Extech Instruments BR80 Manuel utilisateur

User's Guide

Video Borescope Inspection Camera

Model BR80

actoolsupply.com

Extech BR80 Video Borescope Inspection Camera 17mm

BR80-EU-EN-V1.0 10/11

Introduction

Congratulations on your purchase of the Extech BR80 Video Borescope. This instrument was

designed for use as a remote inspection device. Typical applications include HVAC inspection,

automotive inspection, cable routing, and boat/aircraft inspection. This meter is shipped fully

tested and, with proper use, will provide years of reliable service.

Cautions

Do not expose the handle and display to spraying water.

Switch off the Camera if the system is not in use.

Please dispose of the batteries responsibly.

Remove the batteries when cleaning the unit.

Remove the batteries before storing the unit for an extended period of time.

When batteries need replacement, replace all four of the batteries.

Use only the specified battery size and type.

Be sure to install the batteries with the correct polarity as indicated in the battery

compartment.

Exposure to high temperatures can cause the batteries to explode, therefore do not

dispose of the batteries in fire. Place tape over the terminals to prevent direct contact with

other objects. Please follow all applicable regulations.

Description

1 Camera tube connector

2 Battery status indicator

3 Display monitor

4 Cameral light intensity (+) button

5 Image rotation button

6 Flexible camera tube

7 Battery compartment (bottom of handle)

8 Camera and LED lights

9 Handle grip

10 Power button

11 Camera light intensity (-) button

actoolsupply.com

BR80-EU-EN-V1.0 10/11

Safety and Care

Do not expose instrument (display) to moisture

Switch off the instrument when not in use

Remove the batteries when cleaning the instrument

Replace all of the batteries at the same time

Do not immerse the camera in water

Store in a dry place

Only the camera head and the flex tube are water resistant

Warning

Permanent damage to the flex tube and loss of operation will occur if the flex tube is subjected

to narrow radius or sharp angle bends.

Battery Installation

1. Open the battery compartment by sliding the latch at the bottom of the

instrument’s handle

2. Insert four new ‘AA’ 1.5V batteries into the proper slots in the battery

compartment. Proper battery orientation is indicated on the battery

compartment.

3. Close the battery compartment.

Note: Do not mix old and new batteries. Do not mix alkaline, standard (Carbon-Zinc), or

rechargeable (Nickel Cadmium) batteries.

All EU users are legally bound by the battery ordinance to return all used

batteries to collection points in your community or wherever batteries /

accumulators are sold! Disposal in the household garbage is prohibited!

actoolsupply.com

BR80-EU-EN-V1.0 10/11

Operation

Connect the monitor and flexible tube

Connect the camera tube to the instrument body. Ensure that the keyed ends are properly

aligned. Once aligned, tighten the knurled knob to hold the connection firmly in place.

Start-up

1. Press the power button to switch the camera ON; if there is sufficient battery power the

power indicator will illuminate and an image will appear on the LCD.

2. Insert the camera head and the flexible tube into the area to be viewed. Pre-shape the

tube when inserting into areas with bends and curves.

LED intensity:

Four LEDs mounted on either side of the camera are used to illuminate the inspection area.

Use the left (minus) and right (plus) illumination buttons to adjust the intensity. To switch the

illumination off, continue to press the left (minus) button until the illumination switches off. There

are 100 discrete intensity levels.

Image Flip

Press the button to flip the image. The figure to the right demonstrates how

the image is adjusted for each button press.

Auto Power OFF (APO)

APO automatically witches the meter off to extend battery life. To change the APO setting,

press and hold the flip button until the ‘Clock’ icon appears. Use the flip button to step

through the selections (OFF, 5 minutes, and 10 minutes). The meter will return to normal

operation after 3 seconds. If 5 or 10 minute APO is enabled, the clock icon will appear in the

display.

Battery Status Indicator

The rectangular light at the top of the display area is the battery status indicator. When the

indicator is red in color, the batteries are weak. When the indicator appears green in color,

the batteries are charged.

Warning

Permanent damage to the flex tube and loss of operation will occur if the flex tube is

subjected to narrow radius or sharp angle bends.

Accessory tools

The included accessories (mirror, hook and magnet) all attach to the camera head. Snap

the tool clip into the recessed area on the camera assembly.

FLIP

actoolsupply.com

BR80-EU-EN-V1.0 10/11

Specifications

Imaging Sensor CMOS

LCD Screen Type 2.36” TFT-LCD

Pixels 480 x 234

Horizontal View Angle 50 degrees

Working length 1m (39”)

Camera head diameter 17mm (0.67”)

Shaft diameter 9mm (0.35”)

Focus length 5.1 cm (2”)

Auto Power OFF (APO) OFF /5 min. /10 min. selectable

Waterproof Capacity IP67 (imager head and tube)

Power Supply 4 x ‘AA’ 1.5V batteries

Consumption Current (Max.) 150mA

Dimensions 211 x 83 x 76mm (8.3 x 3.3 x 3”) meter body only

Weight 0.61 kg (1.35 lbs) (meter & tube)

Operating Temperature -10°C~+50°C (+14°F~+122°F)

Operating Humidity (Display) 15~85%RH
