ID CPR60

RFID Reader Module

Model

Article No.

ID CPR60-A

5491.000.00

IDENTIFICATION

Installation

ID CPR60

FEIG ELECTRONIC GmbH

Page 2 of 21

M91210-1e-ID-B.docx

Note

Copyright by

FEIG ELECTRONIC GmbH

Lange Strasse 4

D-35781 Weilburg

Tel.: +49 6471 3109-0

http://www.feig.de

With the edition of this document, all previous editions become void. Indications made in this manual may be

changed without previous notice.

The reproduction, distribution and utilization of this document as well as the communication of its contents to

others without express authorization is prohibited. Offenders will be held liable for the payment of damages.

Composition of the information in this document has been done to the best of our knowledge. FEIG

ELECTRONIC GmbH does not guarantee the correctness and completeness of the details given in this

manual and may not be held liable for damages ensuing from incorrect or incomplete information. Since,

despite all our efforts, errors may not be completely avoided, we are always grateful for your useful tips.

The instructions given in this manual are based on advantageous boundary conditions. FEIG ELECTRONIC

GmbH does not give any guarantee promise for perfect function in cross environments and does not give

any guaranty for the functionality of the complete system which incorporates the subject of this document.

FEIG ELECTRONIC call explicit attention that devices which are subject of this document are not designed

with components and testing methods for a level of reliability suitable for use in or in connection with surgical

implants or as critical components in any life support systems whose failure to perform can reasonably be

expected to cause significant injury to a human. To avoid damage, injury, or death, the user or application

designer must take reasonably prudent steps to protect against system failures.

FEIG ELECTRONIC GmbH assumes no responsibility for the use of any information contained in this

document and makes no representation that they free of patent infringement. FEIG ELECTRONIC GmbH

does not convey any license under its patent rights nor the rights of others.

All brand names, trademarks or logos are property of their respective owners.

IDENTIFICATION

Installation

ID CPR60

FEIG ELECTRONIC GmbH

Page 3 of 21

M91210-1e-ID-B.docx

Content

1. Safety Instructions / Warning - Read before start-up ! 4

2. Characterization ID CPR60 5

2.1. Available Accessories.......................................................................................................5

2.2. Available Software Tools, USB Driver and Firmware...................................................... 6

2.3. Development Board...........................................................................................................6

3. Dimensions 7

4. Installation and wiring 8

4.1. Connector X1.....................................................................................................................8

4.2. Connector ANT................................................................................................................ 10

5. Standby / Low Power Card Detection 11

6. Technical Data 12

7. Approvals 14

7.1. Europa (CE)...................................................................................................................... 14

7.2. USA (FCC) and Canada (IC)............................................................................................ 15

ANNEX 15

Annex A: ID CPR60-DevBoard Reference Design................................................................ 17

IDENTIFICATION

Installation

ID CPR60

FEIG ELECTRONIC GmbH

Page 4 of 21

M91210-1e-ID-B.docx

Safety Instructions / Warning - Read before start-up !

The device may only be used for the intended purpose designed by for the

manufacturer.

The operation manual should be conveniently kept available at all times for each user.

Unauthorised changes and the use of spare parts and additional devices which have not

been sold or recommended by the manufacturer may cause fire, electric shocks or

injuries. Such unauthorised measures shall exclude any liability by the manufacturer.

The liability-prescriptions of the manufacturer in the issue valid at the time of purchase

are valid for the device. The manufacturer shall not be held legally responsible for

inaccuracies, errors, or omissions in the manual or automatically set parameters for a

device or for an incorrect application of a device.

Repairs may only be executed by the manufacturer.

Installation, operation, and maintenance procedures should only be carried out by

qualified personnel.

Use of the device and its installation must be in accordance with national legal

requirements and local electrical codes .

When working on devices the valid safety regulations must be observed.

