machine according to the manufacturer’s instructions may result in

conditions which can produce bodily injury and/or property damage.

This dryer comes ready for rear exhausting (see Fig. 1).

WARNINGS

• DO NOT USE NON METALLIC FLEXIBLE DUCT.

• Never use flexible duct inside the dryer.

• Do not terminate exhaust in a chimney, range hood,

gas vent, floor or attic. The combination of lint and

grease could create a fire hazard or damages.

• Provide an access for inspection and cleaning the

exhaust system at least once a year. (See Care and

Cleaning Section.)

EXHAUST LENGTH

The MAXIMUM ALLOWABLE length of the exhaust

system depends upon the type of duct, number of turns,

the type of exhaust hood (wall cap), and all conditions

noted below. The maximum allowable length for both

rigid and flexible metal duct is shown in the table 1

(next page). More than four 90˚ turns is not

recommended.

EXHAUST SYSTEM CHECK LIST

HOOD or WALL CAP

• Terminate in a manner to prevent back drafts or entry

of birds or other wildlife.

• Termination should present minimal resistance to the

exhaust air flow and should require little or no

maintenance to prevent clogging.

• Wall caps must be installed at least 300 mm (12”)

above ground level or any other obstruction with the

opening pointed down.

• If roof vents or louvered plenums are used, they must

be equivalent to a 100 mm (4”) dampered wall cap in

regard to resistance to air flow, prevention of back

drafts and maintenance required to prevent clogging.

SEPARATION OF TURNS

Separate all turns by at least 1 m (3 ft.) of straight duct,

including distance between last turn and dampered wall

cap. If two turns must be closer than 1 m (3 ft.) deduct

3 m (10 ft.) from the maximum lengths shown in the

table for each occurrence.

TURNS OTHER THAN 90˚

• One turn of 45˚ or less may be ignored.

• Two 45˚ turns should be treated as one 90˚.

• Each turn over 45˚ should be treated as one 90˚.

SEALING OF JOINTS

• All joints should be tight to avoid leaks. The male

end of each section of duct must point away from the

dryer.

• Do not assemble the duct work with fasteners that

extend into the duct. They will serve as a collection

point for lint.

• Duct joints can be made air and moisture-tight by

wrapping the overlapped joints with duct tape.

INSULATION

• Duct work which runs through an unheated area or is

near an air conditioning duct, should be insulated to

reduce condensation and lint build up and be sloped

down toward outdoors.

NOTE: Never install screen inside exhaust duct.

CAUTION: THE DRYER MUST EXHAUST TO

THE OUTDOORS.

INSTALLATION INSTRUCTIONS

EXHAUST

298mm

(11 3/4")

91mm

(3 1/2")

NOTE: ADD TO

91mm (31/2")

THE DISTANCE

BETWEEN

CABINET BOTTOM

TO FLOOR SURFACE

Installation Instructions

INSTALLATION INSTRUCTIONS

EXHAUST

ALTERNATE EXHAUST DIRECTIONS

This dryer comes ready for rear exhausting. If space is limited, use the following instructions to exhaust

directly from the side or bottom of the cabinet.

GAS DRYER CAN NOT BE EXHAUSTED DIRECTLY THROUGH THE RIGHT SIDE OF THE CABINET.

WARNING: Protect your hands and arms when working inside the cabinet.

• Never use flexible duct inside dryer.

• Detach and remove the desired knockout.

• Remove the screw inside the dryer exhaust duct end.

Pull on the duct to remove it. Keep the screw for

later.

• Cut the duct as shown, 229 mm (9 inches).

Keep portion A.

• Through the rear

opening, locate the

tab in the middle of

the appliance base.

Lift the tab to about

45˚ using a flat

screwdriver.

• Reconnect and secure the cut portion (A) of the duct

to the blower housing. Make sure that the fixing

hole is aligned with the tab in the base. Use the

reserved screw to secure the duct in place through

the tab on the appliance base.

• Use a standard and ajustable metal elbow and a

metal straight duct to exhaust the dryer through the

knockout choosen. Insert standard elbow and ducts

through rear and side or bottom openings.

