Exmark QUEST 4500-339 Manuel utilisateur

For Serial Nos.

720,000 & Higher

Part No. 4500-339 Rev. A

QUEST®

-1-

-2-

READ OPERATOR’S MANUAL BEFORE

OPERATING OR SERVICING EXMARK EQUIPMENT

TABLE OF CONTENTS

Description Page

Cutter Housing Assembly ................................................7

48” Deck Group............................................................3-4

52” Deck Group............................................................5-6

Decal Group ..................................................................17

Electrical Diagram.....................................................19-20

Electrical Group.............................................................18

Electrical Logic Schematic........................................21-22

Engine Group ...........................................................13-14

Frame Group................................................................8-9

Fuel Group.....................................................................12

Motion Control Group ....................................................10

Seat Group....................................................................11

Transaxle Assembly ......................................................16

Transaxle Group............................................................15

48” DECK GROUP

-3-

Item Part No. Description Qty.

1 109-6253 Asm, Deck W/Decals .............................1

2 52-2860 Washer ..................................................2

3 109-9158 Asm, Idler Arm W/Bearings....................1

3:1 302-40 Zerk, 90° 1/4-28.....................................1

3:2 1-513034 Bearing ..................................................2

4 103-3330 Spring, Extension...................................1

5 1-603384 Bushing..................................................1

6 3231-11 Bolt, Carriage 3/8-16 x 3 1/2 ..................1

7 104-8301 Nut, Nyloc 3/8-16 Flg .............................8

8 1-413113 Bushing..................................................1

9 109-8891 Asm, Pulley and Bearing........................2

10 3231-31 Bolt, Carriage 3/8-16 x 2 1/2 ..................1

11 109-6572 Bushing..................................................2

12 1-603843 Pulley, Idler............................................1

13 109-6868 Bolt, Carriage 3/8-16 x 3........................2

14 109-3723-01 Strut, Deck.............................................1

15 109-8788 Bushing, Flanged...................................4

Item Part No. Description Qty.

16 3231-25 Bolt, Carriage 3/8-16 x 1 1/4..................4

17 109-3449 Shield, Belt ............................................2

18 3230-23 Bolt, Carriage 5/16-18 x 3/4 Short Neck.6

19 109-5667 Ring, Bolt Retaining...............................4

20 104-8300 Nut, Nyloc 5/16-18 Flg...........................10

21 109-5498-03 Baffle, Discharge ...................................1

22 110-6691 Decal, Danger........................................2

23 109-6459 Decal, Belt Shield Warning ....................2

24 109-6034 Decal, Deck 48......................................1

25 109-6035 Decal, Belt Routing................................1

26 109-6036 Decal, Anti-Scalp Roller.........................1

27 93-7009 Decal, Danger........................................1

28 322-2 Screw, HH 5/16-18 x 5/8........................4

29 109-9159 Decal, Hole Cover..................................3

30 1-303520 Decal, Trivantage...................................1

V109-8745 Asm, 48 Deck Complete

Exmark black touch up spray paint – gloss black.

Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).

VIncludes all item shown on pages 3, 4 & 7. Does not include struts or strut hardware.

48” DECK GROUP (Continued)

-4-

Item Part No. Description Qty.

1 109-6388 Kit, Anti-Scalp Roller..............................3

1:1 112-3977 Bolt, Shoulder ........................................1

1:2 1-603299 Roller, Anti-Scalp...................................1

1:3 104-8301 Nut, Nyloc 3/8-16 Flg .............................1

2 109-8744 Asm, Cutter Housing Complete..............3

3 103-6401 Blade, Notched ......................................3

Q109-6389 Blade. Mulch..........................................3

109-6391 Blade, High Lift.......................................3

4109-3747 Sheave, Blade Drive ..............................3

5 109-3410 Hanger, Deck.........................................4

6 109-8788 Bushing, Flanged...................................8

Item Part No. Description Qty.

7 3231-25 Bolt, Carriage 3/8-16 x 1 1/4..................8

8 104-8301 Nut, Nyloc 3/8-16 Flg.............................8

9 109-5364 Belt........................................................1

10 109-6393 Kit, Washout Port...................................1

10:1 95-2747 Fitting, Washout Port .............................1

10:2 46-6290 O-Ring...................................................1

10:3 93-6083 Screw, HWH 1/2-20 x 1/2 Taptite...........2

10:4 95-3270 Connector, Hose....................................1

13 109-8854 Pin, Chute..............................................1

14 109-6886 Spring....................................................1

15 109-5151 Chute, Deflector.....................................1

Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).

Apply Mobil HTS grease (P/N 103-5217 1.5 oz packet) (or a food-grade anti-seize) between the spindles & sheaves.

DO NOT use a copper or nickel based anti-seize.

QRequires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N 109-5980.

52” DECK GROUP

-5-

Item Part No. Description Qty.

1 109-6254 Asm,52 Deck W/ Decals.........................1

2 52-2860 Washer ..................................................2

3 109-9158 Asm, Idler Arm W/Bearings....................1

3:1 302-40 Zerk, 90° 1/4-28.....................................1

3:2 1-513034 Bearing ..................................................2

4 103-3330 Spring, Extension...................................1

5 1-603384 Bushing..................................................1

6 3231-11 Bolt, Carriage 3/8-16 x 3 1/2 ..................1

7 104-8301 Nut, Nyloc 3/8-16 Flg .............................8

8 1-413113 Bushing..................................................1

9 109-8891 Asm, Sheave and Bearing......................2

10 3231-31 Bolt, Carriage 3/8-16 x 2 1/2 ..................1

11 109-6572 Bushing..................................................2

12 1-603843 Pulley, Idler............................................1

13 109-6868 Bolt, Carriage 3/8-16 x 3........................2

14 109-3723-01 Strut, Deck.............................................1

15 109-8788 Bushing, Flanged...................................4

Item Part No. Description Qty.

16 3231-25 Bolt, Carriage 3/8-16 x 1 1/4..................4

17 109-3449 Shield, Belt ............................................2

18 3230-23 Bolt, Carriage 5/16-18 x 3/4 Short Neck.6

19 109-5667 Ring, Bolt Retaining...............................4

20 104-8300 Nut, Nyloc 5/16-18 Flg...........................12

21 109-5498-03 Baffle, Discharge ...................................1

22 110-6691 Decal, Danger........................................2

23 109-6459 Decal, Belt Shield Warning ....................2

24 109-6033 Decal, Deck 52......................................1

25 109-6035 Decal, Belt Routing................................1

26 109-6036 Decal, Anti-Scalp Roller.........................1

27 93-7009 Decal, Danger........................................1

28 322-2 Screw, HH 5/16-18 x 5/8........................6

29 109-9159 Decal, Hole Cover..................................3

30 1-303520 Decal, Trivantage...................................1

V109-8746 Asm,52 Deck Complete

Exmark black touch up spray paint – gloss black.

Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).

VIncludes all item shown on pages 5, 6 & 7. Does not include struts or strut hardware.

52” DECK GROUP (Continued)

-6-

Item Part No. Description Qty.

1 109-6388 Kit, Anti-Scalp Roller..............................3

1:1 112-3977 Bolt, Shoulder........................................1

1:2 1-603299 Roller, Anti-Scalp...................................1

1:3 104-8301 Nut, Nyloc 3/8-16 Flg .............................1

2 109-8744 Asm, Cutter Housing Complete..............3

3 103-6402 Blade, Notched 18.0 ..............................3

Q109-6390 Blade. Mulch..........................................3

109-6392 Blade, High Lift ......................................3

4109-3671 Sheave, Blade Drive ..............................3

5 109-3410 Hanger, Deck.........................................4

6 109-8788 Bushing, Flanged...................................8

Item Part No. Description Qty.

