FERREX 705158 Manuel utilisateur
User Manual
705158
1100 W TURBINE BLOWER
Read all safety warnings and all instructions
thoroughly before operating this product.
Ensure you keep your manual in a
safe place for future reference.
IM ed 2; 03/2022
Product
Info
MODEL No.: TGT2001, PRODUCT No.: 700069
QR codes take you where you want to go
quicky and easily
Whether you require product information, spare parts or accessories,
details on warranties or after sales service, or if you want to watch
a product demonstration video, our QR codes will take you there in
no time at all.
What is a QR code?
A QR-code (QR=Quick Response) is a type of matrix that can be read
with a smartphone camera and that contains a link to a website or
contact details, for example.
Advantage: You are not required to manually enter a website address
or contact details.
How it works
To scan the QR code, all you need is a smartphone with QR codes reader
software and an Internet connection*. This type of software can be
downloaded for free from your smartphone’s app store.
Try it out now
Just scan the QR code with your smartphone and
nd out more about the Aldi product you have
purchased*.
* Depending on your tari you may be charged
for the connection.
Product
Info
REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION.
The product is guaranteed to be free from defects in workmanship and parts for a period of 36 months from the
date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired,
replaced or refunded at our discretion. The benets conferred by this warranty are in addition to all rights and
remedies in respect of the product that the consumer has under the Competition and Consumer Act 2010 and
similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
Warranty details
AFTER SALES SUPPORT
(toll free)
MODEL No.: GBV100W •03/2022 •705158
3
1100 W Turbine Blower
MODEL No.: GBV100W, PRODUCT No.: 705158
Contents
Pack contents / parts 2
Description of symbols 3
General Safety Warnings 5
Parts List 8
Assembly 10
Unpacking 10
Assembling and disassembling the upper blower tube 10
Assembling the lower blower tube 11
Nozzle 11
Attaching the extension cord 11
Operation 12
Starting & stopping 12
Using the blower 12
Adjusting the blowing speed with 2-speed switch 13
Residual risk 13
Maintenance 14
Clean and Storage 14
Cleaning the blower 14
Storage 14
Warranty 15
Environmental Protection 15
What your 3 year warranty means 16
Service Support 16
Accessories and After Sales Parts 16
Troubleshooting 17
Technical Specications 17
MODEL No.: TGT2001, PRODUCT No.: 700069 3
Congratulations on the purchase of your FERREX® 1100 W Turbine Blower. When
you open your packaging, rst remove all items and check there are no parts
damaged or missing. If you nd anything wrong, do not operate the product
until the parts have been replaced or the fault has been rectied. Failure to do so
could result in serious personal injury.
Application
First time users or inexperienced operators pay particular attention to the
operation of the 1100 W Turbine Blower, including details of starting and
stopping and correct use of the 1100 W Turbine Blower on pages 12-13, as well
as the maintenance instructions on page 13.
Intended use of the 1100 W Turbine Blower
It is exclusively intended for home use. It is not designed for trade or commercial
use.
This 1100 W Turbine Blower is intended for residential use only. Use the blower
outdoors to move yard debris as needed.
Any other use or change to the appliance is deemed improper and poses a
signicant risk of accidents.
Contents of carton
1 x 1100 W Turbine Blower
1 x Upper Tube
1 x Lower Tube & Nozzle
1 x Instruction Manual
1 x Warranty Card & details
Pack contents / parts
2
MODEL No.: GBV100W, PRODUCT No.: 705158
MODEL No.: TGT2001, PRODUCT No.: 70096
Description of symbols
The instruction manual, rating plate, or on the product itself, may show
these symbols. These represent important information about the product or
instructions on its use.
To reduce the risk of injury, user must read instruction manual
Keep bystanders away.
Warning of hazard
SWITCH OFF: Remove plug from mains before cleaning or
maintenance.
Do not use in the rain or leave outdoors while it is raining.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
Wear eye protection.
