Ezdupe Mini USB Pro Manuel utilisateur

Content

Mini USB PRO

Duplicator

User Manual

I. Introduction....................................................................................................................2

1. Features........................................................................................................................................2

2. ControlPanelOverview ...............................................................................................................3

3. Specifications...............................................................................................................................4

II. Warning..........................................................................................................................4

III. Asynchronous Operation............................................................................................5

IV. Menu Overview............................................................................................................6

1. Copy .............................................................................................................................................6

2. Compare.......................................................................................................................................6

3. Utility............................................................................................................................................7

3.1 FormatFAT32 ..............................................................................................................................7

3.2 Format exFAT..............................................................................................................................7

3.3 QuickErase ..................................................................................................................................7

3.4 Full Erase.....................................................................................................................................8

3.5 Media Information......................................................................................................................8

3.6 Set Language ...............................................................................................................................8

3.7 System Information ....................................................................................................................8

3.8 SystemUpdate..............................................................................................................................9

I. Introduction

This duplicator system is designed and developed based on the FPGA from the world famous

semiconductor company XILINX. Every processing port is parallel to each other with its own

control unit, therefore the duplicator will not sacrifice speed for the increasing number of targets

loaded - always remain the same and fast copy speed. The duplicator supports fast copy with

multiple file formats created by three major operating systems (Windows/Linux/MAC), and makes

mirror copies of data efficiently. Furthermore, this duplicator has been fully tested with quality

assurance before leaving our manufacturing facility.

1. Features

•Each processing channel has its own control unit and operates independently with dedicated

bandwidth of up to 35MB per second.

•Standalone operation. No PC or software is required, minimizing possible computer virus

infection.

•Instant power on and off, no warm-up or cool-down required.

•Easy-to-use One-Touch copy operation.

•Compare function available for verification of copy accuracy

•Menu options are user-friendly and easily accessed through the 4-button control panel. Use ▲or

▼ button to scroll through the options and view the operation status of each channel on the 2-line

backlit LCD display.

•Support Asynchronous copy mode for best operation efficiency.

•Powerful 32-bit CRC checksum to assure data integrity.

•Heavy-duty hardware construction for commercial production or personal use.

•115V and 230V switching power supply maximizes portability for operation anywhere.

•Designed to save users time and effort in creating multiple copies quickly and reliably.

•Unique source data analysis to copy data area only to achieve highest efficiency

•Supports multiple file formats: Windows: FAT 16/32、exFAT、NTFS, Linux: Ext 2/3/4, Mac:

HFS/HFS+, HFSX

2. Control Panel Overview

▲ Button: Up, Backward

▼ Button: Down, Forward

ENT Button: Enter, OK

ESC Button: Escape, Cancel

2-linebacklitLCD creen

▼ Button

Button

▲ Button

ENT Button

ESC Button

Specifications

Operation

Standalone (No PC or Software is required)

Target

Copy Speed

35 MB/S

Copy Mode

Asynchronous

Copy Area

System and Files (Intelligent Copy)

Supported Media

USB Flash Drive 1.1/ 2.0/ 3.0/ 3.1

Display

2-line Backlit Monochrome LCD

Supported Format

FAT16,FAT32,exFAT,NTFS,ext2/3/4(Linux),HFS/HFS+(Mac)

System Memory

128 MB DDR3

Power Adapter

Input：AC 100-230V Output：DC 12V/3A

Control Button

4 push-button control panel (ENT, ESC, UP, DOWN )

Humidity

Working

20% ~ 80%

Storage

5% ~ 95%

Temperature

Working

41°F ~ 113°F (5℃~ 45℃)

Storage

-4 °F ~ 185°F (-20℃~ 85℃)

II. Warning

1. Source port is write-protected to prevent source data is erased accidently.

2. The duplicator tasks mentioned in this user’s manual are as following: Copy, Compare, Format,

and Erase.

3. The Green LED flashes during the execution process of a task. After the task is done, the Green

LED will stay solid if the process is successful, otherwise the Red LED will be on if the process is

failed.

4. It is strongly recommended that the capacities of the source and target media are equal or similar.

III. Asynchronous Operation

Asynchronous Operation is designed for the duplicator. It means that the duplicator will read the

data from source device into system memory buffer and start to execute a task immediately when

target device(s) inserted. Duplicator does not have to wait for all target device(s) inserted in order to

start the execution of the task at the same time. No matter the data size of the source device,

duplicator can asynchronously execute a task.

1. Insert source media into the source port, select the task to execute from the menu, and press ENT

button. Duplicator will start to execute the task.

2. Target devices can be plugged in during the execution process, and will start to execute the task

immediately

3. Target device can be removed when it finishes the execution process and its green LED is solid

on. New target device can be plugged into the same port for execution of the task again.

4. LCD display will show the percentage of execution process, the number of successful and failed

target(s). Here the percentage of execution process displayed is only for the least processed target

device.

5. During the execution process, the status of each target device can be checked by using the ▲ and

▼ buttons.

6. After the task is done for all target devices, press ESC button to exit from the task. LCD display

will show the total number of successful and failed target(s).

7. Each USB port executes the task asynchronously, doesn’t need to wait for all target devices to be

ready at same time.

IV. Menu Overview

1. Copy

To copy from source device to target device(s) bit by bit and only copy available data area.

When the source device reads fail, all target devices stop copying. When one of the target

devices writes fail, it will stop copying.

2. Compare

This command allows comparing the copied target devices against the source for accuracy.

ENT

Insert source device

and press ENT button

No source device

Copy：01100M

00:00 Wait

1. Copy

Source Not Ready

1. Copy

Ready device: 0

Copy: 0 number of targets

1100M: data to be copied

00:00: executing time

Wait: Waiting for target

drives to be inserted

Copy is finished, the target

devices can be unplugged and

new target devices can be

inserted to start copy again. Or

press ESC button to end the

copy process.

Copy: 0 1100M

P: 4 F: 0 Wait

Copy starts automatically when

target devices are inserted

Copy：41100M

00:10 10%

ENT

No source device

Compare：0 1100M

00:00 Wait

2. Compare

Source Not Ready

1. Compare

Ready device: 0

Result: 01:31

Pass：4Fail：0

Compare：41100M

00:10 10%

ESC

Result: 01:31

Pass：4Fail：0

ESC

Press ESC button to end

the copy process.

Insert source device

and press ENT button

Compare starts automatically

when target devices are inserted

Press ESC button to end

the compare process.

Compare is finished, the target

devices can be unplugged and

new target devices can be

inserted to start compare again.

Or press ESC button to end the

compare process.

Compare: 0 1100M

P: 4 F: 0 Wait

Wait for target devices

3. Utility

3.1 Format FAT32

This option allows to format the target device to FAT32 file format. It will not format the source

device, avoiding accidently erasing the original data content.

3.2 Format exFAT

This option allows to format the target device to exFAT file format. It will not format the source

device, avoiding accidently erasing the original data content.

3.3 Quick Erase

This option erases the table of content of file system of the target device.

Format：0

00:00 Wait

[Utility]

1. Format FAT32

Sure to format?

Yes

Result:

Pass：4Fail：0

ENT

ESC

ENT

Format：4

00:01 100%

Press ESC button to

end the process

Format：0

00:00 Wait

[Utility]

2. Format exFAT

Sure to format?

Yes

Result:

Pass：4Fail：0

ENT

ESC

ENT

Format：4

00:01 100%

Q_Erase：0

00:00 Wait

[Utility]

3. Quick Erase

Sure to erase?

Yes

Result:

Pass：4Fail：0

ENT

ESC

ENT

Q_Erase：4

00:01 100%

Wait for target devices

Format starts automatically

when target devices are inserted

Wait for target devices

Press ESC button to

end the process

Format starts automatically

when target devices are inserted

Wait for target devices

Press ESC button to

end the process

Erase starts automatically when

target devices are inserted

3.4 Full Erase

This option completely erases the content of target device.

