Festool CLEANTEX CT 26 E Manuel utilisateur

702632_009

Festool GmbH

Wertstraße 20

D-73240 Wendlingen

Tel.: +49 (0)7024/804-0

Telefax: +49 (0)7024/804-20608

www.festool.com

Instruction manual

Page 6

IMPORTANT:

Read all instructions before using.

Guide d’utilisation

Page 18

IMPORTANT:

Lire toutes les instructions avant de démarrer les travaux.

Manual de instrucciones

Página 30

IMPORTANTE:

Lea todas las instrucciones antes de usar.

Instruction manual

Guide d’utilisation

Manual de instrucciones

CT 26 E HEPA

CT 36 E HEPA

CT 48 E HEPA

DISTRIBUTED BY:

Pro Wood Finishes

14622 Southlawn Lane

Rockville MD 20850

Ph: (301) 424-3033

2-2

2-3

2-1

1-4

1-7

1-1

1-3

1-2

1-5

1-6

1-9

1-10

1-11

1-12

1-8

Contents

Symbols

About this manual

Save these instructions

It is important for you to read and understand this manual. The information it contains relates to protecting

your safety

and

preventing problems

. The symbols below are used to help you recognize this information.

Symbols ............................................... 6

About this manual................................ 6

Safety instructions............................... 7

Technical data ...................................... 9

Functional description ......................... 10

Intended use ........................................ 10

Operation ............................................. 10

Settings................................................ 12

Working ................................................ 12

Filter..................................................... 13

After finishing work ............................. 15

Service and maintenance .................... 16

Accessories.......................................... 16

Disposal ............................................... 17

Sym-

bol

Significance

Warning of general danger

Risk of electric shock

Read operating instructions and safety

notices!

Wear a dust mask.

Tip or advice

Handling instruction

Wwatt

hhour

min minutes

sseconds

kg kilograms

Pa pascal

dB decibel

Vvolts

Aamperes

Hz hertz

~ a.c. alternating current

d.c. direct current

no load speed

Class II construction

rpm

min

-1

revolutions per minute

’’ inch

lbs. pound

diameter

Sym-

bol

Significance

DANGER Description of imminent haz-

ard and failure to avoid hazard

will result in death.

WARNING Description of hazard and

possible resulting injures or

death.

CAUTION Description of hazard and

possible resulting injuries.

NOTICE Statement including nature of

hazard and possible result.

HINT Indicates information, notes,

or tips for improving your suc-

cess using the tool.

Safety instructions

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basis precautions should always be followed, including the following:

READ ALL INSTRUCTIONS

BEFORE USING THIS DUST EXTRACTOR

WARNING

- To reduce the risk of fire, electric shock, or injury:

–Donotleavethedustextractorwhenplugged in. Unplug from outlet when not in use

and before servicing.

–Useindoorsonly.

–Donotallowtobeusedasatoy.Closeattention is necessary when used by or near

children.

–Useonlyasdescribesinthismanual.Use only manufacturer's recommended at-

tachments.

–Donotusewithdamagedcordorplug.Ifthe dust extractor is not working as it

should, has been dropped, damaged, left outdoors, or dropped into water, return it

to a service center.

–Donotpullorcarrybycord, use cord as a handle, close a door on cord, or pull cord

around sharp edges or corners. Do not run dust extractor over cord. Keep cord away

from heated surfaces.

–Donotunplugbypullingoncord.Tounplug,grasptheplug,notthecord.

–Donothandleplugordustextractorwithwethands.

–Donotputanyobjectintoopenings. Do not use with any opening blocked; keep free

of dust, lint, hair, and anything that may reduce air flow.

–Keephair,looseclothing,fingers,andall parts of body away from openings and

moving parts.

–Turnoffallcontrolsbeforeunplugging.

–Useextracarewhencleaningonstairs.

–Donotusetopickupflammableorcombustible liquids, such as gasoline, or use in

areas where they may be present.

–Connecttoaproperlygroundedoutlet only. See Grounding instructions.

–Donotpickupanythingthatisburningorsmoking,suchascigarettes,matches,or

hot ashes, hot chips or particles, sparks.

–Donotusewithoutdustbagand/orfiltersinplace.

SAVE THESE INSTRUCTIONS

GROUNDING INSTRUCTIONS

This appliance must be grounded. If it should malfunction or breakdown, grounding pro-

vides a path of least resistance for electric current to reduce the risk of electric shock.

This dust extractor is equipped with a cord having an equipment-grounding conductor

and grounding plug. The plug must be inserted into a appropriate outlet that is properly

installed and grounded in accordance with all local codes and ordinances.

WARNING

- Improper connection of the equipment grounding conductor

can result in a risk of electric shock. Check with a qualified electrician or service person

if you are in doubt as to whether the outlet is properly grounded. Do not modify the plug

provided with the dust extractor - if it will not fit the outlet, have a proper outlet installed

by a qualified electrician.

This appliance is for use on a nominal 120-V circuit

and has a grounding attachment plug that looks like

the plug illustrated in sketch A in Figure beside.

Make sure that the appliance is connected to an out-

let having the same configuration as the plug. No

adaptor should be used with this appliance.

Polarization Instructions

To reduce the risk of electric shock, this vacuum

cleaner has a polarized plug (one blade is wider than

the other). This plug will fit in a polarized outlet only

one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not

fit, contact a qualified electrician to install the proper outlet. Do not change the plug

in any way.

Further safety instructions

–Thisappliancemustnotbeused by persons (including children) with reduced phys-

ical, sensory or mental capabilities, or lack of experience and knowledge.

Children

need to be supervised to ensure they do not play with the appliance.

GROUNDED

OUTLET BOX

GROUNDED

OUTLET

GROUNDING METHODS - SKETCH A

CAUTION

This machine is for indoor use only.

This machine shall be stored indoors only.

Health hazard by dust

WARNING!

Various dust created by power sanding, sawing, grinding, drilling and other construction

activities contains chemicals known (to the State of California) to cause cancer, birth defects or other

reproductive harm. Some examples of these chemicals are:

•leadfromlead-basedpaints,

•crystallinesilicafrombricksandcementandother

masonry products, and

• arsenic and chromium from chemically treated

lumber.

The risk from these exposures varies,

depending on how often you do this type

of work. To reduce your exposure to

these chemicals: work in a well ventilated area, and

work with approved safety equipment, such as dust

masks that are specially designed to filter out micro-

scopic particles. Wash hands after handling.

Technical data

WARNING

TO REDUCE THE RISK OF INJURY, USER MUST

READ INSTRUCTION MANUAL.

Dust extractor CT 26 E, CT 36 E, CT 48 E

Power consumption (dust extractor only) 2.9 - 8.3 A (350 - 1000 W)

Total connected load max. 12 A (1440 W)

Max. rating of connected Power Tool 3.7 A

2.)

Volume flow (air), turbine max. 234 m³/h (8264 cu.ft./h)

Vacuum, turbine max. 24000 Pa

Filter surface 6318 cm²(979.3 sq.in.)

Suction hose (diameter x length) 27 mm x 3.5 m (1-1/16" x 11.5’)

Protection type IP X4

Sound pressure level as per IEC 60704-2-1 71 dB(A)

Container capacity CT 26 E 26 l (6.9 gal.)

CT 36 E 36 l (9.5 gal.)

CT 48 E 48 l (12.7 gal.)

Dimensions L x W x H CT 26 E 630 x 365 x 540 mm

(24.8" x 14.4" x 21.3")

CT 36 E 630 x 365 x 596 mm

(24.8" x 14.4" x 23.5")

CT 48 E 715 x 392 x 680 mm

(28.1" x 15.4" x 26.8")

Weight CT 26 E 13 kg (28.7 lbs)

CT 36 E 14.4 kg (31.8 lbs)

CT 48 E 16.3 kg (35.9 lbs)

1. ) 8.3 A (1000 W) is the medium value for different operation conditions, a maximum power consumption of 10 A (1200 W) is possible.

2. ) When the suction power adjuster [1-7] is adjusted to the lowest suction power (see page 12, chapter Settings - Adjusting the suction

power) the maximal rating of a connected power tool can be 9.1 Amps.

Functional description

The pictures for the functional description are on a

fold-out page at the beginning of the instruction

manual. When reading of the manual you can fold

out this page for having always an overview of the

machine.

Accessories shown or described are sometimes not

included in the scope of delivery.

Intended use

The dust extractor is designed for use as specified

for the aspiration and evacuation of non-noxious

dusts, dirt, sand, shavings etc..

The dust extractor is designed as specified for vac-

uuming water.

The dust extractor is designed for household, com-

mercial or both use.

The dust extractor is designed for outdoor use and

indoor storage.

The filtering performance of the overall unit, which

is fitted with a HEPA filter element, corresponds to

HEPA quality 13 (medium degree of filtration

99.95%).

All CT extractors fitted with the HEPA filter element

have HEPA certification both for the filter material

and the whole dust extractor.

Operation

Consider the pictures on the fold-out page.

Initial operation



Open the locking clips

[2-2]

and remove the top

section of the machine

[2-1]



Remove the accessories from the dust contain-

[2-3]

and the packaging!



Insert a filter bag in the dust container (see

chapter "Changing the filter bag").



Attach the cable holder to the rear of the mobile

dust extractor (see Fig.

[3]

[1-1]

Intake opening

[1-2]

Module slot

[1-3]

Appliance socket

[1-4]

Hose store

[1-5]

Handle

[1-6]

SysDoc

[1-7]

Suction power adjuster

[1-8]

Switch

[1-9]

Locking clip

[1-10]

Dust container

[1-12]

Brake

WARNING

The user will be liable for damage due to improp-

er use.

WARNING

Unauthorised voltage or frequency!

Risk of accident



The mains voltage and the frequency of the pow-

er source must correspond with the specifica-

tions on the machine's name plate.



In North America, only Festool machines with

the voltage specifications 120 V/60 Hz may be

used.



Replace the top section

[2-1]

and close the

locking clips

[2-2]



Connect the suction hose to the machine.

Switch on/off



Insert the plug into an earthed socket.

The switch

[1-8]

serves as an On/Off switch. It has

three positions:

Switch position "0"

Appliance socket

[1-3]

is disconnected from the

power, mobile dust extractor is switched off.

"MAN" switch position

Appliance socket

[1-3]

is disconnected from the

power, the mobile dust extractor starts.

"Auto" switch position

Appliance socket

[1-3]

is connected to the power,

the mobile dust extractor starts when the connect-

ed tool is switched on.

Extension Cord

If an extension cord is required, it must have suffi-

cient cross-section to prevent an excessive drop in

voltage or overheating. An excessive drop in voltage

reduces the output and can lead to failure of the

motor. The table below shows you the correct cord

diameter as a function of the cord length for this

tool.

Use only U.L. and CSA listed extension cords.

Never use two extension cords together. Instead,

use one long one.



The lower the AWG number, the stronger the

cord.

The antistatic system

Friction inside the extraction hose causes static

electricity to develop during extraction. Operating

personnel may receive unpleasant electric shocks

while working. The mobile dust extractor is fitted

with an antistatic system as standard to discharge

any static electricity that may develop. However, al-

ways use the enclosed antistatic extraction hose.

CAUTION

Risk of injury from tools starting up unexpectedly



Before setting the switch to the "AUTO" or

"MAN" position, make sure that the connected

tool is switched off.

Total Extension Cord

Lenght (feet)

25 50 100 150

Cable size (AWG) 14 12 not recom-

mended

Settings

Consider the pictures on the fold-out page.

Connecting electric power tools



Connect the electric power tool to the appliance

socket

[1-3]

Connecting pneumatic tools

If the compressed air module

[1-2]

(496141) is in-

stalled, the automatic switch-on function of the

mobile dust extractor also works in combination

with pneumatic tools.

We also recommend installing the VE service unit

(495886). The service unit filters and lubricates the

compressed air and enables an adjustment of the

air pressure. An IAS adapter (454757) is available to

connect Festool pneumatic tools to the IAS system.

The operating pressure of the tool must be 6 bar for

the automatic switch-on unit to function correctly.

Temperature cut-out

To prevent overheating, a temperature cut-out

switches the mobile dust extractor off when it

reaches a critical temperature.



Switch off the mobile dust extractor and allow to

cool for about 5 minutes.



If the mobile dust extractor will not switch on

again, please contact a Festool service workshop.

Adjusting the suction power

You can use the suction power adjuster

[1-7]

to adapt

the machine suction power to different applications.

