Quick Reference

TURN SYSTEM ON

Check to make sure the system is READY -Green ready light is lit

Enter your four digit user code ❑unn

The On/Off (Arm) light will light

Exit through adoor designated by your installer as an exitientry door.

TURN SYSTEM OFF

Enter through adoor designated by your installer as an exiffenty door,

Enter your four digit user code ❑oon

The System On (Arm) light will go out

TURN SYSTEM ON AND STAY INSIDE

Check to make sure the system is READY -Green ready light is lit

~Followed by your user code ❑DDD

The On/Off (arm) fight and the Stay light will both light

REMEMBER: You must turn the system off if you want to open the door or

leave the premises after the exit time has passed,

TURN THE SYSTEM ON: PERIMETER SENSORS

INSTANT MODE AND STAY INSIDE

Check to make sure the system is READY -Green readv light is tit

~followedby - -

~followed by your user code ❑ ❑ ❑ ❑

The On/Off light, the Instant light and the Stay light will all be on

SMOKE DETECTOR RESET

Enter your four digit user code ❑ ❑ ❑❑

ALARM COMPANY SERVICE NUMBER

Introduction

Congratulations on your decision to protect your home or business wiih the

XL-2S security system. You have chosen areliable, state of the afl se:urity

system that is remarkably easy to operate. Your system hae been

professionally installed by your local Security Company who can explain

the specifics of your system.

The keypad is the input and display device for your security system. The

following keypad models can interact with your system. Your Security

Company will suggest the model most appropriate for your premises and

your needs.

XL-4600SM —Asurface mount keypad containing indicator tights for each

of the 6zones (areas of protection). The door coveting the buttons is

optional and can be removed.

6805 —Keypad with aplastic case and a two line English read-out LCD

(liquid crystal display). Status messages for the zones (areas of protection)

are displayed in simple English.

The XL-2S is listed by Undemriters Laboratories for Household Rn? and

Burgla~ applications.

Throughout this manual the following conventions are used to display the

keystrokes required to perform the functions.

~-Button labeled BYPASS

~-Button labeled INSTANT

~-Butte” labeled STAY

1-Button labeled CODE

❑uun -Four digit user code

Please keep your manual in aconvenient location so you can refer to it if

needed.

SYSTEM REFERENCE

ZONE PROTECTED AREA

Entry time Door Exit time

Entry time Door

USER ID ASSIGNED TO

1(MASTER USER .)

5Only Turns System On-Yesn Non

6Ambush/Duress Code -Yesn Non

“Master User can Add, Change, or Erase other user codes.

If No

The following SEND HELP ALERTS are programmed into my system. Both

Buttons must be pressed at the same time to activate the alert.

BUTTONS DESCRIPTION

Leff

Center

Right

Monitoring Station Information

Account #

Telephone #

TU~ING T~ SYSTEM ON

You can turn the Burglar portion of your security system on and off. Before

you turn the system on it must be ready, If you have aprotected door c)pen,

or someone is moving by amotion detector the system will not show ready

The syetemis ready if the ready light ie on or if the display shows:

TURN THE SYSTEM ON AND LEAVE

Enter your four digit user code ❑oon

The System On (Arm) light will go on or the display will show

Exit through adoor designated by your installer as an exiffent~ door. You

must leave within the period of time known as the exit time. Check the

reference sheet for the time that has been set for your system.

NOT READY

If the system is notready to be armed the READY light will be off and the

Zone lights will show which zone or zones are not ready. The zone lights

indicate the following conditions or the display will show as below:

Fast Btink Alarm

Slow BlinWLow Intensity Bypass

Slow Pulse Trouble

SolidOn Not Ready

Exemple: If the Ready light is not lit and the zone one light is sofid on.

An alarm sensor on zone one is not normal. This might mean that awindow

is open or someone is walking through amotion sensor. Check all sensors

on zone one and resolve the problem. When all sensors are normal the

Ready light will come on and the zone hght will go out.

~splay shows:

TO TURN THE SYSTEM ON -NOT READY

Determine which zone or zones is not ready, resolve the problem and turn

the system on normally. If the problem cannot be resolved you may bypass

the zone that is not ready. Bypassing should only be done if the problem

on the zone cannot be resolved OR if you intentionally wish to leave the

zone off, Example: you wish to keep the window open for ventilation. Zones

that are bypassed are not protected whenthesystemison.SeeBypass

for the correct procedure.

TURN SYSTEM ON AND STAY INSIDE

To turn the perimeter potion of your burglar alarm on and move around

freely inside is the STAY mode.

Check to make sure the system is READY when ready press:

~FO[lOwed by your user code ❑oon

If successful the On/Off (arm) light will be lit and the Stay tight will also be

lit or the display shows:

ON: STAY

REMEMBER: You must turn the system off if you want to open the door or

leave the premises after the exit time has passed.

TURN THE SYSTEM ON: PERIMETER SENSORS

INSTANT MODE AND STAY INSIDE

In INSTANT STAY mode the perimeter portion of your burglar alarm system

is on and the time delays are ehminated from your normal ent~/exit door(s).

All interior protection is off so you are free to move around inside.

Check to make sure the system is READY, when ready press:

~followed by

~folfowed by your user code ❑ ❑ ❑ ❑

If successful the On/Off tight, the Instant light and the Stay fight will all be

on or the display shows:

BYPASS

Bypass excludes azone of protection from the security system until it is

unbypasssed unless you have auto-bypassing enabled. Bypassing can only

be done while the syetem is turned off.

Press the Bypass Button followed by your user code and then the Zone #

(1-6) to be bypassed.

-❑ODD ,ONE

NOTE: Bypassed zones are not protected when the system is turned on.

After the bypass command has been accepted the keypad will sound one

long beep and the zone or zones bypassed will slowly blink or the display

shows:

NOTE: Temporary users (i.e. baby sittars, housekeepers, etc.) should not

be shown the Bypass procedure.

UNBYPASS

Unbypasa returns abypassed zone to normal operation.

Unbypass is arepeat of the bypass function,

After unbypassing the zone display will show the state of the zones.

TURN THE SYSTEM OFF

When you turn off the system you turn off only the burglar portion of your

system, any smoke or heat detectors and panic buttons will ramain orl. You

must enter through adesignated entry door and turn off the system within

the time allowed. You can have different amounts of time for different entry

points. See your system reference sheet for the times estabffshed for your

system.

Enter your four digit user code ❑000

[f no alarms have taken place, the On/Off light (labeled arm) will go off or

the display shows

If alarms occurred when the system was on, or if atrouble contition exists

they wifl display on the zone inficator fights as follows:

FastBlink Alarm

Slow BfinWLow Intensity Bypass

Slow Pulse Trouble

SolidOn Not Ready

or the dispfay shows:

Burglary Alarms wilf sound asteady sound through the keypad(s) and fire

alarms will generate apulsing sound.

Important If an intrusion has taken place while you were away, do not enter

until the location has been checked. Call for help from aneighbots house

and wait for the potice.

After you have turned the system off with your user code the message on

display keypads will show

To clear the display of the alarm or trouble conditions and silence the audible

alert:

Enter your four digit user code ❑UUD again.

USER CODES

ADD OR CHANGE AUSER CODE

Users can be entered or modified directly through the keypad. Your system

can have up to 6different User Codes. User #1 is the Master User and is

the only one allowed to add, or delete other users.

Press the Code button followed by the four digit master user code then the

user # and the new four digit user code. The keypad will beep after each

digit is pressed. MasterUser Code User ID New User Code

~❑000 us ❑nnn

There is arecord sheet provided in the back of the book to help you plan

and record your users. On this sheet your installer will indcate if you have

chosen to dedicate auser code to send an emergency signal in the case of

Ambush or Duress. You may also have chosen to reserve one user code

that is only allowed to turn the system on, this code will not be able to turn

the system off.