• Use only 100 mm (4 inch) diameter rigid metallic

duct.

• Cover the opening at the back with the plate (Kit

WE1M454) available from your Local Service

Provider.

WARNING: Never leave the opening at the back

without the plate.

Table 1: RECOMMENDED MAXIMUM LENGTH

ELECTRIC DRYERS GAS DRYERS

Weather Hood Type Weather Hood Type

Recommended Use only for short

run installations Recommended Use only for short

run installations

No. of 90˚

elbows Rigid Metallic

Flexible* Rigid Metallic

Flexible*

27.4 m (90 ft.)

18.3 m (60 ft.)

13.7 m (45 ft.)

10.7 m (35 ft.)

7.6 m (25 ft.)

16.8 m (55 ft.)

12.2 m (40 ft.)

9.1 m (30 ft.)

6.1 m (20 ft.)

4.6 m (15 ft.)

18.3 m (60 ft.)

13.7 m (45 ft.)

10.7 m ( 35 ft.)

7.6 m (25 ft.)

4.6 m (15 ft.)

13.7 m (45 ft.)

9.1 m (30 ft.)

6.1 m (20 ft.)

4.6 m (15 ft.)

3.0 m (10 ft.)

13.7 m (45 ft.)

10.7 m (35 ft.)

7.6 m (25 ft.)

4.6 m (15 ft.)

–

9.1 m (30 ft.)

6.1 m (20 ft.)

3.0 m (10 ft.)

–

9.1 m (30 ft.)

6.1 m (20 ft.)

3.0 m (10 ft.)

–

4.6 m (15 ft.)

3.0 m (10 ft.)

–

* Do not use non metallic flexible duct.

INSTALLATION

IMPORTANT - OBSERVE ALL GOVERNING CODES

Dryer must be levelled and rest firmly on the floor.

SPECIAL INSTALLATION REQUIREMENTS

ALCOVE OR CLOSET INSTALLATION

• The dryer MUST be exhausted to the outdoor. See

EXHAUST INFORMATION section.

• Minimum clearances between dryer cabinet and

adjacent walls or other surfaces are:

0 mm (0”) either side

76 mm (3”) front and rear

• Minimum vertical space from floor to overhead

cabinets, ceilings, etc. is 132 cm (52”).

NOTE: CONSIDERATION MUST BE GIVEN TO

INSTALLING AND SERVICING THE APPLIANCE.

• Closet door must be louvered or otherwise ventilated

and must contain a minimum of 387 cm2(60 in2) of

open area equally distributed. If this closet contains

both a washer and a dryer, doors must contain a

minimum of 774 cm2(120 in2) of open area equally

distributed.

• If yours is a gas dryer, the closet should be vented to

the outdoors to prevent gas pocketing in case of a gas

leak in the supply line.

• No other fuel-burning appliance shall be installed in

the same closet with the dryer.

MINIMUM CLEARANCES OTHER THAN

ALCOVE OR CLOSET INSTALLATIONS.

• Minimum clearances to combustible surfaces and for

air opening:

0 clearance both sides and 25 mm (1”) rear.

MOBILE HOME INSTALLATION

• The dryer must be exhausted to the outdoors with the

termination securely fastened to the mobile home

structure. (See EXHAUST INFORMATION section.)

• The exhaust MUST NOT be terminated beneath the

mobile home.

• The exhaust MUST NOT be connected to any other

duct, vent and chimney.

• Provisions must be made for the introduction of

outside air into the dryer room. The free air opening

shall not be less than 160 cm2(25 in2).

• The exhaust duct material MUST BE METAL.

• Do not connect the exhaust duct with sheet metal

screws or other fastening devices which extend to the

interior of the duct.

• The dryer must be attached to the floor following

instructions available from the dealer.

• Installation must comply with the current CAN/CSA

Z240 MH series Mobile Home Installation Codes.

NOTE: CONSIDERATION MUST BE GIVEN TO

INSTALLING AND SERVICING THE APPLIANCE.

LEVELING THE DRYER

Adjust all 4 leveling legs to match washer height. Dryer

MUST BE LEVEL and rest firmly on all 4 leveling

legs.

