FabiaTech FP8151 Series Manuel utilisateur
ii
Copyright
Copyright © 2009 FabiaTech Corporation, The content of this publication may not
be reproduced in any part or as a whole, transcribed, stored in a retrieval system,
translated into any language, or transcribed in any form or by any means,
electronic, mechanical, and magnetic… or otherwise without the prior written
permission of FabiaTech Corporation.
Disclaimer
FabiaTech makes no representation of warranties with respect to the contents of
this publication. In an effort to continuously improve the product and add features,
FabiaTech reserves the right to revise the publication or change specifications
contained in it from time to time without prior notice of any kind from time to time.
FabiaTech shall not be reliable for technical or editorial errors or omissions, which
may occur in this document. FabiaTech shall not be reliable for any indirect,
special, incidental or consequential damages resulting from the furnishing,
performance, or use of this document.
Trademarks
Trademarks, brand names and products names mentioned in this publication are
used for identification purpose only and are the properties of their respective
owners.
Technical Support
If you have problems or difficulties in using the system or setting up the relevant
devices, and software that are not explained in this manual, please contact our
Returning Your Board For Service & Technical Support
If your board requires servicing, contact the dealer from whom you purchased the
product for service information. You can help assure efficient servicing of your
product by following these guidelines:
A list of your name, address, telephone, facsimile number, or email address
where you may be reached during the day
Description of you peripheral attachments
Description of your software (operating system, version, application
software, etc.) and BIOS configuration
Description of the symptoms (Extract wording any message)
For updated BIOS, drivers, manuals, or product information, please visit us at
www.fabiatech.com
iii
Table of Contents
FP8151 Series User’s Manual..............................................................................................i
Chapter 1 Introducing the FP8151Panel PC.............................................................................. 1
Overview..................................................................................................................................1
Series Comparison Table.......................................................................................................2
Layout.......................................................................................................................................3
Specifications..........................................................................................................................4
Packing List..............................................................................................................................6
Chapter 2 Hardware Installation ............................................................................................... 7
Before Installation...................................................................................................................7
Removing Covers –Installing Hardware...........................................................8
I/O Peripheral Connectors Panel...................................................................14
Connecting the DC Power and Power Button ............................................17
Chapter 3 BIOS Setup............................................................................................................... 19
Overview................................................................................................................................19
BIOS Functions...................................................................................................20
Keyboard Convention .....................................................................................21
STANDARD CMOS SETUP......................................................................................................22
BIOS Features Setup.............................................................................................................24
Chipset Features Setup........................................................................................................28
Integrated Peripherals.........................................................................................................31
POWER MANAGEMENT........................................................................................................36
PnP/PCI Configurations .......................................................................................................39
PC Health Status...................................................................................................................41
Chapter 4 Software Installation ............................................................................................... 43
System Driver.........................................................................................................................43
WIN 2000/XP Driver.....................................................................................................43
VGA Driver.............................................................................................................................44
WIN 2000/XP Driver.....................................................................................................44
Audio Driver...........................................................................................................................44
WIN 2000/XP................................................................................................................44
LAN Driver (Intel 82573L)......................................................................................................45
WIN 2000/XP................................................................................................................45
iv
Touch Screen Driver (FP8151T/FP8151)..............................................................................45
USB Device Driver for WIN2000/XP...........................................................................45
BIOS Flash Utility.....................................................................................................................45
Watchdog Timer...................................................................................................................46
Watchdog Timer Setting...........................................................................................47
Watchdog Timer Enabled ........................................................................................48
Watchdog Timer Trigger ...........................................................................................48
Watchdog Timer Disabled........................................................................................49
Programming RS-485............................................................................................................50
Initialize COM port .....................................................................................................50
Send out one character (Transmit).........................................................................51
Send out one block data (Transmit – the data more than two characters) ...51
Receive data..............................................................................................................51
Basic Language Example.........................................................................................51
Chapter 5 Technical Reference .............................................................................................. 53
Trouble Shooting...................................................................................................................53
Post Beep and Error Messages.................................................................................53
Touch Screen..............................................................................................................56
LCD Display is unstable .............................................................................................56
Technical Reference............................................................................................................57
Physical and Environmental.....................................................................................57
Real-Time Clock and Non-Volatile RAM ................................................................57
CMOS RAM Map........................................................................................................59
Serial Ports ...................................................................................................................60
Appendix................................................................................................................................... 64
Dimension..............................................................................................................................64
v
FabiaTech Corporation
1
Chapter1IntroducingtheFP8151PanelPC
Overview
The FP8151is 15-inch TFT Panel PC, this panel PC with low-power CPU module inside
and touch screen device. This user’s manual provides information on the physical
features, installation, and BIOS setup of the FP8151.
