Speciﬁcations — CCR 204, CCR 306

1

Extron CCR 204, CCR 306 Contact Closure Remote Control Panels • Specications

Switch contact closure

Quantity/type

CCR 204 �� 4 normally open switches

CCR 306 �� 6 normally open switches

Connectors

CCR 204 �� (1) 3�5 mm captive screw connector, 5 pole

CCR 306 �� (1) 3�5 mm captive screw connector, 3 pole

(1) 3�5 mm captive screw connector, 5 pole

Contact rating �� 50 VDC, 25 mA

Pin conﬁgurations

CCR 204 �� Pins 1, 2, 3, 4 = switches 1, 2, 3, 4; pin 5 = GND

CCR 306 �� 3 pole connector: pin 1 = switch 1, pin 2 = switch 2, pin 3 = GND

5 pole connector: pins 1, 2, 3, 4 = switches 3, 4, 5, 6; pin 5 = GND

N Each switch can be used to select an input on a connected switcher. See the CCR's installation

instructions for details.

General

Temperature/humidity�� Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Mounting

Furniture mount�� Yes

Enclosure type �� Metal

Enclosure dimensions

CCR 204

Faceplate�� 1�75" H x 4�0" W x 0�1" D (4�4 cm H x 10�2 cm W x 0�3 cm D)

Device �� 2�6" H x 1�4" W x 1�2" D (6�6 cm H x 3�4 cm W x 3�0 cm D)

(Depth excludes buttons� Allow at least 1�65" [4�2 cm] depth in the wall or

furniture for device and cable clearance�)

CCR 306

Faceplate�� 2�1" H x 4�0" W x 0�1" D (5�3 cm H x 10�2 cm W x 0�3 cm D)

Device �� 2�6" H x 1�4" W x 1�2" D (6�6 cm H x 3�4 cm W x 3�0 cm D)

(Depth excludes buttons� Allow at least 1�65" [4�2 cm] depth in the wall or

furniture for device and cable clearance�)

Product weight

CCR 204 �� 0�1 lb (0�05 kg)

CCR 306 �� 0�1 lb (0�03 kg)

Shipping weight �� 1 lb (<1 kg)

Vibration�� ISTA 1A in carton (International Safe Transit Association)

Regulatory compliance

Environmental�� Complies with the appropriate requirements of RoHS, WEEE

MTBF�� 30,000 hours

Warranty�� 3 years parts and labor

N All nominal levels are at ±10%.

N Speciﬁcations are subject to change without notice.
