Finder 19 Series Manuel utilisateur

KNX Actuator 19.6K

FINDER S.p.A.

ViaDrubiaglio,14-10040ALMESE(TO)-ITALY

Tel.+390119346211Fax+390119359079


FINDER SpA Ver. 2018 KNX Actuator 19.6K 2

Table of Contents
1DEVICE TEMPLATE............................................................................................................................................................. 3
1 PRODUCT NAME AND APPLICATION NAME ON DESCRIPTOR .....................................................................................................4
2 FUNCTIONAL PRIORITIES....................................................................................................................................................4
3 NAME OF THE PARAMETER CONFIGURATION PAGES ONDESCRIPTOR..........................................................................................4
4 LISTOF COMMUNICATIONOBJECTS ....................................................................................................................................5
4.1 Behaviorduringtheinitialization,theRestartandtheBusRecovery. ...................................................................5
5 DETAILED DESCRIPTION OF THE COMMUNICATION OBJECTS.....................................................................................................6
5.1 DPT_ChannelX SetON/OFFF(1.001Switcho7.001Value_2_Ucount)..............................................................6
5.2 DPT_ChannelX ForceOut(1.001Switch)...........................................................................................................8
5.3 DPT_ChannelALL ForceALLOut(1.001Switch) ................................................................................................8
5.4 DPT_ChannelX SelectScene(18.001DPT_SceneControl).................................................................................9
5.5 DPT_ChannelX-Status eDPT_ChannelX-StatusInverted(1.001Switch)...........................................................9
5.6 DPT_ChannelX-LogicInput1eDPT_ChannelX-LogicInput2(1.002Boolean).................................................9
5.7 DPT_ChannelX LockPORT(1.002Boolean).......................................................................................................9
5.8 DPT_ChannelX-HighThresholdandDPT_ChannelX-LowThreshold(7.001Value_2_Ucount) .........................9
5.9 DPT_ChannelX OnDelay(s)andDPT_ChannelX OffDelay(s)(7.005TimePeriodSec) .................................10
5.10 DPT_ChannelX-BlinkOnTime(s)andDPT_ChannelX-BlinkOffTime(s)(7.005TimePeriodSec)......................10
6 ENABLINGCHANNEL LOGICAL BLOCK.................................................................................................................................10
7 LIST OF PARAMETERS OF THE CHANNEL CONFIGURATION PAGE...............................................................................................11
8 LIST OF PARAMETERS OF THE CHANNEL SCENARIOS CONFIGURATIONPAGE...............................................................................12
9 LIST OF GENERAL CONFIGURATION PARAMETERS (VALIDFOR EACH CHANNEL)..........................................................................13
10 DETAILED DESCRIPTION OF THE PARAMETERSOF CHANNEL CONFIGURATION PAGE....................................................................13
10.1 Par_ContactType...............................................................................................................................................13
10.2 PAR_Startup.......................................................................................................................................................13
10.3 PAR_Function.....................................................................................................................................................13
10.4 PAR_OnDelay(s)................................................................................................................................................13
10.5 PAR_OffDelay(s)................................................................................................................................................14
10.6 PAR_Blink On(s),PAR_Blink Off(s).....................................................................................................................14
10.7 PAR_UpperThreshold,PAR_LowerThreshold ....................................................................................................14
10.8 PAR_Comparisonmethod..................................................................................................................................14
10.9 PAR_StairsLightTime(s)....................................................................................................................................14
10.10 PAR_EnableLogicFunction................................................................................................................................14
10.11 PAR_LogicOperator...........................................................................................................................................15
10.12 PAR_ValuePORTLocked ....................................................................................................................................15
10.13 PAR_EnableScenes ............................................................................................................................................15
10.14 PAR_ValueForceOut..........................................................................................................................................15
11 DETAILED DESCRIPTION OF THE PARAMETERS OF CHANNEL SCENES CONFIGURATION PAGE..........................................................15
11.1 PAR_Scene YNumber Y ) ...........................................................................................................................15
11.2 PAR_SceneYValue 4) ...............................................................................................................................15
11.3 PAR_EnableStorageforSceneY )...........................................................................................................16
12 DETAILED DESCRIPTION OF THE GENERAL CONFIGURATION PARAMETERS .................................................................................16
12.1 PAR_ValueForceALLOut...................................................................................................................................16
12.2 PAR_EnableKeyboard........................................................................................................................................16
13 BEHAVIOR OF CHANNEL LED...........................................................................................................................................16
14 SCHEME AND FUNCTIONAL PRIORITIES.................................................................................................................................17











FINDER SpA Ver. 2018 KNX Actuator 19.6K 3

1 Device Template

Input

KNX Actuator

Output

DPT_Channel X Set ON/OFF

DPT_Channel ALL Force ALL Out

DPT_ DPT_Channel X - Status

DPT_Channel X Force Out

DPT_Channel X Status Inverted

DPT_Channel X Select Scene(1)

DPT_Channel X Lock PORT(2) (3)

DPT_Channel X - Logic Input 1(2) (4)

DPT_Channel X - Logic Input 2(2) (4)

DPT_Channel X - High Threshold (7)

DPT_Channel X - Low Threshold(7)

DPT_Channel X On Delay (s)(5)

DPT_Channel X Off Delay (s)(5)

DPT_Channel X- Blink On Time (s)(5)

DPT_Channel X Blink Off Time (s)(5)

Single Channel parameters

Par_Contact Type

PAR_Startup condition

PAR_Function

PAR_On Delay (s)

PAR_Off Delay (s)

PAR_BlinkOn (s)

PAR_BlinkOff (s)

PAR_Upper Threshold(2)(7)

PAR_LowerThreshold(2)(7)

PAR_Comparisonmethod

PAR_Light Time(s)

PAR_Enable Logic Function

PAR_Logic Operator(2)

PAR_Value PORTLocked

PAR_Enable Scenes

PAR_Scene Y Number(6)

PAR_Scene YValue(6)

PAR_Enable Storage for

Scene Y(6)

PAR_Value ForceOut

General Parameters

PAR_Value Force ALL Out

PAR_Enable Keyboard

FINDER SpA Ver. 2018 KNX Actuator 19.6K 4

Legend of notes

Note

Description

(1):

It appears on product descriptor only if the PAR_Enable Scenes parameter is set to

(2):

It appears on product descriptor only if the PAR_Enable Logic Function parameter is set to

(3):

It appears on product descriptor only if the PAR_Logic Operator parameter is set to

(4):

It appears on product descriptor only if the PAR_Logic Operator parameter is set to values AND,

OR, XOR

(5):

It appears on product descriptor only if the PAR_Function parameter is set to corresponding

function.

(6):

Y takes values 1, 2, 3 e 4.

(7):

It appears on product descriptor only if the PAR_Logic Operator parameter is set to

1.1 Product name and Application name on descriptor

Product

Application

6 Channels Switch Actuator 16A 250V 19.6K

Finder Application for Switch Actuator

1.2 Functional priorities

DPT_Channel ALL Force ALL Out Operatinghighestpriority

DPT_Channel X Force Out Operatingmedium priority

DPT_Channel X Select Scene Operatinglowest priority

1.3 Name of the parameter configuration pages on descriptor

Page

Description

General settings

Itcontains thegeneralandconfigurationparameterscommon toall Channels

Channel 1

Parameter configuration page of Channel 1

Channel 2

Parameter configuration page of Channel 2

Channel 3

Parameter configuration page of Channel 3

Channel 4

Parameter configuration page of Channel 4

Channel 5

Parameter configuration page of Channel 5

Channel 6

Parameter configuration page of Channel 6

Channel 1scenes(1)

Parameter configuration page of Channel 1 scenarios

Channel 2scenes(1)

Parameter configuration page of Channel 2 scenarios

Channel 3scenes(1)

Parameter configuration page of Channel 3 scenarios

Channel 4scenes(1)

Parameter configuration page of Channel 4 scenarios

Channel 5scenes(1)

Parameter configuration page of Channel 5 scenarios

Channel 6scenes(1)

Parameter configuration page of Channel 6 scenarios

(1): It appears on product descriptor only if the PAR_Enable Scenes parameter

FINDER SpA Ver. 2018 KNX Actuator 19.6K 5

1.4 List of Communication Objects

Datapoint

DPT

Flags

DPT_Channel X Set ON/OFF

DPT_Switch (1.001)(0)

C-R-W

DPT_Channel X Force Out

DPT_Switch (1.001)

C-R-W

DPT_Channel ALL Force ALL Out

DPT_Switch (1.001)

C-R-W

DPT_Channel X Select Scene(1)

DPT_SceneControl (18.001)

C-R-W-U

DPT_Channel X - Logic Input 1(2)

DPT_Boolean (1.002)

C-R-W

DPT_Channel X - Logic Input 2(2)

DPT_Boolean (1.002)

C-R-W

DPT_Channel X Lock PORT (2)(3)

DPT_Boolean (1.002)

C-R-W

DPT_Channel X - High Threshold (2)(5)

DPT_Value_2_Ucount (7.001)

