Extron electronics FOXBOX HDMI Manuel utilisateur

IMPORTANT:

Go to www.extron.com for the complete

user guide, installation instructions, and

specifications before connecting the

product to the power source.

FOXBOX HDMI • Setup Guide

This guide provides quick start instructions for an experienced installer to set up and operate the Extron FOXBOX HDMI ber optic

extenders.

CLASS 1 LASER PRODUCT, see FOXBOX HDMI User Guide at www.extron.com

CAUTION:

• These units output continuous invisible light, which may be harmful to the eyes; use with caution. For additional safety, plug the

attached dust caps into the optical transceivers when the fiber optic cable is unplugged.

• Ces produits émettent une lumière invisible continue, qui peut être dangereuse pour les yeux ; à utiliser avec précaution. Pour

une sécurité renforcée, associez les bouchons anti-poussière à l’ensemble émetteur/récepteur optique lorsque le câble fibre

optique est débranché.

Installation

FOXBOX Tx HDMI Rear Panel

Front Panel

FOXBOX Rx HDMI Rear Panel

12V

1.0A MAX

POWER

FOXBOX Tx HDMI

AUDIO INPUT

RS-232

OVER FIBER ALARM

Tx Rx 1 2

HDMI INPUT

LINK

OPTICAL

RxTx

LINK

FOXBOX Tx HDMI

AUDIO

HDCP

HDMI

CONFIG

HDMI LOOP THRU

EDID MINDER 50Hz

AUDIO

DIGITAL

ANALOG60Hz

1 2

12V

1.0A MAX

POWER

LINK

OPTICAL

RxTx

LINK

HDMI AUDIO

HDMI

AUDIO

OUTPUTS

OFF

REMOTE

RS-232

Tx Rx

RS-232

OVER FIBER ALARM

Tx Rx 1 2

FOXBOX Rx HDMI

Step 1 — Mounting

Turn off or disconnect all equipment power

sources and mount the transmitter and

receiver as required.

Step 2 — Input and Output

Connections

a. Connect an HDMI video source to the

transmitter HDMI connector.

b. If desired, connect an HDMI video display to the transmitter HDMI Loop-Thru connector.

c. Connect an HDMI video display to the receiver HDMI Output connector.

NOTE: Use a LockIt™ Lacing Bracket to securely fasten an HDMI cable to each device as follows.

1. Plug the HDMI cable into the panel connection

2. Loosen the HDMI connection mounting screw from the panel enough to allow the

LockIt lacing bracket to be placed over it. The screw does not have to be removed.

3. Place the LockIt lacing bracket on the screw and against the HDMI connector, then

tighten the screw to secure the bracket.

ATTENTION:

• Do not overtighten the HDMI connector mounting screw. The shield it

fastens to is very thin and can easily be stripped.

• Ne serrez pas trop la vis de montage du connecteur HDMI. Le blindage

auquel elle est attachée est très fin et peut facilement être dénudé.

4. Loosely place the included tie wrap around the HDMI connector and the LockIt lacing

bracket as shown.

5. While holding the connector securely against the lacing bracket, use pliers or similar tools to tighten the tie wrap, then

remove any excess length.

d. Connect an audio input device to the transmitter Input Audio 3.5 mm mini jack.

e. Connect an audio device to the receiver Audio captive

screw connector. See the drawing at right.

ATTENTION:

• For unbalanced audio, connect the sleeves to the ground contact. DO NOT connect the sleeves to the negative (-) contacts.

• Pour l’audio asymétrique, connectez les manchons au contact au sol. NE PAS connecter les manchons aux

contacts négatifs (–).

Do not tin the wires!

Unbalanced Stereo OutputBalanced Stereo Output

Tip

NO GROUND HERE

Tip

Sleeves

Tip

Ring

Tip

Ring

Sleeves

FOXBOX HDMI • Setup Guide (Continued)

f. If you want the FOXBOX HDMI units to pass serial data or control signals, such as for serial control of a

ALARM

Tx Rx 1 2

RS-232

OVER FIBER

projector, connect the primary device to the transmitter and the slave device to the receiver via the left three poles (Tx, Rx,

and _) of the RS-232 Over Fiber/Alarm 5-pole captive screw connectors on both units.

g. For serial control of a unit, connect a host device, such as a computer, to one of the following ports on the unit to be

controlled:

Transmitter or receiver Conﬁguration port — A 2.5 mm mini jack. A TRS RS-232 cable is included with the transmitter.

CONFIG

Receiver Remote RS-232 port — Use the Remote RS-232 3-pole captive screw connector.

The protocol for both of these ports is as follows:

REMOTE

RS-232

Tx Rx

•9600 baud •no parity •8 data bits

•1 stop bit •no flow control

h. For remote monitoring of the status of the Rx optical link on either the transmitter or receiver, connect a locally

ALARM

Tx Rx 1 2

RS-232

OVER FIBER

constructed or obtained device to the two right Alarm poles of the RS-232 Over Fiber/Alarm 5-pole captive screw

connector on that unit. The unit shorts both poles together when no light is detected.

Step 3 — Throughput Connections

NOTES:

• See the two fiber cable connection drawings below. You can connect the transmitter and one or more receivers in one of three

ways:

• One way (transmitter to receiver) only, perform step a.

• Two way (transmitter to receiver and return), perform steps a and b.

• One way (transmitter to receiver) with daisy chain (receiver to receiver), perform steps a and c.

• HDCP compliance requires both fiber cables.

a. Connect the fiber between the Tx port on the transmitter and the Rx port on the receiver.

b. If you want the receiver to return serial data (such as responses from a controlled device) to the transmitter, connect a

cable between the Tx port on the receiver and Rx port on the transmitter.

c. If you want a receiver to daisy-chain the optical signal to another receiver (up to 10 receivers in a daisy chain):

•Connect the receiver Tx fiber cable to the Rx port on another receiver.

•Set each receiver to daisy chain mode. See “Return Link and

Daisy Chain Modes,” below.

Operation

After all receivers, the transmitter, and their connected devices

are powered up, the system is fully operational. If any problems

are encountered, verify that the cables are routed and connected properly and that all display devices have identical

resolutions and refresh rates. If problems persist, call the Extron S3 Sales & Technical Support Hotline at the number that is

closest to you.

Return Link and Daisy Chain Modes

The receiver can operate in one of two modes (or both modes can be disabled):

Return link mode — The receiver outputs data on its Tx connector for return to the transmitter.

Daisy chain mode — The receiver daisy-chains its Rx connector input through to its Tx connector output.

Use SIS commands to toggle between return disable, normal, daisy chain modes. Connect a PC to the receiver and issue the following

command: 66*0*n#, where n= 0= disable, 1= enable return link (default mode), and 2= daisy chain enable.

NOTES:

• Up to 10 receivers, each in daisy chain mode, can be connected in a daisy chain to a single transmitter.

• Daisy chain mode works with non-HDCP sources only.

HDMI Audio Switch

This switch mutes (Off position) and unmutes (On position) the embedded audio output on the HDMI output connector.

HDMI AUDIO

OFF

The audio on the captive screw output always remains active regardless of the setting of this switch.

Receiver

ansmitter

Tx Rx

and

From Transmitter

or Daisy-Chained

Receiver

Tx Rx

Indications

Tx Link and Rx Link LEDs — When lit, the link is active (light is output [Tx] or received [Rx]).

OPTICAL

Tx Rx

LINK

NOTE: The Link LEDs indicate transmission of light only, not whether there is data encoded in the optical link.

Power LED — This LED lights to indicate that power is applied to the unit.

AUDI

HDCP

HDMI

HDMI LED — This LED lights on both units when the transmitter detects a signal on its video input.

HDCP LED — This LED lights on both units when the input signal is HDCP encrypted.

Audio LED — This LED lights on both units when the transmitter detects a low level audio signal for a short period of time.

EDID

EDID Minder switch — Set this switch to one of the

positions at right to select the source of the DDC or a

specic resolution.

Position 0 — An EDID that has been captured from

the display connected to the transmitter HDMI loop-

thru connector.

Position 1 — The DDC is selected via a serial port

on the Tx only using an SIS command or the FOX

Extender Control Program.

Position 2 - F — Specify a resolution. The table identies the switch positions and the associated resolutions.

Pos. Source or resolution Pos. Resolution Pos. Resolution

0 User recorded EDID 6 1280 x 800 C 1600 x 1200

1 RS-232 7 1280 x 1024 D 1680 x 1050

2 800 x 600 8 1360 x 768 E 1920 x 1080

3 1024 x 768 9 1366 x 768 F 1920 x 1200

4 1280 x 720 A 1400 x 1050

5 1280 x 768 B 1440 x 900

68-1984-50 Rev. B

10 20

For information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related topics, see the

Extron Safety and Regulatory Compliance Guide on the Extron website.

All trademarks mentioned are the property of their respective owners.
