1. INTRODUCTION

The DUOX Relay allows for dry contacts in BUS2 systems, with various operating and activa-

tion modes to be conﬁgured:

- Relay activation using commands generated from the residential terminals, entry panels

or guard units.

- External activation using buttons, additional external switches, etc.

The DUOX relay can be installed in any part of the duox bus. You can install one or several

relays: by apartments, block or installation.

Notes:

-Theduoxrelayalsoprovidesthenecessarycurrent(12Vdc), toactivate thepower tocontrol:

standard lock-release, bells, etc.

3257

REF.

DISABLE

OUTPUT

12V 0.3A

SEC SINGLE

MIN ALL

OUT

RELAY

AV TRES CRUCES, 133

FERMAX ELECTRONICA, SAU

4 017 VALENCIA - SPAIN

MADE IN SPAIN

BUS

OUTPUT

RX PRG

MODULO RELE

DUOX

DUOX RELAY

MODULE

BUS INPUT

PRG TX

+12V

RESET/

SET

1. BUS INPUT: DUOX Input Connector.

2. BUS OUTPUT: DUOX Output Connector.

3. Dry contacts (max 3A):

- C: Common.

- NC: Normally Closed.

- NO: Normally Open.

Relay ON: Active relay output indicator Led

4. External relay control:

- RESET/DISABLE , - : Disables any action taken on the relay (as a result of an external

command or activation) during a short circuit between both terminals.

- SET, -: Relay activation through external contact. Activates the relay as a result of a

short circuit between SET and - (negative) terminals, and also transmits commands.

+12V Auxiliary voltage output 12Vdc (300mA max).

6. Operating Mode:

- TX: The mode where the relay sends commands to other devices depending on the

conﬁgured command (in this mode, the relay does not activate the output).

- RX: Themode wheretherelayactivates theoutputifthe conﬁguredcommandis received

by the bus and coincides with the other conﬁgured parameters.

Page 7

The functions implemented on the relay are summarised below.

Functions implemented in TX Mode:

- Lock-release function after receiving a call.

- Lock-release function to a conﬁgured panel.

- Guard-unit call function.

- F1 relay activation or deactivation function.

- F2 relay activation or deactivation function.

- Remote relay activation or deactivation function.

- Doormatic function.

Functions implemented in RX Mode:

- Activating the relay upon receiving a lock-release command.

- Activation upon receiving a guard-unit call command.

- Activation upon receiving a call to residence command from a panel.

- Activation upon receiving an Auto-start command.

- Activation upon receiving an Activate F1 relay command.

- Activation upon receiving an Activate F2 relay command.

- Activation upon receiving an Activate/Deactivate relay command.

Note:

- Whenever terminals from different blocks are required to activate the same relay, it must be

conﬁgured as General Entrance.

Other conﬁgurations:

- Conﬁguration of activation times via integrated push-buttons.

- Resetting Parameters.

7. PRG: Programming Access button.

8. Min/All - Sec/Single: Buttons for Functions and Activation Times

- For Functions: In combination with the PRG button (programming input), they are

pressed to program the relay’s different possible functions.

- For activation times.

* Timed: This allows you to conﬁgure the activation time between 1 and 120 seconds

in the seconds range and between 1 and 120 minutes in the minute range.

* Continued: Allows the relay to be conﬁgured to keep the contact closed until

deactivation occurs by means of a short-circuit between the RESET and -.

9. C, D, T: LED diodes that give information when programming, relative to the status: off,

on, fast ﬂash...etc.

10. Telephone Connector: For the DUOX Programmer connection.

1.1 FUNCTIONS / CONFIGURATIONS

VERY IMPORTANT NOTE:

Even though the relay is implemented on all functions detailed below, SOME functions may

not yet be applied because the devices used for this will be available in the future.

Page 8

1.2 USAGE CONSIDERATIONS

-There shouldn´tbemore thanonerelaywith thesameaddressin theinstallation(independent

of the type of address).

- To conﬁgure the terminal´s destinations, it must be in night mode.

- If entering the terminal addresses via the integrated button programming the ON Relay led

doesnot light-up,re-call toensure thattheaddresshasbeenproperlysaved. Ifthe addressis

alreadysaved inthememory,the leddoesnotlight-upandthe addresscan notbeduplicated.