C-R-W

DPT_Channel X - Low Threshold (2)(5)

DPT_Value_2_Ucount (7.001)

C-R-W

DPT_Channel X On Delay (s) (4)

DPT_TimePeriodSec (7.005)

C-R-W

DPT_Channel X Off Delay (s) (4)

DPT_TimePeriodSec (7.005)

C-R-W

DPT_Channel X- Blink On Time (s) (4)

DPT_TimePeriodSec (7.005)

C-R-W

DPT_Channel X- Blink Off Time (s) (4)

DPT_TimePeriodSec (7.005)

C-R-W

DPT_Channel X - Status

DPT_Switch (1.001)

C-R-T

DPT_Channel X - Status Inverted

DPT_Switch (1.001)

C-R-T

(0): if the PAR_Enable Logic Function parameter and the PAR_Logic Operator parameter is set to

the switching DPT for the channel will be DPT_Value_2_Ucount (7,001).

(1): it appears on product descriptor only if the PAR_Enable Scenes

(2): it appears on product descriptor only if the PAR_Enable Logic Function

(3): it appears on product descriptor only if the PAR_Logic Operator

(4):it appears on product descriptor only if the PAR_Function parameter is set to corresponding function.

(5): it appears on product descriptor only if the PAR_Logic Operator

1.4.1 Behavior during the initialization, the Restart and the Bus Recovery.

During the initialization, the Restart and the Bus Recovery, no Communication Object is sent on the Bus.

FINDER SpA Ver. 2018 KNX Actuator 19.6K 6

1.5 Detailed description of the communication objects

1.5.1 DPT_Channel X Set ON/OFF F (1.001 Switch o 7.001 Value_2_Ucount)

The DPT_Channel X Set ON/OFF message is relayed to the device in order to define the output status of

the channel X. The status of the relay on the X Channel switches mutually depending by the value assigned to

the PAR_Contact Type parameter. Moreover, the channel switching depends on the channel function set by

the PAR_Function parameter.

1.5.1.1 Function Set On/Off example

When the PAR_Function parameter is set to Set On/Off . At each switching the

DPT_Channel X - Status message is sent on the bus with the value of the new status of the

channel, as well as the DPT_Channel X - Status Inverted message (not shown), which

representsthe negation.

1.5.1.2 Function Stairs light switching example

When the PAR_Function Stairs light Each time the button is pressed, the

channel switches from the OFF to ON status on receipt of DPT_Channel X Set ON/OFF = On

message. The resulting switching of the relay turn on the lights. The light timer remainslocked

untilthe DPT_Channel X Set ON/OFF = Off message is received.

After the release of the button (instant t0, t'0 and t''0) the device starts the light timer that will

expire after the interval indicated by the PAR_Stairs Light Time (s) parameter. If the button is

pressed when lights are ON, the timer is stopped and subsequent release of the button

involves reset of the light timer (e.g. instant t'0). At the end of the turn-on period the device

switches the channel relay to OFF state, turning off the lights and sends the DPT_Channel X -

Status = Off message. In the figure are not shown the DPT_Channel X - Status Inverted

messages that are sent aswell from thedevice in correspondence with the status changing.

FINDER SpA Ver. 2018 KNX Actuator 19.6K 7

1.5.1.3 switching example

When the PAR_Function Blinking . By receiving the DPT_Channel X Set

ON/OFF = On message the channel starts to blink following PWM mode with the ON status

duration set by the PAR_Blink On (s) parameter and the OFF one by the PAR_Blink Off (s)

parameter. The values of these durations can be changed run-time via the DPT_Channel X-

Blink On Time (s) and DPT_Channel X- Blink Off Time (s) messages without overwriting

parameters values. The blinking cycle always begins with the full execution of the ON time

programmed. In the figure are not shown the DPT_Channel X - Status Inverted messages

that are sent as well from the devicein correspondence with the status changing.

1.5.1.4 On d switching example

When the PAR_Function pa By receiving the DPT_Channel X

Set ON/OFF = On message the channel status, if it was OFF, switches ON after a time set by

PAR_On Delay (s) parameter. The subsequent receipt of the message with the Off value

switches channel status from ON to OFF immediately. If the channel status is ON and the

device receives again the message DPT_Channel X Set ON/OFF = On, the cycle restarts and

once delay has elapsed the DPT_Channel X - Status and DPT_Channel X - Status Inverted

messages will be sent on the bus. The delay time can be changed run-time via the

DPT_Channel X On Delay (s) message without overwriting parameter value. In the figure

are not shown the DPT_Channel X - Status Inverted messages that are sent as well from the

device in correspondence with the status changing. The functioning with the PAR_Function

is similar. In this case the delay starts by receiving the

DPT_Channel X Set ON/OFF = Off message, while the activation takes place immediately.

FINDER SpA Ver. 2018 KNX Actuator 19.6K 8

1.5.2 DPT_Channel X Force Out (1.001 Switch)

The DPT_Channel X Force Out message allows to control the channel X status with the medium priority

level, as shownin the table below, regardlessof the selected Channel function and the previous outputstatus.

The channel status is set on the value defined by the PAR_Value Force Out parameter if the device receives

the message with value On and is maintained until the DPT_Channel X Force Out message will be received

with the value Off or a higher priority message is sent to the device. In the forcing state the reception of

messages different from DPT_Channel ALL Force ALL Out or DPT_Channel X Force Out will be ignored

by the device and will not have any effect on Changing Channel status. These messages will then be sent back

when the forcing ceases by receiving the DPT_Channel X Force Out = Off message. The DPT_Channel X -

Status and DPT_Channel X - Status Inverted messages, activating the forcing status, will always be sent by

the device if they are used in group addresses. By receiving the DPT_Channel X Force Out = Off message,

the channel status remains the one acquired on forcing, until the device gets a message that make it Switch,

except for the case where the channel function is "Stairs lights" that, if lights were lit by forcing, they will turn

off after the period set with the PAR_Stairs Light Time (s) parameter.

Received message

Priority

DPT_Channel ALL Force ALL Out

High

DPT_Channel X Force Out

Medium

DPT_Channel X Select Scene

Low

Table 1

1.5.3 DPT_Channel ALL Force ALL Out (1.001 Switch)

The DPT_Channel ALL Force ALL Out message is sent to the device, with the value On, each time all

outputs have to be forced with the highest priority in the status defined by the PAR_Value Force ALL Out

parameter. In the forcing status the reception of messages different from DPT_Channel ALL Force ALL Out

will be ignored by the device and will not have any effect on changing the Channel status. These messages

will then be sent back when the forcing ceases by receiving the DPT_Channel ALL Force ALL Out = Off

message. In order to avoid bus overloading by sending datagrams after the activation of the forcing status,

pairs of DPT_Channel X - Status and DPT_Channel X - Status Inverted messages will be sent every 100ms,

starting from Channel 1. The status messages are always sent at the activation of the high priority forcing

independently by of the status of the channels, if any used inthe group addresses.

By receiving the DPT_Channel ALL Force ALL Out = Off message, the status of each channel remains the

one acquired on forcing, until the device gets a message that make it Switch, except for the case where the

channel function is "Stairslights" that, if lights werelit by forcing, theywill turnoff after the period set withthe

PAR_Stairs Light Time (s) parameter.

FINDER SpA Ver. 2018 KNX Actuator 19.6K 9

1.5.4 DPT_Channel X Select Scene (18.001 DPT_Scene Control)

Typically, the scenarios are used to set a predetermined channels configuration of the device, when the

function (direct,logical or analog Set PAR_Function parameter is set to value 0.

The DPT_Channel X Select Scene message is sent to device whenever user wants to recall an expected

scenario for the Channel X. TheDPT assigned to this message is 18.001.

User can set up to four different scenarios for each individual channel. If the channel scenarios are enabled

through the PAR_Enable Scenes parameter, the scenarios configuration page appears, on which will include

the relevant parameters. The number that can be set as scenario is attributed to the PAR_Scene Y Number

parameter -64]. Leaving the parameter with the default value No scene number , the

scenario has no effect because even if it was enabled, it is not assigned any numbers. In this way the user has

the option to configureonly the scenarios that actually will use. Channel status on scenario Y will be set by the

PAR_Scene Y Value parameter value channel output status

can be changed by sending the message DPT_Channel X - Out. If the PAR_Enable Storage for Scene Y

parameter , the user is able to reprogram the channel status of the scenario with the

current status value. When the device receives the message with the value

DPT_Channel X Select Scene = 0x80 | PAR_Scene YNumber

the PAR_Scene Y Value parameter will update with the current status of the channel set by the user and to

store it for the next recall of scenario Y.

1.5.5 DPT_Channel X - Status e DPT_Channel X - Status Inverted (1.001 Switch)

TheDPT_Channel X - Status and DPT_Channel X - Status Inverted messages are relayed from the device on

the bus everytime Channel X status switches, asshownin the previous figures.

1.5.6 DPT_Channel X - Logic Input 1 e DPT_Channel X - Logic Input 2 (1.002 Boolean)

If the PAR_Enable Logic Function

the DPT_Channel X - Logic Input 1and DPT_Channel X - Logic Input 2 messages appear on device

descriptor only if the PAR_Logic Operator parameter is set to AND, OR, XOR. They are the Boolean values to

be sent to the device and that will be composed with the DPT_Channel X Set ON/OFF message for channel

switching.

1.5.7 DPT_Channel X Lock PORT (1.002 Boolean)

If the PAR_Enable Logic Function and the PAR_Logic Operator

DPT_Channel X Lock PORT message

appear on device descriptor, together with the PAR_Value PORT Locked parameter, which defines the value

that the message must have to lock the logic function PORT formed with theinput channel switching.

The DPT_Channel X Set ON/OFF message will have effect in order to change the channel status in

accordance with the selected function, only if device has not received previously the DPT_Channel X Lock

PORT message with the value set by the PAR_Value PORT Locked parameter. Otherwise the channel status

preserves the value it had before the switching request, meaning that all DPT_Channel X Set ON/OFF

messagesreceived afterlockingthePORT will not beconsidered by the device.

1.5.8 DPT_Channel X - High Threshold and DPT_Channel X - Low Threshold (7.001Value_2_Ucount)

These messages allow to change run-time the thresholds set by the PAR_Upper Threshold and PAR_Lower

Threshold parameters without overwriting them. They only appear on the device descriptor if the

PAR_Enable Logic Function chosen by the PAR_Logic

Operator

FINDER SpA Ver. 2018 KNX Actuator 19.6K 10

1.5.9 DPT_Channel X On Delay (s) and DPT_Channel X Off Delay (s) (7.005 TimePeriodSec)

These messages allow to Change run-time the delays set by the PAR_On Delay (s) and PAR_Off Delay (s)

parameters without overwriting them. They only appear on the device descriptor selecting the corresponding

channel function by the PAR_Function parameter.

1.5.10 DPT_Channel X- Blink On Time (s) and DPT_Channel X- Blink Off Time (s) (7.005 TimePeriodSec)

These messages allow to change run-time the blinking periods set by the PAR_Blink On (s) and PAR_Blink

Off (s) parameters without overwriting them. They only appear on the device descriptor selecting the

corresponding channel function by the PAR_Function parameter.

1.6 Enabling Channellogical block

If the PAR_Enable Logic Function , the communication objects related to

the logical functions are displayed on the device descriptor. The logical operator is selected through the

PAR_Logic Operator parameter. Selections are listedin Table 2.

PAR_Logic

Operator

Value

AND

DPT_Channel X - Logic Input 1 AND DPT_Channel X -Logic Input 2 AND DPT_ChannelX

SetON/OFF

DPT_Channel X - Logic Input 1 OR DPT_Channel X - LogicInput 2 OR DPT_ChannelX Set

ON/OFF

XOR

DPT_Channel X - Logic Input 1 XOR DPT_Channel X -Logic Input 2 XOR DPT_Channel X

SetON/OFF(*)

PORT

THRESHOLD

FLIP_FLOP (DPT_ChannelX LockPORT,DPT_ChannelX SetON/OFF)

SOGLIA (DPT_Channel X Set ON/OFF, PAR_Upper Threshold, PAR_Lower Threshold,

PAR_Comparison method)

Table 2

(*) The logical valueis true if only one of the inputs is true, or both inputs are true.

The channel will change status, according to the configured logical operator. In the case of AND, OR or XOR

selections, switchingwill occur only if the result of the logical computation on the three inputs DPT_Channel

X Set ON/OFF, DPT_Channel X - Logic Input1 and DPT_Channel X Logic Input 2 is TRUE.

In case the PAR_Logic Operator parameter is set to the value of the DPT_Channel X Set

ON/OFF message will be processed comparing it with the thresholds set by the PAR_Upper Threshold and

PAR_Lower Threshold parameters

(or with the values for the DPT_Channel X - High Threshold and DPT_Channel X - Low Threshold

messages, once received by the device),in order to build the logical input for channel switching.

If the value of the message exceeds the channel activation threshold (DPT_Channel X Set ON/OFF

PAR_Upper Threshold), the logical input value will be TRUE. Conversely, if the value of the message exceeds

the channel deactivation threshold (DPT_Channel X Set ON/OFF PAR_Lower Threshold), the logical

input valuewill be FALSE.

1.6.1.1 Logical function PORT (FLIP-FLOP)

By setting the PAR_Logic Operator switching status depends by

the DPT_Channel X Lock PORT message the device receives.

Ce manuel convient aux modèles suivants

Table des matières

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur

finder 19 Series Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques
