DATE 10-31-97 CDP-01
Fig. Sheet 1-766
CDP-01
Additional Instruction Manual
For Armless Recoiler Application (Fixed Ratio)
DATE 10-31-97 CDP-01
Fig. Sheet 1-766
DATE 10-31-97 CDP-01
Fig. Sheet 1-766
NOTE
These additional instructions explain the special features of the system delivered to the customer. They
are intended for being used in conjunction with the CDP-01 Reference Manual. The CDP-01 Reference
Manual applies except as noted to the contrary in these instructions.
Copyright:
All rights reserved. Any reproduction of this Additional Instruction Manual, in any form, in whole or in part,
requires the prior written consent of FIFE.
The information given in this Additional Instruction Manual is subject to change without notice.
We have compiled this Additional Instruction Manual with the greatest possible care and attention:
however, the possibility of error can not be completely excluded. FIFE accepts no legal liability for
incorrect information given and the consequences arising therefrom.
Copyright 1996 FIFE Corporation, P.O. Box 26508, Oklahoma City, OK 73126, U.S.A.
FIFE GmbH,Postfach 1240, D-65762 Kelkheim/Ts., Germany
DATE 10-31-97 CDP-01
Fig. Sheet 1-766
CONTENTS I
DATE 10-31-97 CDP-01
Fig. Sheet 1-766
Table of contents
GENERAL INTRODUCTION 1
APPLICATION DESCRIPTION..............................................................................................1-1
SOFTWARE PART NUMBERS .............................................................................................1-1
CONNECTING THE SYSTEM COMPONENTS.....................................................................1-1
OVERVIEW OF FUNCTION 2
OPERATOR CONTROL OPTIONS .......................................................................................2-1
SPECIAL FEATURES OF EXTERNAL CONTROL................................................................2-1
INPUT MATRIX - EXTERNAL CONTROL.............................................................................2-2
EXPLANATION OF THE OPERATING MODES....................................................................2-3
START UP / POSITION SENSOR CALIBRATION ................................................................2-6
START UP / GUIDING SENSOR CALIBRATION..................................................................2-8
TROUBLESHOOTING 3
FAULT DIAGNOSIS - FAULT RECTIFICATION....................................................................3-1
DATE 10-31-97 CDP-01
Fig. Sheet 1-766
SUPPLEMENTARY OPERATING MANUAL 1
1-1
DATE 10-31-97 CDP-01
Fig. Sheet 1-766
GENERAL INTRODUCTION
Application description
Armless Recoiler Application, using linear analog position feedback for both the mandrel and the sensor
positioner. The sensor seeks the web edge. The sensor follows the web edge as long as the Auto
Permissive input is high. Once the Auto Permissive input goes low, the sensor position and the mandrel
position are read. The mandrel then follows the sensor positioner movements.
A CDP-01-MHH is used for this application. Drive 1 is not used. The mandrel is connected to Drive 2
and the sensor positioner is connected to Drive 3.
Software part numbers
The software part numbers are located on the side of the CDP-01 housing. They include the Matrix Setup
no. (MS) , State Machine no. (SM) and firmware version ( Dx ).
D1:5650xx-02x MS: 100003.02x Please quote these
D2:5650xx-02x SM: 100004.02x details with all inquiries.
D3:5650xx-02x FIFE USA
Connecting the system components
The system components are to be connected according to the Cable Connection Diagram contained in the
documentation.
DATE 10-31-97 CDP-01
Fig. Sheet 1-766
