XC-14A, XC-22A, XC-30A SERVICE MANUAL Portable Air Condioners
GENERAL DESCRIPTION
General air condioning system
1) convenonal air condioners cool the enre enclosed environment.
2) They act as "heat exchangers", equiring an interior unit (evaporator) to blow
cool air into the interior and an exterior unit (condenser) to exhaust
exchanged heat to the outdoors.
1) The XC-14A / XC-22A / XC-30A is a spot
cooler which directs cool air to parcular
areas or objects.
2) The XC-14A / XC-22A / XC-30A has the
following features.
3) The innovave design of the XC-14A /
XC-22A / XC-30A has resulted in one
compact unit, replacing the need for two
separate units.
4) With the whole cooling system built into
one compact unit, the XC-14A / XC-22A /
XC-30A requires no piping and can be
easily transported and installed.
5) The XC-14A / XC-22A / XC-30A is
economical because it cools only the
area or objects which need to be cooled.
Portable air condioning system
Xtreme Power Conversion® (XPC) Corporaon
Page 4
Condenser
Outdoor Unit
Evaporator
Indoor Unit
Intake air
(to Evaporator)
Intake air
(to Condenser)
Filter
Filter
Exhaust Hot Air
Cooling Air