7 3231-25 Bolt, Carriage 3/8-16 x 1 1/4..................8

8 104-8301 Nut, Nyloc 3/8-16 Flg.............................8

9 109-3661 Belt........................................................1

10 109-6393 Kit, Washout Port...................................1

10:1 95-2747 Fitting, Washout Port .............................1

10:2 46-6290 O-Ring...................................................1

10:3 93-6083 Screw, HWH 1/2-20 x 1/2 Taptite...........2

10:4 95-3270 Connector, Hose....................................1

13 109-8854 Pin, Chute..............................................1

14 109-6886 Spring....................................................1

15 109-5151 Chute, Deflector.....................................1

Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).

Apply Mobil HTS grease (P/N 103-5217 1.5 oz packet) (or a food-grade anti-seize) between the spindles & sheaves. DO NOT

use a copper or nickel based anti-seize.

QRequires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N 109-5982.

CUTTER HOUSING ASSEMBLY

-7-

Item Part No. Description Qty.

1 109-9380 Asm, Cutter Housing..............................1

1:1 62-3661 Spacer, Bearing.....................................1

1:2109-9379 Bearing, Ball ..........................................2

2 80-4380 Spacer...................................................1

3 80-4360 Shield, Bearing ......................................1

Item Part No. Description Qty.

4 109-7431 Spindle, Hex Pilot ..................................1

5 109-7429 Washer, Blade Drive..............................1

6 116-0005 Bolt, Sems Blade...................................1

7 3219-6 Nut, Hex 5/8-18......................................1

8 32144-41 Screw, HWH 3/8-16 x 7/8 Taptite...........6

Apply Mobil HTS grease (P/N 103-5217 1.5 oz packet) (or a food-grade anti-seize) between the spindle & bearings. DO NOT

use a copper or nickel based anti-seize.

FRAME GROUP

-8-

Item

Part No.

Description

Qty.

1 109-8825 Asm, Frame W/ Decal............................1

1:2 109-6008 Decal, Drive Release .............................2

1:3 106-5517 Decal, Surface, Hot................................2

1:4 109-8965 Decal, Safety Warning ...........................1

2 109-8845 Asm, Seat Box W/ Decals......................1

2:2 109-9182 Decal, Control, Motion............................1

2:3 109-9173 Decal, Control/Brake..............................1

2:4 109-9120 Decal, Fuse Block..................................1

2:5 109-6014 Decal, Belt Routing ................................1

2:6 109-6210 Decal, Danger........................................1

3 32144-70 Screw, HWH 5/16-18 x 3/4 TF................16

4 109-3678 Bearing, Ball ..........................................4

5 109-6218-01 Wld, Caster Fork....................................2

6 109-3724 Washer ..................................................2

8 109-6405 Asm, Caster Wheel................................2

8:1 105-1863 Asm, Caster Wheel W/Bearings.............1

8:1:1 105-1864 Tire ........................................................1

8:1:2 62-5580 Bearing..................................................2

8:1:3 83-4740 Bearing..................................................1

Item

Part No.

Description

Qty.

8:1:4 302-5 Zerk 1/4-28 Str Thrd Forming................. 1

8:1:5 93-4244 Tube, Inner............................................ 1

8:2 104-3667 Spanner, Wheel.....................................1

8:3 325-20 Screw, HH 1/2-13 x 6.............................1

8:4 92-2651 Washer.................................................. 2

8:5 3296-45 Nut, Nyloc 1/2-13 Thin........................... 1

9 109-3667 Bearing, Flange..................................... 4

10 104-8300 Nut, Nyloc 5/16-18 Flg........................... 21

11 322-5 Screw, HH 5/16-18 x 1........................... 10

12 109-6045-03 Bracket, Tank Mount..............................1

13 3230-23 Bolt, Carriage 5/16-18 x 3/4, Short Neck. 2

14 109-6867-01 Bracket, Rear Tank (LH)........................1

15 109-3406-01 Bracket, Rear Console (RH).................. 1

16 109-3381-01 Guard, Engine (LH)................................1

17 109-3391-01 Guard, Engine (RH)............................... 1

18 109-5363-01 Casting, Rear ........................................ 1

19 109-3709 Panel, Front...........................................1

20 109-3707 Fender, Exmark (LH)............................. 1

21 109-3708 Fender, Exmark (RH).............................1

Exmark black touch up spray paint – gloss black.

Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).

