Farho XANA PLUS Manuel
Fitting and Operating Instructions
XANA PLUS
Warning
Please read these instructions carefully and keep them for future consultation.
This heater must be installed by an accredited, qualified electrician and must
observe Low Voltage Regulations. The installation as a whole should meet the
provisions of aforesaid regulation. Any claim presented will be deemed invalid
if the prevailing regulations have not been met.
CONTENTS
3
3
4
5
6
6
7
7
8
10
11
15
16
16
16
18
18
19
20
21
21
INSTRUCTIONS FOR USE
General information
Description of the keypad and display
How to select a language
How to set the clock
How to raise or lower the room temperature
How to know whether or not a radiator is consuming power
How to block or unblock the keypad
How to activate or deactivate programmes
How to display the memorised programmes
How to customise programmes
How to reset the radiator
TROUBLESHOOTING
The Farho Xana Plus radiator is not responding to the controls
The radiator is not giving off heat
FITTER’S INSTRUCTIONS
Power Supply
Position
Fitting
TECHNICAL CHARACTERISTICS
CARE AND MAINTENANCE
IINSTRUCTIONS FOR USE
Información general
3
Thank you for purchasing a FARHO heater. This item has been
manufactured in an ultra-modern, production-line process. It is noteworthy
for its elegant shape, its user friendliness, its great heating power and
the safety of its use and operation.
It has been designed and manufactured in accordance with domestic
appliance requirements pursuant to EN 60950, EN 300 220, EN 301
489, EN60335-1, EN60335-2-30 Standards.
This product has been tested at an authorised laboratory in accordance
with aforementioned standards.
A heater is an appliance that uses the electric current it receives to
transform it into heat and to emit said heat in the space in which it has
been fitted according to the user’s heating requirements.
Correctly sized, the heater will provide sufficient heat to keep the space
in which it has been fitted warm, in accordance with the user’s
requirements. A well-insulated house is obviously an advantage and
will help to keep heating costs down.
After your heating system has been installed, you will want to make
sure that the heat coming from same remains inside the house. This is
why insulation is so important.
In addition to providing added value, the insulation prevents your
money – quite literally – from escaping through the doors, the roof, the
walls, the windows, etc. Consequently, if we fit weather slips in the
windows, or if we change single-paned windows for double-glazed
ones and insulate roofs and walls we will manage to keep the cold
outdoors and the heat indoors. Moreover, a well insulated house is
much cooler in the summer.
General Information
4
Información generalDESCRIPTION OF THE KEYPAD AND DISPLAY
DO NOT COVER the heater surfaces, given that these will be hot.
DO NOT PLACE inflammable articles, or those in danger of catching
fire, on the heaters. Consequently, clothes, towels, magazines, spray
cans and volatile substances or objects within at least 25 cm of the
heater.
1.OPERATION CONFIRMATION KEY.
2.UP KEY
3.MENU/CANCEL KEY. All menu settings
4.DOWN KEY.
The XANA PLUS model is controlled by means of intuitive menus, thus
greatly facilitating the use of same.
All you have to do to access the menu is to press the key and
scroll down by means of the and keys. Press the key
of the options menu in order to select one of the menu options.
To return to the previous menu, simply press the key again.
12
4
1.TIME.
2.ACTIVATED PROGRAMMES.
3.DAY OF THE WEEK.
4.ROOM TEMPERATURE.
5.DESIRED TEMPERATURE.
13
45
2
3
5
HOW TO SELECT A LANGUAGE
Press the key.
Press the key ONCE, which will make the “ ”
indicator position itself in front of “Settings”.
Press the key.
Press the key ONCE, which will make the “ ”
indicator position itself in front of “Languages”.
Press the key.
Press the and keys in order to scroll down the
menu, and position the “ ” indicator in front of the
desired “Language”.
Press the key.
Go to the “Settings” menu and select the language you
require in the “Language” section.
The FARHO XANA PLUS model enables you to select the language that
best suits you as regards handling the radiator. The following languages
are available in this model: Spanish, Catalan, Basque, Galician,
German, French, Hungarian, English, Italian and Portuguese.
Follow the steps below to change the menu language:
HOW TO SET THE CLOCK
6
In order to set the time in the radiator, follow the steps given below:
Press the key.
Press the key ONCE, which will make the “ ”
indicator position itself in front of “Settings”.
Press the key.
The “ ” indicator will now be positioned in front of
“Time”. Press the key again.
Press the and keys to enter the correct hour
setting.
Press the key.
Press the and keys to enter the correct minute
setting.
Press the key.
Press the and keys to enter the correct day of
the week.
Press the key.
HOW TO RAISE OR LOWER THE ROOM TEMPERATURE
To raise or lower the room temperature all you have to do is to simply
press the and keys until the temperature indicator displays the
desired heat level. The FARHO heater will automatically adjust the heat
emission efficiently until reaching the temperature level you have set.
Go to the “Settings” menu. Once there, select “Time”. Use the
and keys to select the right hour setting and accept with the
key when you are ready. Do the same with the minutes and the
date.
Press the and keys to raise and lower the operating
temperature, respectively.
7
HOW TO KNOW WHETHER OR NOT A RADIATOR IS CONSUMING
If the heater is in the consumption mode the pre-set temperature
indicator on the display will flicker. If it is not flickering, the
heater is in the idle mode.
The FARHO XANA PLUS heater will indicate
at all times whether or not it is consuming
power or not. When it is not consuming power
it is in the idle mode.
Look at the radiator display screen. If the pre-
set temperature indicator is flickering, the
radiator is in the consumption mode.
Contrariwise, if the indicator is not flickering
this means that it is in the idle mode.
HOW TO BLOCK OR UNBLOCK THE KEYPAD
Press on the key for four seconds in order to block or
unblock the keypad.
The FARHO XANA PLUS model heaters have a keypad blocking function
to avoid its handling by children, or unauthorised persons.
Press on the key for four seconds. The keypad will now be unblocked.
Press on the key for four seconds. The keypad will now be blocked.
If you press on any of the keys, the radiator will not respond to the
orders. The screen will simply display the word “Blocked”.
How to block the keypad:
How to unblock the keypad:
Press the key.
The “ ” indicator will position itself in front of
“Programmes”. Press the key.
The indicator “ ” will be in front of “Deactivate”.
Press the key. The programmes have now been
deactivated. (Note: If on reaching this step the “ ”
indicator is positioned in front of the word “Activate”
instead of “Deactivate”, this means that programmes
had already been deactivated).
8
HOW TO ACTIVATE OR DEACTIVATE PROGRAMMES
Press the key.
The “ ” indicator will position itself in front of
“Programmes”. Press the key.
The indicator “ ” will be in front of “Activate”. Press
the key. The programmes have now been activated.
(Note: If on reaching this step the “ ” indicator is
positioned in front of the word “Deactivate” instead of
“Activate”, this means that programmes had already
been activated).
Go to the “Programmes” menu, select “Activate” or
“Deactivate”. If the programmes are active, only the
“Deactivate” option will come up on the menu, and vice
versa.
To activate programmes follow the steps given below:
To deactivate programmes follow the steps given below:
