Ferrules Direct FD100K Manuel utilisateur
FD100K
Operating Instructions
Terminal Crimping Machine
FD100K
Operang Instrucons
2
Product Description
FERRULES DIRECT’S FD100K pneumatic press is a versatile, heavy
duty machine capable of crimping wire ferrules ranging from 24
to 06 AWG (.25mm2to 60.00mm2) as well as terminals and con-
nectors 24 to 6 AWG (.25mm2 to 16.00mm2).
• Versatile: Die sets can be changed in seconds, A full selection
of crimping die sets( sold seperately) complement the FD100K.
• Powerful: With a 1.35T compression force, FD100K can crimp
all types of terminals and connectors including: wire ferrules,
coaxial cables, open barrel terminals, and ag terminals.
• Heavy Duty: A Veritable work horse, the FD100K press is ideal
for crimping large quantities of terminals
• Light Weight: Weighing only 12.20 lbs (6.0kg), the FD100K
crimping press can easily be trans ported from one location
to another.
FD100K Operang Instrucons
3
Installation and Operation
1. Make sure that the air tubing and compressed air source is
disconnected
2. Remove the screws that secure the die set, located in the
crimping head
3. Place the selected die set in the now available slot, tighten
the screws fully to prevent movement while crimping
4. Connect the air tubing to the ports located on the side of the
FD100K and the foot pedal
5. The FD100K is now ready to use, while crimping keep your
hands clear of the crimping head to prevent personal injury
Maintenance and Storage
• Lubricate moving parts every 10,000 crimping cycles by add-
ing a few drops of a normal lubricant used for this purpose.
• Every few months, check that all bolts and screws are still
properly tightened. Proceed accordingly if they are not.
• Do not operate crimping press in environments with very high
or very low temperature or with high humidity, recomended
operating conditions: 40 °F to 120 °F.
• When not in use remove all tubing and cover open ports with
dust caps
• Keep machine in a dry, cool place and cover it with a suit-
able blanket to avoid dust and possible rust spot
FD100K
Operang Instrucons
4
Name ........................................Pneumatic Type Crimping Machine
Model # .................................................................................... FD100K
Output Force ................................................................................ 1.35T
Recommended Air pressure ..................... Between 80 and 100 psi
Crimping Range ....................................................... WF : 24-06 AWG
T&C : 24-06 AWG
Dimensions ...................... 10.20 x 4.70 x 5.50” (260 x 120 x 140 mm)
Weight ...................................................................... 12.20 lbs (6.0 kg)
Maintenance and Storage
Service Condition and Notes
• The uid used for the equipment: compressed air
• Use environment and uid temperature: 5-60oC
• The medium this equipment cylinder can only be used after
it is processed by a lter element of 40 um and above (the
compressed air can only be used for the clylinder after it has
gone through an air lter)
• The corresponding air tube and joint shall be chosen for the
pipeline connecting to the equipment and internal dirty ob-
ject must be removed, in order to prevent the sundry into the
cylinder from damage to the cylinder.
• When crimping big terminals, please ensure the air source
and air pressure is suficient.
• If it is used in low temperature environment, antifreeze mea-
sures should be taken to prevent water in the system from
freezing.
FD100K Operang Instrucons
5
Compatible Die Sets
22-18 AWG
22mm Wide
WDC2208D
08-04 AWG
FD1025RVD
22-10 AWG
FDT10011D
24-10 AWG
FDT10040D
10-04 AWG
WDC1004D
04-01 AWG
WDC0401D
22-10 AWG
FDT10023D
22-10 AWG
FDT10043D
10-04 AWG
22mm Wide-
WDC1004-22D
02-01 AWG
RD3550RVD
08-06 AWG
FDT10024D
24-10 AWG
FDT10044D
26-08 AWG
WDC2807
26-10 AWG
FDT10010D
22-08 AWG
FDT10020D
22-14 AWG
FDT10050D
FD100K
Operang Instrucons
6
Compatible Die Sets
14-10 AWG
FDT10051D
18-14 AWG
FDT10055D
Coaxial Cable
FDT1008121D
Coaxial Cable
FDT1008161D
Coaxial Cable
FDT1008181D
12-10 AWG
Flag Terminal
FD11GVD
Coaxial Cable
FDT1008171D
22-10 AWG
FDT10052D
12-10 AWG
FDT10058D
Coxial Cable
FDT1008131D
Coxial Cable
FDT1008141D
Coxial Cable
FDT1008151D
22-14 AWG
FDT10053D
22-10 AWG
FDT10060D
20-18 AWG
FDT10054D
Coaxial Cable
FDT1008111D
FD110K Operang Instrucons
Imporant Safety Information
• Use this product only according to these instructions. Improper
use can create hazards
• Wear ANSI-approved safety goggles and heavy duty work
gloves during use.
• Keep hands and ngers away from the crimping dies when
using this product. This tool creates approximately 2.5 tons of
crimping tools
• NEVER attempt to crimp wires that are plugged into an outlet
and are electrically charged.
• Refer to the wire manufacturer’s instruction manual for specic
wire crimping instructions prior to using this product.
• Keep area clean and well lit.
• Do not overreach. Keep proper footing and balance at all
times. This enables better control of the product in unexpected
situations.
• Keep bystanders out of the area during product assembly and
use.
• Do not assemble or operate when tired or when under the
inuence of drugs or medication.
• This product is not a toy. Do not allow children with or near this
product.
• Use for intended purpose(s) only.
• Inspect before use. Do not use if parts are missing or damaged.
• Maintain product label and name plates. These carry
important, If unreadable or missing, contact Ferrules Direct.
7
Visit us at www.FerrulesDirect.com
We oer an extensive selection of terminals and ferrules to complement
the FD100K Pneumatic Crimping Press. Please visit out website to see
our variety of products at incredibly low prices!
Find us on social media!
Facebook.com/FerrulesDirect
Twier.com/FerrulesDirect
Instagram.com/FerrulesDirect
Youtube.com/FerrulesDirect
