FCONEGY FC500 Manuel utilisateur
User Manual
Portable Car Jump Starter
Model:FC500
Support Team:
support@fconegy.cn
User Manual
Portable Car Jump Starter
Model:FC500
Support Team:
1* FC500 Car Jump Starter 1*Smart Battery Clamp 1*USB-C Charging Cable 1*User Manual
1*EVA Bag 1*DC- Cigarette Lighter
Adapter
Package Contents
01
Product Specifications
Model FC500
1200A
2500A
5V/3A 18W(Max)
5V/2.4A
5V/3A 9V/2A 12V/1.5A
12V-16V 10A
10W(Max)
-20℃~60℃
192*88*38mm
590g
Starting Current
Battery Capacity 25800mAh
Peak Current
Type C Input & Output
USB1 Output
USB2 Output (Quick Charge)
DC Output
Wireless Charger
Temperature Rang：
Dimensions（L*W*H）
Weight
02
1
2
3
89
4
65
12
7
13
Technical Specifications
03
10
11
FUNCTION
Jump Starting Port
LED Flashlight
USB Output 1
USB Output 2
Type C Input and Output
DC Output
Power Button
Red Clamp
Black Clamp
Plug
Force Start Button
LCD Screen
NO. OPERATION
Insert the plug into the jump starting port
Flashlight modes: Solid, SOS, Alert
5V/2.4A
5V/3A 9V/2A 12V/1.5A
5V/3A 18W(Max)
12V-16V 10A
Power ON/OFF
Connect the black clamp to the negative terminal of the car battery
Connect the red clamp to the positive terminal of the car battery
Insert the plug into the jump starting port
Force start function
Show the percent power
Show charge and discharge status
04
1
2
3
4
5
6
7
8
9
10
11
12
13 Wireless Charger 10W(Max)
05
Charging the jump starter:
1. Connect the jump starter and the power source via the USB C cable.
2. Short press the ON/OFF button to turn on the product. While charging
the jump starter, the LED Display Screen will show the percent power
increased. Once it is fully charged, the LCD Display Screen will show 100%.
3. Unplug the cable when no charge is required.
NOTE:
●When using product for the first time, please make sure that the
jump starter is fully charged.
●Wall adapter is not included in the package.
●In cold winter,we suggest to store the jump starter indoor instead of the car.
GETTING STARTED
06
How to jump starter your car
NOTE: This product is for 12V car only.
●Check to make sure that battery level is above 70% before you use it to jump start your car.
Step 1: Insert the plug of the smart battery clamp completely into the jump starter. If the green and red light
indicators on the battery clamp are flashing alternately you are safe to move on to to the next step.
Step 2: Connect the red clamp to the positive terminal(+) of the car battery and connect the black clamp to the
negative terminal(-) of the car battery. If the green light on the clamp is on with click sound, you are safe to
move on to the next step.
07
Step 3: Start your car.
When the indicator light of the smart clamp is green, you need to start the vehicle within 30s.lf over 30s, the
clamp will stop working,you need to connect again from Step 1. If you failed to start your car, you need to
disconnect the battery clamp from the vehicle and the jump starter. Wait for at least 1mins, then try again.
Force Start Function
If you are sure you followed every step and the red light is always on,please try the force start function.
a. Insert the plug of the smart battery clamp completely into the jump starter.
b. Connect the red clamp to the positive terminal(+) of the car battery and connect the black clamp to
the negative terminal(-) of the car battery.Wrong connection will cause short- circuited.
c. Long press Force Button for 3 seconds,then the green light will be on.
d. Get back to your car in 30s then start the engine.
START
08
Step 4: Once your car is started, please remove the battery clamp from the car-battery and the
jump starter within 30 seconds.
Trouble Shooting of LED Indicator on the Clamp
Indicator
Red and green lights flash alternately.
Green light is always on,and the buzzer beeps once.
Red Light is ON
The clamp only connected to the jump starter
Correct Connection and ready to work
1.If the connection is totally correct, the voltage of
the car battery is too low,continuous short buzzer
-please try “force start”function.
2.The voltage of the starter is too low
-- try to replace the start up power supply or
charge it in time
3.Reverse connection
-The buzzer keeps on,connect the to clamp the RED
jumper cable to the POSITIVE (+) post And BLACK
jumper cable to NEGATIVE (-) post or car interior.
4.The clamp is short- circuited
-The buzzer keeps on,check whether two damps
together connect or connect both cable damps to
the same piece of metal
Situation
09
Charging your devices
USB/Type-c Output
1. Connect FC500 and your iPhone, smart phones or other electronic devices via USB/Type-c cable.
2. Press the ON/OFF button to turn on the car jump starter.
3. Unplug the cable when no charge is required.
Wireless Charging
10W(Max) wireless charging is compatible with all Qi-enabled devices such as cell phones
Airpods and AirPods Pro etc.
DC Output
The DC output only support 12V device less than 100W.
LED Flashlight
Long press for 3 seconds to turn on the light.
Press shortly to switch modes among Solid, SOS, Alert and Off.
