POWER BEAM INSTALLATION GUIDELINES
Wiring Schematic
4-2-2 Wiring Schematic
8-Wire Shared Neutral
“2 + 2” - 2 Utility Circuits, 2 Dedicated
8 Wires 4 Circuits Receptacles Specifications
4 Lines (12 ga.) 2 Utility circuits Duplex - Up to 12 duplex receptacles per circuit System rated for connection to a grounded 120/240 V single phase, 20A,
2 Neutrals (10 ga.) 2 Dedicated Circuits (Up to 48 per infeed) 60Hz or 120/208 V, 3 phase, 20A, 60Hz branch circuit for U.S. and 15A if
2 Grounds (12 ga.) product is marked with a C-UL Mark. Outlets rated 15A max.
Power Distribution Housing
Parts List
1 Power Distribution Housing
A Power Distribution Housing is connected to the power beam raceway channel to
create a powered beam and usb. It serves to provide a point of attachment and electrical
connection for duplex receptacles, flexible harness connectors, and power entry
components.
Ensure that all panels are mechanically connected prior to electrical connection.
STEP 1: Raceway covers must be removed to allow installation.
STEP 2: Attach the Power Distribution Housing to the panel raceway channel. To
do this, slide the bottom fingers of the spring clips “A“ (attached at either end of
the Power Distribution Housing) into the slots in the bottom of the raceway channel
and snap the top of the spring clips “B” into the brackets provided at the top
of the raceway, “C” above the slots.
STEP 3: Replace the raceway cover.
