Fein ASW 18-6 Manuel utilisateur
ASW 18-6; ASW 18-12; ASW 18-18; ASW 18-6-PC; ASW 18-12-PC; ASW 18-18-PC
Technical data
C-SC_CSSM
Version 1.0
2017-10-09
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 1of 1
Technical data
All the technical data can be found in the operating instructions for the model.
Tests
Up-to-date test data and test instructions after repair can be found on the FEIN Extranet (Customer Service → Repair Guides).
Lubricants / Auxiliary substances
The lubricants or auxiliary substances and their container sizes available from FEIN can be found on the FEIN Extranet
(Customer Service → Repair Guides).
Lists of spare parts
Lists of spare parts and exploded views are available online at www.fein.com
ASW 18-6; ASW 18-12; ASW 18-18; ASW 18-6-PC; ASW 18-12-PC; ASW 18-18-PC
Notes and requirements
C-SC_CSSM
Version 1.0
2017-10-09
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 1of 1
Please note
These instructions are only intended for persons with suitable technical training. It is assumed that the reader has mechanical and
electrical training.
Only use original FEIN spare parts.
Provisions
Please note that power tools may only be repaired, maintained and checked by a trained electrician, as improper repair can result in
serious risks to the user.
The provisions set out in DIN VDE 0701-0702 should be observed after repairs.
The relevant accident prevention regulations of the employer’s liability insurance associations are to be observed when
commissioning.
The German Equipment and Product Safety Act [ProdSG] applies for correct use.
Outside Germany, the regulations applicable in the relevant country must be observed.
ASW 18-6; ASW 18-12; ASW 18-18; ASW 18-6-PC; ASW 18-12-PC; ASW 18-18-PC
Lubricants and auxiliary substances required
C-SC_CSSM
Version 1.0
2017-10-09
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 1of 1
Lubricants
Grease 0 40 123 0100 0 0.6 g Tool holder; clutch ring
Auxiliary substances
Loctite 638
Loctite 243
ASW 18-6; ASW 18-12; ASW 18-18; ASW 18-6-PC; ASW 18-12-PC; ASW 18-18-PC
Troubleshooting
C-SC_CSSM
Version 1.0
2017-10-09
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 1of 1
Not yet available.
ASW 18-18; ASW 18-18-PC
Removal
C-SC_CSSM
Version 1.0
2017-10-09
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 1of 9
Removing the motor housing
1. Remove the Sealing ring (1).
2. Slide back the cover (2).
3. Unscrew the eleven screws (3).
4. Pry off the motor housing (4).
Place the screwdriver between the clutch and the upper part of the housing.
Tools:
- Flat-head screwdriver
40x2
- Flat-head screwdriver
90x4.5
- Torx T10
2
3
4
1
ASW 18-18; ASW 18-18-PC
Removal
C-SC_CSSM
Version 1.0
2017-10-09
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 2of 9
Removing the gearbox housing
1. Remove all components.
2. Remove the toggle switch (1).
1
ASW 18-18; ASW 18-18-PC
Removal
C-SC_CSSM
Version 1.0
2017-10-09
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 3of 9
Removing the electronics
1. Pull off the plug (1).
2. Remove the rotor (2).
3. Pull off the plug (3).
4. Unsolder the three cables (4).
5. Remove the three ferrite cores (5).
Tools:
- Soldering station
1
2
3
4
5
ASW 18-18; ASW 18-18-PC
Removal
C-SC_CSSM
Version 1.0
2017-10-09
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 4of 9
Removing the electronics
1. Lift the hook (1) on each side.
2. Pull off the switch (2).
1
1
2
ASW 18-18; ASW 18-18-PC
Removal
C-SC_CSSM
Version 1.0
2017-10-09
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 5of 9
Removing the electronics
1. Remove the plug (1).
2. Remove the cover (2).
3. Remove the plug (3).
1
2
3