Applying the brake

Folding out the brake lever

[1-12]

prevents the mo-

bile dust extractor from rolling. To achieve this, lift

the front end of the mobile dust extractor slightly

and push the brake lever downwards until it latches

into place. Push the lever

[1-11]

again to release.

Working

Handling

Hose store:

after finishing work, you can feed the

suction hose through the recess

[4-3]

and place it

in the hose store. You can do the same with the

mains cable through the other recess

[4-2]

SysDoc Systainer attachment system:

a Systainer

can be attached to the storage area via the two

slides

[4-1]

WARNING

Risk of injury



Observe the maximum appliance socket con-

nected load (see chapter "Technical data")



Switch off the electric power tool.

WARNING

Risk of injury



Make sure that the pneumatic tool is switched

off before connecting or disconnecting.

4-1 4-2

4-3

Extracting dry materials

Remember:

A damp main filter will clog more

quickly when dry materials are extracted. There-

fore, dry the main filter before extracting dust or re-

place the damp filter with a dry one.

Extracting fluids



The main filter shall only be used for extracting

dry materials.

Before extracting fluids, remove the filter bag (see

chapter "Changing the filter bag"). We recom-

mend using a special wet filter.

The dust extractor stops automatically when the

maximum level is reached.

Filter

Changing the filter bag

Inserting the filter bag



Open the locking clips

[2-2]

and remove the top

section of the machine

[2-1]



Insert a new filter bag (SC-FIS-CT 26/36/48)

(Fig.

[5]

) in the inlet port of the dust container

and interlock it.

Important:

be aware that the

locking engages.



Make sure that the filter bag is not pinched be-

tween the top and bottom sections.



Replace the top section

[2-1]

and close the

locking clips

[2-2]

Removing the filter bag



Open the locking clips

[2-2]

and remove the top

section of the machine

[2-1]



Remove the filter bag (Fig.

[6]



Dispose of the used bag in accordance with stat-

utory regulations.



Clean the dust container

[2-3]



Insert a new filter bag if necessary (see Insert-

WARNING

Not suitable to vacuum hazardous or toxic sub-

stances or dusts e.g. asbestos.



The filters will not be able to capture all particles

and may exhaust them back into the environment.

WARNING

Risk of injury



Do not evacuate combustible liquids!

CAUTION

Escaping foam and fluids



Switch off the machine immediately and empty

the dust container.

WARNING

Risk of injury



During the following procedure, take care not to

raise dust more than is unavoidable. Moisten the

main filter with a water spray before removing it.

SC-FIS-CT 26/36/48

Autres manuels pour CLEANTEX CT 26 E

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Festool Aspirateur

Festool

Festool CLEANTEX CT 26 E Manuel utilisateur

Festool

Festool CLEANTEX CT 26 E Manuel utilisateur

Festool

Festool CTL MINI Instructions d'installation

Festool

Festool CLEANTEX CT 26 E Manuel utilisateur

Festool

Festool CLEANTEX CTL 26 E SD Instructions d'installation

Festool

Festool CTM 26 E AC Manuel utilisateur

Festool

Festool CLEANTEX CTL 26 E SD Instructions d'installation

Festool

Festool Cleantec Series Instructions d'installation

Festool

Festool CT 15 E HEPA Manuel utilisateur

Festool

Festool Planex Mode d’emploi

Festool

Festool CT 22 E Manuel utilisateur

Festool

Festool CT 15 E HEPA Manuel utilisateur

Festool

Festool CTL SYS Instructions d'installation

Festool

Festool CT 22 E Manuel utilisateur

Festool

Festool CTH 26 E/a Instructions d'installation

Festool

Festool CT 22 E Manuel utilisateur

Festool

Festool CTM 22 E SG Manuel utilisateur

Festool

Festool CTC SYS I Manuel utilisateur

Festool

Festool CLEANTEX CT 36 E AC Manuel utilisateur

Festool

Festool CTL 48 E LE EC/B22 R1 Instructions d'installation

Festool

Festool CTL 22 E SG Instructions d'installation

Festool

Festool CLEANTEX CTL 26 E SD Instructions d'installation

Festool

Festool CTL 26 E Manuel utilisateur

Festool

Festool CTL 48 E LE EC/B22 Instructions d'installation

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