- Once the range of addresses is programmed from the relay, you can change the start ad-

dress and place it before the last one. You must make sure that the start and end address

in the range are properly saved.

1.3 BASIC CONNECTION DIAGRAM

The DUOX relay can be installed in any part of the duox bus. You can install one or several

relays: by apartments, block or installation.

3257

REF.

DISABLE

OUTPUT 12V 0.3A

SEC SINGLE

MIN ALL

OUT

RELAY

AV TRES CRUCES, 133

FERMAX ELECTRONICA, SAU

4 017 VALENCIA - SPAIN

MADE IN SPAIN

BUS

OUTPUT

RX PRG

MODULO RELE

DUOX

DUOX RELAY

MODULE

BUS INPUT

PRG TX

+12V

RESET/

SET

3257

REF.

DISABLE

OUTPUT 12V 0.3A

SEC SINGLE

MIN ALL

OUT

RELAY

AV TRES CRUCES, 133

FERMAX ELECTRONICA, SAU

4 017 VALENCIA - SPAIN

MADE IN SPAIN

BUS

OUTPUT

RX PRG

MODULO RELE

DUOX

DUOX RELAY

MODULE

BUS INPUT

PRG TX

+12V

RESET/

SET

3257

REF.

DISABLE

OUTPUT 12V 0.3A

SEC SINGLE

MIN ALL

OUT

RELAY

AV TRES CRUCES, 133

FERMAX ELECTRONICA, SAU

4 017 VALENCIA - SPAIN

MADE IN SPAIN

BUS

OUTPUT

RX PRG

MODULO RELE

DUOX

DUOX RELAY

MODULE

BUS INPUT

PRG TX

+12V

RESET/

SET

F1 F1 F1 F1

Vac

-+-+

18 - 24 Vdc

18Vdc/2A

MADE IN SPAIN

INPUT

REF. 3244

DUOX POWER

SUPPLY FILTER

OUTPUT

18Vdc/2A

Ref. 3244

18 Vdc IN PREV BUS

PWR BUS PWR BUS

Page 9

2. CONFIGURATIONS - FUNCTIONS

2.3 RESETTING PARAMETERS

Function description.

It performs a reset of the parameters to the default values:

- Conﬁgured command: None

- Relay address: 000

- Relay block: 00

- Continued mode: Deactivated

- Panels: Not conﬁgured

- Terminals: Not conﬁgured.

- Start of the Range: Not conﬁgured.

- End of the Range: Not conﬁgured.

- List of terminals: Empty.

- Activation time: 3 seconds.

Function conﬁguration.

1. Press the PRG button 4 times so that the C, D and Tleds remain blinking rapidly.

2. Press the Min/All and Sec/Single buttons simultaneously, the LEDS remain ﬁxed for

4 seconds so that when they are off, the relay´s conﬁguration is reset to the default

parameters.

Note:

- If the duox relay has been previously conﬁgured, and if you are unsure about the previous

conﬁguration, we recommend performing a parameter rest to not interfere with the prior

conﬁgurations.

CONFIGURATIONS

2.1 CONFIGURATION AS BLOCK

Connect the DUOX relay, press the "PRG" pushbutton, and the C led should light up. You

will then have 60 seconds to program its address. To program the address, make a call

from one of the terminals that is connected to the BUS OUTPUT terminal. The outdoor

panel of the block must previously have been programmed with the parameters of the

block number.

In this way, the block number will be conﬁgured in the relay. The relay can then be acti-

vated from any of the terminals that belong to this block number.

The DUOX relay can be conﬁgured as Block (2.1) or as General Input (2.2).

2.2 CONFIGURATION AS GENERAL ENTRANCE

If the relay is in RX mode and F1 or F2 command programming, it can be conﬁgured as a

general entrance block.

To do this, repeat the steps mentioned in 2.1, but make sure that a bridge has been set up

in advance between the – terminals and RESET/DISABLE.

In this way, the block will be conﬁgured as general entrance, and this relay will be able to

be activated from any monitor or guard unit, regardless of the block number.

Page 10

Note:

- You can not conﬁgure the times in both ranges (minutes and seconds). If the conﬁguration

startswithintherange(minutesorseconds), continuewithin thesame rangeand thebuttons

pressed on the other range will not be considered.

