AMPLIFIER

Owner’s Manual

Models:

XM12.1

XM15.4

XM30.2

JAVELIN

SPECIFICATIONS Multichannel

Amplier Class Class D

Frequency Response: 30 - 200Hz

Total Harmonic Distortion <0.5%

Signal to Noise Ratio: 92dB

Gain Range 0.2 - 6V

Low Pass Crossover Range 50 - 250Hz

Subsonic Crossover Range 15 - 250Hz

Bass Boost @ 45Hz: 0 to +18dB

Operational Efciency > 85%

Remote Bass Control Yes

Damping Factor: > 200

CEA-2006 Compliant Yes

SPECIFICATIONS Monoblock

Amplier Class Class D

Frequency Response: 30 - 200Hz

Total Harmonic Distortion < 0.5%

Signal to Noise Ratio: 92dB

Gain Range 0.2 - 6V

Low Pass Crossover Range 50 - 250Hz

Subsonic Crossover Range 15 - 250Hz

Bass Boost @ 45Hz: 0 to +18dB

Operational Efciency > 85%

Remote Bass Control Yes

Damping Factor: > 200

CEA-2006 Compliant Yes

XM12.1

Channels 1

Into 1 ohm 1200w x 1

Into 2 ohm 880w x 1

Fuse Size: 40A x 3

Power/Ground Wire Size: 4 Gauge

Dimensions: 15.0in L x 7.5in W x 2.3in H

XM15.4

Channels 4

Into 4 ohm 150w x 4

Into 2 ohm 225w x 4

In to 4 ohm Bridged 450w x 2

Fuse Size 40Ax2

Power/Ground Wire Size 4 AWG

Dimensions 12.7in L x7.5in W x 2.3in H

XM30.2

Channels 2

Into 4 ohm 300w x 2

Into 2 ohm 420w x 2

In to 4 ohm Bridged 840w x 1

Fuse Size 40Ax2

Power/Ground Wire Size 4 AWG

Dimensions 10.8in L x 7.5in W x 2.3in H

JAVELIN

Channels 5

Into 4 ohm 80w x 4

Into 2 ohm 120w x 4

In to 4 ohm Bridged 240w x 2

Into 2 ohm (Sub CH) 800w x 1

Into 4 ohm (Sub CH) 500w x 1

Fuse Size 40Ax3

Power/Ground Wire Size 4 AWG

Dimensions 15.0in L x 7.5in W x 2.3in H

Power Amplier XM SERIES

All amplifer power specications listed

are CEA-2006 compliant and have

been rated accordingly.

Ampliers were tested at 14.4V with

a 4 ohm load and ≤ 1% THD+N

JAVELIN 5 Channel Power Amplier

OUTPUT

Connect preamp signal cables from the head unit to

these terminals.

FRONT AND REAR

Connect preamp signal cables from the head unit to

these terminals.

GAIN

Used to reach maximum amplier power with a wide

variety of headunits.

HPF

Controls the high pass crossover point for the

speaker outputs.

LPF

Controls the low pass crossover point for the

speaker outputs.

BASS BOOST

Variable bass boost from 0 to +18dB @ 45 Hz.

SUB INPUT

Switch to Front if using the FRONT input.

Switch to Sub if using the SUB input.

SUB

Connect subwoofer preamp signal cables from the head unit to

this terminal.

REMOTE

This port is for connecting the optional remote level control

(XMRB1). This allows up to 20dB of volume adjustment. This is

not a bass boost, it controls the level of the low pass signal.

POWER/PROTECT

Indicates if the amplier is working correctly (BLUE) or gone into

protect mode (RED).

SPEAKER OUTPUTS

Used to connect the amplier to the speakers. Use the

left channel positive (+) and the right channel negative (-) for

bridged mode.

12V+

This must be connected to the fused positive terminal (+12V) of

the car’s battery.

REMOTE

This must be connected to switched +12V, usually a trigger wire

coming from the head unit or ignition.

GND

This must be connected to the negative terminal of the car’s

battery or bolted to a clean, unpainted part of the chassis of

the vehicle.

2 Channel Power Amplier XM30.2

OUTPUT

Connect preamp signal cables from the head unit to

these terminals.

INPUT

Connect preamp signal cables from the head unit to

this terminal.

HPF

Controls the high pass crossover point for the

speaker outputs.

XOVER

HF - Sends high frequency signal to speakers.

FULL - Sends a full range signal to speakers.

LF - Sends low frequency signal to subwoofer.

LPF

Controls the low pass crossover point for the

speaker outputs.

BASS BOOST

Variable bass boost from 0 to +18dB @ 45 Hz.

GAIN

Used to reach maximum amplier power with a wide

variety of headunits.

POWER/PROTECT

Indicates if the amplier is working correctly (BLUE) or gone into

protect mode (RED).

SPEAKER OUTPUTS

Used to connect the amplier to the speakers. Use the

left channel positive (+) and the right channel negative (-) for

bridged mode.

FUSE

This amplier requires two 40A fuses.

12V+

This must be connected to the fused positive terminal (+12V) of

the car’s battery.

REMOTE

This must be connected to switched +12V, usually a trigger wire

coming from the head unit or ignition.

GND

This must be connected to the negative terminal of the car’s

battery or bolted to a clean, unpainted part of the chassis of

the vehicle.

tower speakers

4ohm

2ohm

Cabin

Amplifier Subwoofer

Amplifier

Tower

Amplifier

cabin speakers

subwoofer

Stereo

Battery Starting

Battery

Perko

Battery

Selector

Switch

ANL Fuse

Holder

L R L R

R L

1/0 ga.

4 ga.

Ground

Distribution

Block

MANL Fused

Power

Distribution

Block

InputInput

Input:

Source Unit

ZLD

zoned line driver

Aux Input:

phone/

mp3 player

R L R L

L RL R

XMRB1 Bass Control

111

SWITCH

L R

Input

Marine Installation Guide POWERFLOW

XM SERIES Power Amplier

tower speakers

4ohm

2ohm

Cabin

Amplifier Subwoofer

Amplifier

Tower

Amplifier

cabin speakers

subwoofer

Stereo

Battery Starting

Battery

Perko

Battery

Selector

Switch

ANL Fuse

Holder

L R L R

R L

1/0 ga.

4 ga.

Ground

Distribution

Block

MANL Fused

Power

Distribution

Block

InputInput

Input:

Source Unit

ZLD

zoned line driver

Aux Input:

phone/

mp3 player

R L R L

L RL R

XMRB1 Bass Control

111

SWITCH

L R

Input

XM15.4 4 Channel Power Amplier

OUTPUT

Connect preamp signal cables from the head unit to

these terminals.

INPUT (FRONT AND REAR)

Connect preamp signal cables from the head unit to

these terminals.

HPF

Controls the high pass crossover point for the

speaker outputs.

XOVER

HF - Sends high frequency signal to speakers.

FULL - Sends a full range signal to speakers.

LF - Sends low frequency signal to subwoofer.

LPF

Controls the low pass crossover point for the

speaker outputs.

BASS BOOST

Variable bass boost from 0 to +18dB @ 45 Hz.

GAIN

Used to reach maximum amplier power with a wide

variety of headunits.

POWER/PROTECT

Indicates if the amplier is working correctly (BLUE) or gone into

protect mode (RED).

REMOTE

This port is for connecting the optional remote level control

(XMRB1). This allows up to 20dB of volume adjustment. This is

not a bass boost, it controls the level of the low pass signal.

SPEAKER OUTPUTS

Used to connect the amplier to the speakers. Use the

left channel positive (+) and the right channel negative (-) for

bridged mode.

FUSE

This amplier requires two 40A fuses.

12V+

This must be connected to the fused positive terminal (+12V) of

the car’s battery.

REMOTE

This must be connected to switched +12V, usually a trigger wire

coming from the head unit or ignition.

GND

This must be connected to the negative terminal of the car’s

battery or bolted to a clean, unpainted part of the chassis of

the vehicle.

INPUT

Connect preamp signal cables from the head unit to

these terminals.

GAIN

Used to reach maximum amplier power with a wide

variety of headunits.

PHASE

Switches the output signal 180°.

SUBSONIC

Controls the highpass crossover point for the speaker outputs to

eliminate extreme low frequencies.

FREQ

Controls the lowpass crossover point for the

speaker outputs.

BASS BOOST

Variable bass boost from 0 to +12dB @ 45 Hz.

LPF

Variable bass boost from 0 to +12dB @ 45 Hz.

POWER/PROTECT

Indicates if the amplier is working correctly (BLUE) or gone into

protect mode (RED).

SPEAKER OUTPUTS

Used to connect the amplier to speakers. SM600.1 minimum

impedance of 2 ohm.

REMOTE

This port is for connecting the optional remote level control

(XMRB1). This allows up to 20dB of volume adjustment. This is

not a bass boost, it controls the level of the low pass signal.

FUSE

This amplier requires three 40A fuses.

12V+

This must be connected to the fused positive terminal (+12V) of

the car’s battery.

REMOTE

This must be connected to switched +12V, usually a trigger wire

coming from the head unit or ignition.

GND

This must be connected to the negative terminal of the car’s

battery or bolted to a clean, unpainted part of the chassis of the

vehicle.

Monoblock Power Amplier XM12.1

LIMITED WARRANTY

Exile warrants this product to be free from defects in material and workmanship under normal use for a period of one year from date of original purchase when

purchased from an Authorized Exile Dealer. If the product is labeled B Stock/Refurbished and purchased from an Authorized Exile Dealer, it is warranted for 90

days from date of purchase, regardless of place of installation. Should service be necessary under this warranty for any reason due to manufacturing defect

or malfunction during the warranty period, Exile will replace or repair (at its discretion) the defective merchandise with equivalent merchandise at no charge.

Warranty replacements on B-Stock merchandise may have cosmetic scratches and blemishes. Discontinued products may be replaced with more current

equivalent products. This warranty is valid only for the original purchaser and is not extended to owners of the product subsequent to the original purchaser. Any

applicable implied warranties are limited in duration to a period of the express warranty as provided herein beginning with the date of the original purchase at

retail, and no warranties, whether express or implied, shall apply to this product thereafter. Some states do not allow limitations on implied warranties, therefore

these exclusions may not apply to you. This warranty gives you specic legal rights; however you may have other rights that vary from state to state. This

warranty is only valid within the USA, for warranties outside of the USA consult the appropriate international distributor.

PORTLAND, OR USA

WWW.EXILEAUDIO.COM

DESIGNED AND ENGINEERED IN THE USA