The reader module is a limited module. The HF Reader IC has no internal shielding. The

module is designed for installation in electronic devices. (e.g. printers, terminals, hand

scanners, etc.) Care must be taken to ensure that no switching power supply, oscillator

or high current lines are routed directly along the module or located under the module.

Only the antennas, mentioned in the manual, may be used. The cable length to the an-

tenna is limited to 1,0 m. Take care that the PCB design in the host environments is EMC

compliant.

Special advice for carriers of cardiac pacemakers:

Although this device doesn't exceed the valid limits for electromagnetic fields you

should keep a minimum distance of 25 cm between the external antenna and your cardi-

ac pacemaker and not stay in an immediate proximity of the device respective the an-

tenna for some time.

IDENTIFICATION

Installation

ID CPR60

FEIG ELECTRONIC GmbH

Page 5 of 21

M91210-1e-ID-B.docx

Characterization ID CPR60

The ID CPR60 is a RFID reader which supports ISO/IEC 14443 A/B and ISO 15693 contactless

smart cards and transponders. It also offers 4 interfaces to connect ISO 7816 smart cards with

contacts.

The reader is designed to connect an external individual RFID antenna to the 50 Ohm antenna

output. For operation in USA and Canada approved antennas are permitted only (see 7.2. USA

(FCC) and Canada (IC)).

Optional the RFID interface can support the contactless standards ISO18000-3M3 and NFC Peer-

to-Peer (P2P; Passive Initiator Mode) in accordance with ISO/IEC 18092. This support is available

on request only.

For host communication ID CPR60 offers an USB device full speed interface, an RS232-LVTTL

interface (COM Interface) and an SPI interface. For data transfer with a host computer the ISOHost

mode (polling) is available via the USB, COM and SPI interface.

The functionality of the ID CPR60 is based on the well known CPR-family, like the reader module

ID CPR74 or the wall-mount reader ID CPR50.10 and is compatible with them mainly.

The use of ISOHost commands guarantees an easy creation of user software as well as the com-

patibility with all other FEIG RFID readers.

Beside the CPRStart software for demonstration and configuration of the reader capabilities and

the Firmware Update Tool a lot of different Software Development Kits (SDK) and drivers are

available to support an easy integration into the customer's application.

2.1.

Available Accessories

Tab. 1 Available Accessories and spare parts

Part Number

Part name

Description

5604.000.00

ID CPR60-DevBoard

Development Board for the ID CPR60

incl. Power Supply with European plug

3674.000.00

ID ISC.ANT40/30-U.FL-A

50 Ohm Antenna with U.FL-connector for the connection

to the ID CPR60

Dimensions: 40 mm x 30 mm

3673.000.00

ID ISC.ANT100/100-U.FL-A

50 Ohm Antenna with U.FL-connector for the connection

to the ID CPR60

Dimensions: 100 mm x 100 mm

3540.000.00

ID ISC.ANT.C05-A

50 Ohm antenna cable with U.FL connector on both sides

for the connection of an external antenna to the ID CPR60

Dimension : 500 mm; Color: black

IDENTIFICATION

Installation

ID CPR60

FEIG ELECTRONIC GmbH

Page 6 of 21

M91210-1e-ID-B.docx

2.2.

Available Software Tools, USB Driver and Firmware

The USB driver and the test and configuration tool “CPRStart” are available on our FEIG download

area:

https://www.feig.de/en/login

Username: CPR60

Password : cpr_reader

For firmware updates we are providing the “FirmwareUpdateTool” and a external firmware xml-file.

2.3.

Development Board

For demonstration and development purposes a special PCB with connectors, smart card con-

nectors, power supply and antenna is available on request (see 2.1. Available Accessories).

The ID CPR60-DevBoard offers 3 SAM sockets for ID-000 smart cards, 1 smart card connector for

full size ID 1 cards and different connectors for the USB, COM and SPI interface. The integrated

antenna can be used in combination with the CPR60 to communicate with transponders.

