R
1
hank you for purchasing FATEK HMI. Before installing or operating the unit, pleas
ead this installation guide carefully to ensure correct use.
. Safety Precautions
(Read these precautions before use.
1.1 General
Unpack and check the delivery for transportation damage. If any damage o
deformation is found, please notify the supplier.
The supplier is not responsible for the disassembled, altered or modifie
device.
Never allow fluid or any conductive particles to enter into the HMI.
Otherwise, it may damage the HMI, cause fire or malfunction.
Only qualified personnel may install the HMI, perform maintenance an
inspection.
The liquid crystal inside the LCD panel is a hazardous substance. If the pane
is damaged, avoid contact with the leaked liquid crystal. If the liquid crysta
spills on clothing or skin, use soap and wash off thoroughly. In case of ey
contact the liquid, hold the eye open, flush with plenty water and get medica
attention as soon as possible.
Do not touch any terminals while the power is on. Otherwise, it may caus
injury due to electrical shock.
Disconnect the power supply before installing the HMI, do wiring operation
perform maintenance or inspection. Otherwise, it may cause damage o
electrical shock.
1.2 Installation
The installation may be carried out by qualified personnel only.
Install the HMI according to the installation procedures.
Check the power source voltage is within the specified range and the polarit
is correct before connecting the HMI.
Keep signal and power supply cables away from high-voltage, large-curren
carrying cables.
P2043S HMI Installation Guide
