Extreme Networks ExtremeWireless AP3935i Manuel utilisateur

ExtremeWireless™AP3935i &

AP3935e Installation Guide

9034915-02

Published July 2016

Legal Notice

Extreme Networks, Inc. reserves the right to make changes in speciﬁcations and other information

contained in this document and its website without prior notice. The reader should in all cases

consult representatives of Extreme Networks to determine whether any such changes have been

made.

The hardware, ﬁrmware, software or any speciﬁcations described or referred to in this document

are subject to change without notice.

Trademarks

Extreme Networks and the Extreme Networks logo are trademarks or registered trademarks of

Extreme Networks, Inc. in the United States and/or other countries.

All other names (including any product names) mentioned in this document are the property of

their respective owners and may be trademarks or registered trademarks of their respective

companies/owners.

For additional information on Extreme Networks trademarks, please see:

www.extremenetworks.com/company/legal/trademarks/

Support

For product support, including documentation, visit: www.extremenetworks.com/documentation/

For information, contact:

Extreme Networks, Inc.

145 Rio Robles

San Jose, California 95134

USA

Table of Contents

Preface.........................................................................................................................................4

Text Conventions...................................................................................................................................................................4

Terminology............................................................................................................................................................................. 4

Providing Feedback to Us.................................................................................................................................................5

Getting Help.............................................................................................................................................................................5

Related Publications............................................................................................................................................................ 5

Chapter 1: About This Guide.....................................................................................................7

Who Should Use This Guide............................................................................................................................................ 7

How to Use This Guide....................................................................................................................................................... 7

Chapter 2: Introduction.............................................................................................................8

About the AP3935i and AP3935e................................................................................................................................ 8

AP3935 Overview................................................................................................................................................................. 8

Architectural Features.......................................................................................................................................................12

Chapter 3: Installation..............................................................................................................14

Unpacking the AP3935.....................................................................................................................................................14

Accessories.............................................................................................................................................................................14

Access Point Installation Procedures.........................................................................................................................15

Conﬁguring AP3935e Channel Settings...................................................................................................................19

Appendix A: Speciﬁcations.................................................................................................... 26

External Power Supplies................................................................................................................................................. 26

Internal Antenna APs........................................................................................................................................................27

External Antennas..............................................................................................................................................................33

Appendix B: Regulatory Information....................................................................................35

ExtremeWireless AP3935i and AP3935e................................................................................................................35

ExtremeWireless™ AP3935i & AP3935e Installation Guide 3

Preface

Text Conventions

The following tables list text conventions that are used throughout this guide.

Table 1: Notice Icons

Icon Notice Type Alerts you to...

General Notice Helpful tips and notices for using the product.

Note Important features or instructions.

Caution Risk of personal injury, system damage, or loss of data.

Warning Risk of severe personal injury.

New This command or section is new for this release.

Table 2: Text Conventions

Convention Description

Screen displays This typeface indicates command syntax, or represents information as it appears on the

screen.

The words enter and

type

When you see the word “enter” in this guide, you must type something, and then press

the Return or Enter key. Do not press the Return or Enter key when an instruction

simply says “type.”

[Key] names Key names are written with brackets, such as [Return] or [Esc]. If you must press two

or more keys simultaneously, the key names are linked with a plus sign (+). Example:

Press [Ctrl]+[Alt]+[Del]

Words in italicized type Italics emphasize a point or denote new terms at the place where they are deﬁned in

the text. Italics are also used when referring to publication titles.

Terminology

When features, functionality, or operation is speciﬁc to a switch family, such as ExtremeSwitching™or

Summit®, the family name is used. Explanations about features and operations that are the same across

all product families simply refer to the product as the switch.

ExtremeWireless™ AP3935i & AP3935e Installation Guide 4

Providing Feedback to Us

We are always striving to improve our documentation and help you work better, so we want to hear

from you! We welcome all feedback but especially want to know about:

•Content errors or confusing or conﬂicting information.

•Ideas for improvements to our documentation so you can ﬁnd the information you need faster.

•Broken links or usability issues.

If you would like to provide feedback to the Extreme Networks Information Development team about

this document, please contact us using our short online feedback form. You can also email us directly at

internalinfodev@extremenetworks.com.

