2. The 15cm Composite Sound Metamodal TX™woofer diaphragm is identical to Ganymede’s.
It remains a perfect piston over two octaves past its in use frequency range, and its optimized
ratio of radial to circumferential stiffness helps to linearize off-axis behavior as we approach our
2khz crossover. The diaphragm is precisely shaped to behave as an optimized waveguide for
the concentric tweeter, and the geometry of the tweeter diaphragm has been further optimized
to load this waveguide.
3. The FEA optimized ferrite motor structure and high performance spider bring distortion
performance nearly on a par with our flagship neodymium systems in Pulsar and Quasar, and
feature the same new copper shorting sleeve to lower high frequency inductance.
CABINET
While fully sealed like all our loudspeakers, Titan is the first loudspeaker in our line to depart
from our traditional use of Valchromat, opting instead for an extraordinarily rigid aluminum
extrusion, which comes with several benefits for the application. First, much thinner panels are
necessary to achieve an extremely inert enclosure, which has helped keep the physical footprint
of these tiny object oriented surrounds to a minimum. Secondly, the ½” rear baffle is threaded
with hard points for standard MIS-D 75x75mm and 100x100mm VESA mounting points,
allowing for a highly flexible array of mounting deployments. PLEASE NOTE THAT WE
REQUIRE ALL 8 MOUNT POINTS TO BE SECURED FOR PROPER SAFETY, ESPECIALLY
IN OVERHEAD DEPLOYMENTS THAT DO NOT PLACE PRIMARILY SHEAR LOAD ON THE
MOUNTS! We have tested and endorse solutions from Triad Orbit, Iso-Acoustics and
Spacelabs Systems for mounting. WE STRONGLY DISCOURAGE THE USE OF LOWER
QUALITY CONSUMER MOUNTING HARDWARE, AS WE CANNOT GUARANTEE THE
ROBUSTNESS OF THE FASTENING HARDWARE PROVIDED WITH THESE SOLUTIONS.
ALWAYS PERIODICALLY (AT LEAST TWICE A YEAR) EXAMINE ALL FASTENERS TO
ENSURE A TIGHT CONNECTION AND NO WEAR OR DEGRADATION OF THE THREADS!
AMPLIFIERS
All our loudspeakers employ second generation Hypex Ncore amplifier modules, which combine
high efficiency with ultra-low distortion and output impedance. Titan uses an individual
NC122MP module per satellite, which provides the woofer with 100W and the tweeter with 50W
(voltage limited). Titan is sold exclusively in packs of four, and comes with an included 2RU
DSP and amplifier pack that can power all four modules. ALWAYS LEAVE AT LEAST 1RU OF
VENTILATION SPACE ABOVE AND BELOW THE AMPLIFIER PACK! FAILURE TO DO SO
MAY RESULT IN DAMAGE TO THE ELECTRONIC COMPONENTS.