Different multi-pin connectors offer the possibility to measure and analyse signals on the different

interfaces and connectors.

The DevBoard will be delivered including a power supply. A suitable reader ID CPR60 must be

ordered separately.

Further information about the ID CPR60-DevBoard can be found in Annex A: ID CPR60-DevBoard

Reference Design.

IDENTIFICATION

Installation

ID CPR60

FEIG ELECTRONIC GmbH

Page 7 of 21

M91210-1e-ID-B.docx

Dimensions

The ID CPR60 reader module has been designed for the integration into terminals, printers or

handheld devices and so on.

Figure 1: Dimension (Top View)

Figure 2: Dimension (Side View)

IDENTIFICATION

Installation

ID CPR60

FEIG ELECTRONIC GmbH

Page 8 of 21

M91210-1e-ID-B.docx

Installation and wiring

4.1.

Connector X1

X1 (Connector Type: Hirose DF17(2.5)-80DP-0.5V(57)) is the main connector for power supply,

interfaces and control signals. The following table shows the pin-assignment of the connector. In-

terfaces and functions are described from the ID CPR60 view (an input must be connected to one

output or vice versa).

Figure 3: Connector X1

At connector X1 four external smart card connectors can be connected. SAM1, SAM2, SAM3 and

KCC whereas only KCC supports a card presence signal, which also can used to awake the

CPR60 form standby mode (see: 5. Standby / Low Power Card Detection).

Function

Remark

Function

Remark

n.c.

GND

3,3 V DC Supply

GND

SAM3_ CLK

n.c.

KCC_CLK (SAM4)

n.c.

SAM1_I/O

n.c.

SAM2_I/O

n.c.

SAM3_I/O

n.c.

KCC_I/O (SAM4)

SAM1_VCC

n.c.

SAM2_VCC

IDENTIFICATION

Installation

ID CPR60

FEIG ELECTRONIC GmbH

Page 9 of 21

M91210-1e-ID-B.docx

Function

Remark

Function

Remark

n.c.

SAM3_VCC

n.c.

GND

n.c.

KCC_VCC (SAM 4)

GND

SAM1_CLK

SPI_MISO*

CPR60 is Slave

SAM2_CLK

SPI_MOSI*

CPR60 is Slave

USB DP*

SPI_nCS**

CPR60 Input

USB DM*

SPI_CLK**

CPR60 Input

n.c.

SAM1_ RST

n.c.

SAM2_ RST

nKCC_DET (SAM 4)

Smartcard present con-

nector input

0: Card preset

1: Card no present

SAM3_RST

nLOW_PWR

Control input for low

power card detection

0: low power mod low

1: normal mode

KCC_RST (SAM 4)

n.c.

GND

n.c.

GND

n.c.

5 V DC Supply

n.c.

nRESET

Reset Input

RS232_TxD

reader TxD, host RxD

RS232_RxD*

Reader RxD, Host TxD

n.c.

SPI_INT

IRQ output with double

function:

SPI-IRQ

Low power card

detection: Card de-

tected

n.c.

GND

n.c.

* 5 V tolerant Input

** 3,3 V tolerant Input

IDENTIFICATION

Installation

ID CPR60

FEIG ELECTRONIC GmbH

Page 10 of 21

M91210-1e-ID-B.docx

4.2.

Connector ANT

The ID CPR60 module is equipped with an connector for an external 50 -antenna.

The connection of the external antenna is possible via the U.FL connector „ANT“.

Figure 4: Connection of an external antenna

The technical description and hints for building external 50 -antennas can be taken from

the application note N20901-#d-ID-B.pdf.

NOTICE:

Only for use with 50 matched external antennas. The permanent usage of unmatched

antennas can damage the reader electronic.

The antenna output is neither permanent short circuit protected nor permanent no-load

protected.

The antenna cable should be no longer than 1m. The use of other cable length are pos-

sible after consulting the manufacturer.

ANT:

(U.FL)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Feig Electronic Système RFID

Feig Electronic

Feig Electronic OBID classic-pro ID CPR40.30-A Manuel utilisateur

Feig Electronic

Feig Electronic OBID i-scan ID ISC.ANT.MUX Manuel utilisateur

Feig Electronic

Feig Electronic OBID i-scan ID ISC.ANT.UMUX Manuel d'utilisation et d'entretien

Feig Electronic

Feig Electronic ID LRU500i-BD Series Manuel utilisateur

Feig Electronic

Feig Electronic OBID classic-pro ID CPR.M04.P/AB-U2 Manuel utilisateur

Feig Electronic

Feig Electronic OBID i-scan UHF ID ISC.MRU102-PoE-LED Manuel utilisateur

Feig Electronic

Feig Electronic ID ISC.ANT.U500/270-DM Manuel utilisateur

Feig Electronic

Feig Electronic ID LR5400 Manuel utilisateur

Feig Electronic

Feig Electronic OBID i-scan HF ID ISC.ANT1300/680-GPC Manuel utilisateur

Feig Electronic

Feig Electronic OBID classic-pro ID CPR.04.P/AB-USB Manuel utilisateur

Feig Electronic

Feig Electronic ID CPR50.10-E Manuel utilisateur

Feig Electronic

Feig Electronic OBID classic-pro ID CPR.03.20-CD Manuel utilisateur

Feig Electronic

Feig Electronic OBID i-scan ID ISC.LRM2500-A Manuel utilisateur

Feig Electronic

Feig Electronic ID ISC.LRU3500 Manuel utilisateur

Feig Electronic

Feig Electronic ID HyWEAR compact Manuel utilisateur

Feig Electronic

Feig Electronic ID ISC.MR102 Manuel utilisateur

Feig Electronic

Feig Electronic ID CPR40.30-U Manuel utilisateur

Feig Electronic

Feig Electronic OBID i-scan RFID-Tunnel Instructions d'installation et d'utilisation

Feig Electronic

Feig Electronic ID ISC.LRU3500 Manuel utilisateur

Feig Electronic

Feig Electronic OBID classic-pro ID CPR.02.10-AD Manuel utilisateur

Feig Electronic

Feig Electronic OBID i-scan Instructions d'installation et d'utilisation

Feig Electronic

Feig Electronic OBID i-scan ID ISC.MR101-USB Manuel utilisateur

Feig Electronic

Feig Electronic ID ISC.PRH101-A Manuel utilisateur

Feig Electronic

Feig Electronic OBID ID RW40.30-USB Manuel utilisateur

Manuels Système RFID populaires d'autres marques

Chainway

Chainway R1 Manuel utilisateur

IFM

IFM DTC600 Manuel utilisateur

Elatec

Elatec TWN4 MULTITECH NANO LEGIC 63 M Manuel utilisateur

RHOMBUS

RHOMBUS DR20 Manuel utilisateur

Sirit

Sirit IDentity 6204 Manuel utilisateur

SOREX

SOREX FLEX Manuel utilisateur

Omron

Omron V780-HMD68-EIP-KR Manuel utilisateur

IDENTEC SOLUTIONS

IDENTEC SOLUTIONS iPOINT Si Instructions d'utilisation

Shuttle

Shuttle BR06 Instructions d'utilisation

Digilock

Digilock Curve Keypad Basic Manuel utilisateur

Atid

Atid AT870 Manuel utilisateur

Chacon

Chacon 34958 Manuel utilisateur

Paxton

Paxton PROXIMITY architectural reader Manuel utilisateur

CipherLab

CipherLab 1800 series Manuel utilisateur

Brady

Brady FR22 Manuel utilisateur

Kronotech

Kronotech BLUEBOX GEN2 M30 UHF Manuel utilisateur

Unitech

Unitech RH767 Manuel utilisateur

Honeywell

Honeywell 026366.00 Manuel utilisateur
