F5-4511 Series 10/100Mbps to 4E1 Converter
F5-4513 User Manual
(Version: 3.2)
Beijing Fibridge Co., Ltd.
F5-4513 User Manual V3.2
- 2 -
Content
1. Overview...................................................................3
2. Features....................................................................3
3. Specification.............................................................4
3.1 E1 Port.........................................................4
3.2 Ethernet Port ...............................................4
3.3 Dimensions..................................................4
3.4 Power ..........................................................4
3.5 Environment ................................................4
4. Panel .........................................................................5
4.1 Front Panel..................................................5
4.2 LED Description...........................................5
4.3 DIP Switch Description................................6
4.4 Factory Setting of DIP Switch:.....................7
4.5 Rear Panel...................................................7
4.6 Button ‘IN’ & ‘OUT’.......................................8
5. Application................................................................8
6. Order Information....................................................9
F5-4513 User Manual V3.2
- 3 -
1. Overview
F5-4511 Series F5-4513 Converter is the most new
promoted product that can convert 10/100Mbps
Ethernet to 4E1 Signal, and vice versa. This protocol
converter can extend the bandwidth to 7.68Mbps. It is
widely used in two LAN connecting, remote monitor
and video broadcasting.
2. Features
zCompatible with ITU-T G703, G704 and G823
zSupport 10Base-T, 100Base-TX protocol
zEnable any group of CH1-CH4 E1 channel to
transmit the data at will
zExtend the bandwidth to 7.68Mbps when using
4E1 channels
zSupport auto-inspection of effective E1 channel
without interruption of data transfer.
zAutomatically cut off the E1Channel when it has
LOS and AIS alarm
zSupport remote E1 Loop function
z75/120 ohm Optional of E1 channel impedance
zSupport VLAN & IEEE802.1q protocol
zInternal power supply, AC220V or DC–48V
F5-4513 User Manual V3.2
- 4 -
optional
3. Specification
3.1 E1 Port
zBit rate: 2.048 Mbps
zLine code: HDB3
zStandard: Compatible with ITU-T G703, G704
zConnector: Standard BNC Port, RJ45 Port
zImpedance: 75ohm &120ohm Optional
zNumber of E1 channel: 4
zJitter Performance: compatible with G.823
3.2 Ethernet Port
zPort Speed: 10/100Mbps Auto-Selection
zAuto-negotiation with half/full duplex
zStandard: Compatible with IEEE802.3u
zConnector: RJ45 (MDI/MDI-X Optional)
zNumber of Ports: 1
3.3 Dimensions
z420mm(W) ×184mm（D）× 44mm（H）
3.4 Power
zAC Power: 100V-240V, 0.4-0.2A, 50-60 Hz
zDC Power: -48V, 0.4A
zConsumption: Less than 3 Watts
3.5 Environment
zTemperature: 0℃-50℃
F5-4513 User Manual V3.2
- 5 -
zHumidity: 30%-90%
4. Panel
4.1Front Panel
4.2 LED Description
Table 1: LED Status Description
LED Color Stat. Description
RX Yellow BLINK Receiving data
TX Yellow BLINK Transmitting data
LINK Green ON Ethernet port link OK
ON 10Base-T
SPD Green OFF 100Base-TX
ON Full Duplex
FDX Green OFF Half Duplex
ON Ethernet Line Collision
COL Red OFF No Collision or Full Duplex
ON The 1st E1 Channel Lose
CH1 Red OFF Normal Working
CH2 Red ON The 2nd E1 Channel Lose
LED Alternate MDI/MDI-X
Connection of Ethernet
DIP Switch Ethernet Port
F5-4513 User Manual V3.2
- 6 -
OFF Normal Working
ON The 3rd E1 Channel Lose
CH3 Red OFF Normal Working
ON The 4th E1 Channel Lose
CH4 Red OFF Normal Working
PWR Green ON Power supply OK
4.3 DIP Switch Description
Table 2: DIP Switch Description
PIN When ON When OFF
1
2 See Table3: Ethernet Mode
3 Normal working Local Loop
4 Normal working Remote Loop
5 ON
6 OFF
7 IN-TIME Mode, for Video Reliable Mode, for Data
8 BER limit: 10E-6 BER limit: 10E-5
Note: When one E1 channel ‘s BER limit is beyond
the setting by pin 8, the device will automatically stop
transmitting data through this channel.
F5-4513 User Manual V3.2
- 7 -
Table 3: Ethernet Mode Description
Pin1 Pin2 Description
OFF OFF 10/100Mbps, Half/Full DuplexAuto-Negotiation
OFF ON 10Mbps, Half/Full Duplex Auto-Negotiation
ON ON 10Mbps, Full Duplex
ON OFF 100Mbps, Full Duplex
4.4 Factory Setting of DIP Switch:
PIN 1 2 3 4 5 6 7 8
Stat. OFF OFF ON ON ON OFF OFF ON
4.5 Rear Panel
Definition of the 120ohm:
Pin 3 4 5 6 2,7 Other
Def. TX+ TX- RX- RX+ GND N.A.
Power Input E1 Channel
F5-4513 User Manual V3.2
- 8 -
4.6 Button ‘IN’ & ‘OUT’
When press button IN down, the round of the ‘IN
port’ of each E1 channel will be connected to GND,
When let button IN up, the round of the ‘IN port’ of
each E1 channel will float.
When press button OUT down, the round of the
‘OUT port’ of each E1 channel will be connected to
GND, When let button OUT up, the round of the ‘OUT
port’ of each E1 channel will float.
From below figure, you can find the meaning of
‘round’ and ‘tip’.
5. Application
TIP
Round
BNC
EthernetEthernet
F5-4513 F5-4513
SDH/PDH
4E1 4E1
F5-4513 User Manual V3.2
- 9 -
In point-point application, the F5-4513 should be
used in pairs.
6. Order Information
Model:
F5-4511 Ethernet to 1-8 E1 Protocol Converter
Series
P/N:
F5-4513A 10/100Mbps Ethernet to 4E1
converter, standalone, 220VAC power
F5-4513D 10/100Mbps Ethernet to 4E1
converter, standalone, -48VDC power