FRAME GROUP (Continued)

-9-

Item

Part No.

Description

Qty.

22 109-8870-01 Wld, Shaft Front.....................................1

23 109-8871-01 Wld, Shaft Rear......................................1

24 114-1658-03 Guard, Muffler........................................1

25 9266714 Screw, HWH 1/4-20 x .50.......................6

26 3234-5 Screw, HH FLG 5/16-18 x 3/4 ................11

27 104-8301 Nut, Nyloc 3/8-16 Flg .............................4

28 3231-9 Bolt, Carriage 3/8-16 x 2 3/4 ..................4

29 3256-3 Washer, 5/16 Std ...................................2

30 109-8758 Asm, Height Adjust W/ Decal .................1

30:2 109-8759 Decal, Cut Height...................................1

31 109-5819 Pin, Clevis..............................................2

32 3256-26 Washer, 1/2 SAE ...................................3

33 32120-47 Ring, Retaining ......................................3

34 109-8755 Stop, Height Adjust ................................1

35 109-5814 Arm, Float Link.......................................1

36 109-5818 Pin, Pivot................................................1

37 109-6172 Pin, Clevis..............................................1

Item

Part No.

Description

Qty.

38 93-4696 Pin, Hitch...............................................1

39109-6177 Pin, Spring.............................................1

40 109-5486 Asm, Wheel And Tire (48" Only)............2

40 109-5268 Asm, Wheel And Tire (52" Only)............2

40:1 109-5487 Wheel (48" Only)....................................1

40:1 109-5270 Wheel (52" Only)....................................1

40:2 109-5488 Tire, 20 X 8-8 (48" Only)........................1

40:2 109-5269 Tire, 20 X 10-8 (52" Only)......................1

41 242-50 Nut, Lug 1/2-20......................................8

42 109-6190-03 Cover, Hydro Fan ..................................1

43 99-6810 Screw, HH 1/4-20 x 5/8..........................2

44 92-7054 Spring, Compression .............................3

45 109-6214 Stop, Motion Control..............................2

46 1-303435 Washer, Spring Disc 1/4........................4

47 321-2 Screw, HH 1/4-20 x 1/2..........................4

48 109-6280 Decal, Quest Logo.................................1

Exmark black touch up spray paint – gloss black.

Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).

Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on Spring Pin hub threads.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Exmark Tondeuse à gazon

Exmark

Exmark LAZER Z Manuel utilisateur

Exmark

Exmark QUEST SP Manuel

Exmark

Exmark ULTRAVAC 126-6122 Manuel utilisateur

Exmark

Exmark Turf tracer Manuel utilisateur

Exmark

Exmark M216KA, M216KASP Manuel utilisateur

Exmark

Exmark Lazer Z XP Manuel utilisateur

Exmark

Exmark Lazer ZXS Manuel utilisateur

Exmark

Exmark Laser Z XP Manuel utilisateur

Exmark

Exmark LAZER Z E-SERIES Operators Manuel utilisateur

Exmark

Exmark Metro 26 Manuel utilisateur

Exmark

Exmark Frontrunner FR20KC Manuel utilisateur

Exmark

Exmark Lazer Z Series Manuel

Exmark

Exmark PIONEER S-SERIES Operators Manuel utilisateur

Exmark

Exmark Turf Ranger TR23KC Manuel utilisateur

Exmark

Exmark Lazer Z 72 Manuel utilisateur

Exmark

Exmark LAZER Z Manuel utilisateur

Exmark

Exmark Self Propelled Mower Manuel utilisateur

Exmark

Exmark VH3615KA Manuel utilisateur

Exmark

Exmark LAZER Z Manuel utilisateur

Exmark

Exmark Turf tracer HP Manuel utilisateur

Exmark

Exmark VIKING 408 Manuel utilisateur

Exmark

Exmark NAVIGATOR Manuel utilisateur

Exmark

Exmark Lazer ZXP Manuel utilisateur

Exmark

Exmark VIKING HYDRO Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Toro

Toro Groundsmaster 3505-D Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Toro

Toro 74806 Manuel utilisateur
