EZQuest Duplicators
King Boa DVD Duplication
User's Manual
Copyright and Trademark
The information in this manual is subject to change without prior notice and does
not represent a commitment on the part of vendor, who assumes no liability or re-
sponsibility for any errors that may appear in this manual.
This manual contains materials protected under International Copyright Laws. All
rights reserved. No part of this manual may be reproduced, transmitted or tran-
scribed without the expressed written permission of the manufacturer and author of
this manual.
The EZQuest King Boat DVD to DVD-R/RW Duplicator is merely used for copy-
ing and editing personal audio and video data. Violating Copy Right is a criminal
act. ACARD's Copy Smart Plus only supports legal backup operation.
EZQuest Inc.. is not responsible for the user"s illegal actions.
Page 2
Buttons and LCD
There are four buttons and an LCD on the panel of the copy smart plus. They are
described as follows.
1 2 4
3 5
1. It shows all functions and messages.
2. It is used to scroll up through functions or menus.
3. It is used to scroll down through functions or menus.
4. It is used to execute a selected function.
5. It is used to cancel a selected function.
After you power on,and the King Boa detects installed hardware like DVD-
ROM, DVD writers, it will execute a self-test for seconds. When the self-test finishes,
LCD will show the messages as follows.
1. 2.
DVD Duplicator
1-3 ver: 2.03K
Initialize SDRAM
Page 3
EZQu
EZQuest
3. 4.
Detect Drives 1. Copy
There are 12 functions for you to use. Function 1 is Copy. You can press t to select
other functions.
lPlace a source DVD into DVD-ROM.
lSwitch to function 1 Copy by pressing s .Place blank DVD disks into the
DVD writers, and press ENT to start copying.
lWhen copying comes to an end, the passed DVDs will eject automatically.
The default is eject automatically, but you can change it.
lThe failed DVDs will remain in the writers. The default is keeping failed
DVDs in the writers, but you can change it. To take the failed DVDs you
need to press the ìejectî buttons on the writers.
Page 4
Chapter 5 Functions
There are 12 functions: Copy, Test, Test & Copy, Verify, Compare, Prescan, Disc
Info, Select Source, Image, Edit Track, Setup and Advanced Setup. Among the 12
functions, Edit Track is designed exclusively for editing a collection of favorite
songs from CDs. During operation if you do not understand an LCD message, you
can see Appendix 2.
5.1 Copy
Function 1 Copy is to copy data from a source DVD directly into blank DVD disks.
Before copying be sure that the source DVD is placed onto DVD-ROM, or there are
data in a certain HDD partition if you have installed a hard disk. If you are not so
sure of real copying, you can use Function 2 Test to simulate first.
1.Copy
Select function 1. Put a source DVD onto DVD-ROM and blank DVD disks onto
the DVD writers. DVD rewriteable disks containing old data are usable, too.
After the DVD-ROM and DVD writers detect DVDs, press ENT to start copying.
LCD will show the copying information as follows.
Copying- DVD 0%
4213.4MB d:20:15
Page 5
When copying is in progress, MB and time will decrease whereas the percentage of
completion increase.
When copying comes to an end, LCD will show the results as follows. The passed
DVDs will eject automatically.
1.Copy
OK: 03
5.2 Test
Function 2 Test is to simulate the copying progress. When simulation finishes, there
will be no data really written into DVD disks.
Select function 2. Put a source DVD onto DVD-ROM and blank DVD disks onto
the DVD writers.
2.Test
Press ENT to start simulation. If you use DVD rewriteable discs that contain data,
the old data will be quickly erased before simulation as shown below.
Erasing disc
Page 6
LCD will show the testing information as follows.
Testing- DVD 0%
4213.4MB d:20:15
When the test comes to an end, LCD will show the results as follows.
2.Test
OK: 03
Stopping the test halfway does not affect the DVD disks, but if the DVD-rewriteable
disks contain important data, they may be destroyed.
5.3 Test & Copy
Select function 3. Put a source DVD onto DVD-ROM and blank DVD disks onto
the DVD writers.
3.Test & Copy
Press ENT to start simulation. LCD will show the testing information as follows.
Testing- DVD 0%
4213.4MB d:20:15
Function 3 Test & Copy is to test first and then copy actually.
Page 7
When the test finishes, actual copying will begin as shown below.
Copying- DVD 0%
4213.4MB d:20:15
When the whole process finishes, LCD will show the results as follows.
3.Test & Copy
OK: 03
5.4 Verify
Function 4 Verify is to examine if the target DVDs can be read correctly after copying.
Select function 4.
4.Verify
Press ENT to verify. LCD will show the verification information as follows.
Verify- DVD 0%
4213.4MB 2:29:14
Page 8
When verification comes to an end, LCD will show the results as follows.
4.Verify
OK: 03
5.5 Compare
Function 5 Compare is to make a comparison between the source DVD and the
target DVDs after copying.
Select function 5. Put the source DVD onto DVD-ROM and the target DVDs onto
DVD writers.
5.Compare
Press ENT to compare.LCD will show the comparison information as follows.
Compare- DVD 0%
4213.4MB 1:05:06
When comparison comes to an end, LCD will show the results as follows.
Compare OK: 3
Fail: 0 Diff: 0
Page 9
Press ENT to see the details of source 1 as shown below.
Src: 01 DVD-ROM
Total: 4213.4MB
Press ENT to see the details of source 2. If the comparison is identical, LCD will
show the message as follows.
Src: 02 DVD-RW
Identical
If comparison fails, LCD will show the failure. By pressing ENT twice, LCD will
show that the contents of source 1 and those of source 2 do not match as follows.
Src: 02 DVD-RW
TOC not match
5.6 Prescan
Function 6 Prescan is to scan if the source DVD can be read correctly, and by the
way to test the reading speed.
Select function 6. Put the source DVD onto DVD-ROM.
6.Prescan
Page 10
