Fiat New 500 Guide de l'utilisateur

Dear Customer,

We would like to congratulate and thank you for choosing the Fiat New 500.

We have written this handbook to help you get familiar with all the features of your car.

Here you will find information, advice and important warnings regarding use of your car and how to achieve the best

performance from the technical features of your Fiat New 500.

You are advised to read it right through before taking to the road for the first time, to become familiar with the controls; at the

same time, you can understand the car behaviour on different road surfaces.

This document contains specifications, special procedures and essential information for caring for and maintaining your Fiat

New 500 over time, driving it safely and running it correctly.

After reading it, you are advised to keep the handbook inside the car, for an easy reference and for making sure it remains on

board the car should it be sold.

In the attached Warranty Booklet you will also find a description of the Services that Fiat offers to its customers, the Warranty

Certificate and the detail of the terms and conditions for maintaining its validity.

We are sure that these will help you to get in touch with and appreciate your new car and the service provided by the people at

Fiat.

Enjoy reading. Happy driving!

ATTENTION

All the versions of the Fiat New 500 are described in this Owner Handbook. Options, equipment dedicated to

specific markets or versions are not explicitly indicated in the text: as a consequence, you should only consider the

information which is related to the trim level, motor and version that you have purchased. Any content introduced

throughout the production of the model, outside the specific request of options at the time of purchase, will be

identified with the wording (where provided). All data contained in this publication are purely indicative. FCA Italy

S.p.A. can modify the specifications of the car model described in this publication at any time, for technical or

marketing purposes. For further information, contact a Fiat Dealership.

ESSENTIAL INFORMATION!

STARTING THE ENGINE

With the transmission in position P (Park), when the ignition device is brought to the ENGINE position, an acoustic warning

is emitted and the message "READY" appears on the instrument panel display to indicate that the electric traction system of

the the New 500 has started. The New 500 is now ready to go.

ELECTRICAL ACCESSORIES

If, after buying the car, you decide to add electrical accessories (with the risk of gradually draining the 12V battery), contact a

Fiat Dealership. They can calculate the overall electrical requirement and check that the car's electric system can support the

required load.

SCHEDULED SERVICING

Correct maintenance of the car is essential for ensuring that it maintains its performance and its safety features, its

environmental friendliness and low running costs for a long time to come.

USE OF THE OWNER HANDBOOK

OPERATING INSTRUCTIONS

Each time an instruction is given that concerns direction (left/right or forward/backward), it is written to be read from the

perspective of an occupant in the driver's seat. If a direction is written from a different perspective, it will be specified as such in

the text as appropriate.

The figures in the Owner Handbook are provided by way of example only: this might imply that some details of the image do

not correspond to the actual arrangement of your car. In addition, the Handbook has been conceived considering vehicles

with steering wheel on the left side; it is therefore possible that on vehicles with steering wheel on the right side, the position or

construction of some controls is not exactly mirror-like with respect to the figure.

To identify the chapter with the information needed you can consult the index at the end of this Owner Handbook.

The sections can be rapidly identified with dedicated graphic tabs, at the side of each odd page. A few pages further there is

a key for getting to know the section order and the relevant symbols in the tabs. There is in any case a textual indication of the

current section at the side of each even page.

WARNINGS AND CAUTIONS

While reading this Owner Handbook you will find a series of WARNINGS to prevent procedures that could damage your car.

There are also PRECAUTIONS that must be carefully followed to prevent incorrect use of the components of the car, which

could cause accidents or injuries.

Therefore, all WARNINGS and CAUTIONS must always be carefully followed.

WARNINGS and CAUTIONS are recalled in the text with the following symbols:

personal safety;

car safety;

environmental protection.

NOTE These symbols, when necessary, are indicated besides the title or at the end of the line and are followed by a number.

That number recalls the corresponding warning at the end of the relevant chapter.

SYMBOLS

Some car components have coloured labels with symbols indicating precautions to be observed when using this component.

CHANGES/ALTERATIONS TO THE CAR

WARNING Any change or alteration of the car might seriously affect its safety and road grip, thus causing accidents, in which

the occupants could even be fatally injured.

WARNING The use of these devices inside the passenger compartment (without an external aerial) may cause the electrical

systems to malfunction. This could compromise the safety of the car in addition to constituting a potential hazard for

passengers' health.

ACCESSORIES PURCHASED BY THE OWNER

If after buying the car, you decide to install electrical accessories that require a permanent electrical supply (e.g. radio, satellite

anti-theft system, etc.) or accessories that in any case burden the electrical supply, contact a Fiat Dealership, whose personnel

will check whether the car's electrical system is able to withstand the load required, or whether it needs to be integrated with a

more powerful 12V battery.

WARNING Take care when fitting additional spoilers, alloy wheel rims or non-standard wheel hubs: they could reduce the

ventilation of the brakes and affect efficiency under sharp, repeated braking or on long descents. Make sure that nothing

obstructs the pedal stroke (mats, etc.).

INSTALLING ELECTRICAL/ELECTRONIC DEVICES

Electrical and electronic devices installed after buying the car in the context of after-sales service must carry the following label

FCA Italy S.p.A. authorises the installation of transceivers provided that installation is carried out at a specialised centre, in a

workmanlike fashion and in compliance with manufacturer's specifications.

WARNING Traffic police may not allow the car on the road if devices have been installed which modify the features of the car.

This may also cause invalidation of warranty in relation to faults caused by the change either directly or indirectly related to it.

FCA Italy S.p.A. shall not be liable for damage caused by the installation of accessories either not supplied or recommended by

Fiat and/or not installed in compliance with the provided instructions.

RADIO TRANSMITTERS AND MOBILE PHONES

Radio transmitter equipment (car mobile phones, CB radios, amateur radio etc.) cannot be used inside the car unless a

separate aerial is mounted on the roof.

Transmission and reception of these devices may be affected by the shielding effect of the car body. As far as the use of EC-

approved mobile phones is concerned (GSM, GPRS, UMTS, LTE), follow the usage instructions provided by the mobile phone

Manufacturer.

WARNING The use of these devices inside the passenger compartment (without an external aerial) may cause the electrical

systems to malfunction. This could compromise the safety of the car in addition to constituting a potential hazard for

passengers' health.

GRAPHICAL INDEX

KNOWING YOUR CAR

KNOWING THE INSTRUMENT PANEL

SAFETY

STARTING AND DRIVING

IN AN EMERGENCY

MAINTENANCE AND CARE

TECHNICAL SPECIFICATIONS

MULTIMEDIA
