USER MANUAL
+420 730 893 828
www.fencee.eu
Electric fencing
AUTOMATIC SMART CHICKEN DOOR
Manual for models Art.Nr. 8225, 8226, 8227
VNT electronics s. r. o.
Dvorská 605, 563 01
Czech Republic
2
CONTENT
1Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2Installatio+n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3Solar panel install . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4Set up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.1 System time setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.2 Opening mode setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.3 Closing mode setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5Anti-pinch function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7Technical specications . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3
1. PREPARATION
CONFIRM THAT THE SPACE IS LARGE ENOUGH.
Before installing/assembling, make sure that you have enough space at the
place of the intended installation/assembly. For smooth operation of the
device, it is necessary to provide a minimum of 31 cm of space above the
upper edge of the door, left, right, and below at least 3 cm from the edge of
the device. Therefore, the required size of the opening you need to mount the
appliance is 20,3 × 4,8 × 25,4 cm.
PARTS NEEDED FOR INSTALLATION
• Two AA alkaline batteries (included in package, don't use rechargeable
batteries)
• 6 pcs Tapping screw (included in package)
• DC cable (included in Art.Nr. 8226 version - Automatic chicken coop door AC)
• Solar panel 2W, Art.Nr. 8228 (not included, optional accessories
for Art.Nr. 8227 version - Automatic chicken coop door AC + Solar)
• 5,2 V 1A USB adapter (included in package Art.Nr. 8226 Automatic chicken
coop door AC)
PARTS NEEDED FOR INSTALLATION
• Screwdriver
•Pencil
• Power drill
• Jigsaw/ keyhole hand saw
We recommend the use of safety goggles and gloves.
4
2.1.
Use a screwdriver to unscrew the two
screws that secure the battery cover.
2. INSTALLATION
2.2.
Remove the battery cover and place
two AA alkaline batteries inside
(Don't use rechargeable batteries).
Then close the battery cover and
tighten the screws.
2.3.
First time the door is turned on, the
door must be closed; opening does
not respond. Press the button to clo-
se the door, then perform the basic
cycle manually, press the button to
open the door until it reaches,
then the button to close the door .
2.4.
Position the opened door where it
will be installed and mark the sides
of the opening.
5
2.5.
Drill holes in the marked corners to
make it easier to use a jigsaw to cut
out the door from the hole.
2.6.
Use a jigsaw to saw off the opening
by connecting the hole.
2.7.
Before installing the door, please
make sure that the installation
surface of the door is flat and do not
bend the door panel.
2.8.
Put the door panel in the position to
be installed, and screw in the screws
gently.
Do not overtighten the screws or the
rails will be crushed and the door will
not move!
6
2.9.
Press to test the door
opening and closing.
2. INSTALLATION
3.1.
Fix the solar panel and the brackets
with screws.
3. 2 W SOLAR PANEL INSTALL (Art. Nr. 8228)
3.2.
Place the solar panel slanted upward
as shown, and x the solar panel
beside the door panel with four
selftapping screws.
3.3.
Plug the power cord from the solar
panel into the controller. Now you can
adjust the angle of the solar panel to
receive more sunlight, and tighten the
screws on the bracket after that.
7
Warning
Timer
Sensor
Mix
Battery level
Open and
close state
UP DOWNOK
Close state
Open state OPENING
CLOSING
3. 2 W SOLAR PANEL INSTALL (Art. Nr. 8228)
4. SET UP
DEFAULT MODE
The door automatically works on default mode if not congured differently
by the user. Default mode is sensor mode (Both open and close). ln the
default mode, the door detects the ambient brightness through the light
sensor, open when it detects daylight, and close when it is dark.
8
4.1. SYSTEM TIME SETTING (12/24 HOUR)
4.2. OPENING MODE SETTING
1. Press any key to light up the screen, and then press to enter the
settings.
2. Press to set the time convention, 12-hour or 24-hour. Then press
to save and enter the current time setting.
3. Press to set the hour when the hour flashes, press to save
and enter the minute setting.
4. Press to set the minute when the minute flash, press to save
and enter the next step.
1. The icon is displayed , and the coop door icon is fully open, as shown
below. Press to switch between the various modes, the top icons
will also change to indicate the selected mode.
2. Press to select the required mode and enter its settings.
This mode is for automatic opening of the coop door in the morning at the
time you have set, as shown on the following gure.
Press to set the hour when the hour flashes, press to conrm and
enter the minute setting.
Press to set the minute when the minutes flash, press to conrm
and proceed to the next step.
9
Current ambient
light level
Desired ligt level (light range
of the sensor : 45 - 99)
4.3. CLOSING MODE SETTING
This mode is for automatic opening of the coop door at dawn using the light
sensor, as shown below. The number on the left shows the current ambient
light level, and the flashing number on the right is the desired light level you
would like to set for opening the door. Press to adjust the flashing
value, press to conrm and enter the next step. The door will open when
the ambient light level reaches the desired light level you have set.
3. After the door opening mode is set, it will go to the next step.
1. The icon is displayed, and the coop door icon is fully close, as shown
below. Press to switch between the various modes, the top icons
will also change to indicate the selected mode.
2. Press to select the required mode and enter its settings.
10
Current ambient
light level
Desired light lever (light range
of the sensor : 00 - 44)
This mode is for the automatic closing of the coop door at the time you have
set, as shown on the following gure.
Press to set the hour when the hour flashes, press to conrm and
enter the minute setting.
Press to set the minute when the minutes flash, press to conrm
and proceed to the next step.
This mode is for the automatic closing of the coop door in the evening /at
dusk using the light sensor, as shown below. The number on the left shows
the current ambient light level, and the flashing number on the right is the
desired light level you would like to set for closing the door. Press to
adjust the flashing number to a desired light level, press to save and
enter the next step. The door will close when the ambient light level reaches
the desired light level you have set.
This mode uses a combination of both Sensor and Timer, when selecting this
mode, you will be requested to set the default time rst, and the screen will
display . Then you will be requested to set the Sensor, and the screen will
display .
