Fender ROCPRO 700 Manuel utilisateur

P/N 050337

Reference and

Owner's Manual

ube-Driven

Hybrid

Amplifier

mplifier

tone •tradition •innovation

Roc•Pro

Fender Musical Instruments

7975 North Hayden Road, Scottsdale, Arizona 85258 U.S.A.

Since 1946, Fender realized the importance of your amplifier. You see, your amplifier

is more than just a combination of dials, wires and speakers. Your amplifier is a

musical instrument. And like any fine musical instrument, it should be treated with

special care and attention to detail.

At Fender, we know what building guitar amplifiers is all about. For over half a century,

we have been designing and producing some of the world's best amplifiers helping

shape the face of music. In fact, many of the world's most classic and best sounding

amplifiers have proudly worn the Fender name.

Whether you're after that classic Fender tone, a clean crisp sound for your Bass or

Keyboard or the raw driving power of modern distortion, your decision to purchase a

Fender amplifier is one you will appreciate with each passing note for years to come.

Wishing you years of enjoyment and a heartfelt thank you,

Bill Schultz

Chairman

Fender Musical Instruments Corporation

Fender • Tone

Bill Schultz

FENDER®TUBE-DRIVEN HYBRID AMPLIFIERS

• A UNIQUE MELDING OF TUBE AND FENDER STANDARD SERIES TECHNOLOGY

BRINGS OUT THE BEST OF BOTH CIRCUIT DESIGNS

• ROAD WORTHY AND MUSICAL COMPONENTS, CAPABLE OF HANDLING THE

MOST DEMANDING PERFORMANCE SITUATIONS

• FENDER'S UNIQUE UNDERDAMPED POWER AMPLIFIER DESIGN PRODUCES

SPARKLE, PUNCH AND AN INCREASE IN THE AMPLIFIER'S LOUDNESS

• SOPHISTICATED POWER AMPLIFIER PROTECTION SCHEME PREVENTS

AMPLIFIER FAILURE DUE TO BAD SPEAKER CORDS OR INCORRECTLY

CONNECTED SPEAKER JACKS

• THREE-WAY VARIABLE EFFECTS LOOP CIRCUITRY ALLOWS THE USE OF

VIRTUALLY ANY EFFECTS DEVICE

• MAGNETIC INTERFERENCE REDUCING ALUMINUM CHASSIS HELPS

ELIMINATE UNWANTED NOISE AND RADIO INTERFERENCE

• FENDER SPECIAL DESIGN 12" HIGH PERFORMANCE SPEAKER FOR THAT

GREAT FENDER TONE

• UNPARALLELED TUBE DRIVE CHANNEL OFFERS AN INCREDIBLE MIX

OF VERSATILITY

• CABINETRY CONSTRUCTED FROM HAND-SELECTED WOODS EMPLOYING

RUGGED CORNER JOINERY FOR ENDURING RELIABILITY

• COVERED IN GENUINE TOLEX WITH TOUGH METAL GRILLE FRONTS FOR

LONG LIFE AND LASTING GOOD LOOKS

Fender • Tradition

Roc Pro 700 REFERENCE AND OWNER'S MANUAL

INTRODUCTION

Fender • Innovation

Congratulations on your purchase of a Roc Pro

Tube-Driven Hybrid Amplifier, a melding of

Fender’s distinctive Tube -Tone and cutting edge

Standard Series technology. Designed for today’s

innovative guitarists, our Roc Pro amplifiers have

what it takes to define your sound.

The Roc Pro 700 you now have in your possession

is an amplifier of incredible versatility and enduring

reliability.

Read through this manual and familiarize yourself

with the Roc Pro’s many features, then experiment!

Take the time to uncover the broad spectrum of

tone colors available via the front panel’s EQ and

GAIN controls. And don’t forget the VOLUME and

TONE controls on your guitar! An inherent feature

of the Roc Pro's Hybrid tube design is its sensitivity

to subtle changes in the input signal level. Dial in a

crunch rhythm tone with your guitar’s volume on

10, then slowly roll off the volume and listen to the

cleansing effect. Change your pick attack from

light to heavy, push, pull, thump and pump your

axe, your Roc Pro will respond to every nuance of

your playing!

•All Roc Pro amplifiers use a real 12AX7 / ECC83

preamp tube in their TUBE DRIVE channel to gen-

erate a stunning array of Fender tones from Vintage

Overdrive to Sonic Explosion.

•Select the NORMAL channel and dial up ultra

clean… fat and funky… power crunch… And

everything in between.

FEATURES: Roc Pro 700

70 Watts into 8 ohms, 1-12” Fender Special Design

Speaker, Dual Selectable channels (Normal and

Tube Drive) 12AX7 / ECC83 preamp tube, Variable

EFX loop, Line Out, 2-Button footswitch (Channel

Select and Reverb), Genuine Black Tolex and

Rugged Metal Speaker Grill.