3.5 Media Information

This option displays the information of selected device media, such as total capacity, file format and

the size of data content.

3.6 Set Language

This option allows choose the language for display: English, Spanish, Portuguese, and Japanese.

English is the default language.

3.7 System Information

This option displays general information of the duplicator, including controller model, system

memory size, firmware version and number of targets.

ENT

Use ▲or ▼to select

device

[#0] 29.8G

FAT32 20.1G

[Utility]

5. Media Information

Port # Total Capacity

File Format Data Size

ENT

Display system info

F0104V 128MB

V2.00.41

[Utility]

7. System Information

Model Memory

Firmware

F_Erase：0

00:00 Wait

[Utility]

4. Full Erase

Sure to erase?

Yes

Result:

Pass：4Fail：0

ENT

ESC

ENT

F_Erase：0

01:00 100%

Use ▲or ▼to select and

press ENT to confirm

ENT

[Language]

English

[Utility]

6. Set Language

Wait for target devices

3.8 System Update

This option allows user to update the firmware of duplicator when necessary. Please obtain the

proper firmware file from manufacturer, and save the unzipped file under home folder on the flash

device (DO NOT save the file under sub folder). Insert the flash device containing the firmware

into the source port of duplicator and press ENT. It will update the system, reboot the duplicator

after update, and operate under the new firmware. The file system of the flash drive must be

FAT32.

Update complete!

Please wait for reboot

ENT

Searching disc

Update BIOS

Identify disc…

[Utility]

8. System Update

Update BIOS

Complete! Reboot!

Table des matières

Autres manuels ezdupe duplicateur de disques

ezdupe

ezdupe hdmini Manuel utilisateur

ezdupe

ezdupe NV-05M Manuel utilisateur

ezdupe

ezdupe Media Maven Manuel utilisateur

ezdupe

ezdupe NVMe CyCLONE Pro Manuel utilisateur

ezdupe

ezdupe Flex PRO SD Manuel utilisateur

ezdupe

ezdupe media mirror Manuel utilisateur

ezdupe

ezdupe DVD Coach Manuel utilisateur

ezdupe

ezdupe Classic NVMe CyCLONE Manuel utilisateur

ezdupe

ezdupe PRO Series Manuel utilisateur

ezdupe

ezdupe Gold Premier Manuel utilisateur

ezdupe

ezdupe HD Pal Series Manuel utilisateur

ezdupe

ezdupe USATA900 Manuel utilisateur

Manuels duplicateur de disques populaires d'autres marques

Riso

Riso CV Series Manuel

MicroBoards Technology

MicroBoards Technology GX-2 Manuel utilisateur

Addonics Technologies

Addonics Technologies HDUS325DX Manuel utilisateur

Carry

Carry Pro118 Manuel utilisateur

CopyPro

CopyPro PowerPro II Manuel utilisateur

Primera

Primera Max Manuel utilisateur

Logicube

Logicube EchoPlus-NG Manuel utilisateur

Silca

Silca Delta 2000 SA Manuel utilisateur

Reflex7

Reflex7 Daisy Chain Series Manuel utilisateur

Vinpower Digital

Vinpower Digital SharkCopier DC Manuel utilisateur

Codonics

Codonics Virtua E Manuel utilisateur

Octave

Octave Copy Master II Manuel utilisateur

Kanguru

Kanguru U2-DVDDUPE-S Manuel utilisateur

StarTech.com

StarTech.com 8STSATDUP11 Manuel utilisateur

DUPLO SEIKO CORPORATION

DUPLO SEIKO CORPORATION Duprinter DP-460 Manuel utilisateur

Addonics Technologies

Addonics Technologies UDFH7 Manuel utilisateur

Vinpower Digital

Vinpower Digital MiniLoader VDX-1 Manuel utilisateur

Addonics Technologies

Addonics Technologies CFASTD5 Manuel utilisateur

ezdupe Mini USB Pro Manuel utilisateur

Manuels duplicateur de disques populaires d'autres marques
