Firstech CM7000 Manuel d'utilisation et d'entretien

MASTER GUIDE

CM7 v3.5

Firstech, LLC.

21903 68th Ave S.

Kent, WA

98032

Phone.

888-820-3690

Fax.

206-957-3330

Please visit www.firstechdata.com for additional installation resources

Alarm

and

Starter

System

www

.firstechdata.com

CM7

Master

Guide

Page

able

Contents

Introduction

Kit

Contents

Installation

Basics

emote

Programming

outine

alet

Mode

Placement

and

Use

Components

Common

Procedures

iring

D e s c r ip tion s

Option

Programming

ables

Feature

Option

D e s c r i p ti o n s

Special

Option

Groups

and

Option

Programming

roubleshooting

Frequently

Questions

echnical

Support

Contacts

CM7000 Master Guide

Alarm and Starter System

www.firstechdata.com

































































































































































































































































































































Green / White Loop

Alarm

and

Starter

System

www

.firstechdata.com

CM7

Master

Guide

LLC.

Page

Introduction

Thank you!

For selecting a Firstech remote start security system as your product of choice. The following manual is a

complete Master guide to the CM7 universal Control Module and is intended for experienced and

authorized Firstech technicians only. If you need any further technical support, please call us at 888-820-

3690 ext. 203 or visit our website at www.firstechdata.com

Caution: The Manufacturer’s warranty will be void if this product is installed by anyone other

than an authorized Firstech dealer. Firstech provides installation support services to authorized

dealers only.

This manual may change frequently. Please check www.firstechdata.com for updates.

Kit Contents

All Firstech CM7 controller kits include the following:

• CM7000 or CM7200 main control module

• Wiring diagram sheet

• High Current ignition harness with one external relay

• Low current ignition harness

• Wiring harnesses

• Hood pin

• Mountable bright blue LED (CM7000 only)

• FT-DAS or FT-DAS II Firstech Digital Adjustable Sensor (Required for Manual Transmissions) (CM7000 only)

RF Kits with remote(s), Antenna, and Antenna Cable are not included with the CM7 controller kit.

The following sensors are available but not included with every system:

• Auto lock and unlock system (FT-EZGO)

• Remote pager sensor (FT-RPS TOUCH) or (FT-RPS-2)

• Temperature sensor (FT-TEMP SENSOR) (Drone and 2 Way remote LCD systems)

• Shock sensor (FT-SHOCK)

The remote(s) and antenna are modular and are not specific to the control modules. You can pair almost any

Firstech remote(s) and antenna receiver to the CM7 control module. This includes all 4 and 6 pin antennas.

Any questions on contents please contact your distributor or us directly at 1.888.820.3690, Monday

through Friday, 7AM to 5PM Pacific Time.

Alarm

and

Starter

System

www

.firstechdata.com

CM7

Master

Guide

LLC.

Page

Installation Basics

If you are new to installing Firstech Series Remote Starts and/or Alarms, we highly recommended that you

thoroughly review this manual to installing your first unit.

Remote Programming:

You must code remotes to this system before anything will function. Begin by cycling the ignition ON and OFF

five times within 10 seconds and press and release button 1 (half second) on the first remote, and then press and

release button 1 (half second) on the second remote.

Tach learning procedure: When using tach mode this must be done before the first remote start attempt.

Learn tach by: (1.) Starting the vehicle with the key, (2.) Press and hold the foot brake, then (3.) Activate the

remote start sequence - one chirp and parking light flash indicates that the vehicle tach signal has been

successfully learned. Two chirps and three parking light flashes indicate that the control module failed to see a

proper tach signal. (These units have the option for Tachless and 3 second assume cranking).

DAS Sensor (Required for Manual Transmission Installs):

The DAS sensor monitors forward movement for remote starting manual transmissions, dual stage impact,

and auto adjusting tilt sensor. See the DAS Sensor section of this manual for details.

Internal green/white loop must be cut for AUTOMATIC transmission vehicles.

By default, the units come MANUAL transmission ready, you MUST select a reservation set up procedure

to allow proper manual transmission function. You will need to cut the green/white loop inside the control

module if you are installing the unit in an AUTOMATIC transmission.

High Current 2nd Ignition Output (CN1 Blue Wire) (Jumper Programmable)

High Current Parking Light Output (CN1 Green/White Wire) (Jumper Programmable) High

Current Accessory Output (CN1 White Wire) (Jumper Programmable)

Optional Low Current Outputs Available (CN3 Pin 1 - 3 Amp (+) In) Harness Included. When Using

Connector, CN1 (High Current Connector) Not Required.

2nd RS232 Data Port (Grey CN6) Default DroneMobile Protocol w/Fortin Protocol

Optional.

Lock connector functions added to Connector 5 - 20 Pin Grey Harness

Lock connector functions are now available via POC 3, 4 and 7. There is also a lock connector for FT-

DM600/FT-DM700 on rear of Control Module. (CN11)

Built-In Troubleshooting diagnostics

Notice! In order to properly diagnose remote start/stop failure the parking light output must be connected to either

(+) Positive or (-) Negative parking light circuit on the vehicle.

Alarm

and

Starter

System

www

.firstechdata.com

CM7

Master

Guide

LLC.

Page

emote

Programming

outine

IMPORTANT: All remotes must be coded to the control module prior to performing all operations.

STEP 1: Activate programming mode by manually turning the vehicle’s key between the Ign On and Off

(or the Acc & On positions) five times within 10 seconds. The vehicle’s parking lights will flash

once with the successful completion of this step.

STEP 2: Within a 2 second period after the 5th ignition cycle tap (a quick 0.5 second press and release)

the Lock button on the Firstech remote. The parking lights will flash once to confirm the

transmitter has been coded. Repeat step 2 for each additional remote, up to 4.

NOTE: If using one of the FMX frequency remotes you will need to tap the programming button

on the antenna after the key cycles. The LED on the antenna will come on solid red Tap

(a quick 0.5 second press and release) the lock button on the remote. The LED flash green

for each remote that is successfully programmed)

Note: if you only have 2 remotes please program each remote twice.

**parking lights will flash twice signaling the end of programming mode.

**NEW**

Remote programming procedure: PTS (Push to Start vehicles) application

STEP 1: Set the vehicle to the ignition or “ON” position

STEP 2: Within 5 seconds push to the “OFF” position

STEP 3: Within 5 seconds set the vehicle to the ignition or “ON” position (do not start)

STEP 4: Within 5 seconds depress and release the foot brake 3 times *parking lights will flash 1 time to

indicate remote programming is enabled

STEP 5: Tap (a quick 0.5 second press and release) the lock button on the remote * the parking lights

will flash 1 time indicating the remote code has been accepted (Repeat step 5 for each

additional remote, up to 4

STEP 6: After 10 seconds of no valid remote codes being transmitted the CM will automatically

exit programming mode

NOTE: If using one of the FMX frequency remotes you will need to tap the programming

button on the antenna after the foot brake presses. The LED on the antenna will come on

solid red Tap (a quick 0.5 second press and release) the lock button on the remote. The LED

will flash green for each remote that is successfully programmed)

Note: If no valid remotes are programmed the CM will enter valet mode.

Alarm

and

Starter

System

www

.firstechdata.com

CM7

Master

Guide

LLC.

Page

Valet Mode

Valet Mode disables all system features except for the keyless entry. Use Valet when servicing or loaning your

vehicle to others to avoid any inconvenience or mishap when operating the vehicle. There are no visual

indicators when the security system is in Valet Mode. There is a parking light indication when remote starting in

Valet Mode. (3 flashes followed by 10 flashes). Also, when in Valet Mode, the keyless entry feature will still

operate.

The system can be put into valet mode one of 3 ways:

1. While holding the foot brake (12V+ brake input), cycle the key to the Ignition or ‘On’ position and then back

to the ‘Off’ position 5 times within 10 seconds. The parking lights will flash once indicating that the system

has entered Valet Mode.

2. Turn the key to the Ignition or ‘On’ position then using a 4-button remote press and release the lock and

trunk buttons together simultaneously for a half second. The vehicle parking lights will flash 1 time to

indicate the system has successfully entered valet mode.

**NEW**

3. The user may enter valet mode by performing the PTS vehicle remote programming procedure and make

sure there are no remotes transmitting.

Step 1: Set the vehicle to the ignition or “ON” position.

Step 2: Within 5 seconds turn ignition off

Step 3: Within 5 seconds set the vehicle to the ignition or “ON” position. (do not start)

Step 4: Press and release the foot brake 3 times within 5 seconds *parking lights will flash 1 time

to indicate programming is enabled.

Step 5: After 10 seconds, the parking light will flash 2 times, indicating the system has entered valet mode

Alarm

and

Starter

System

www

.firstechdata.com

CM7

Master

Guide

LLC.

Page

The System can be taken out of Valet mode by one of the following procedures:

1. No Remote: If there are no remotes or there are no remotes available you can exit Valet Mode by turning

the key to the ignition on or ‘Run’ position then press and release the foot brake pedal 10 times within 10

seconds. This procedure will only deactivate Valet Mode it will not activate Valet Mode. The vehicles

parking lights should flash 2 times to indicate the system has exited valet mode

2. With Remote: While within remote range of the vehicle, using a 4-button remote, press and release the lock

and trunk button together simultaneously for a half second. The vehicle’s parking lights will flash 2 times to

indicate the system has exited Valet Mode.

Placement and Use of Components

IMPORTANT: The placement and use of components are critical to the performance of this system.

Antenna and Cable

Firstech antennas are calibrated for horizontal installation at the top of the windshield. The cable that connects

the antenna to the control module must be free from any pinches or kinks. Installing the antenna in areas other

than the windshield may adversely affect the effective transmitting distance of the remotes.

LED (external)

There will be an external mountable Blue LED for theft deterrent included. It is important to discuss mounting

locations with the end user, trying to make it visible and bright when recommending locations. The LED will

light up solid blue when armed for approx. 25 seconds allowing the impact sensor to set up. Once the LED is

flashing the sensors are ready. The LED will also provide security diagnostics:

2 Flash Door Input

3 Flash Shock stage 1

4 Flash Shock stage 2

5 Flash Tilt

6 Flash Ignition on

7 Flash Hood Input

8 Flash Trunk Input

9 Flash AUX sensor stage 1

10 Flash AUX sensor stage 2

RPS Touch and RPS (Remote Paging Sensor)

The RPS is an optional feature. The car call/RPS feature uses a small sensor that is mounted on the inside of

your windshield.

Alarm

and

Starter

System

www

.firstechdata.com

CM7

Master

Guide

LLC.

Page

1. RPS Touch (Remote Paging Sensor)

The new RPS touch has multiple features including: remote paging, 4-digit pin unlock/disarm, and arm/

lock. All features are operated with a simple touch of the sensor. Note: check feature 3-16 to make sure it

is set to RPS touch setting. (default to RPS touch)

RPS Touch and car call functions do not require programming, however to unlock/disarm your vehicle you

must program a 4-digit passcode (numbers 1 through 10 only) you can view our video library for

programming instructions at: www.firstechdata.com NOTE: If you enter the wrong code more than 5

times within 30 minutes the RPS touch function will be disabled for 1 HOUR

Programming Your Code

STEP 1: Choose your RPS Touch 4-digit code. ‘0’ is not available.

STEP 2: Turn ignition to the ‘ON’ position and leave driver’s door open. (Door Input must be connected)

STEP 3: Hold your finger over the ‘Red Circle’ icon for 3 seconds.

STEP 4: When the siren chirps and LEDs flash in a circular pattern, tap on your first number. (Hold the

number for 2.5 seconds to choose 6 through 10.) After choosing your first number you will get 1

siren chirp and LEDs will flash in a circular pattern.

STEP 5: Repeat Step 4 until all four digits are set. You will get 1 siren chirp and 1 parking light flash.

Repeat Steps 2 - 5 if you get 3 chirps and light flashes. Your RPS Touch is now programmed.

Alarm rearm and lock

To rearm hold your finger on the ‘Red Circle’ for 3 seconds.

Alarm disarm and unlock

To disarm hold your finger over the ‘Red Circle’ for 3 seconds. Once the LEDs start their circular pattern,

enter your 4-digit code by touching the window with the flat part of the tip of any finger over the number for

each digit of your code. (Refer to Step 4 above or training video at www.firstechdata.com) Two seconds

after entering the 4th digit, your system will first re-arm/lock. In two seconds, it will disarm/ unlock.

2 Way LCD remote paging

To page a 2 Way LCD remote, hold your finger over the ‘Red Circle’ twice.

Touch Panel Sensitivity

To change touch sensitivity, open the driver’s door, hold the button on the back of the RPS Touch until the

LEDs go out. Release button and tap again. The number of solid LEDs represent sensitivity of touch, 1

being the lowest, 5 the highest.

RPS Touch on or Off

You can turn the RPS Touch off from your remote. Just follow the instructions below:

Alarm

and

Starter

System

www

.firstechdata.com

CM7

Master

Guide

LLC.

Page

STEP 1: Enter remote programming mode by holding down buttons 2+3 (Trunk and Key/Start buttons

on 2W901R-SS) simultaneously for 2.5 seconds. The remote will beep once and the LCD or

read “REMOTE MENU” indicating that you have entered programming mode.

STEP 2: Scroll through the remote options by taping button 3 or 4 (Function button 2W901R-SS).

Once the LCD RPS icon flashes reads “RPS-ON” tap button 1 or (Lock button 2W901R-SS)

to turn this feature on. The LCD will read “RPS-OFF”

STEP 3: Exit remote programming by holding down buttons 2+3 (Trunk and Key/Start 2W901R-SS)

buttons simultaneously for 2.5 seconds. The remote will beep indicating that you have

successfully exited programming.

RPS (Remote Paging Sensor) Unlock/Disarm

RPS and car call functions do not require programming, however to unlock/disarm your vehicle you must

program a 4-digit passcode (numbers 1 through 10 only) using the instructions below:

STEP 1: Disarm/unlock the alarm (remote must be programmed first) and choose a 4-digit code. You

cannot have zeros.

STEP 2: Turn ignition key to the “on” position and leave the driver’s door open.

STEP 3: Knock on the windshield in front of the RPS a total of 5 times (each time you knock the LED on

the RPS will flash RED). The LED will begin to flash rapidly in BLUE with successful

completion of this step.

STEP 4: Enter the first digit of the desired four-digit pass code by knocking on the windshield in front

of the RPS the desired number of times. For example, to enter 3, knock on the sensor 3 times

(each time you knock the LED will flash RED) then wait.

STEP 5: The LED on the RPS will confirm your first number by flashing BLUE slowly. Once the LED

begins to flash rapidly in BLUE, enter your second number by repeating step 4.

STEP 6: Repeat steps 4 & 5 to enter all four numbers.

STEP 7: Turn the ignition OFF - the RPS disarm/unlock passcode is now programmed. Follow steps 3 –

5 to enter you disarm/unlock code.

Alarm rearm and lock

To rearm, knock on your sensor 5 times.

Alarm disarm and unlock

To disarm, knock on your sensor 5 times. Wait for the Blue LEDs to flash rapidly. Follow STEP 4 and 5

above to enter your 4-digit passcode.

2 Way LCD remote paging

To page a 2 Way LCD remote just knock on the RPS twice.

Autres manuels pour CM7000

Table des matières

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
