HotPointTM

HardwareInstallationGuide

HotPoint 5200 Access Point

Published March 2014

(Revised 2016)

Firetide, the Firetide logo, Reliable connectivity anywhere, HotPort and HotPoint are all

trademarks of Firetide, Inc. All other trademarks are the property of their

respective

owners.

Information in this document is subject to change without notice.

Firetide, Inc.

2105 S. Bascom Avenue, Suite 220

Campbell, CA 95008

USA

www.firetide.com

iii

About this document

This section lists theaudience, purpose, and conventions used in this document.

Audience

Thisdocumentisintendedfor qualifiedinstallersandadministratorsofFiretide

products.

Purpose

Thisdocument hasthe information necessary toconfigure, install, and dobasic

troubleshootingforHotPoint5200accesspoints.

Conventions

Certain information has special meaning for the reader. This information appears

with an icon that indicates a particular condition, such as a warning or caution,

oralabel,suchas“Note”or“BestPractice”.

Electricalhazards

arethose environments wherethe dangerof

electrocutionisprobable.Thisimageappearsbeforeeachelectrical

hazard statement.

Warnings

contain safety information that you must obey. If you do

not obey the instruction in a warning, the result might includeserious

injury or death. This image appearsbeforeeach warning statement.

Cautions

contain information that you should obey to avoid minor

injury,inconvenience,anddamagetoequipment.Thisimageappears

beforeeachcautionstatement.

Notes

contain optional advice and information particular to a special case or

application.

Best practices

contain specific recommendations based on industry-standard

expectations.

Document feedback

If you find an error or content missing from this document, we want to hear

about it. You cansend your feedbackabout any of our documents to

techpubs@firetide.com.

Contacting customer support

If you need support, depending on the problem, you might be asked for this

information:

•

Description of the problem

•

ComputerwithHotView Proandan installed managementlicense

•

Channel and frequency plans

•

Recent spectrum analysis

•

Device topology in Google Earth (KMZ file)

•

Network map ortopology plan with the namesand device information

Youmust also have administrator access to the mesh to be able to receive

technical support.

Thenext tablelists thecontactinformationfor customersupport.

Worldwide customer support

Days/Hours

Contact

Americas

Monday to Friday

7:00amto 5:30pmPST

(Pacific standard time)

http://www.firetide.com/requestsupport

1 (877) FIRETIDE, extension 2

+1(408)399-7771,extension 2

+1(408) 355-7271

Africa

Monday to Friday

http://www.firetide.com/requestsupport

Asia

8:00 am to 5:30 pm IST

+918040215111

Australia

(India standard time)

Fax +1(408) 317-2257

Europe

Contents

About this document

iii

Audience .....................................................................

iii

Purpose .......................................................................

iii

Conventions ................................................................

iii

Document feedback .....................................................

iii

Contacting customer support.......................................

HotPoint 5200 access point overview 1

Hardware features .......................................................

Management options..................................................

Web interface

HotView Pro

Optional accessories.....................................................

HotPoint 5200 access point setup 3

Verifyingthe boxcontents..........................................

Parts of a HotPoint access point .................................

Attachingcablesandconnectors ................................

Connecting a computertoa new access point ..............

LEDs...................................................................................

LEDboot operation

LED operation during client association and

data traffic

LED operation duringa firmwareupgrade

Radios ........................................................................

Ground screw..............................................................

Outdoor device installation 9

Safe installation practices ..........................................

Preparing earth ground ...............................................

GroundingaHotPointaccesspoint.............................

Required tools .............................................................

Preparing the access point for outdoor installation .. 14

Checkingtheoutdoorenvironmentforsafety..............

Install the access point in a

permanent outdoor location..........................................

Installing a HotPort 5200 access point

toapoleorwall ......................................................15

Antennas for outdoor use............................................

Attaching an antenna..................................................

Connecting antennas...................................................

Recommendations for indoor use ...............................

Recommendations for corrosive environments ............

Weatherproof procedures

Tools and materials to weatherproof connections.......

Makingaweatherproofantennaconnection................

Making a weatherproof cableto node connection ........

Troubleshooting

Resetting an outdoor node to factory default settings 25

Improving client experience and device performance 26

HotPoint5200 access point overview

TheFiretideHotPoint5200wirelessMIMOaccesspointis astandalone access

solutionfor outdoor use. Thissectionexplains thehardware featuresofthe

access point and management options.

Hardware features

TheHotPoint5200accesspointis astandaloneaccesspoint.Standalonedevices

do not require any other network deviceor equipment to configure or manage

them. Each access point, withits antennas, is a complete system for wireless

access service delivery.

Thenext figure showsthe HotPoint 5200 access pointcorrectly oriented for

installation to a pole or mast.

In locations where access to Ethernet or power is limited, the access point can

receive Power over Ethernet (PoE).

Caution!

