EZCast Mini Box Manuel utilisateur
Product information is subject to change without prior notice.
Rev 1.4
EZCast Mini Box Display Receiver
Quick Start Guide
Software Installation
EZCast supports multiple wireless display standards, including
EZCast, Miracast, DLNA and EZAir (compatible with iOS and
macOS). Ongoing firmware upgrades are provided to support
latest operating systems. Please read this guide to install and
setup your EZCast. Happy Casting!
Visit https://www.EZCast.com/app to download platform-specif-
ic applications and User Manual.
Scan the QRCode below to download EZCast mobile App.
Introduction
1
Your TV screen shall display the instructions once EZCast is
connected successfully. Please follow the instructions to
complete setup.
Set your TV’s source/ input selection to HDMI port that
connected to the EZCast dongle
Connect successfully
Install EZCast Mini Box
2
3
1
HDMI1
HDMI2
HDMI3
PC
USB
Hardware Installation
2
(a)MiniBox to power: Connect the DC port to power (5V/2A).
(b)Mini Box to TV: Connect to the HDMI port of your TV.
(c)Connect to network: Connect to network wirelessly or via
LAN port.
Select source
3 4
MiniBox
LAN port
or
Router
HDMI
a
b
c
5V/2A
Download EZCast app
Scan QRCode on TV screen or search
“EZCast” on Google Play/App Store.
LAN light of Mini Box turns on when connected to router via
LAN port.
Setup for smart device (Android/ iOS)
3
Connect to network:
Via LAN port
POWER LAN USB WIFI
Connect wirelessly
(1) Launch EZCast App and follow the guide to add device.
If the guide doesn’t pop out, click at the upper right and
click “+” at the upper left.
(2) Press and scan the QRCode on your screen.
(3) Make sure the SSID and picture shown are correct.
(4) Connect the device to your home Wi-Fi by entering the
correct password. After the connection, press “next” button.
(6) Sign up an EZCast account to save hashtags, create
playlists, voice control, and autoplay.
(5) Check whether the connection status at the upper right on
your screen shows your home wifi or not. If connection fails,
please connect again.
Home Wi-Fi Next
Home Wi-Fi
Password
Screen Mirroring for Android
4
EZCast/ Mirror (Android 5.0 above)
Click the Mirror icon on the top bar.
Note: For EZCast/ Mirror, it only captures the screen
without sound due to limitations in Android. To mirror the
sound to your TV, please use EZMirror instead.
Google Home
You may download Google Home App from Google Play.
Launch the Google Home App, login with Google account.
Then you may mirror to EZCast using Google Home.
Steps: Choose device name: MiniBox-xxxxxxxx > Cast my
screen > Cast screen
Note: Make sure that EZCast Band 1 and your device are
both connected to same Wi-Fi. Use 5GHz WiFi, instead of
2.4GHz, which provides higher speed connection and
better performance for Google Home mirroring.
2
1
3
MiniBox-12345678
Cast my screen
Cast screen
MiniBox-12345678
MiniBox-12345678
Cast to
Screen
Mirroring
Screen Mirroring
5
Screen Mirroring for iOS
EZAir
Note: Make sure that EZCast and your iOS device are
both connected to same network.
Mirror to EZCast using Miracast if your Android devices
support Smart View on Samsung, Multi-screen on Huawei,
Multi-screen Interaction on OPPO, or etc.
Screen mirroring may be done by EZAir on iOS smart devices.
Swipe and click Screen Mirroring, and then find and select
MiniBox-xxxxxxxx.
Miracast
Vivo
Screen mirroring
OPPO
Multi-screen
Interaction
Samsung
Smart View
Huawei
Multi-screen
6
Internet:
Connect EZCast to WiFi.
Resolution:
Change output resolution.
Language:
Change language preference.
Password:
Change password of EZCast.
Device Name:
Change device name of EZCast.
EZChannel (Auto play):
Automatically start video streaming which created at your
EZChannel playlist once your EZCast dongle is connected to
WiFi.
EZAir Mode (only for iOS):
Switch mirroring mode of EZCast between “mirror only” and
“mirror + streaming” for iOS devices.
Wallpaper:
Set a keyword and automatically play the pictures related
during standby mode.
Upgrade:
Upgrade your EZCast firmware to latest version for better user
experience. Please do NOT turn off the Wifi and the power of
EZCast during firmware.
Reset to default:
Reset EZCast to default settings.
EZCast Mini Box Settings
7
EZChannel:
Create an EZCast account and bind with your EZCast Mini
Box dongle to get advance functions.
(1) Discover and personalize your video channels.
(2) Search videos across different media sites.
(3) Auto-play: Automatically start video streaming which are
created at your EZChannel playlist once your EZCast dongle
is connected to WiFi.
Video/ Photo/ Music:
Stream and playback local media files from devices to EZCast
dongle wirelessly.
Live Camera:
Capture videos from local camera to EZCast dongle.
DLNA:
Stream multimedia files via DLNA protocol.
Cloud Storage:
Access data from Cloud server (Dropbox, Google drive, or
etc.).
Voice Control:
Pair EZCast Mini Box with any Google Home/ Assistant/
Amazon Echo Dot, and stream cloud videos just by asking.
e.g.
“Hey Google, ask EZCast to play holiday video.”
User manual please refers to website as below.
https://www.ezcast.com/support
Features of EZCast
8
Screen Mirroring
Download and install EZCast application
1
2
3
Setup for laptop (Windows/ MacOS)
Click Mirroring in EZCast application.
Download at https://www.ezcast.com/app.
(1) Click Wi-Fi list from your laptop and connect to your
MiniBox-xxxxxxxx by entering password on TV screen.
(2) Launch EZCast application, your EZCast device will
connect automatically and shows SSID at the upper right.
Setting shall pop out (or find from side bar). Click Internet
and connect to your Wi-Fi.
(3) Click Search Device and select your MiniBox-xxxxxxxx
on the device list.
Connect to WiFi
3
2
1
Setting
Search Device
Mirror MiniBox-xxxxxxxx
EZCast app
Mon 09:30 AM
2019/07/01
ENG
MiniBox-12345678
9
1
2
3
Mirror/ Extend Screen for Mac
Screen Mirroring
Connect to EZCast dongle
Mirror/ Extend
Click icon on the top bar and select MiniBox-xxxxxxxx to
mirror.
Connect to EZCast dongle from Wi-Fi setting on the top bar:
directly connect to MiniBox-xxxxxxxx or connect to the same
Wi-Fi as EZCast Mini Box.
100% Fri 09:30 AM
Same Wi-Fi as EZCast Mini Box
MiniBox-12345678
Once your Mac is screen mirroring, you could select “Mirror
Built-in Display” to mirror, or “Use As Separate Display” to
extend your screen.
100% Fri 09:30 AM
Mirror Built-in Display
Use As Separate Display
2
3
MiniBox-12345678