Built to unleash the total potential of the Intel Celeron-M Processor, Able to support
CPU C-M 600MHz CPU, this system supports one 10/100/1000M Base –TX LAN ports,
1GB DDR2-RAM, mini PCI socket for wireless LAN, four USB2.0 ports, and a dual
display VGA controller.
Each FP8151 has one port for I/O communications. One RS232/RS485 port is
available.
The FP8151is perfect for ATM machines, KIOSK, point-of-sales/point-of- information,
gaming and infotainment, measurement technology, lotteries, banking and Thin
Client and small Embedded Control. The unit is only 63.5mm (D) X401mm (W)
X308mm (H).
FabiaTech Corporation
2
SeriesComparisonTable
Model FP8151T
System Processor
Intel C-M 600MHz/512K
N+S-Chipset QG82910GMLE+NH82801FBM
Memory
1*200 Pin-DIMM (Max.)
DDR2 400
1GB/2GB
Storage HDD One CF and SATA
Watchdog Timer Yes
Multi I/O One RS232/RS485
USB 2.0 Four USB ports
Audio Ear-Phone And MIC-In
RJ45 LAN port
One PCIE Intel 82573L
10/100/1000Mbps
Mini-PCI Socket One
Panel Display Type 15’0 TFT LCD
Max. Resolution 1024X768
Max. Colors 16.2M
Luminance(cd/
㎡
) 250 cd/
㎡
Dot Size(mm) 0.297*0.297
Viewing Angle 140°(H)/125°(V)
Lamp Life 50,000Hrs
Touch Screen (w/T) 5 Wire, Analog Resistive
Resolution 2048*2048
Light Transmission 80%±%5
Life Time 10 Million Activations
Operating Temperature
0~+50℃(32~122℉)
Storage Temperature -20~+60℃(4~140℉)
Dimensions (Unit: mm)
63.5(D) x 401(W) X 308(H)
FabiaTech Corporation
3
Layout
/DC12~24V
CF
Antenna
USB
MIC
LINE
OUT
GIGALAN
KB/MOUSE
COM
CRT
RESET
POWER
DC IN 12V~24V
DC IN 12V~24V
USB
CF
FP8151
FabiaTech Corporation
4
Specifications
Processor Board –
Intel® Celeron®M processor 600MHz with 1GB DDR2-RAM.
I/O Outlets –
One PCIE 10/100/1000 base-TX Ethernet LAN port.
Four USB ports (2.0) and one RS-232/RS485 serial port.
One VGA (CRT) and one PS/2 compatible keyboard/mouse interface.
Two audio connector for Earphone and Microphone-in.
One Mini PCI Socket for Wireless module.
One DC-In plug connector and one terminal block for DC power input.
One power button and one reset button.
Storage Bay-
Compact Flash socket for Compact Flash modules or MicroDrives.
One 2.5" SATA hard disk space.
LCD Display-
Front panel with 15.0-inch color LVDS TFT LCD panel.
Supports up to XGA 1024X768 16.2M colors
Resistive Touch screen –(Only For FP8151T)
5-wire analog resistive touch screen device with USB interface.
The USB interface Software support Windows 2000/2003/XP/Vista.
Temperature
Operating temperature 0~50℃(32~122℉)
Storage temperature -20~60℃(-4~140℉)
FabiaTech Corporation
5
Power requirement –
+12V ~ +24V DC, 2.64A maximum (1.96A typical) with DC19V Input.
Dimensions –
63.5mm (D) x 401.0mm (W) x 308.0mm (H)
Certifications-
EMC: CE/FCC
Others-
Front panel protection Approval: IP65 Compliant
Weight: 7.24Kg (Standard packing)