DELETE AUSER CODE

To delete user #3, press the code button followed by the four digit master

user code, then the user #then “to delete.

MasterUserCode User ID -to delete

-[ ❑oon ,*

NOTE User #1, the master user, cannot be deleted b“t it ca” be ~hanged “sing the AOD

OR CHANGE USER PROCEDURE.

TURN SYSTEM ON ONLY (Maid Code)

If you choose to have acode that cannot turn the system off, but can turn

the system on, have your installer program this feature. If programmed,

user code #5 will have System On capability only and you can issue this

code to atemporary user so they can secure the premises when they leave.

KEYPAD SE~ HELP CONDITIONS

Your system can be programmed for 3separate Send Help Alerts which

would send an emergency signal to your central station, See System

Reference sheet to see wMch have been programmed for your system,

Duress

Your system can be programmed to send an emergency signal to the

Central Station if you are forced to enter the premises. If you choose to

include this feature, User Code number 6is dedicated to this function and

must only be used under aduress circumstance.

Quick On -(Quick Arming) Yes ❑No ❑

If programmed by your installer, QUICK ON, or Quick Arming allows you to

turn the system on to the away mode without user code. NOTE: Turning

your system Off always requires avalid User Code.

Quick Forced On -Yes ❑No ❑

If programmed by your installer Quick Forced On, allows you to turn the

burglar portion of your alarm system on to the away mode bypassing all

zones that are not ready.

NOTE: Avalid user code is still required to turn the system off.

NOTE: This feature is disabled on UL installations.

Quick Bypass Yes ❑No ❑

If you have quick bypass programmed for your system you will not have to

use your user code to bypass zones. The quick bypass procedure is:

ml ZONE (,-6)

NOTE: Bypassed zones are not protected when the system is turned on.

After the bypass command has been accepted the keypad will sound one

long beep and the zone or zones bypassed will slowly blink or the display

will show

NOTE: Temporay users ~,e. baby sitters, housekeepers, etc.) should not

be shown the Bypass procedure.

Turn Ckime OtiOff

Chime is an optional feature that causes the keypad to chima when selected

doors are opened when the burglary protection is off or disarmed.

Only your installer can program azone for the chime feature, but once

programmed you can turn ctime on or off to meet your daily needs. To turn

chime on or off. Press #6

i@de the ~miti. IE

COVER

{OPEM

Autres manuels pour XL-2

Table des matières

Autres manuels FBII Système de sécurité

FBII

FBII XL-21 Manuel utilisateur

FBII

FBII XL-2 Gold Manuel utilisateur

FBII

FBII XL-1 Manuel utilisateur

FBII

FBII XL-4 Manuel utilisateur

FBII

FBII Star XL4800 EZ Manuel utilisateur

FBII

FBII Star XL4800 EZ Manuel utilisateur

FBII

FBII XL-2 Manuel utilisateur

FBII

FBII XL-21 Manuel utilisateur

FBII

FBII Star XL4800 EZ Manuel utilisateur

FBII

FBII LEGEND 7100 Manuel utilisateur

FBII

FBII Omni-408A Manuel utilisateur

FBII

FBII OMNI-400 EU Instructions de montage

FBII

FBII LEGEND SERIES Manuel utilisateur

FBII

FBII XL4600DL Manuel utilisateur

FBII

FBII Star XL4800EZ Manuel utilisateur

FBII

FBII OMNI-600EU Manuel utilisateur

FBII

FBII XL-4 Mode d'emploi

FBII

FBII XL-21 Manuel utilisateur

FBII

FBII OMNI-624EU Manuel utilisateur

FBII

FBII OMNI-408EU Manuel utilisateur

FBII

FBII XL-20 Manuel utilisateur

FBII

FBII XL-2T Instructions de montage

FBII

FBII XL Star 4500 Manuel utilisateur

FBII

FBII XL-20 Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur

DSC

DSC PC 4010 Manuel du propriétaire
