Sound selection table
1 Alt rnat two-ton 800 - 1000 0.5 1 1 1 1 1 Fir Alarms
2 Alt rnat two-ton 2500 - 3100 0.5 0 1 1 1 1 S curity Alarms
3 Alt rnat fast two-ton 800 - 1000 0.25 1 0 1 1 1 Incr as d urg ncy
4 Alt rnat fast two-ton 2500 - 3100 0.25 0 0 1 1 1 S curity d t rr nt
5 Alt rnat two-ton 440 - 554 0.4/0.1 1 1 0 1 1 AFNOR, Franc
6 Alt rnat two-ton 430 - 470 1.0 0 1 0 1 1
7 Alt rnat v. fast two-ton 800 - 1000 0.13 1 0 0 1 1
8 Alt rnat v. fast two-ton 2500 - 3200 0.07 0 0 0 1 1
9 Alt rnat two-ton 440 - 554 2.0 1 1 1 0 1 Turn-out, Sw d n
10 Continuous ton 700 - 0 1 1 0 1 All-cl ar, Sw d n
11 Continuous ton 1000 - 1 0 1 0 1
12 Continuous ton 1000 - 0 0 1 0 1
13 Continuous ton 2300 - 1 1 0 0 1
14 Continuous ton 440 - 0 1 0 01
15 Int rrupt d ton 1000 2.0 1 0 0 0 1
16 Int rrupt d ton 420 1.25 0 0 0 0 1 AS2220, Australia
17 Int rrupt d ton 1000 0.5 1 1 1 1 0
18 Int rrupt d ton 2500 0.25 0 1 1 1 0
19 Int rrupt d ton 2500 0.5 1 0 1 1 0
20 Int rrupt d ton 700 6/12 0 0 1 1 0 Pr -vital m ss, Sw d n
21 Int rrupt d ton 1000 1.0 1 1 0 1 0
22 Int rrupt d ton 700 4.0 0 1 0 1 0 Air-raid, Sw d n
23 Int rrupt d ton 700 0.25 1 0 0 1 0 Local warning, Sw d n
24 Int rrupt d ton 720 0.7/0.3 0 0 0 1 0 Industrial alarm, G rmany
25 Int. fast rising volum 1400 0.25 1 1 1 0 0
26 Fast sir n 250 - 1200 0.085 0 1 1 0 0
27 Rising constant, fall 1000 10/40/10 1 0 1 0 0 Industrial alarm, G rmany
28 ISO 8201 Evacuation 800 - 1000 as std 0 0 1 0 0 Int. vacuation alarm
29 Fast whoop 500 - 1000 0.15 1 1 0 0 0
30 Slow whoop 500 - 1200 4.5 0 1 0 0 0 Evacuation, Th N th rlands
31 R v rs sw ap 1200 - 500 1 1 0 0 0 0 Evacuation, G rmany
32 Sir n 500 - 1200 3.0 0 0 0 0 0
Switch s ttings: ON=1 und OFF=0
First and Second Stage Fre uency / Rept. Switches Special
Hz rate 1 2 3 4 5 Application
The PFEER sound signals recommended by UKOOA are:
G n ral Alarm Sound signal 15 Int rrupt d ton 1000 Hz
PAPA Sound Signal 31 R v rs Sw p 1200-500 Hz
Toxic Gas Sound Signal 11 Continuous Ton 1000 Hz
Warning:
Loud alarm sound. Wear ear defenders when testing,
installing and commissioning.
Housing Polycarbonat
Colour R d, similar to RAL 2002
Insulation class II
Prot ction d gr IP 65 acc. to IEC 60529
Cabl gland int nd d for M20 x 1.5 or S lf-s aling gromm t
Volum approx. 97-110 dB(A) (d p nding on signal ton )
Signals 32 diff r nt signal ton s, s diagrams
2nd stag can b turn d on xt rnally
Tmp ratur rang
Op ration -25 °C to +55 °C
Storag -40 °C to +70 °C
Wight AC 0.4 kg / DC 0.3 kg
Op rating voltag 24 VDC, 115 VAC, 230 VAC
Conn cting t rminals Clamping capacity 2.5 mm2solid conductor / 1.5 mm2strand d conductor
Technical Data