32 MODEL No.: GBV100W, PRODUCT No.: 705158
MODEL No.: GBV100W, PRODUCT No.: 705158 4
36
Box
Conforms to relevant standards for electrical safety and electromagnetic
compatibility.
Warning
Class II equipment
36 Months Warranty
The box is recyclable at the kerbside.
The inserts are recyclable at the kerbside.
Noise label rating 100db(A). You must wear ear protection at all times.
100
MODEL No.: GBV100W, PRODUCT No.: 705158
WARNING! Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric shock, re and/
or serious injury.
Save all warnings and instructions for future reference.
- This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction con-
cerning use of the appliance by a person responsible for their safety.
- Children should be supervised to ensure that they do not play with the
appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
The appliance is designed only for blowing of dry leaves in private house-
holds and as a hobby appliance in the garden. Any other utilization, which is
not explicitly approved in these directions, can lead to damage to the
appliance and represent a serious danger to the user.
• The appliance is designed for use by adults. Young people over 16 years
may use the appliance under supervision only.
• The use of the appliance in the rain or in a humid environment is
forbidden.
• The manufacturer is not liable for damage which is caused through
inappropriate use or incorrect operation.
NOTE: Do not use the machines with low power for heavy work. DO NOT use
your appliance for purposes for which it has not been designed.
WARNING! To reduce the risk of injury, user must read and
understand instruction manual.
5
General safety warnings
MODEL No.: GBV100W, PRODUCT No.: 705158 6
1) Training
a) Read the instructions carefully. Be familiar with the controls and the proper
use of the appliance;
b) Never allow children to use the appliance.
c) Never allow people unfamiliar with these instructions to use the appliance.
Local regulations may restrict the age of the operator;
d) Never operate the appliance while people, especially children, or pets are
nearby;
e) The operator or user is responsible for accidents or hazards occurring to
other people or their property.
2) Preparation
a) While operating the appliance, always wear substantial footwear and long
trousers. Do not operate the equipment when barefoot or wearing open
sandals;
b) Do not wear loose clothing or jewellery that can be drawn into the air
inlet. Keep long hair away from the air inlets.
c) Wear protective goggles while operating
d) To prevent dust irritation the wearing of a face mask is recommended
e) Before using, check the supply and extension cord for signs of damage
and aging. Do not use the appliance if the cord is damaged or worn.
f) Never operate the appliance with defective guards or shields, or without
safety devices.
g) Only use a weather proof extension cable tted with a coupler according
to IEC 60320-2-3.
h) It is recommended that the appliance should be supplied via a residual
current device (RCD) with a tripping current of not more than 30 mA.
i) If an extension cord is used make sure it is for outdoor use and marked
as such. The recommended size of extension cord is not lighter than
0.75mm2.
MODEL No.: GBV100W, PRODUCT No.: 705158
3) Operation
a) Always direct the cord to the rear away from the appliance.
b) If the cord becomes damaged during use, disconnect the supply cord
from the mains immediately. DO NOT TOUCH THE CORD BEFORE
DISCONNECTING THE SUPPLY.
c) Do not carry the appliance by the cord.
d) Disconnect the appliance from the mains supply
- whenever you leave the machine;
- before clearing a blockage;
- before checking, cleaning or working on the appliance;
- if the appliance starts to vibrate abnormally.
e) Operate the appliance only in daylight or in good articial light.
f) Do not overreach and keep your balance at all times.
g) Always be sure of your footing on slopes.
h) Walk, never run;
i) Keep all cooling air inlets clear of debris.
j) Never blow debris in the direction of bystanders.
h) Do not put hands or feet near or under rotating parts.
4) Maintenance and storage
a) Keep all nuts, bolts and screws tight to be sure the appliance is in safe
working condition;
b) Replace worn or damaged parts.
c) Use only genuine replacement parts and accessories.
d) Store the appliance only in a dry place.
7
