Specifications — ISM 182, ISM 482 Scaling Matrix Switchers

Video

Routing.......................................... 8 x 2 matrix

Video input

Number/signal type ................... 8 RGBHV, RGBS, RGsB, RGBcvS, component video, S-video, composite video

Connectors .................................... 8 x 5 female BNC

Nominal level ............................... 1 Vp-p for Y of component video and S-video, and for composite video

0.7 Vp-p for RGB

0.3 Vp-p for R-Y and B-Y of component video, and for C of S-video

Minimum/maximum levels ...... Analog: 0 V to 1.0 Vp-p with no offset

Impedance ....................................

Horizontal frequency

ISM182 ...............................

ISM 482 ..............................

Vertical frequency .......................

Resolution range ..........................

Video processing

Decoder .........................................

75 ohms

Autoscan 15 kHz to 85 kHz (RGB)

Autoscan 15 kHz to 100 kHz (RGB)

Autoscan 50 Hz to 100 Hz

Autoscan 720 x 525 to 1600 x 1200

9 bit digital

Digital sampling .......................... 24 bit, 8 bits per color; 13.5 MHz standard (video), 140 MHz standard (RGB)

Colors ............................................ 16.78 million

Horizontal filtering ..................... 4 levels

Vertical filtering ........................... 8 levels

Video output

Number/signal type ................... 2 scaled RGBHV, RGBS

Connectors .................................... 2 x 5 BNC female, (2) 15-pin HD female

Nominal level ............................... 0.7 Vp-p for RGB

Minimum/maximum levels ...... 0 V to 0.7 Vp-p

Impedance .................................... 75 ohms

Scaled resolutions

ISM 182 .............................. 640x4801,3,4,6, 800x6001,3,4,6, 832x6243,4,6, 848x4803,6, 852x4803,6, 1024x7681,3,4,5,6

ISM 482 .............................. 640x4801,3,4,6, 800x6001,3,4,6, 832x6243,4,6, 848x4803,6, 852x4803,6, 1024x7681,3,4,5,6,

1280x7682,6, 1280x10241,3, 1360x7653,6, 1365x10243,6, 1400x10501,3,6, 576p1,6, 720p3,6,

1080p3,6, 1080i1,3,6

1= at 50 Hz 2= at 56 Hz 3= at 60 Hz 4= at 75 Hz 5 = 85 Hz

6 = locked to the current input’s vertical refresh rate (Accu-RATE Frame Lock)

Return loss .................................... -30 dB @ 5 MHz

DC offset ....................................... ±5 mV with input at 0 offset

Sync

Input type ..................................... Autodetect RGBHV, RGBS, RGsB, RGBcvS

Output type .................................. RGBHV, RGBS

Standards ...................................... NTSC 3.58, NTSC 4.43, PAL, SECAM

Input level ..................................... 0 V to 5.0 Vp-p

Output level.................................. 0 V to 5.0 Vp-p, unterminated

Input impedance.......................... 510 ohms

Output impedance ...................... 75 ohms

Max input voltage ....................... 5.0 Vp-p

Max. propagation delay.............. 20 ns

Polarity .......................................... Positive or negative (selectable)

1-2 ISM 182, ISM 482 • Specifications

Audio

Routing .......................................... 8 x 2 stereo matrix

Gain ............................................... Unbalanced output: 0 dB; balanced output: +6 dB

Frequency response ..................... 20 Hz to 20 kHz, ±0.05 dB

THD + Noise ................................ 0.03% @ 1 kHz at nominal level

S/N ................................................ >90 dB at maximum output (unweighted)

Crosstalk ....................................... <-80 dB @ 1 kHz, fully loaded

Stereo channel separation .......... >90 dB @ 1 kHz

CMRR ............................................ >75 dB @ 20 Hz to 20 kHz

Audio input

Number/signal type ................... 8 stereo, balanced/unbalanced

Connectors .................................... (8) 3.5 mm captive screw connectors, 5 pole

Impedance .................................... >10k ohms unbalanced/balanced, DC coupled

Nominal level ............................... Configurable: -60 dBV (1 mVrms), +4 dBu (1.23 Vrms), 0 dBu (0.775 Vrms),

-10 dBV (316 mVrms), -20 dBV (100 mVrms)

Maximum level ............................ +19.5 dBu, (balanced or unbalanced) at 1%THD+N

Input gain adjustment................. –24 dB to +9 dB, adjustable per input

0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV 2 dBu.

Audio output

Number/signal type ................... 2 stereo, balanced/unbalanced

Connectors .................................... (2) 3.5 mm captive screw connectors, 5 pole

Impedance .................................... 50 ohms unbalanced, 100 ohms balanced

Gain error ...................................... ±0.1 dB channel to channel

Maximum level (Hi-Z) ................ >+21 dBu, balanced or unbalanced at 1%THD+N

Maximum level (600 ohm) ......... >+15 dBm, balanced or unbalanced at 1%THD+N

Control/remote — switcher/scaler

Serial control port ........................ RS-232, 9-pin female D connector

Baud rate and protocol ............... 9600 baud, 8 data bits, 1 stop bit, no parity

Serial control pin configurations 2 = TX, 3 = RX, 5 = GND

Ethernet control port ................... 1 RJ-45 female connector

Ethernet data rate ........................ 10/100Base-T, half/full duplex with autodetect

Ethernet protocol ......................... ARP, ICMP (ping), TCP/IP, Telnet

Program control ........................... Extron’s control/configuration program for Windows®

Extron’s Simple Instruction Set (SIS™)

Microsoft®Internet Explorer, Telnet

General

Power............................................. 100 VAC to 240 VAC, 50/60 Hz, 60 watts, internal, autoswitchable

Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Rack mount ................................... Yes

Enclosure type .............................. Metal

Enclosure dimensions ................. 5.25" H x 17.5" W x 11.2" D (3U high, full rack wide)

13.3 cm H x 48.3 cm W x 28.4 cm D

(Depth excludes connectors and knobs. Width excludes rack ears.)

Product weight ............................. 11.2 lbs (5.1 kg)

Shipping weight ........................... 17 lbs (8 kg)

DIM weight

USA/Canada.................... 18 lbs (9 kg)

International ..................... 21 lbs (10 kg)

ISM 182, ISM 482 • Specifications 1-3

Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)

Listings .......................................... UL, CUL

Compliances ................................. CE, FCC Class B

MTBF ............................................. 30,000 hours

Warranty ....................................... 3 years parts and labor

All nominal levels are at ±10%

Specifications are subject to change without notice.

(7.51-120904-D6)

1-4 ISM 182, ISM 482 • Specifications