Getting Help

If you require assistance, contact Extreme Networks using one of the following methods:

•Global Technical Assistance Center (GTAC) for Immediate Support

•Phone: 1-800-872-8440 (toll-free in U.S. and Canada) or +1 408-579-2826. For the support

phone number in your country, visit: www.extremenetworks.com/support/contact

•Email: support@extremenetworks.com. To expedite your message, enter the product name or

model number in the subject line.

•GTAC Knowledge — Get on-demand and tested resolutions from the GTAC Knowledgebase, or

create a help case if you need more guidance.

•The Hub — A forum for Extreme customers to connect with one another, get questions answered,

share ideas and feedback, and get problems solved. This community is monitored by Extreme

Networks employees, but is not intended to replace speciﬁc guidance from GTAC.

•Support Portal — Manage cases, downloads, service contracts, product licensing, and training and

certiﬁcations.

Before contacting Extreme Networks for technical support, have the following information ready:

•Your Extreme Networks service contract number and/or serial numbers for all involved Extreme

Networks products

•A description of the failure

•A description of any action(s) already taken to resolve the problem

•A description of your network environment (such as layout, cable type, other relevant environmental

information)

•Network load at the time of trouble (if known)

•The device history (for example, if you have returned the device before, or if this is a recurring

problem)

•Any related Return Material Authorization (RMA) numbers

Related Publications

ExtremeWireless and ExtremeWireless AP documentation can be found on Extreme Documentation

page at: http://documentation.extremenetworks.com

Extreme recommends the following guides for users of ExtremeWireless products:

Preface

ExtremeWireless™ AP3935i & AP3935e Installation Guide 5

•ExtremeWireless AP3935i & AP3935e Installation Guide

•ExtremeWireless AP3965i & AP3965e Installation Guide

•ExtremeWireless Appliance C5210 Quick Reference

•ExtremeWireless Appliance C5110 Quick Reference

•ExtremeWireless Appliance C4110 Quick Reference

•ExtremeWireless Appliance C25 Quick Reference

•ExtremeWireless Appliance C35 Quick Reference

•ExtremeWireless CLI Reference Guide

•ExtremeWireless End User License Agreements

•ExtremeWireless External Antenna Site Preparation and Installation Guide

•ExtremeWireless External Antenna with Wave 2 Site Preparation and Installation Guide

•ExtremeWireless Getting Started Guide

•ExtremeWireless Integration Guide

•ExtremeWireless Maintenance Guide

•ExtremeWireless Open Source Declaration

•ExtremeWireless User Guide

•IdentiFi Wireless WS-AP3865e Installation Guide

•IdentiFi Wireless WS-AP3825i & WS-AP3825e Installation Guide

•IdentiFi Wireless WS-AP3805i & WS-AP3805e Installation Guide

Preface

ExtremeWireless™ AP3935i & AP3935e Installation Guide 6

1About This Guide

Who Should Use This Guide

How to Use This Guide

The guide describes how to mount and connect cables to the ExtremeWireless AP3935 access point. In

addition, this guide provides information on the product certiﬁcations and national approvals for the

AP3935 access point.

Note

This guide does not provide information on conﬁguration of the access points. For

information on how to conﬁgure the access points, see the ExtremeWireless User Guide.

Who Should Use This Guide

Warning

Electrical Hazard: Only qualiﬁed personnel should install or service this unit.

Riesgo Electrico: Nada mas personal capacitado debe de instalar o darle servicio a esta unida.

Elektrischer Gefahrenhinweis: Installationen oder Servicearbeiten sollten nur durch

ausgebildetes und qualiﬁziertes Personal vorgenommen werden.

How to Use This Guide

Read through this guide completely to familiarize yourself with its contents and to gain an

understanding of the features and capabilities of the AP3935 access point. A general working

knowledge of data communications networks is helpful when setting up this product.

This preface provides an overview of this guide, deﬁnes the conventions used in this document, and

instructs how to obtain technical support from Extreme Networks .

ExtremeWireless™ AP3935i & AP3935e Installation Guide 7

2Introduction

About the AP3935i and AP3935e

AP3935 Overview

Architectural Features

This installation guide provides an overview and installation instructions for the ExtremeWireless Access

Points AP3935i and AP3935e.

About the AP3935i and AP3935e

The AP3935 is designed to extend your Wireless LAN around indoor locations. The AP3935 supports

the 802.11ac and 802.11n wireless standards, with full backward compatibility with legacy 802.11a, and

802.11b/g devices.

