INSTRUCTION MANUAL
STEP 1.
STEP 4.
STEP 7.
STEP 2.
STEP 5.
STEP 8.
STEP 3.
STEP 6.
STEP 9.
SET-UP INSTRUCTIONS
DESERT SHADE 90°
CAR AWNING
R ANGE
Before begin the set-up, ensure the area
around the car awning is clear from trees and
any other hazards.
Person one needs to support the awning while
person two completes steps 5 & 6.
Loop the bottom of the roof arm through the
whole in the awning frame to secure. Attach
the Velcro straps from fabric around the arm.
Installation requires 2 people. Begin
by unzipping the car awning protective
cover bag.
Person two can now unfold the two roof arms
from the awning bracket.
Lower both legs from the awning frame. Adjust
to desirable height by twisting legs at the join.
Undo the three Velcro straps around the car
awning. Roll down the fabric/frame.
The roof arms can be adjusted in length by
twisting them at the join. Extent these to the
same length as the awning fabric.
Secure the awning to the ground using the
two tie-down straps and steel pins.
INSTRUCTION MANUAL
STEP 1.
STEP 5.
STEP 2. STEP 3.
STEP 6.STEP 4.
PACK-DOWN INSTRUCTIONS
DESERT SHADE 90°
CAR AWNING
R ANGE
Take off the two tie-down straps and pins from
the awning and fold up the two support legs
back into the awning frame.
Once the fabric is rolled up, secure with the
two Velcro straps and tuck the tie-down ropes
into the beg.
Person one can start to undo the Velcro
from the two awning arms while person two
supports the awning.
Person two can then shorten then awning
arms and fold them back into the awning
bracket.
Zip the protective cover bag closed.
NEVER TRAVEL WITH AWNING OR AWNING
BAG OPEN.
Tightly roll up the car awning fabric into the
protective cover.