A HotPort 7020 cannot supply power to a HotPoint 5200

access point.

TheHotPoint 5200 access point hasa UL2043 plenum-rated enclosureand has

these hardware features:

•

AnRJ-45 connector for attaching to a Firetide HotPort wireless mesh node or

a conventional Ethernet port

•

Tworadios (Radio 1 operates in the 2.4 GHzband and Radio 2 operates in the

5 GHz band)

HotPoint 5200 access point overview

•

LEDs

2.4 GHz

5 GHz

Power

Management options

Youcan choose to manage HotPoint access points in one of these ways:

•

Web user interface

•

HotViewPronetworkmanagementsoftwarerelease10.15.0.0andlater

Web interface

Theweb(HTTP)interface is a management interfacethat comeswitheachaccess

point. With this software you can configure each access point individually

througha browser.This method is goodfor smallnetworkswithfew devices.

HotView Pro

HotView Prois a robust network management software (NMS). It lets you manage

many Firetide devices at the same time. To use HotView Pro you need to purchase

one managementlicense for eachaccess point.

Optional accessories

These accessories are available for purchase:

•

2.4 GHz, 8 dBi omni-directional 3x3 MIMOantenna (AO-024-MIMO-8)

•

5 GHz, 8 dBi omni-directional 3 x 3 MIMO antenna (A0-050-MIMO-9)

•

LMR400cablewithlowlosslightningsuppressors

1.5m length

5 m length

Note.

For more information about these and other accessories, see the

Firetide

Antenna, Cables and Accessories Guide.

Power Consumption table

Power input fromDC supply: 33 W (Typical), 33 W (Max)

Power input from PoE: 23 (Typical),26 W (Max)

dio

HotPoint 5200 access point setup

Before you install an access point outside, you need to make sure:

•

The parts are all in the box.

•

Attach the cables and antennas for testing.

•

Make an initial connection from a laptop that is running the web interface or

HotViewProso youcanmakesurethedevice works as expected.

Verifying the box contents

The box contains these items:

•

OneHotPoint5200accesspoint

•

One power cable (USA type)

•

One Power over Ethernet (PoE) injector

•

Six dual-band 2.4 GHz and 5 GHz, 3 dBi omni-directional staging antennas

•

Six SMA to type-N plug adapters

•

OneEthernetcable

•

Onefield-installableEthernetconnector

•

Mount kit

•

Quick Start Guide

If any of these items is missing from the box, call your reseller for help.

Parts of a HotPoint access point

The next pictureshows the radios, LEDs and connectors on the access point.

LEDs: 2.4 GHz 5 GHz

Power

Resetbutton

Ethernetport

Ground screw

DC power connector

HotPoint 5200 access point setup

Attaching cables and connectors

Before you install the device in a permanent location, assemble the device

completely and verify that the LEDs come on.

Toassembletheaccesspointforconfiguration andtesting:

Put an adapter on the end of each staging antenna.

Removeanddiscardthe rubberprotectivecoversontheantennaconnectors.

Attach one staging antenna assembly to each antenna connector.

Bend the staging antennas at the joints. Refer to the next diagram.

Connect the PoE injector assembly to the access point and the

administrator’s computer.

Attach one Ethernet cable fromtheEthernet port of the accesspoint to

the OUT port of the PoE injector.

AttachanotherEthernetcablefromtheadministrator’s computerto

theINport ofthePoEinjector.

(Optional) Attach the power cable to a power source.

Connecting a computer to a new access point

Youneed to change the TCP/IP4 settings on your computer so that you can

communicate with the access point. The first time you connect to theaccess

point, you need to change the TCP/IP4 setting on your computer.

Note:

IfyouareusingPoE,connectyourcomputerdirectlytotheINportonthe

POEinjector.

192.168.224.160 is the default IP address of the access point.

To connect to an access point for the first time:

Attach the Ethernet cable from the Ethernet port on the access point to an

Ethernetporton the administrator computer.

Supply power to the access point.

If you are using PoE, the access point receives power from your computer.

The access point boots in 1.5to 2 minutes. The power LED glows steady.

Table des matières

Autres manuels Firetide Point d'accès sans fil

Firetide

Firetide HotPort 3203 Manuel

Firetide

Firetide HotPoint 5100 Manuel

Firetide

Firetide HotPoint 5100 Manuel utilisateur

Firetide

Firetide HotPort 6101 Manuel

Firetide

Firetide HotPoint 4100 Manuel utilisateur

Firetide

Firetide FWB-100 Manuel utilisateur

Firetide

Firetide HotPort 6100 Series Manuel

Firetide

Firetide HotPort 5020-E Manuel utilisateur

Firetide

Firetide HotPoint 4500 Manuel utilisateur

Firetide

Firetide HotPort 8020 Manuel utilisateur

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Cisco

Cisco Aironet 1550 Series Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur
