Fike 10-2528 Manuel utilisateur

INSTALLATIONINSTRUCTIONS



Doc.No.06‐479● Rev.3,March2019

ISO9001:2015Certified



Page1of5

DIGITALALARMCOMMUNICATORTRANSMITTER(DACT)MODULEKIT(P/N10‐2528)

ImportantNoticesBeforeYouBegin

1. Pleasereadtheinstructionscarefully!Fikeproductsare

usedfortheprotectionoflifeandcriticalassetsand

mustbeinstalledandtestedasdescribedinthis

document.

2. DonotuseFikeproductsforanyapplicationforwhich

theyarenotintended.Fikeshallnotbeinanywayliable

foranydamagesorlossesincurredbyyouorthird

partiesarisingfromtheuseofanyFikeproductfor

whichtheproductisnotintendedbyFike.

3. DonotuseFikeproductsdescribedinthisdocument

outsideoftherangesspecifiedbyFike.Fikeshallhave

noliabilityformalfunctionsordamagesarisingoutof

theuseofFikeproductsbeyondsuchspecifiedranges.

4. Fikereservestherighttochangeproductdesignsor

specificationswithoutobligationandfurthernotice.

5. ThisdocumentissubjecttotheFikefulldisclaimerat

http://www.fike.com/disclaimer.

6. Visitwww.fike.comtocontactusortodownloadthe

latestversionofthisdocument.

ImportantSafetyNotes

Thefollowingformatsareusedforsafetynotesinthese

instructions.

WARNING

Thistypeofnoteisusedtoindicatethepresenceofa

hazardthatwillormaycausepersonalinjuryordeathor

lossofserviceifsafetyinstructionsarenotfollowedorif

thehazardisnotavoided.



CAUTION

Thistypeofnoteindicatesthepresenceofahazardthat

willormaycausedamagetotheequipmentifsafety

instructionsarenotfollowedorifthehazardisnot

avoided.



NOTE

Indicatesthemessageisimportant,butnotofawarning

orcautioncategory.Thesenotescanbeofgreatbenefitto

theuserandshouldberead.

MountingLocation

TheDACTmountinglocationvariesdependinguponthe

controlpanelenclosureitistobeinstalledinto.Theimages

belowshowtheappropriateDACTmountinglocationsfor

eachcompatiblecontrolpanelenclosure.

IMPORTANT!WheninstallingtheDACTintheCyberCat™

50orCheetah™Xi50enclosures,theDACTmustbe

installedbeforethecontrolboard.



DACTMountingforCyberCat™50orCheetah™Xi50



DACTMountingforCyberCat™254/1016orCheetah™Xi



Page2of5

ISO9001:2015CertifiedDoc.No.06‐479● Rev.3,March2019

Installation

Installationandwiringshouldbeperformedbyqualified

personnelonly.Equipmentdamageand/ormalfunction

mayresultfromimproperinstallation.Disableallcritical

systemfunctionsandremoveallpowerfromthesystem

untiltheinstallationiscompleteandreadyfortesting.

CAUTION

TheDACTcircuitboardcontainsstatic‐sensitive

components.Handletheelectronicsbytheedgesonly

andavoidtouchingtheintegratedcomponents.Keep

electronicsintheprotectivestaticbagitwasshippedin

untiltimeforinstallation.Alwaysgroundyourselfwitha

properwriststrapbeforehandlingthemodule(s).Ifthe

installerisproperlygroundedatalltimes,damagedueto

staticdischargewillnotoccur.Ifthemodulerequires

repairorreturntoFike,itmustbeshippedinananti‐

staticbag.

TheDACTisinstalledontothethreadedpressstuds

providedinthebackoftheenclosureusingthe



following

mountinghardwaresuppliedwiththecard.

StandoffHardwareKit,P/N02‐12037,includes:

02‐117516‐32hex.Standoff,2”long,F/F

(CyberCat™254/1016andCheetah™Xi)

02‐118336‐32hex.Standoff,5/8”long,F/F

(CyberCat™50andCheetah™Xi50)

02‐15896‐32x.375Phillipspanheadscrew,zinc

plated(CyberCat™50andCheetah™Xi50)

02‐168706‐32hex,Standoff3/8”long,M/F

(CyberCat™254/1016andCheetah™Xi)

ToinstalltheDACTintotheCyberCat™50orCheetah™Xi

50systemenclosures:

1. CarefullyunpacktheDACTandcheckforshipping

damage.

2. Securethefour.625”F/Fstandoffs(P/N02‐11833)onto

thethreadedpressstudsonthebackoftheenclosure,

asshownintheimagebelow.

