EVOC CPC-3811CLD4N Manuel utilisateur

CPC3811CLD4N

3UCompactPCIMotherboardwithWide

Temperature andLowConsumption

Version:C00

Announcement

What contained inthis User Manual does not represent the commitments of EVOC

Company. EVOC Company reserves the right to revise this User Manual, without

priornotice,andwillnotbeheldliableforanydirect,indirect,intendedorunintended

lossesand/orhiddendangersduetoinstallationorimproperoperation.

Before purchasing, pleasehave a detailedunderstanding of the product performance

toseewhetheritmeetsyourrequirements.

EVOC is a registered trademark of EVOC Intelligent Technology Co., Ltd. All

trademarks, registered trademarks, and trade names used in this User Guide are the

propertyoftheirrespective owners.

manual can be reproduced in any form or by any means, such as in electronic or

mechanicalway,withoutpermissioninwritingfromEVOC.

SafetyInstructions

1. Pleasecarefullyreadtheusers’manualbeforehandlingtheproduct;

2. For the board which is not ready to be installed, please put it intheantistatic

packaging;

3. Beforetakingtheboardoutfromantistaticpackaging,please putyourhandon

groundedmetalobjectforawhile(about10seconds)todischargestatic;

4. Pleasewearstaticprotectivegloveswhenholdingtheboard;andalwaysholdthe

boardbyedges;

5. Before inserting, removing or reconfiguring the motherboard or the expansion

card,pleasefirstlydisconnecttheACpowerorunplugtheACpowercablefrom

the power source to prevent damage to the product and ensure your personal

safety;

6. BeforeremovingtheboardsorPCboxes,firstlyturnoffallpowerresourcesand

unplugthepowercablefrompowersource;

7. ForPCBoxproducts,wheninsertingorremovingboards,pleasedisconnectthe

ACpowerinadvance;

8. Before connecting or disconnecting any device, make sureall power cablesare

unpluggedinadvance;

9. Toavoidunnecessarydamagecausedbyturningon/offcomputerfrequently,wait

atleast30secondsbeforereturningonthecomputer.

Contents

Chapter1ProductIntroduction ................................................................................1

Overview ............................................................................................................1

EnvironmentandDimensions ..............................................................................1

TypicalPowerConsumption ................................................................................2

CPU....................................................................................................................2

Chipset ...............................................................................................................2

SystemMemory..................................................................................................2

VideoFunction....................................................................................................3

LAN ...................................................................................................................3

PowerFeature .....................................................................................................3

ExpansionBus ....................................................................................................3

StorageDevices...................................................................................................3

ExternalI/OInterfaces.........................................................................................4

WatchdogFunction..............................................................................................4

Chapter2Installation...............................................................................................5

ProductOutline ...................................................................................................5

TheLocationsofInterfaces..................................................................................7

InstructionofCPC3811CLD4N1.......................................................................9

JumperSetup ..................................................................................................9

JTAGInterface ...............................................................................................9

ResetSwitch.................................................................................................10

CompactPCIInterface..................................................................................10

ConnecterbetweenBoards ............................................................................12

USBInterface ...............................................................................................13

Indicator .......................................................................................................13

LANPort......................................................................................................13

VideoInterface............................................................................................. 14

InstructionofCPC3811CLD4N2 .................................................................... 15

JumperSetting.................................................................................................. 15

LVDSBacklightControl............................................................................... 15

SerialPort .................................................................................................... 16

KeyboardandMouseInterface...................................................................... 17

USBInterface............................................................................................... 17

LVDSInterface ............................................................................................ 17

SATAInterface............................................................................................. 18

ConnecterbetweenBoards............................................................................ 18

InstructionofIOBoardCPCRP38111............................................................. 19

JumperSetting ............................................................................................. 19

SerialPort .................................................................................................... 19

SATAInterface............................................................................................. 19

ConnecterbetweenBoards............................................................................ 20

LANPort ..................................................................................................... 20

USBInterface............................................................................................... 20

CompactPCIInterface ................................................................................. 20

InstructionofIOBoardCPCRP38112............................................................. 21

ConnecterbetweenBoards............................................................................ 21

OpticalLANPortIndicator........................................................................... 21

OpticalLANPort ......................................................................................... 21

Chapter3BIOSSetup ........................................................................................... 22

Appendix.............................................................................................................. 23

WatchdogProgrammingGuide.......................................................................... 23

I/OAddressMap............................................................................................... 25

IRQAssignmentTable ...................................................................................... 26

Chapter1ProductIntroduction

CPC3811CLD4N -1-

Chapter1ProductIntroduction

Overview

CPC3811CLD4N CPCI single board computer is committed to provide a system

managementplatformblending highperformancecalculation,managementplatform,

advanced network transmitting platform and highperformance storage platform

together. It is also committed to meet the requirement of radar image processing

customersfora3UCPCI withdualcore,multinetworkportandindependentdisplay

card.

CPC3811CLD4N CPCI adopts Intel 45nm Intel® Core 2 Duo Processors, withits

codename as Penryn. L2 cache reaches up to 3M, which supports New SSE4

command. It adopts Intel® 3100 Chipset with Codename as Whitmore Lake and

support 800 FSB. Onboard DDR2 ECC REG memory supports up to 1GB and

integrates abundant external interfaces; it features in high performance and low

consumption,whichisquitesuitableforanembeddedplatform.We’vedesigneda3U

CompactPCI system board with dualcore based on the platform, which supports

complete hotswap; four 10/100/1000Mbps Ethernet ports; two SFP optical socket

ports; it adopts PCIindependentdisplaycard connectedby PCI,32bit memory bus

and independent display memory up to 32MB; it also supports VGA+LVDS

independent dualdisplay.

EnvironmentandDimensions

l OperatingEnvironment:

Temperature: 20 °C～70°C

Humidity:5%～95%(Noncondensing);

Chapter1ProductIntroduction

-2-CPC3811CLD4N

l StorageTemperature:

Temperature: 40°C～85°C;

Humidity:5%～95%(Noncondensing);

l Dimension:

CPC3811CLD4N1:161.50mm×100.00mm;

CPC3811CLD4N2:46.38mm×100.00mm;

CPCRP38111:81.50mm×100.00mm;

CPCRP38112:66.00mm×100.00mm.

TypicalPowerConsumption

CPU: onboardIntelCore2DuoU93001.20GHz

Memory: onboard SamsungDDRII4001G

l +5V@4.9A; +5%/3%;

l +3.3V@4.23A; +5%/3%;

l +12V@0.79A; +5%/3%;

CPU

Intel Core 2 Duo CPU SU9300, 800MHz FSB,1.2GHzprimary frequency, 3M L2

cache,uBGASFF (956balls) package.

Chipset

Intel®3100Chipset,800MHzFSB,bothnorthandsouthbridgeintegratesasasingle

chip.

SystemMemory

Onboard 1GB400MHzDDR2 memory.

Chapter1ProductIntroduction

CPC3811CLD4N -3-

VideoFunction

Adopt XGI Z9S PCI independent display chip, 32bit memory bus, 32MB

independentdisplaymemoryandsupportCRT+LVDSindependentdualdisplay.CRT

supportsupto 1600x1200@60Hz.

LAN

ExpandthroughtwoPCIEx1andonePCIEx4channels;connectwithtwoRealtek

8111C and one Intel 82571; four 10/100/1000MbpsEthernet electric portsandtwo

1000Mbps Ethernet optical ports. The two electric ports and two optical ports of

Intel82571 support TRUNK function. The electrical ports and optical ports of

Intel82571are optional.

PowerFeature

The power conversion chips on the single board include MAX8771, ISL6532,

TPS51124 and so on. CPU power is adjusted by 5V through IMVP6+ MAX8771

GTL+chip;itsmaximumcurrentis 18A.

ExpansionBus

Intel®3100PCI32bit/33BusprovidesCompactPCIbus:3U32bitCompactPCIbus

standard,compatiblewithPICMG2.0, PICMG2.1.

StorageDevices

Onboardonepowered 7+15pin SATA interfaceandtwo 7pin SATA interfaces.

Chapter1ProductIntroduction

-4-CPC3811CLD4N

ExternalI/OInterfaces

l Four USB2.0 interfaces;

l TwoCOMswithDB9interfaceandoneCOMpin(among whichCOMswithDB9

interfaces areRS232/RS422/RS485optional; the COM pin only supports RS232

modeanditisoptional withthe DB9interfaceonmotherboard);

l OnePS/2 keyboardandmouseinterface(provideby SMSC3114).

WatchdogFunction

l 1255 secondsor 1255minutes, 510 levels;

l Watchdogovertimeinterruptorresetsystem.

Chapter2Installation

CPC3811CLD4N -5-

Chapter2Installation

ProductOutline

19.93

86.00

161.50

54.07

74.00

88.90

85.00

10.00

100.00

80.00

CPC3811CLD4N1

Chapter2Installation

-6-CPC3811CLD4N

4.00

42.38 46.38

58.16

100.00

CPC3811CLD4N2

100.00

19.93

81.50

88.90

60.07

80.00 10.00

77.00

CPCRP38111

88.90 5.55

100.00

5.93

66.00

CPCRP38112

Unit:mm