DUCT LENGTH

For maximum performance, refer to table for maximum allowable length of exhaust system (Exhaust section).

ELECTRICAL POWER SUPPLY

CAUTION: NEVER USE AN EXTENSION CORD WITH THIS APPLIANCE.

Note: If the electrical power supply provided does not meet the specifications listed below, call a licensed electrician.

FOR ELECTRIC DRYERS, POWER SUPPLY...

1. Must be of 120/240 volts or 120/208 volts, 60 Hz

circuit with wall receptacle as

shown beside.

2. Must be protected with 30A

FUSES OR BREAKERS.

3. Must be WELL GROUNDED.

4. Must CONFORM TO LOCAL

CODES.

FOR GAS DRYERS, POWER SUPPLY...

1. Must be of 120 volts, 60 Hz

circuit with wall receptacle as

shown beside.

2. Must be protected with 15 or

20A FUSES OR BREAKER.

3. Must be WELL GROUNDED.

4. Installation must be in accordance

with the current CSA C22.1 Canadian Electrical code

part 1 and/or local codes.

4 LEVELING

LEGS

SIDE

VIEW

Installation Instructions

INSTALLATION – GAS DRYER

IMPORTANT - OBSERVE ALL GOVERNING CODES

Dryer must be levelled and rest firmly on the floor.

Dryer must be exhausted to the outdoors.

FOR YOUR SAFETY

What to do if you smell gas

• Do not try to light appliance.

• Do not touch any electrical switch ; do not use

any phone in your building.

• Clear the room, building or area of all occupants.

• Immediately call your gas supplier from a

neighbor’s phone. Follow the gas supplier’s

instructions.

• If you can not reach your gas supplier, call fire

department.

• Installation and service must be performed by

a qualified installer, service agency, or the gas

supplier.

FOR YOUR SAFETY

Do not store or use gasoline or

other flammable vapors and

liquids in the vicinity of this or

any other appliance.

GAS CONNECTION INFORMATION

Installation must conform with local Gas Codes and

with CAN/CGA-B149, Natural Gas Installation Code.

Some local codes restrict installation of gas appliances

in garages. They must be 45 cm (18”) off the ground

and protected by a barrier from vehicules.

GAS BURNER ORIFICE

This gas dryer is equipped with a Valve & Burner

Assembly for use ONLY WITH ONE TYPE OF GAS.

Using the appropriate kit, your local service

organization can convert this dryer for use with the

alternate fuel.

Use kit WE25M35 to convert from Natural Gas to LP

Gases (Propane).

Use kit WE25M36 to convert from LP Gases to Natural

Gas.

WARNING: CONVERSION SHALL BE CARRIED

OUT IN ACCORDANCE WITH THE

REQUIREMENTS OF THE PROVINCIAL

AUTHORITIES HAVING JURISDICTION AND/OR

ACCORDANCE WITH THE REQUIREMENTS OF

THE CAN/CGA B149.1 AND B149.2

INSTALLATION CODE.

GAS SUPPLY

• Supply line is to be 12.7 mm (1/2 in) rigid pipe.

(9.53 mm (3/8 in) copper tubing may be used if the

dryer is operated on propane gas) and equipped with

an accessible shutoff within 6 feet (2 m) from, and in

the same room with the dryer. Increase pipe size for

runs longer than 20 feet (7 m).

• During pressure test:

– When test pressure is in excess of 1/2 PSIG

(3.45kPa), disconnect dryer and its individual

shutoff valve from gas supply line prior to test.

– When test pressure is equal to or less than 1/2 PSIG

(3.45kPa), close the dryer shutoff valve prior to test.

• A 3.18 mm (1/8 in) National Pipe Taper thread

plugged tapping, accessible for test gauge connection,

must be installed immediately upstream of the gas

supply connection to the dryer. Contact your local gas

utility should you have questions on the installation of

the plugged tapping.

• Pipe dope must be resistant to the action of propane

and applied sparingly to all male threads.

• If local codes permit, it is recommended the dryer be

connected to the gas supply with approved semi-rigid

metal tubing or listed connectors.

LEAK TEST

Check all connections for leaks with soapy solution or

equivalent. Leak test solutions must not contain ammonia

which could cause damage to brass fittings or pipe.

CAUTION: NEVER USE AN OPEN FLAME TO

TEST FOR GAS LEAKS.

51mm

(2")

66 mm

(2 5/8")

MALE THREAD GAS SUPPLY

9.52 mm (3/8")

OPERATING YOUR DRYER

WARNING – To reduce the risk of fire, electric shock, or injury to persons

when using your appliance read the IMPORTANT SAFETY INSTRUCTIONS

before operating this appliance.

Drying Selections. Select the proper heat on the Fabric

Care selector for your load.

NOTE: Drying times will vary according to the type of

heat used (Electric, Natural gas or LP gas), size of load,

types of fabrics, wetness of clothes, and condition of

exhaust ducts.

*Fluff-No Heat option can be used with an automatic cycle, but for best

performance it is recommended to be used with a timed cycle.

Cycle Selector. Turn the Cycle Selector to the desired

cycle setting. The selector may be turned in either

direction.

Press Guard Cycle. (Available on some models.)

The Press Guard cycle operates only with the

Automatic Permanent Press and Automatic Cottons

cycles. Turn the Press Guard knob to SET or press the

pad to select, and turn the Cycle Selector Dial to the

desired amount of heated drying time.

To minimize the wrinkle setting in clothes, the Press

Guard cycle provides from15 to 20 minutes of no-heat

tumbling after the clothes are dry.

Used the End Cycle Signal to remind you to remove

the dried laundry.

End Cycle Signal. (Available on some models.)

Set End Cycle Signal, if desired. This signal operates

with any cycle on some models. The control can be set

anywhere between OFF and LOUD, depending on the

desired sound level. The signal will start to sound just

before the end of the cycle to remind you to remove the

clothes. To stop the signal while sounding, turn the

signal control to OFF or advance the Cycle Selector to

OFF.

This signal should always be used when drying

polyester knits or permanent press items which should

be removed as soon as the dryer stops to help prevent

setting of wrinkles.

If the signal is on and you choose the Press Guard

cycle, you will hear the signal sound on and off

throughout the cycle. This reminds you that the clothes

are dry.

Start. Turn the Start knob or press the Push to Start

button to start the dryer. (Opening the door during

operation stops the dryer. To restart, close the door and

follow above directions.)

Drying Automatic Automatic

Selections Cottons Perm. Press Timed

Cottons

High Heat

Perm. Press

Medium Heat

Knits/Delicates

Low Heat

Fluff

No Heat*

Should be used with cycles indicated

Features and appearances may vary

51 3 4 2

Autres manuels pour DE09

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Fisher & Paykel Séchoir

Fisher & Paykel

Fisher & Paykel DH8060P1 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel DE62T27D Instructions de montage

Fisher & Paykel

Fisher & Paykel DH9060FS Manuel utilisateur

Fisher & Paykel

Fisher & Paykel AeroSmart DE62T27CW1 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel SMARTLOAD DRYER DGGX2 US FP Manuel utilisateur

Fisher & Paykel

Fisher & Paykel DE4024P1 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel DG60FA2 Instructions de montage

Fisher & Paykel

Fisher & Paykel DG60FA27AW2-96979 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel Smartload DEGX1US Manuel utilisateur

Fisher & Paykel

Fisher & Paykel AeroCare DE7027P2 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel DG7027G1 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel AeroCare DE7027J1 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel Smartload DEGX1 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel DE8060P2 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel Intuitive DEIX2 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel DE4560M1 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel DE6060P1 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel DH8060P1 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel DH9060P2 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel Smartload DEGX1 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel DE7027J1US Manuel utilisateur

Fisher & Paykel

Fisher & Paykel DE60FA27AW2-96983 Manuel utilisateur

Fisher & Paykel

Fisher & Paykel DE6060P Manuel utilisateur

Fisher & Paykel

Fisher & Paykel DE62TD1 Instructions de montage

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