The AP3935 interoperates fully with Wireless LANs, including support for VoWLAN, branch oce mode,

guest services, RTLS, availability, and mobility features. The operating temperature: 0 - 50C.

The AP3935i and AP3935e have the following features in common:

•Both support two MIMO 4x4 (up to four 802.11ac spatial streams).

•They provide two single band radios for dual-band, concurrent operation, optimized for indoor

antenna coverage:

•5 GHz (Radio 1) in any of the following modes: IEEE802.11ac, a/b/g and/or n

•2.4 GHz (Radio 2) in any of the following modes: IEEE802.11ac, a/b/g and/or n

•They are enclosed in a rectangular, compact case.

•Both models can be mounted on walls and drop/suspended ceilings.

•They provide 80 MHz Bandwidth at 2.4/5 GHz operation (Channel Bonding).

•Power is provided through two Ethernet ports (LAN port). This is the preferred method of powering

the AP on ceiling and wall installations. The AP3935 can also be powered by an external DC power

supply by plugging the supply’s input jack into the DC-In port.

Note

The AP3935 comes in two models: the AP3935i has 8 internal single-band antennas while the

AP3935e has 8 external RSMA connectors for connecting external antennas. Within this

document, any reference to AP3935 applies to both models.

AP3935 Overview

The AP3935 access point is available in two models:

•AP3935i contains eight internal single-band antennas

•AP3935e contains eight external RSMA connectors for optional external antennas, for greater range

and coverage versatility

ExtremeWireless™ AP3935i & AP3935e Installation Guide 8

Figure 1: ExtremeWireless AP3935i Top View and Figure 2: ExtremeWireless AP3935e Top View on page

10 show the top view of each model.

Figure 3: AP3935 Bottom View on page 11 shows the location of the LAN ports, console port, external

power supply connector, and reset switch.The bottom panel is the same for both models, but there are

no external antenna RSMA connectors on the AP3935i.

Figure 4: AP3935 LEDs on page 11 illustrates the LEDs on the AP3935.

Figure 1: ExtremeWireless AP3935i Top View

Introduction

ExtremeWireless™ AP3935i & AP3935e Installation Guide 9

Figure 2: ExtremeWireless AP3935e Top View

Introduction

ExtremeWireless™ AP3935i & AP3935e Installation Guide 10

Autres manuels pour ExtremeWireless AP3935i

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Extreme Networks Point d'accès sans fil

Extreme Networks

Extreme Networks ExtremeMobility AP410i/e Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeWireless AP460i Manuel utilisateur

Extreme Networks

Extreme Networks Altitude 4700 Series Manuel d'installation et d'exploitation

Extreme Networks

Extreme Networks AP305C Manuel d'installation

Extreme Networks

Extreme Networks ExtremeWireless WS-AP3915i-FCC Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeWireless AP3000X Manuel utilisateur

Extreme Networks

Extreme Networks Altitude 3510 Manuel utilisateur

Extreme Networks

Extreme Networks Altitude 3550 Guide de référence rapide

Extreme Networks

Extreme Networks Altitude 4511 Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeWireless AP360i ExtremeWireless... Manuel utilisateur

Extreme Networks

Extreme Networks AP-7522 Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeWireless AP3935i Manuel utilisateur

Extreme Networks

Extreme Networks Altitude 4532 Series Manuel utilisateur

Extreme Networks

Extreme Networks AP-8533 Manuel du propriétaire

Extreme Networks

Extreme Networks WS-AP3805i Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeWireless AP5050D Manuel utilisateur

Extreme Networks

Extreme Networks ExtremeWireless AP3917i Manuel utilisateur

Extreme Networks

Extreme Networks AP460C Manuel d'installation

Extreme Networks

Extreme Networks Altitude 3500 Series Manuel d'installation et d'exploitation

Extreme Networks

Extreme Networks Altitude 450 Manuel utilisateur

Extreme Networks

Extreme Networks AP-7602 Manuel de service

Extreme Networks

Extreme Networks AP60C Manuel d'installation

Extreme Networks

Extreme Networks AP305C Manuel d'installation

Extreme Networks

Extreme Networks Altitude 4511 Manuel utilisateur

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Cisco

Cisco Aironet 1550 Series Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur
