FCI Electronics Manual Part No. 166647-001
Issued: (5/11/98) Page 10 of 10
Rev. 12/07/06 ECR V10361 Revision F
HT-152 MINITEK (AWG 32-36)
DWG NO. DESCRIPTION QTY DWG NO. DESCRIPTION QTY
1 HT-02-001 HANDLE-A 1 20 HT-02-020 LINK 2
2 HT-02-002 HANDLE-B 1 21 411223 INS CRIMPER 1
3 HT-03-003 SLIDE BLOCK 1 22 411221 WIRE CRIMPER 1
4 HT-02-004 RATCHET ROD 1 23 411224 INS ANVIL 1
5 HT-02-005 HOUSING 1 24 411222 WIRE ANVIL 1
6 HT-02-006 RATCHET 1 25 HT-02-025 RING RATCHET
ROD
2
7 HT-02-007 SPRING
RATCHET
1 26 HT-02-026 SPACER HOUSING 2
8 HT-02-008 SPACER COLLAR 1 27 HT-03-027 FLOATING SHEAR 1
9 HT-03-009 SPRING
RELEASE
1 28 HT-03-028 ANVIL HOLDER 1
10 HT-02-010 ADJUST ROD 1 29 HT-03-029
HT-03-01D
TERMINAL GUIDE 1
11 HT-03-011 LINK PIN-A 1 30 HT-03-030
HT-03-01D
STRIP GUIDE 1
12 HT-02-012 CENTER PIN 1 31 HT-03-031 SPRING FLOATING
SHEAR
1
13 HT-02-013 LINK PIN-B 1 32 HT-03-032 WIRE STRIPPER 2
14 HT-02-014 SHOULDER PIN 1 33 HT-03-033 SPRING STRIPPER 2
15 HT-02-015 SPRING HANGER 1 34 HT-03-034 ADJUST BALL 1
16 HT-02-016 SEM TUBULAR
RIVET-A
1 35 HT-03-035 SPRING ADJUST 1
17 HT-02-017 SEM TUBULAR
RIVET-B
1 36 HT-03-036 SCREW SOC SET
(M 4X4)
1
18 HT-02-018 STOP RING 2 37 HT-03-037 SCREW SOC HD.
CAP (M 3X15)
1
19 HT-02-019 E-C RING 2