Continued function conﬁguration.

1. Press the PRG button 3 times. The Tled must remain lit.

2. Simultaneously press the buttons Sec/Single and Min/All, the leds should turn off.

Note:

- Once the relay has been activated it will remain active until a short circuit is done between

RESET and -.

2.5 FUNCTIONS DEPENDING ON OPERATING MODE

2.5.1 TX Operating Mode

-Themodewherethe relaysendscommandstoother devicesdependingontheconﬁgured

command (in this mode, the relay does not activate the output).

-To access this mode conﬁgure the bridge to TX mode.

FUNCTIONS:

- Lock-release function after receiving a call.

- Lock-release function to a conﬁgured panel.

- Guard-unit call function.

- F1 relay activation or deactivation function.

- F2 relay activation or deactivation function.

- Remote relay activation or deactivation function.

- Doormatic function.

FUNCTIONS

2.5.1.1 LOCK-RELEASE FUNCTION UPON RECEIVING A CALL

Function description.

You can associate the duox relay to a house so that upon calling a home you have 30 sec-

onds, via activation of the Set terminal (button connected between the SET terminals and -)

for the Lock-release command to be sent to the panel that last made the call. This way the

user does not have to go to the house´s terminal to press the lock-release button.

2.4 CONFIGURING ACTIVATION TIME VIA THE INTEGRATED BUTTONS (Sec/Single -

Min/All)

Function description.

Conﬁguration of activation times.

* Timed: This allows you to conﬁgure the activation time between 1 and 120 seconds

in the seconds range and between 1 and 120 minutes in the minute range.

* Continued: Allows the relay to be conﬁgured to keep the contact closed until

deactivation occurs by means of a short-circuit between the RESET and -.

Timed Function conﬁguration.

1. Press the PRG button 3 times. The Tled must remain lit.

2. a) If you want to conﬁgure the time in seconds press the Sec/Single button, with each

press it increases the time 1 second and the Tled ﬂashes. If you have reached the

maximum conﬁgurable time (120 seconds), the T led ﬂashes rapidly.

b) If you want to conﬁgure the time in minutes press the Min/All button, with each press

it increases the time 1 minute and the Tled ﬂashes. If you have reached the maximum

conﬁgurable time (120 minutes), the Tled ﬂashes rapidly.

3. Once the desired conﬁgured time is conﬁgured, press PRG. All leds must be off.

Autres manuels pour DUOX RELAY

Table des matières

Autres manuels Fermax Relais

Fermax

Fermax DUOX RELAY Guide de l'utilisateur

Fermax

Fermax DUOX PLUS Manuel utilisateur

Fermax

Fermax DUOX Guide de l'utilisateur

Fermax

Fermax WAY KIT Guide de l'utilisateur

Fermax

Fermax 2013 Manuel utilisateur

Fermax

Fermax F03233 Manuel utilisateur

Manuels Relais populaires d'autres marques

Shelly

Shelly Pro Series Manuel utilisateur

GE MVAX 11 Manuel utilisateur

ABB

ABB RELION REF615R Manuel utilisateur

Pilz

Pilz PNOZ X10 Manuel du propriétaire

ABB

ABB SPAJ 142 C Manuel de la liste des pièces

Kemo Electronic

Kemo Electronic B197 Manuel utilisateur

Seg

Seg MRM3 Manuel utilisateur

Basler

Basler BE1-700C Manuel utilisateur

CD Automation

CD Automation REVEX 2PH 280A Manuel utilisateur

Ruelco

Ruelco 1S04 Manuel utilisateur

Basler

Basler V3E Z1P B2C1F Manuel utilisateur

Doepke

Doepke Dupline DSM 2 Manuel utilisateur

Siemens

Siemens SIRIUS 3RT1966-4D Manuel utilisateur

GE DGP Manuel utilisateur

Kyongbo Electronics

Kyongbo Electronics GDR-D01 Manuel utilisateur

Siemens

Siemens SIPROTEC 4 Manuel utilisateur

Siemens

Siemens BD2-AK03X/FS Series Manuel utilisateur

Leuze

Leuze MSI-SR5B Manuel utilisateur