NOTE

FortheCyberCat™50orCheetah™Xi50,installthe

DACT,theninstallthesystemcontrolboard.

3. InstalltheDACTontothestandoffsandsecureitin

placebythreadingthefour6‐32”screws(P/N02‐1589)

throughtheboardandintothestandoffs.



DACTMountingforCyberCat™50orCheetah™Xi50

ToinstalltheDACTintotheCyberCat™254/1016or

Cheetah™Xisystemenclosures:

1. CarefullyunpacktheDACTandcheckforshipping

damage.

2. Securethefour2”F/Fstandoffs(P/N02‐11751)onto

thethreadedpressstudsonthebackoftheenclosure,

asshownatright.Thelower‐rightstandoffmustbe

installedthroughthemountingholeprovidedinthe

systemcontrolboard.

NOTE

FortheCyberCat™254/1016andCheetah™Xi,install

thesystemcontrolboard,theninstalltheDACT.

3. InstalltheDACTontothestandoffsandsecureitin

placebythreadingthefour3/8”standoffsthroughthe

DACTboardandintothe2”standoffs.



DACTMountingforCyberCat™254/1016orCheetah™Xi



Doc.No.06‐479● Rev.3,March2019ISO9001:2015CertifiedPage3of5

DACTWiring:CyberCat™254/1016andCheetah™Xi

Thewiringdiagrambelowshowshowtoelectricallyconnect

theDACTintotheCyberCat™andCheetah™Xipanels.

1. Installwiringtoconnect24VDCcontinuouspowerfrom

thesystemcontroller(TerminalP7,Aux.Output,+/‐)to

theDACT,asshownbelow.

2. Apply24VDCpowertotheDACTandprogramusingthe

10‐2477five‐zonehand‐heldDACTprogrammer.



3. InstallRS485wiringfromthesystemcontroller(terminal

P6)totheDACT(‐toA;+toB),asshownbelow.

4. Connectincomingphonelinesandtestforproper

operation.

NOTE

WhentheDACTmoduleisinstalled,theincomingphone

lines(power‐limited)mustberoutedseparatelyfrom

anynon‐power‐limitedrelayconnectionstothesystem

controller.



DACTWiring:CyberCat™254/1016andCheetahXi™



Page4of5

ISO9001:2015CertifiedDoc.No.06‐479● Rev.3,March2019

DACTWiring:CyberCat™50andCheetah™Xi50

Thewiringdiagrambelowshowshowtoelectrically

connecttheDACTintotheCyberCat™50andCheetah™Xi

50:



1. Installwiringtoconnect24VDCcontinuouspowerfrom

thesystemcontroller(terminalP6,Aux#1,+/‐)tothe

DACTasshownbelow.

2. Apply24VDCpowertotheDACTandprogramusingthe

10‐2477five‐zonehand‐heldDACTprogrammer.



3. InstallRS485wiringfromthesystemcontroller

(terminalP6)totheDACT(‐ toA;+toB),asshown

below.

4. Connectincomingphonelinesandtestforproper

operation.

NOTE

WhentheDACTmoduleisinstalled,theincomingphone

lines(power‐limited)mustberoutedseparatelyfrom

anynon‐power‐limitedrelayconnectionstothesystem

controller.



DACTWiring:CyberCat™50andCheetah™Xi50



Doc.No.06‐479● Rev.3,March2019ISO9001:2015CertifiedPage5of5

DACTProgramming

WhenusingtheintelligentRS485connection,theDACT

mustbeaddedtothecontrolpanel’speripheraldevicelist

(address2–32)andselectedforsupervision.Thisallows

troublewiththeDACTtobereportedtotheFikecontrol

systemandtransmittedtothereceivingstationononeof

thephonelines.

DACToperationalfunctionsmustbeprogrammedintothe

deviceusingthe10‐2477(BoschFMR‐DACT‐KEYPAD)five‐

zone,hand‐heldprogrammer,asshownbelow.



RefertoBoschdocumentFPT‐DACTOperationand

InstallationGuidefordialer‐specificoptionsand

programminginstructions.Thefollowingoptionsmustbe

configuredintotheDACTforproperoperationwithFike

controlsystems:

SystemDateandTime

AccountNumbers

PhoneNumbers

PhoneControl(reportingformat)

ReportSteering(phonetwoasbackuptype)



Supervision

BusAddress=133(donotchange)

SuperviseBus=Yes(donotchange)



NOTE

IfusingtheDACT’soptionalprogrammablepointinputs

forcommunicationtothereceivingstation,referto

BoshdocumentFPT‐DACTOperationandInstallation

Guideforwritingandprogramminginstructions.



DACTProgrammer
